Page 25 of 212

19
In Brief
Picture no: 14034s.tif
Selecting with the multifunction button
(adjuster wheel via the four-way rocker
switch 378):
Press and turn multifunction button.
To exit a menu, turn the multifunction
button left or right to Return or Main and
select.
To select with steering wheel buttons 3:
Select menu options via the menus using
the buttons.
Information display 377.
Diesel particle filter
3
The diesel particle filter system filters
harmful soot particles out of the exhaust
gases. The system includes a self-cleaning
function that run automatically during
driving. The filter is cleaned by burning off
the soot particles at high temperature. This
process takes place automatically under
set driving conditions and may take up to
25 minutes. Fuel consumption may be
higher during this period. The emission of
smells and smoke during this process is
normal.
Under certain driving conditions, e.g. short
distances, the system cannot clean itself
automatically.
Picture no: 18528s.tif
If the filter requires cleaning and previous
driving conditions did not enable
automatic cleaning, control indicator
!
flashes.
Further instructions 3116.
Page 46 of 212

40 Seats, InteriorzSit with your shoulders as far back
against the backrest as possible. Set the
backrest rake so that you can easily
reach the steering wheel with your arms
slightly bent. Maintain contact between
your shoulders and the backrest when
turning the steering wheel. Do not angle
the backrest too far back. We
recommend a maximum rake of
approx. 25.
zAdjust the steering wheel 36.
zSet seat height 3 high enough to have a
clear field of vision on all sides and of all
display instruments. There should be at
least six inches of clearance between
your head and the headlining. Your
thighs should rest lightly on the seat
without pressing into it.
zAdjust the head restraint.
zAdjust the height of the seat belt 352.
Picture no: 15997s.tif
Heated front seats 3
Two pushbuttons ß in centre console.
With the ignition switched on, the heating
of the relevant front seat is activated by
pressing the button ß.
LED ß on: the relevant front seat is heated.
LED ß off: heating of relevant front seat is
switched off.
For vehicles with natural gas operation 3,
only switch ß is available. Operation for
both front seats when the ignition is on.
Picture no: 13781s.tif
Head restraints Adjusting the front and outboard rear
seat headrestraints 3
To adjust, hold head restraint at side, tilt
forward, hold and adjust height.
To improve visibility when the rear seats
are unoccupied or to fold down a rear seat
or the front passenger seat, push the head
restraint all the way down or remove.
If the rear seats are occupied, adjust the
rear head restraints to the appropriate
level for the occupant’s body size.
The open frame head restraint on the
Combo Van cannot be adjusted.
Page 62 of 212

56 Seats, Interior
Picture no: 16424s.tif
Airbag system Front airbag
The front airbag system consists of one
airbag in the steering wheel and one in the
instrument panel. These can be identified
by the word AIRBAG.
The front airbag system comprises:
zan airbag with inflator in the steering
wheel and a second one in the
instrument panel 3,
zthe control electronics with impact
sensor,
zthe control indicator for airbag
systemsv in the instrument,
Picture no: 11734s.tif
The front airbag system will be triggered:
zdepending on the severity of the
accident,
zdepending on the type of impact,
zwithin the range shown in the illustration,
zindependently of the side airbag
system3.
The ignition must be switched on. Examples of events triggering the front
airbag system:
zImpact against a non-yielding obstacle:
the front airbags are triggered at low
vehicle speed.
zImpact against a yielding obstacle:
(such as another vehicle): the front
airbags are only triggered at a higher
vehicle speed.
Page 66 of 212

