Page 71 of 128
THE ALARM* This provides two types of protec- tion: Ãexterior protection: when this is
set, the alarm sounds if a door, the tailgate or the bonnet is opened.
à interior protection: when this is
set, the alarm sounds if the sen-sors detect a variation in the airmovement inside the vehicle(breaking of a window or a move-ment inside the vehicle).
Setting the alarm Switch off the ignition and get out of the vehicle.
Set the alarm within five minutesof getting out of the vehicle, bylocking or deadlocking using theremote control (button Aindica-
tor light flashes once persecond).
Note: if you wish to lock your vehicle
without setting the alarm, use thedoor lock. When the alarm is triggered, thesiren sounds and the direction indi-cators flash for thirty seconds. After triggering, the alarm remains set.
Warning:
if the alarm has been trig-
gered ten times in succession, on the eleventh time it becomes inactive. Note: if button Aflashes rapidly, the
alarm has been triggered while you were away from your vehicle. Disarming Unlock the vehicle with the remote control key (button Aindicator light
goes out). Note: if the alarm has been triggered
while you were away from your vehicle, the rapid flashing of the indi-cator light will stop when you switchon the ignition.
To set the alarm with exterior protection only If, while you are away from the vehicle, you wish to leave a windowpartially open or a pet inside thevehicle, you should choose exterior
protection only. Switch off the ignition,
In the next ten seconds, press button Auntil the indicator light
is on continuously,
Get out of the vehicle,
Set the alarm by locking or dead-locking using the remote control(button Aindicator light flashes
once a second).
Note: when the alarm is set but the
remote control does not operate: Unlock the doors with the key
and open the door. The alarm istriggered.
Switch on the ignition in the next
ten seconds. The alarm is disarmed.
Incorrect operation When the ignition is switched on, if button Alights for ten seconds, there
is a fault in the siren connection.
Contact a PEUGEOT dealer to have the system checked. Automatic activation** The alarm is activated automatically two minutes after the last opening(door or boot) is closed. In order to avoid accidental triggering of the alarm when a door or the bootis opened, it is essential to first pressthe remote control opening button.
* According to specification
** According to country
YOUR 307 IN DETAIL
68
Page 72 of 128
THE DOORS Opening the doors from outside Opening the doors from inside The front door unlocking controls permit complete unlocking of thevehicle.
However, the rear door unlocking controls only unlock the door concer-ned. Note:the door opening switches do
not function when the vehicle is deadlocked. Locking / Unlocking from the inside Press button
A.
This allows locking or unlocking of the doors and the tailgate. Note: if the vehicle is deadlocked,
button Adoes not function. In this
case use the remote control for unlocking. "Door open" alert With the engine running or the vehicle moving, the flashing of thecentral "STOP" warning light,
accompanied by an audible signaland a diagram locating the problem
on the multifunction display, warnsyou that a door is not properly clo-sed. Child safety This prevents either of the rear doors being opened from inside.
Turn the red plastic switch a quarter of a turn using the ignition
key.
YOUR 307 IN DETAIL 69
Page 73 of 128
TAILGATE Simultaneous locking or unlocking of the tailgate andthe doors The tailgate is locked or unlocked by the remote control or the driver'sdoor lock.
To open, pull handleAand lift the
tailgate.Note: the tailgate locks automatical-
ly when the vehicle is being driven at 6 mph (10 km/h) and unlocks whenone of the doors is opened or at aspeed below 6 mph (10 km/h).
"Tailgate open" warning When the engine is running or if the vehicle is being driven, the flashingof the central "STOP"warning light,
accompanied by an audible signaland a diagram on the multfunction
display, warns you that the tailgate isnot properly closed. Tailgate release This enables the tailgate to be unloc- ked in the event of a central lockingfault.
- Fold back the rear seats to gain
access to the lock from inside the boot,
- Insert a small screwdriver into hole A of the lock to unlock the tailgate. THE SUNROOF * -
to partially open the roof: Turn
the switch to the right (three pos- sible settings).
- to close: Turn the switch back to
position "O".
- to open the roof completely:
Turn the switch to the left (six pos-sible settings).
