diagram Peugeot 206 CC 2002.5 Owner's Manual

07-10-2002
PEUGEOT SERVICING25
Recommendations for approved lubricants The oils which appear in the table opposite are suitable for most purposes. The diagram opposite states the opti- mum range of viscosity depending onthe temperatures at which the oils areto be used. It is also possible to use "superior quality" synthetic oils. In the absence of semi-synthetic or
synthetic oils, oils of API SH/SJ qualitymay be used by following the "arduousconditions" servicing schedule whichspecifies shorter service intervals. Do not hesitate to ask for advice from an
approved PEUGEOT dealer to maintaindriving pleasure and to minimise themaintenace cost of your vehicle. For vehicles outside Europe, please
contact a local PEUGEOT dealer.
ONLY ONLY
Manual gearbox ESSO GEAR OIL BV TOTAL TRANSMISSION BV 75W-80 PR 9736.41 75W-80
AL4 Automatic ONLY
gearbox ATF 4HP20-AL4 PR 9736.22
Power steering ESSO ATF D TOTAL FLUIDE AT42 PR 9730.94
Brake fluid PEUGEOT DOT4
Coolant PROCOR TM108/GLYSANTIN G33 or REVKOGEL 2000 ONLYProtection to minus Ð35 ¡C
Other approved products

YOUR 206 CC IN DETAIL71
Opening the doors from outside
DOORS
Opening the doors from inside
LOCKING AND UNLOCKING THE BOOT Lock the boot using the key (turn the
key from Ato C) or the remote control.
Unlock it using the key (turn the key
from Ato B).
The lighting is controlled by open- ing the boot.
Locking from the inside
To lock, press button
A.
Locking one of the front doors locks the doors and the boot. Unlocking from the inside
To unlock, pull button Aor the handle.
''Door open'' alert
With the engine running an audible
signal and a message or diagram locating the problem on the multifunc-tion screen, warns you that a door isnot properly closed. Also, when the vehicle is moving ,
with the courtesy light button in the "lighting on opening a door" position,the courtesy light flashes.
07-10-2002