60 Seats, InteriorImportant
zNo objects or accessories must be placed
in the area in which the airbags inflate,
as they could cause injury when the
components are deployed.
zDo not place any objects between the
airbag systems and the vehicle
occupants. Danger of injury. Do not
install a child restraint system 3 on the
front passenger seat. Danger to life.
zUse the hooks in the roof frame only to
hang up light articles of clothing or coat
hangers. Do not place any objects in the
pockets of the hanging items – risk of
injury.
zThe airbag systems and belt tensioner
control electronics can be found in the
centre console area. In order to avoid
malfunctions, do not store magnetic
objects in this area. zDo not stick anything on the steering
wheel, instrumnet panel or front seat
backrests in the vicinity of the airbags.
Do not cover any of these areas with
other materials.
zUse only a dry cloth or interior cleaner to
clean the steering wheel, instrument
panel and front seat backrests. Do not
use any aggressive cleaning agents.
zOnly protective covers which are
approved for your vehicle with side
airbag may be fitted on the front seats.
When fitting the protective covers, make
sure that the airbag units on the
outboard sides of the front seat
backrests are not covered.
zThe airbag systems are triggered
independently of one another
depending on the severity of the
accident and type of impact.
zEach airbag is only deployed once. Have
deployed airbags replaced by a
workshop immediately.
zThe speeds, directions of movement and
deformation properties of the vehicles,
and the properties of the obstacle
concerned, determine the severity of the
accident and triggering of the airbags.
The degree of damage to your vehicle
and the resulting repair costs alone are
not indicative that the criteria for
triggering of the airbags were met. zDo not perform any alterations on the
components of the airbag system, as this
would render the vehicle unroadworthy.
zWe recommend having the steering
wheel, the instrument panel, all panelling
parts, the door seals, the handles and
the seats removed by a workshop.
zThe applicable safety regulations must
be adhered to when the vehicle is
disposed of. The vehicle should therefore
be disposed of by a recycling company.
zAnyone weighing less than 35 kg should
seat in the rear seat.
9 Warning
As with any other object, child restaint
systems must not be carried on a
passenger’s lap. Danger to life.
9 Warning
If handled improperly the airbag
systems can be triggered in an explosive
manner – risk of injury!
Page 73 of 212

67
Instruments
Picture no: 18529s.tif
Flashes when the ignition is onFault in the electronic immobiliser system;
the engine cannot be started 321.Z
Exhaust emission
Control indicator lights up and/or flashes
yellow
It illuminates when the ignition is switched
on and goes out shortly after the engine
starts.
Illuminates when the engine is running
Fault in emission control system. The
permissible emission limits may be
exceeded. Contact a workshop for
assistance immediately.
Picture no:
If it flashes when the engine is running:Fault that could lead to catalytic converter
damage. Ease up on the throttle until the
flashing stops 3115. Seek the immediate
assistance of a workshop. v
Airbag systems 3, Belt tensioners
Control indicator lights up red
Illuminates when the engine is runningFault in the airbag or belt tensioner system
350, 359.
I
Engine oil pressure
Control indicator lights up red
It illuminates when the ignition is switched
on and goes out shortly after the engine
starts.
Illuminates when the engine is running
1. Depress clutch 3.
2. Set manual transmission to neutral, or
with manual transmission automated 3
place selector lever in N.
3. Move out of the flow of traffic as quickly
as possible without impeding other
vehicles.
4. Switch off ignition.
Contact a workshop for assistance. Caution
Engine lubrication may be interrupted.
This may result in damage to the engine
and/or locking of the drive wheels.
9 Warning
When the engine is off, considerably
more force is needed to brake and steer.
Do not remove key until vehicle has
come to a standstill, otherwise the
steering column lock could engage
unexpectedly.
Page 76 of 212

70 Instruments
Picture no: 18529s.tif
S
Engine oil level 3
Control indicator lights up yellow.
The engine oil level is checked
automatically.
Illuminates when the engine is running
Engine oil level too low. Check engine oil
level and top up engine oil if necessary
3175.
Picture no:
EPS
1)
Electric power steering 3
Control indicator lights up yellow.
Fault in the electric power steering. It is still
possible to drive. Although it is still possible
to steer the vehicle, it is significantly more
difficult. Contact a workshop for
assistance.
1)EPS
= Electric
Power
Steering.
Y
Fuel level 3
Control indicator lights up and/or flashes
yellow
Lamps
Level in fuel tank too low.
Flashes
Fuel level is used up, fuel immediately.
Never let the tank run dry!
Erratic fuel supply can cause the catalytic
converter to overheat 3114.
Diesel engines: Bleed the fuel system if the
fuel tank is allowed to run dry 3128.
Page 84 of 212