- to close it completely: Turn the
switch back to position "O".
- safety auto-reverse: When the
sunroof is closing and meets anobstacle, it stops then opensagain.
- After a safety auto-reverse manoeuvre, to synchronise theposition of the switch with the roofposition, press and hold the switch.
Note: the sunroof shutter is manual.
* According to specification.
YOUR 307 IN DETAIL
70
Page 74 of 128
OPENING THE BONNET From inside:push the handle on the
driver's side under the fascia. From outside: lift the catch and
raise the bonnet. Bonnet strut Secure the strut to hold the bonnet open. Before closing the bonnet, replace the strut in its housing.
To close Lower the bonnet and release it at the end of its travel. Check that thebonnet is properly locked. "Bonnet open" warning* With the engine running or the vehicle moving, flashing of the
"STOP" centralised warning light accompanied by an audible signaland a diagram on the multi-function
display, warns you that the bonnet isnot properly closed. FILLING WITH FUEL Low fuel level
When the minimum fuel level in the tank is rea-ched, this warning lightcomes on.
You can still drive
approximately 30 miles (50 km). Flashing of the warning light indi- cates a malfunction of the fuelgauge.
Contact a PEUGEOT dealer.The engine must be switched off when filling with fuel.
Open the fuel filler flap.
Insert the key then turn it to theleft.
Remove the cap and hang it onthe hook located on the inside ofthe flap.
A label affixed inside the fuel fillerflap indicates which type of fuel touse. When you fill your tank, do not conti-
nue after the third cut-off of the
pump. This could cause your vehicleto malfunction. The capacity of the tank is approxi- mately 13 gallons (60 litres). After filling the tank, lock the cap and close the fuel filler flap.
* According to specification.
YOUR 307 IN DETAIL 71
Page 75 of 128
THE LIGHTS STALK Front and rear lights Selection is by turning ring A.
Lights off Side lights on Dipped/main beam headlamps Automatic switching on of lights* Dipped/Main beam change Pull the stalk fully towards you. Note:
with the ignition off, if the dri-
ver's door is left open, a buzzer sounds if you have left your lights on. Front fog lamps* and rear fog lamp Rotate the ring forwards to switch on
and backwards to switch off. The statusis confirmed by the light on the instru-ment panel.
Vehicles fitted with a rear fog lamp (ring B)
Rear fog lamp
This operates with the dipped/mainbeam headlamps.
Vehicles fitted with front fog lamps* and a rear fog lamp (ring C) Front fog lamps (first rota-tion of the ring forwards).
These operate with the side lightsand the dipped beam lamps. Front and rear foglamps (2nd rotation ofthe ring forwards).
These operate with the side lightsand the dipped/main beam head-lamps. Note: to switch off the rear fog lamp
and the front fog lamps, turn the ring backwards twice in succession. Direction indicators (flashers)
Left : downwards.
Right : upwards.
*According to specification
YOUR 307 IN DETAIL
72
In good or rainy weather, both day and night, therear fog lamp is dazzlingand is prohibited.
Do not forget to switch the foglamp off when it is no longer needed.
Page 76 of 128
AUTOMATIC SWITCHING ON OF LIGHTS* Side lights and dipped beam head- lamps switch on automatically if the
light is poor, or during operation of
the windscreen wipers. They switch
off as soon as the light becomesbright enough or the windscreenwipers stop. Note :In foggy weather the bright-
ness sensor can detect sufficient
light. As a consequence, the lights
wil not come on automatically. This function is active when the
vehicle is supplied to the customer.
To disarm or activate the function: Start with the key in the accesso- ries position (1st notch),
Press the end of the stalk formore than two seconds.
Note: after the ignition is switched
off and depending on the brightness,the lights remain on for 45 secondsor until the vehicle is locked. Do not cover the brightness sen- sor located in the centre of thefascia. It is used for automaticswitching on of the lights. Operating check
Triggering of the sensorActivation of this function is accom- panied by an audible signal and themessage
"Automatic lighting" on
the multifunction display. The light also comes on as soon as the driver changes the stalk positionto 0.
