SERVICE DATA AND SPECIFICATIONS (SDS)
LU-33
[YD22DDTi]
C
D
E
F
G
H
I
J
K
L
MA
LU

SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
Standard and LimitEBS00CTZ
OIL PRESSURE
OIL PUMP
Unit: mm (in)
REGULATOR VALVE
Unit: mm (in)
OIL CAPACITY (APPROXIMATE)
Unit: · (Imp qt)
Tightening TorqueEBS00B0F
Unit: N·m (kg-m, ft-lb)
Unit: N·m (kg-m, in-lb)* Engine speed rpm
Approximate discharge pressure kPa (bar, kg/cm
2 , psi)
Idle speed
2,000140 (1.40, 1.43, 20.3) or more
270 (2.70, 2.75, 39.2) or more
Oil pump housing to outer rotor radial clearance 0.114 - 0.260 (0.0045 - 0.0102)
Inner rotor to outer rotor tip clearance Below 0.18 (0.0071)
Oil pump housing to inner rotor side clearance 0.050 - 0.090 (0.0020 - 0.0035)
Oil pump housing to outer rotor side clearance 0.030 - 0.190 (0.0012 - 0.0075)
Inner rotor to oil pump housing clearance 0.045 - 0.091 (0.0018 - 0.0036)
Regulator valve to valve hole clearance 0.040 - 0.097 (0.0016 - 0.0038)
With oil filter change 5.2 (4-5/8 Imp qt)
Without oil filter change 4.9 (4-3/8 Imp qt)
Dry engine (engine overhaul) 6.3 (5-1/2 Imp qt)
Oil pressure switch 13.0 - 17.0 (1.4 - 1.7, 10 - 12)
Oil pan drain plug34 (3.5, 25)
Oil filter bracket21.5 (2.2, 16)
Oil filler body (TYPE B) 22 (2.2, 16)
Oil filter (TYPE A)18 (1.8, 13)
Oil pump cover Bolts 6.9 (0.7, 61)*
Screws 6.9 (0.7, 61)*
Regulator plug54 (5.5, 40)
Water hose connector 23.6 (2.4, 17)
Oil cooler24.5 (2.5, 18)

LU-34
[YD22DDTi]
SERVICE DATA AND SPECIFICATIONS (SDS)