78 Instruments
Picture no: 16711t.tif
Graphical information display
3,
selecting functions
The graphical information display depicts
functions and their menus.
Functions are selected and executed in the
menu on the display using the four-way
button, the multifunction button 3 on the
infotainment system or the buttons 3 on
the steering wheel.
Picture no: 15593t.tif
To select with four-way button
Select menu items via menus and with the
buttons/four-way button of the
infotainment system.
Picture no: 15559t.tif
To select with multifunction button 3
Turn the multifunction button to highlight
menu items or commands and to select
function areas.
Press the multifunction button to select the
highlighted item or confirm a command.
To exit a menu, turn the multifunction
button left or right to Return or Main and
select.
FMAS[TP]REGCDinMP3
90.6
MHz
19,5° 19:36
Page 85 of 212

79
Instruments
Picture no: 14034s.tif
To select with steering wheel buttons 3
Select menu options via the menus using
the buttons.
Picture no: 16711t.tif
Function ranges
Each function has a main page, which is
selected from the upper row of the display
(not in Infotainment system CD 30):
zAudio,
zNavigation 3,
zTelephone 3.
For audio, navigation 3 and telephone
functions 3, see infotainment system
instructions.
Picture no: 16712t.tif
System settings
The settings are accessed via the
Settingsmenu.
Press the Main button 3 (not found on all
infotainment systems) on the infotainment
system (call up main display).
Press the Settings button on the
infotainment system. For Infotainment
system CD 30, no menu may be selected.
The Settings menu opens.
FMAS[TP]REGCDinMP3
90.6
MHz
19,5° 19:36
7
Settings 19,5° 19:36
Time, Date19:36
Language
Units 10 . 07 . 2004
Contrast
Day / Night
6 Ign. logic
Page 89 of 212

83
Instruments
Adjustable wiper interval
To set the wiper interval to a value between
2 and 15 seconds:
Lever to interval operation $, lever to §,
wait for required interval delay, Level to
interval operation again $.
The selected interval will remain stored
until the next time it is changed or until the
ignition is switched off.
After switching on the ignition and moving
the lever up, $ the interval is set to
7seconds.
Picture no: 14056h.tif
Windscreen washer system
Pull the lever towards the steering wheel.
Washer fluid sprays onto the windscreen
and the windscreen wipers switch on for a
few sweep movements.
Picture no: 14057h.tif
Rear window wiper 3 and rear window
washer system 3
Push the lever forwards. The rear window
wiper swipes in timed interval mode. Switch
off by pulling the lever towards the steering
wheel.
If the stalk is held forwards, washer fluid is
sprayed on the rear window.
Page 91 of 212

85
Lighting
Picture no: 18475s.tif
Main beam, headlamp flash Push stalk forward to switch from dipped
beam to main beam.
To switch to dipped beam, push lever down
again.
To operate the headlamp flash, pull stalk
towards steering wheel. The main beam is
switched on for as long as the the stalk is
held in this position.
Picture no: 14054h.tif
Turn signal lamps If the stalk is moved past the resistance
point, the turn signal lamp remains on.
When the steering wheel moves back
toward the straight-ahead position, the
turn signal lamp is automatically
deactivated.
Touch turn signal operation: press lever
until resistance can be felt and release
again.
The turn signal lamps are switched off
manually by moving the lever back to the
middle position.
Reversing lamps The reversing lamps come on when the
ignition is on and reverse gear is engaged.
Lever upwards = Right turn signal
Lever downwards = Left turn signal