Disarming Disarming of the function is accom- panied by an audible signal. Note: the function is temporarily
disarmed when the driver uses the manual lighting controls. If the brightness sensor does not function correctly , the system acti-
vates the function (the lights come
on). The driver is alerted by anaudible signal, accompanied by themessage "Automatic switching on
of lights faulty"
Contact a PEUGEOT dealer to have the system checked.
*According to specification
YOUR 307 IN DETAIL 73
Page 77 of 128
Operation In position 1or 2, when the vehicle
stops, the windscreen wiper changes to a lower wiping speed, thenresumes its initial speed when thevehicle starts again. When the ignition has been swit- ched off for more than a minute
with the control in the AUTO posi-tion*, it is necesary to reactivatethis function.
To do this, move the control to any position, then move it back to the
AUTO* position.
Screenwash/headlamp wash* Pull the windscreen wiper stalk towards you. The windscreen wash then the wind- screen wipers operate simultaneous-ly for two seconds, only if the dip-
ped beam or main beam head-lamps are on.
YOUR 307 IN DETAIL
74
WINDSCREEN WIPER STALK Front windscreen wipers2 Fast wipe (heavy rain).
1 Normal wipe(moderately heavy rain).
AUTO Automatic wipe*
0 Off
Single wipes (press downwards)
Automatic timed windscreen wipers* In the AUTOposition, the wind-
screen wipers operate automatically and adapt their speed to the intensi-ty of the rainfall.
Operating check ActivationWhen the function is activated, the message "Automatic windscreen
wipers activated" appears on the
multifunction display. Switching off
Switching off the function is accom- panied by an audible signal. In the event of malfunction, the driver is informed by an audible signal andthe message "Automatic wind-
screen wipers faulty" on the multi-
function display. In the event of malfunction in the
AUTO position, the windscreen
wiper will operate intermittent mode.
Contact a PEUGEOT dealer to have the system checked.
* According to specification
Page 78 of 128
Maintenance position This position enables the wiper blade to be removed.
In the minute following switching off of the ignition, any action on the stalkpositions the wipers in the centre ofthe windscreen (winter parking, clea-ning, replacement of the blades).
To reposition the wipers after this has been done, switch on the ignitionand operate the stalk.
* According to specification
YOUR 307 IN DETAIL75
Do not cover the rain sen- sor located on the wind-screen behind the interior
mirror.
When using an automatic carwash, switch off the ignition orcheck that the wiper stalk is not inthe automatic position In winter it is advisable to wait for the windscreen to completelyclear of ice before operating theautomatic wipe.Rear windscreen wiper
Turn ring Ato the first notch
for intermittent wiping.
Rear windscreen wash Turn ring Apast the first
notch; the windscreen wash then the windscreen wiperoperate for a specified time.
Page 79 of 128
TRIP COMPUTER*Each successive press on the end of the wash/wipe stalk displays in turn:
Display B
- the date,
- the remaining range,
- the distance travelled,
- the average consumption,
- the current consumption,
- the average speed. Zero reset Press the stalk for more than two seconds.
* According to specification.
YOUR 307 IN DETAIL
76
Page 80 of 128
Range The display shows the distance which can still be covered with thefuel remaining in the tank. Note :this figure may rise if there is
a change in driving style or road sur- face, accompanied by a significantdrop in current fuel consumption. If there are less than 3 litres of fuel in the tank, only three segments will bedisplayed. Current consumption This gives the fuel consumption recorded during the last two
seconds. This function is displayedonly when the vehicle is travelling atapproximately 15 mph (20 km/h). The display stops at 10 mpg (30 l/100km). Average consumption This is the ratio between the amount of fuel consumed and the distancetravelled since the computer was lastreset to zero. The display stops at 10 mpg (30 l/100km).
Distance travelled This shows the distance travelled since the computer was last reset tozero. After the trip computer has been reset to zero, the range databecomes meaningful only after thevehicle has been in use for a certainperiod. If horizontal segments are displayed instead of figures when driving,
contact a PEUGEOT dealer.
YOUR 307 IN DETAIL
77
Average speed This is obtained by dividing the dis- tance travelled by the period of timethe vehicle has been in use (with theignition on), since the computer waslast reset to zero.
