WARNING
Always follow the instructions below.
Failure to do so could result in damage
to the charging system and cause per-
sonal injury.
1. If the booster battery is in another vehicle,
position the two vehicles to bring their bat-
teries into close proximity to each other.
Do not allow the two vehicles to touch.
2. Apply parking brake. Move the shift lever tothe N (Neutral) position (On automatic trans-
mission models, move the selector lever to
the P (Park) position). Switch off all unnec-
essary electrical systems (light, heater, air
conditioner, etc.).
3. Remove vent caps on the battery (if so
equipped). Cover the battery with an old
cloth as illustrated to reduce explosion haz-
ard.
4. Connect jumper cables in the sequence as
illustrated.
CAUTION
Always connect positive (+) to posi-
tive (+) and negative (−) to body
ground not to the battery.
Make sure that cables do not touch
moving parts in the engine compart-
ment and that clamps do not contact
any other metal.
5. Start the engine of the other vehicle and let it
run for a few minutes.
6. Keep the engine speed of the other vehicle at
about 2,000 rpm, and start your engine in the
normal manner.
CAUTION
Do not keep starter motor engaged for
more than 10 seconds. If the engine
does not start right away, turn the key
off and wait 3 to 4 seconds before trying
again.
7. After starting your engine, carefully discon-
nect the negative cable and then the positive
cable.
8. Replace the vent caps (if so equipped). Be
sure to dispose of the cloth used to cover the
vent holes as it may be contaminated with
corrosive acid.
SCE0389A
6-8
In case of emergency
06.4.14/T30-J/V5.0
Page 192 of 281
Do not attempt to start the engine by pushing
the vehicle.
CAUTION
Automatic transmission models can-
not be push started. Attempting to do
so may cause transmission damage.
Three way catalyst equipped models
should not be started by pushing
since the three way catalyst may be
damaged.
Never try to start the vehicle by tow-
ing it; when the engine starts, the
forward surge could cause the ve-
hicle to collide with the tow vehicle.
WARNING
Do not continue to drive if your ve-
hicle overheats. Doing so could
cause a vehicle fire.
To avoid the danger of being scalded,
never remove the radiator cap while
the engine is still hot. When the ra-
diator cap is removed, pressurized
hot water will spurt out, possibly
causing serious injury.
Do not open the hood if steam is
coming out.
If your vehicle is overheating (indicated by an
extremely high temperature gauge reading), or if
you feel a lack of engine power, detect abnormal
noise, etc., take the following steps:
1. Move the vehicle safely off the road, apply the
parking brake and move the shift lever to the
N (Neutral) position (automatic transmission
to the P (Park) position).
Do not stop the engine.
2. Turn off the air conditioner switch. Open all
the windows, move the heater or air condi-tioner temperature control to maximum hot
and fan control to high speed.
3. If engine overheating is caused by climbing a
long hill on a hot day, run the engine at a fast
idle (approximately 1,500 rpm) until the tem-
perature gauge indication returns to normal.
4. Get out of the vehicle. Look and listen for
steam or coolant escaping from the radiator
before opening the hood. (If steam or coolant
is escaping, turn off the engine.) Do not open
the hood further until no steam or coolant can
be seen.
5. Open the engine hood.
WARNING
If steam or water is coming from the
engine, stand clear to prevent getting
burned.
6. Visually check if the cooling fan is running.
The radiator hoses and radiator should not
leak water.
If coolant is leaking or the cooling fan does
not run, stop the engine.
PUSH STARTING IF YOUR VEHICLE OVERHEATS
In case of emergency
6-9
06.4.14/T30-J/V5.0
Page 193 of 281
WARNING
Be careful not to allow your hands,
hair, jewelry or clothing to come into
contact with, or to get caught in the
cooling fan, or drive belt.
The engine cooling fan can start at
any time when the coolant tempera-
ture is high.
7. After the engine cools down, check the cool-
ant level in the reservoir tank with the engine
running. Add coolant to the reservoir tank if
necessary. Have your vehicle repaired at the
nearest NISSAN dealer.When towing your vehicle, all provincial and
local regulations for towing must be followed.
Incorrect towing equipment could damage your
vehicle. Towing instructions are available from a
NISSAN dealer. Local service operators are
generally familiar with the applicable laws and
procedures for towing. To assure proper towing
and to prevent accidental damage to your ve-
hicle, NISSAN recommends having a service
operator tow your vehicle. It is advisable to have
the service operator carefully read the following
precautions.
WARNING
Never ride in a vehicle that is being
towed.
Never get under your vehicle after it
has been lifted by a tow truck.
CAUTION
When towing, make sure that the
transmission, axles, steering system
and powertrain are in working condi-
tion. If any unit is damaged, dolliesmust be used.
