handbrake Peugeot 206 CC 2002.5 Owner's Manual

1Side windows demisting vents
2 Adjustable side vent
3 Passenger air bag
4 Windscreen demisting vents
5 Multifunction display
6 Central locking control*
7 Hazard warning lights switch
8 Instrument panel lightingrheostat
9 Lights and direction indica-tors stalk
10 Steering wheel height adjust-ment control
11 Steering lock 12
Windscreen wash/wipe / trip computer stalk
13 Driver's air bag
Horn
14 Radio steering column stalk
15 Headlamp height adjustment
16 Passenger air bag disarmingswitch*
17 Alarm button*
18 Dynamic stability control(ESP/ASR) button
19 Storage compartment
20 Fuse box
21 Gear lever
22 Lighter
23 Electric retractable roof control 24
Electric window switches
25 Electric mirror switches
26 Handbrake
27 Front ashtray
28 Heating / ventilation / air con- ditioning controls Rear screen and mirrors demisting
29 Audio RD3
30 Adjustable central vents
31 Glove box
32 Bonnet opening control
* According to destination. 3
YOUR AT
A GLANCE
07-10-2002

THE ELECTRIC
RETRACTABLE ROOF Opening the roof Park the vehicle on level ground. Ensure that the screen 1is
hooked on (nothing must be placed on the screen; if thereis luggage in the boot, it mustnot cause the screen to lift up).
 Check that there are noobjects on the rear shelf. When stationary , with the
handbrake applied, turn the ignition key to position M.
 Completely release the two
hooks 2; this operation is vali-
dated by an audible signal.
 Press on button 3until you
hear a signal to indicate thatthe roof opening operation iscomplete.
Note: during this operation, the
windows open. Closing the roof
When stationary , with the
handbrake applied, turn the ignition key to position M.
 Press button 3until you hear a
signal to indicate that the roofopening operation is complete.
 Lock the two hooks 2.
Note: the window control switches
become operational again after theroof manoeuvre.
YOUR AT A GLANCE
The roof must not beoperated when a load-ed luggage carrier isfitted on the boot lid.
During roof opening or closingoperations, to avoid risk ofinjury, ensure that no-one is inthe proximity of the movingparts.
If there is any danger,release the control switch;the operation will stopinstantly
Never release button 3 forany length of time, norswitch off the ignition, whenthe roof is in an intermedi-ate position (neither com-pletely open nor completelyclosed).
07-10-200273

PEUGEOT SERVICING23
- Engine oil
Level
Operations Operation descriptions 1st service
AC
Intermediate visit
- Oil filter- Fuel filter- Air filter element- Spark plugs
- Engine oil (check + top-up)- Manual gearbox oil (check + top-up)- Battery (check + top-up) if removable cap- Coolant level (check + top-up)- Front windscreen wash (check + top-up)- Brake fluid (check + top-up)- Power steering fluid (check + top-up according to specification)
- Operation of lights and indicators- Condition of glass, headlamp and light lenses and mirrors- Horn- Condition of wiper blades- Windscreen jets- Condition and tension of the ancillary drive belts- Handbrake- Condition of hydraulic circuits (hoses and covers) and check for leaks- Condition of rubber boots and gaiters- Brake pad wear o- Play in hubs, link rods, ball joints, flexible mountings- Shock absorbers: check for leaks- Rear drum brake lining wear- Condition and pressure of tyres (including spare tyre)- Emission control check according to current legislation- Pollen filter (according to specification)o- Visual check of the whole vehicle by a PEUGEOT dealer
- Courtesy vehicle

All driving conditions. oIf there are specific conditions. * According to country.
DRAIN AND REFILL
REPLACE
LEVELS
CHECK
SERVICE*
ROAD TEST
TYPE A AND C SERVICES AND THE INTERMEDIATE VISIT
07-10-2002

INSTRUMENTS AND CONTROLS
26
1.Seat belt not fastened warning light*
2. Passenger air bag disarming indi- cator light*
3. Front and side air bags warning light
4. Front fog lamps indicator light
5. Anti-lock braking system (ABS)warning light
6. Rear fog lamp indicator light
7. Left-hand direction indicator
8. Total distance recorder, service indi-cator and engine oil level indicator
9. Right-hand direction indicator 10.
Engine autodiagnostics warning light
11 . Main beam headlamps
12. Handbrake, brake fluid level andelectronic brake force distributionwarning light
13. Dipped beam headlamps
14. Battery charge warning light
15. Engine oil pressure and tempera-ture warning light
16. Coolant temperature and low levelwarning light
17. Engine oil temperature indicator 18.
Total distance recorder button
19. Central (STOP) warning light
20. Speedometer
21. Coolant temperature indicator
22. Rev counter
23. Lighting rheostat button
24. Fuel gauge
25. Low fuel level warning light
26. Dynamic stability control(ESP/ASR) warning light
* According to destination.
INSTRUMENT DIALS: MANUAL GEARBOX
07-10-2002