CO-1
ENGINE COOLING SYSTEM
B ENGINE
CONTENTS
C
D
E
F
G
H
I
J
K
L
M
SECTION
A
CO

ENGINE COOLING SYSTEM
QR
PRECAUTIONS .......................................................... 3
Precautions for Liquid Gasket .................................. 3
LIQUID GASKET APPLICATION PROCEDURE ..... 3
PREPARATION ........................................................... 4
Special Service Tools ............................................... 4
Commercial Service Tools ........................................ 4
OVERHEATING CAUSE ANALYSIS .......................... 5
Troubleshooting Chart .............................................. 5
COOLING SYSTEM .................................................... 7
Cooling Circuit .......................................................... 7
System Chart ........................................................... 8
ENGINE COOLANT .................................................... 9
Inspection ................................................................. 9
LEVEL CHECK ..................................................... 9
LEAK CHECK ....................................................... 9
Changing Engine Coolant ........................................ 9
DRAINING ENGINE COOLANT ........................... 9
REFILLING ENGINE COOLANT ........................ 10
FLUSHING COOLING SYSTEM ......................... 10
RADIATOR ................................................................ 12
Removal and Installation ........................................ 12
REMOVAL ........................................................... 12
INSTALLATION ................................................... 13
INSPECTION AFTER INSTALLATION ............... 13
Checking Radiator Cap .......................................... 13
Checking Radiator .................................................. 13
RADIATOR (ALUMINUM TYPE) .............................. 14
Disassembly and Assembly ................................... 14
PREPARATION ................................................... 14
DISASSEMBLY ................................................... 14
ASSEMBLY ......................................................... 15
INSPECTION ...................................................... 17
COOLING FAN ......................................................... 18
Removal and Installation ........................................ 18
REMOVAL ........................................................... 18
INSTALLATION ................................................... 18
DISASSEMBLY AND ASSEMBLY ...................... 18WATER PUMP .......................................................... 20
Removal and Installation ........................................ 20
REMOVAL ........................................................... 20
INSPECTION AFTER REMOVAL ....................... 21
INSTALLATION ................................................... 21
INSPECTION AFTER INSTALLATION ................ 21
THERMOSTAT AND WATER CONTROL VALVE .... 22
Removal and Installation ........................................ 22
REMOVAL ........................................................... 22
INSPECTION AFTER REMOVAL ....................... 23
INSTALLATION ................................................... 23
INSPECTION AFTER INSTALLATION ................ 23
SERVICE DATA AND SPECIFICATIONS (SDS) ...... 24
Standard and Limit .................................................. 24
CAPACITY ........................................................... 24
THERMOSTAT .................................................... 24
WATER CONTROL VALVE ................................. 24
RADIATOR .......................................................... 24
Tightening Torque ................................................... 24
YD22DDTi
PRECAUTIONS ........................................................ 25
Precautions For Liquid Gasket ............................... 25
LIQUID GASKET APPLICATION PROCEDURE ... 25
PREPARATION ......................................................... 26
Special Service Tools ............................................. 26
Commercial Service Tools ...................................... 26
OVERHEATING CAUSE ANALYSIS ........................ 27
Troubleshooting Chart ............................................ 27
COOLING SYSTEM .................................................. 29
Cooling Circuit ........................................................ 29
System Chart .......................................................... 30
ENGINE COOLANT .................................................. 31
Inspection ............................................................... 31
LEVEL CHECK .................................................... 31

CO-2 CHECKING RADIATOR SYSTEM FOR LEAKS ... 31
Changing Engine Coolant ....................................... 31
DRAINING ENGINE COOLANT .......................... 31
REFILLING ENGINE COOLANT ......................... 32
FLUSHING COOLING SYSTEM ......................... 33
RADIATOR ................................................................ 34
Removal and Installation ........................................ 34
REMOVAL ........................................................... 34
INSTALLATION .................................................... 34
INSPECTION AFTER INSTALLATION ................ 34
Checking Radiator Cap .......................................... 35
Checking Radiator .................................................. 35
COOLING FAN .......................................................... 36
Removal and Installation ........................................ 36
REMOVAL ........................................................... 36
INSTALLATION .................................................... 36
DISASSEMBLY AND ASSEMBLY ....................... 36
RADIATOR (ALUMINUM TYPE) ............................... 38
Disassembly and Assembly .................................... 38
PREPARATION ................................................... 38
DISASSEMBLY ................................................... 38
ASSEMBLY ......................................................... 39
INSPECTION ....................................................... 41WATER PUMP ........................................................... 42
Removal and Installation ......................................... 42
REMOVAL ............................................................ 42
INSPECTION AFTER REMOVAL ........................ 43
INSTALLATION .................................................... 43
INSPECTION AFTER INSTALLATION ................ 43
THERMOSTAT AND WATER PIPING ....................... 44
Removal and Installation ......................................... 44
REMOVAL ............................................................ 44
INSPECTION AFTER REMOVAL ........................ 45
INSTALLATION .................................................... 45
INSPECTION AFTER INSTALLATION ................ 45
SERVICE DATA AND SPECIFICATIONS (SDS) ...... 46
Standard and Limit .................................................. 46
CAPACITY ........................................................... 46
THERMOSTAT ..................................................... 46
RADIATOR ........................................................... 46
Tightening Torque ................................................... 46

PRECAUTIONS
CO-3
[QR]
C
D
E
F
G
H
I
J
K
L
MA
CO

[QR]PRECAUTIONSPFP:00001
Precautions for Liquid GasketEBS00MRX
LIQUID GASKET APPLICATION PROCEDURE
1. Remove old liquid gasket adhering to the liquid gasket application surface and the mating surface.