Always attach safety chains before
towing.TOWING YOUR VEHICLE
6-10
In case of emergency
06.4.14/T30-J/V5.0
Page 194 of 281
TOWING RECOMMENDED BY
NISSAN
Two-Wheel drive modelsNISSAN recommends that your vehicle be
towed with the driving (front) wheels off the
ground or place the vehicle on a flatbed truck as
illustrated.
CAUTION
Never tow automatic transmission
models with the front wheels on theground or four wheels on the ground
(forward or backward) as this may
cause serious and expensive damage
to the transmission.
If it is necessary to tow the vehicle
with the rear wheels raised, always
use towing dollies under the front
wheels.
When towing automatic transmission
models with the front wheels on tow-
ing dollies:•Turn the ignition key to the OFF
position, and secure the steering
wheel in a straight ahead position
with a rope or similar device.
Never secure the steering wheel
by turning the ignition key to the
LOCK position. This may damage
the steering lock mechanism.
•Move the selector lever to the N
(Neutral) position.
When towing Two-Wheel drive auto-
matic transmission model with the
rear wheels on the ground (if you do
not use towing dollies): Always re-
lease the parking brake.
SCE0495
Two-Wheel drive models
In case of emergency
6-11
06.4.14/T30-J/V5.0
Page 195 of 281
Four-Wheel drive modelsNISSAN recommends that towing dollies be
used when towing your vehicle or the vehicle be
placed on a flat bed truck as illustrated.
CAUTION
Never tow 4WD models with any of the
wheels on the ground as this may cause
serious and expensive damage to the
drive train.
SCE0496
Four-Wheel drive models
SCE0478
6-12
In case of emergency
06.4.14/T30-J/V5.0
Page 196 of 281
VEHICLE RECOVERY (Freeing a
stuck vehicle)
WARNING
Stand clear of a stuck vehicle.
Do not spin the tires at a high speed.
This could cause them to explode
and result in serious injury. Parts of
your vehicle could also overheat and
be damaged.
CAUTION
Tow chains or cables must be at-
tached only to the vehicle recovery
hooks or main structural members of
the vehicle. Otherwise, the vehicle
body will be damaged.
Do not use the vehicle tie downs to free
a vehicle stuck in sand, snow, mud, etc.
Never tow the vehicle using the vehicle
tie downs or recovery hooks.
Always pull the cable straight outfrom the front of the vehicle. Never
pull on the hook at an angle.
Pulling devices should be routed so
they do not touch any part of the
suspension, steering, brake or cool-
ing systems.
Pulling devices such as ropes or can-
vas straps are not recommended for
use in vehicle towing or recovery.
If your vehicle is stuck in sand, snow, mud, etc.,
use the following procedure:
1. Turn off the Vehicle Dynamic Control (VDC)
system.
2. Make sure the area in front and behind the
vehicle is clear of obstructions.
3. Turn the steering wheel right and left to clear
an area around the front tires.
4. Slowly rock the vehicle forward and back-
ward.
Shift back and forth between R (reverse) and
D (drive).
Apply the accelerator as little as possible to
maintain the rocking motion.Release the accelerator pedal before shifting
between R and D.
Do not spin the tires above 55 km/h (35
MPH).
5. If the vehicle can not be freed after a few
tries, contact a professional towing service to
remove the vehicle.
In case of emergency
6-13
06.4.14/T30-J/V5.0
Page 197 of 281
MEMO6-14
In case of emergency
06.4.14/T30-J/V5.0
Page 198 of 281
7 Appearance and careCleaning exterior ................................................................... 7-2
Washing ............................................................................ 7-2
Removing spots .............................................................. 7-2
Waxing ............................................................................... 7-2
Glass .................................................................................. 7-3
Underbody ........................................................................ 7-3
Aluminum alloy wheels .................................................. 7-3
Chrome parts ................................................................... 7-3
Tire dressing .................................................................... 7-3
Plastic parts ..................................................................... 7-3
Cleaning interior .................................................................... 7-4Floor mats ......................................................................... 7-4
Glass .................................................................................. 7-5
Seat belts ......................................................................... 7-5
Luggage floor board ........................................................ 7-5
Corrosion protection ............................................................ 7-5
Most common factors contributing to vehicle
corrosion ........................................................................... 7-5
Environmental factors influence the rate of
corrosion ........................................................................... 7-5
To protect your vehicle from corrosion ..................... 7-6
06.4.14/T30-J/V5.0
Page 199 of 281
In order to maintain the appearance of your
vehicle, it is important to take proper care of it.
In the following cases, please wash your vehicle
as soon as possible to protect the paint surface.