INSTRUMENTS AND CONTROLS27
1. Seat belt not fastened warning light*
2. Passenger air bag disarming indi- cator light*
3. Front and side air bags warning light
4. Front fog lamps indicator light
5. Anti-lock braking system (ABS)warning light
6. Rear fog lamp indicator light
7. Left-hand direction indicator
8. Total distance recorder, service indi-cator and engine oil level indicator
9. Right-hand direction indicator 10.
Engine autodiagnostics warning light
11 . Main beam headlamps
12. Handbrake, brake fluid level andelectronic brake force distributionwarning light
13. Dipped beam headlamps
14. Battery charge warning light
15. Engine oil pressure and tempera-ture warning light
16. Coolant temperature and low levelwarning light
17. Operating programmes 18.
Gear lever position indicator
19. Total distance recorder button
20. Central (STOP) warning light
21. Speedometer
22. Coolant temperature indicator
23. Rev counter
24. Lighting rheostat button
25. Fuel gauge
26. Low fuel level warning light
27. Dynamic stability control (ESP/ASR) warning light
* According to destination.
INSTRUMENT DIALS: AUTOMATIC GEARBOX
07-10-2002

INSTRUMENTS AND CONTROLS
28
Handbrake, low brake fluid level and fault inElectronic Brake ForceDistribution systemwarning light
Linked with the central STOP warning light. Indicates either:
Ð that the handbrake is on or has not been released correctly,
Ð an excessive drop in the brake fluid level (if the light remains lit even with the handbrake released),
Ð a fault in the Electronic Brake Force Distribution system if lit simultane-
ously with the ABS warning light.
Stop immediately.
Contact a PEUGEOT dealer.
INSTRUMENTS AND CONTROLS
A permantly lit warning light or one that flashes, with the engine run-ning, indicates an operating fault inthe relevant unit. Some warninglights may be accompanied by anaudible signal and a message onthe multifunction screen. Do notignore this warning: contact a PEUGEOT dealer as soon as possi-
ble. If the Central STOP warninglight comes on when you are dri-ving, stop immediately where it issafe to do so.
Anti-lock brake system (ABS) warning light This comes on for 3 seconds
each time the ignition is switched on. If the warning light remains on or comes on above 12 km/h, this indi-
cates an ABS malfunction.
However, the vehicle retains conven- tional servo-assisted braking. Lighting of this warning light is accom- panied by an audible signal and themessage "ABS fault" on the multi-
function display.
Contact a PEUGEOT dealer.
Engine oil pressure warning light
Linked with the central STOP
warning light.
Stop immediately.This warning light indicates either:
Ð insufficient oil pressure,
Ð lack of oil in the lubrication circuit. Top up the oil level.
Ð oil temperature which is too high. Switching on of the warning light is accompanied by an audible signal.
To lower the oil temperature, reduceyour speed.
Contact a PEUGEOT dealer.
Coolant temperature and low level warninglight
Linked with the central STOP warning light.
Stop immediately.Allow the engine to cool before top- ping up. The cooling system is pressurised.In the event of breakdown and to pre-
vent the risk of scalding , turn the
cap twice to allow the pressure to drop. Once the pressure has dropped, remove the cap and top up the level.
Contact a PEUGEOT dealer.
Central STOP warning light Linked with the warning
light for the "engine oil pressure", the "coolant temperature and low levelgauge", the "handbrake", the "brakefluid low level" and ''electronic brakingsystem fault''. Stop immediately if the light is flashing with the engine running.
Contact a PEUGEOT dealer.
07-10-2002

YOUR 206 CC IN DETAIL73
THE ELECTRIC RETRACTABLE ROOF Opening the roof Park the vehicle on horizontal ground.
Ensure that the screen 1is hooked
on (no object must be placed on the screen; if there is luggage in theboot, this must not push the bootupwards).
 Check that no object has been placed on the rear parcel shelf.
 With the vehicle stationary and
the handbrake applied, turn theignition switch to position M.
 Release the two hooks 2 com-
pletely ; this operation is confirmed
by an audible signal.
 Pull switch 3until you hear a signal
to indicate that the roof openingoperation is complete.
When carrying out this manoeuvre, the front windows and then the rear
quarter panel windows lower, the bootlid opens, the roof folds up and stores
itself in the boot. Then the boot lidcloses and the detachable shelf posi-tions itself. Note: The control buttons for the win-
dows become operational again at the end of the roof operation.Operating hitch: If the operation is
interrupted, a continuous audible sig- nal sounds:  Release switch 3, then press it
again to finish opening the roof.
If the malfunction persists, contact a
PEUGEOT dealer to have the systemchecked.
After rain or washing the vehicle, it is advisable to wait for the roof todry before opening it.
07-10-2002