Remove liquid gasket completely from the liquid gasket application surface, mounting bolts, and bolt
holes.
2. Wipe the liquid gasket application surface and the mating surface with white gasoline (lighting and heating
use) to remove adhering moisture, grease and foreign materials.
3. Attach liquid gasket tube to the tube presser (special service
tool).
Use Genuine Liquid Gasket or equivalent.

Within five minutes of liquid gasket application, install the mat-
ing component.

If liquid gasket protrudes, wipe it off immediately.

Do not retighten mounting bolts or nuts after the installation.

Wait 30 minutes or more after installation before refilling
engine oil and engine coolant.
PBIC2160E

CO-4
[QR]
PREPARATION

PREPARATIONPFP:00002
Special Service ToolsEBS00KOC
Commercial Service ToolsEBS011T8
Tool number
Tool nameDescription
EG17650301
Radiator cap tester adapterAdapting radiator cap tester to radiator cap
and radiator filler neck
a: 28 (1.10) dia.
b: 31.4 (1.236) dia.
c: 41.3 (1.626) dia.
Unit: mm (in)
KV99103510
Radiator plate pliers AInstalling radiator upper and lower tanks
KV99103520
Radiator plate pliers BRemoving radiator upper and lower tanks
WS39930000
Tube presserPressing the tube of liquid gasket
S-NT564
S-NT224
S-NT225
S-NT052
Tool nameDescription
Radiator cap tester Checking radiator and radiator cap
PBIC1982E

OVERHEATING CAUSE ANALYSIS
CO-5
[QR]
C
D
E
F
G
H
I
J
K
L
MA
CO

OVERHEATING CAUSE ANALYSISPFP:00012
Troubleshooting ChartEBS00KOD
Symptom Check items
Cooling sys-
tem parts
malfunctionPoor heat transferWater pump malfunction Worn or loose drive belt
— Thermostat and water con-
trol valve stuck closed—
Damaged finsDust contamination or
paper clogging
Physical damage
Clogged radiator cooling
tubeExcess foreign material
(rust, dirt, sand, etc.)
Reduced air flowCooling fan does not oper-
ate
Fan assembly — High resistance to fan rota-
tion
Damaged fan blades
Damaged radiator shroud — — —
Improper engine coolant
mixture ratio—— —
Poor engine coolant quality — Engine coolant viscosity —
Insufficient engine coolantEngine coolant leaksCooling hoseLoose clamp
Cracked hose
Water pump Poor sealing
Radiator capLoose
Poor sealing
RadiatorO-ring for damage, deterio-
ration or improper fitting
Cracked radiator tank
Cracked radiator core
Reservoir tank Cracked reservoir tank
Overflowing reservoir tankExhaust gas leaks into
cooling systemCylinder head deterioration
Cylinder head gasket dete-
rioration

CO-6
[QR]
OVERHEATING CAUSE ANALYSIS

Except cool-
ing system
parts mal-
function— Overload on engineAbusive drivingHigh engine rpm under no
load
Driving in low gear for
extended time
Driving at extremely high
speed
Power train system mal-
function
— Installed improper size
wheels and tires
Dragging brakes
Improper ignition timing
Blocked or restricted air
flowBlocked bumper —
— Blocked radiator grilleInstalled car brassiere
Mud contamination or
paper clogging
Blocked radiator —
Blocked condenser
Blocked air flow
Installed large fog lamp Symptom Check items

COOLING SYSTEM
CO-7
[QR]
C
D
E
F
G
H
I
J
K
L
MA
CO

COOLING SYSTEMPFP:21020
Cooling CircuitEBS00KOE
PBIC2592E

CO-8
[QR]
COOLING SYSTEM

System ChartEBS00KOF
PBIC1232E