After a rainfall to prevent possible damage
from acid rain
After driving on coastal roads
When contaminants such as soot, bird drop-
pings, tree sap, metal particles or bugs get on
the paint surface
When dust or mud builds up on the surface
Whenever possible, store or park your vehicle
inside a garage or in a covered area.
When it is necessary to park outside, park in a
shady area or protect the vehicle with a body
cover.
Be careful not to scratch the paint surface
when putting on or removing the body
cover.WASHINGWash dirt off the vehicle with a wet sponge and
plenty of water. Clean the vehicle thoroughly
using a mild soap, a special vehicle soap or a
general purpose dishwashing liquid mixed with
clean, lukewarm (never hot) water.
CAUTION
Do not use strong household soap,
strong chemical detergents, gasoline
or solvents.
Do not wash the vehicle in direct
sunlight or while the vehicle body is
hot, as the surface may become
water-spotted.
Avoid using tight-napped or rough
cloths, such as washing mitts. Care
must be taken when removing
caked-on dirt or other foreign sub-
stances so that the paint surface is
not scratched or damaged.
Rinse the vehicle again with plenty of clean
water.
Inside flanges, seams and folds on the doors,
hatches and hood are particularly vulnerable to
the effects of road salt. Therefore, these areas
must be regularly cleaned. Make sure that the
drain holes in the lower edge of the door are
open. Spray water under the body and in the
wheel wells to loosen the dirt and wash away
road salt.Avoid leaving water spots on the paint surface
by using a damp chamois to dry the vehicle.
REMOVING SPOTSRemove tar and oil spots, industrial dust, insects,
and tree sap as quickly as possible from the
surface of the paint to avoid lasting damage or
staining. Special cleaning products are available
at a NISSAN dealer or any automotive accessory
store.WAXINGRegular waxing protects the paint surface and
helps retain new vehicle appearance. After wax-
ing, polishing is recommended to remove
built-up residue and to avoid a weathered ap-
pearance.
If you wish to wax your vehicle, only use a wax
specified for use over clear coats, such as
NISSAN Liquid or Spray Wax. A NISSAN dealer
can assist you in choosing the proper product.
Wax your vehicle only after a thorough wash-
ing. Follow the instructions supplied with the
wax.
Do not use a wax containing any abrasives,
cutting compounds or cleaners that may
damage the vehicle finish.
CLEANING EXTERIOR7-2
Appearance and care
06.4.14/T30-J/V5.0
Page 200 of 281
Machine compounding or aggressive pol-
ishing on a base coat/clear coat paint
finish may dull the finish or leave swirl
marks.GLASSUse glass cleaner to remove smoke and dust film
from the glass surfaces. It is normal for glass to
become coated with a film after the vehicle is
parked in the hot sun. Glass cleaner and a soft
cloth will easily remove this film.UNDERBODYIn areas where road salt is used in winter, the
underbody must be cleaned regularly. This will
prevent dirt and salt from building up and caus-
ing underbody and suspension corrosion. Be-
fore the winter period and again in the spring, the
underseal must be checked and, if necessary,
re-treated.ALUMINUM ALLOY WHEELSWash the wheels regularly with a sponge damp-
ened in a mild soap solution, especially during
winter in areas where road salt is used. The salt
residue from road salt could discolor the wheels
if it is not washed off regularly.
CAUTION
Follow the directions below to avoid
staining or discoloring the wheels:
Do not use a cleaner that uses strong
acid or alkali contents to clean the
wheels.
Do not apply wheel cleaners to the
wheels when they are hot. The wheel
temperature should be the same as
ambient temperature.
Rinse the wheel to completely re-
move the cleaner within 15 minutes
after the cleaner is applied.CHROME PARTSClean all chrome parts regularly with a non-
abrasive chrome polish to maintain the finish.TIRE DRESSINGNISSAN does not recommend the use of tire
dressings. Tire manufacturers apply a coating to
the tires to help reduce discoloration of the
rubber. If a tire dressing is applied to the tires, it
may react with the coating and form a com-pound. This compound may come off the tire
while driving and stain the vehicle paint.
If you choose to use a tire dressing, take the
following precautions:
Use a water-based tire dressing. The coating
on the tire dissolves more easily with an
oil-based tire dressing.
Apply a light coat of tire dressing to help
prevent it from entering the tire tread/grooves
(where it would be difficult to remove).
Wipe off excess tire dressing using a dry
towel. Make sure the tire dressing is com-
pletely removed from the tire tread/grooves.
Allow the tire dressing to dry as recom-
mended by tire dressing manufacturer.
PLASTIC PARTSPlastic parts can be cleaned with a mild soap
solution. If the dirt cannot be easily removed, use
a plastic cleaner. Do not use any solvents.
Appearance and care
7-3
06.4.14/T30-J/V5.0