07-10-2002
YOUR 206 CC IN DETAIL
74
Closing the roof
With the vehicle stationary and
the handbrake applied, turn the ignition key to position M.
 Press switch 3 until you hear a sig-
nal to indicate that the roof openingoperation is complete.
When carrying out this operation, thefront windows and then the rear quar-ter panel windows open, the boot lidopens and the detachable parcel shelffolds up, the boot lid opens, the roofsunfolds and positions itself, then theboot lid closes again.  Lock the two hooks 2.
Note: The control buttons for the win-
dows become operational again at the end of the roof operation. Operating hitch: If the operation is
interrupted, a continuous audible sig- nal sounds:  Release switch 3, then press it
again to finish closing the roof.
If the problem persists, contact a
PEUGEOT dealer to have the systemchecked. When the vehicle is moving, if a con-tinuous audible signal can be heard,this means that the roof or the boot lid,or both, are not locked:
Stop the vehicle and apply the handbrake,
 Open the roof and close it again
completely, in accordance with theprocedure.
If the problem persists, contact a
PEUGEOT dealer to have the systemchecked. The roof must not be oper-ated when a loaded lug-gage carrier is fitted to theboot lid.
During roof opening and closingoperations, to avoid any risk of
injury, ensure that there is no-onein the proximity of the movingparts.
In the event of danger, release the control knob, the operation
will stop instantly. Never release button 3 for any
length of time, nor switch off theignition when the roof is in anintermediate position (neithercompletely open or closed).
In the case of an electric or hydraulic malfunction of the roof, it is possible
to close the roof manually. When the side windows no longer
open completely, it is impossible tooperate the roof; however it is possibleto close it by using a special proce-
dure. Please consult the breakdown pro- cedure described at the end of thishandbook.

07-10-2002
YOUR 206 CC IN DETAIL
86
AUTOMATIC AUTOADAPTIVE GEARBOX Moving Off
To move off, move the selector lever to position
Nor P. Press the brake to exit
position P. Stopped or parked Always leave the lever in position Pwhen you get out of your vehicle.
If not, a buzzer will sound when you open the driver's door. Positions of the selector lever These positions are displayed on the instrument panel. P. Park: use with the handbrake.
R. Reverse: this must only be engaged when the vehicle is stationary, engine at idle.
N. Neutral: if Nis engaged by mistake while the car is moving, allow the engine
to return to idle before engaging a new forward gear.
D. Drive: in this position, the four gears change automatically. The gear change
points vary depending on the programme selected.
3. Automatic changing of the first three gears only. Select this position when you notice frequent changes between third and fourth gear (town driving or on winding roads).
2. Automatic changing of the first two gears only. This position is particularly suitable for mountain roads, when going uphill (to make the best use of the engine's power) and downhill (engine braking).

07-10-2002
YOUR 206 CC IN DETAIL87
Operating programmes
You have a choice of three operating pro- grammes:
Ð Autoadaptive (normal).
Ð Sport.
Ð Snow.One press on button
Aor Bwill select
Sport or Snow respectively. The selec- tion is displayed on the instrumentpanel. Pressing the button a secondtime will return to the autoadaptive(normal) programme. Autoadaptive programme (normal) Gear changes are carried out on the basis of various parameters, such as:
Ð driving style,
Ð road characteristics,
Ð vehicle load.The gearbox selects the most suitable programme from those in the memoryfor the current driving conditions. Sport programme The Sport programme automatically favours more dynamic driving. Snow Programme In position
D, the Snow programme
provides smooth driving suited to slip- pery roads in order to improve traction
and stability. Starting is in 2nd gear
and changing down is at low enginespeeds. Special operating features
Ð During prolonged braking, the gear- box changes down automatically, so
as to provide efficient engine braking.
Ð If you take your foot off the acceler- ator suddenly (when you are takenby surprise, for example), the gear-box will not change up, so as to
improve safety.
Ð When the engine is cold, the gearbox automatically selects a special pro-gramme that enables the engine toreach its ideal temperature morequickly in order to decrease pollution.
Kickdown For immediate maximum acceleration
without touching the gear lever, pressthe accelerator pedal down as far as it
will go. The gearbox will change downautomatically or stay in the gearselected, up to maximum enginespeed.Any disruption of the system is signalled by the simultane-ous flashing of the Sport andSnow lights on the instru-
ment panel. In such a case, the gear-box will operate in downgrade mode.
You may feel a substantial knock whenreverse is selected from Pto Ror Nto
R (without any risk of damage to the
gearbox). Do not exceed 100km/h.Contact a PEUGEOT dealer without
delay. When the engine is idling with the car
in gear, the car will move even withoutyou accelerating. Do not accelerate while a gear is being selected, when the vehicle is
stationary.
When stationary, have your foot on the
brake pedal when selecting a gear. Do not accelerate in gear with the brakes on. If work needs to be done with the engine running, apply the handbrakeand select position P.
Do not change down to brake on slip-pery roads. Never select position Nwhen the
vehicle is moving.Never engage Por Rif the vehicle is
not stationary.Do not leave children inside the vehicle unsupervised when theengine is running.
