Page 15 of 173
22-09-2003
PEUGEOT SERVICING
18
PEUGEOT SERVICING
Your vehicle benefits from extended service intervals.
Ð For 2 litre 180 bhp engine vehicles: every 12,000 miles (20,000 km) or every two years.
Ð For 1.6 litre and 2 litre engine vehicles: every 20,000 miles (30,000 km) or every two years.
Your service indicator indicates when the services are due; the point at which a service is due is calculated from the last ind i-
cator reset (see corresponding section).The point at which a service is due is determined by two parameters:
Ð the distance travelled,
Ð the time elapsed since the last service. Note: the distance remaining may be weighted by the time factor, in accordance with the user's driving habits.
The extension of the service intervals means that the engine oil level must be checked regularly: topping up of the oil between oil changes is normal. It is for this reason that the PEUGEOT network invites you to an intermediate visit between each regular Service. The service indicator does not show when this service is due. It must be carried out every 10,000 miles (15,000 km) maximum for the 1.6 litre and 2 litre engines and every 6,000 miles (10,000 km) maximum for the 2 litre 180 bhpengines.
A PEUGEOT dealer will carry out a quick check, and will top up the levels if necessary (oil, coolant, screen-wash up to 2 litres). If the oil level is too low there is a risk of serious damage to the engine: check the engine oil level at least every 2,000 to 3,000 miles (3,000 to 5,000 km), depending on the conditions of use. This extended servicing has been made possible by modifications to our vehicles and to the lubricants:
THUS IT IS ESSENTIAL TO ONLY USE LUBRICANTS WHICH ARE SUITED TO YOUR ENGINE AND RECOMMENDED
BY THE MANUFACTURER (see "Lubricants" pages). * Whichever comes first.
Page 23 of 173
PEUGEOT SERVICING25
TYPE A AND C SERVICES AND THE INTERMEDIATE VISIT
Level
Operations Operation descriptions1st service visitA C Intermediate
DRAIN AND REFILLÐ Engine oil
Ð Oil filter Ð Fuel filter* REPLACEÐ Air filter element Ð Spark plugs Ð Engine oil (check + top-up) Ð Manual gearbox oil (check + top-up) Ð Battery (check + top-up) if removable cap LEVELSÐ Front windscreen wash (check + top-up) Ð Coolant (check + top-up) Ð Brake fluid (check + top-up) Ð Power steering fluid (check + top-up according to specification) Ð Operation of lights and indicators Ð Condition of glass, headlamp and light lenses and mirrors Ð Horn Ð Windscreen jets Ð Condition of wiper blades Ð Condition and tension of the ancillary drive belts Ð Handbrake Ð Condition of hydraulic circuits (hoses and covers) and check for leaks CHECKÐ Condition of rubber boots and gaiters Ð Brake pad wear Ð Play in hubs, link rods, ball joints, flexible mountings Ð Shock absorbers: check for leaks Ð Rear drum brake lining wear Ð Condition and pressure of tyres (including spare tyre) Ð Emission control check according to current legislation Ð Passenger compartment filter (according to specification) Ð Visual check of the whole vehicle by a PEUGEOT dealer
SERVICE*Ð Courtesy vehicle
ROAD TEST
: All driving conditions : If there are specific conditions * According to destination.22-09-2003
Page 26 of 173
22-09-2003
INSTRUMENTS AND CONTROLS
28
PETROL INSTRUMENT PANEL DIALS: MANUAL GEARBOX
1 - Rev counter.
2 - Seat belt not fastened warning light.
3 - Engine diagnostics warninglight.
4 - Handbrake and low brake fluidlevel warning light.
5 - Left-hand direction indicator.
6 - Coolant temperature indicator.
7 - Battery charge warning light. 8 -
Central (STOP) warning light.
9 - Low fuel level warning light.
10 - Engine oil pressure warning light.
11 - Fuel gauge.
12 - Right-hand direction indicator.
13 - ABS warning light.
14 -
Air bags and rear, protective,pop-up roll-over hoops warning light.
15 - Passenger air bag disarming indicator light.
16 - Speedometer.
17 - Service indicator, oil level and
total distance recorder.
18 - Trip recorder zero reset.
19 - Rear fog lamp indicator light.
20 - ESP/ASR warning light.
21 - Front fog lamps indicator light.
22 - Low coolant level warning light*.
23 - Main beam headlampsindicator light.
24 - Dipped beam headlampsindicator light.
25 - Lighting rheostat.
26 - Engine oil temperature gauge.
* According to engine.
Page 27 of 173
22-09-2003
INSTRUMENTS AND CONTROLS29
PETROL INSTRUMENT PANEL DIALS: AUTOMATIC GEARBOX
1 - Rev counter.
2 - Seat belt not fastened warning light.
3 - Engine diagnostics warninglight.
4 - Handbrake and low brake fluidlevel warning light.
5 - Left-hand direction indicator.
6 - Coolant temperature indicator.
7 - Battery charge warning light. 8 -
Central (STOP) warning light.
9 - Low fuel level warning light.
10 - Engine oil pressure warning light.
11 - Fuel gauge.
12 - Right-hand direction indicator.
13 - ABS warning light.
14 -
Air bags and rear, protective,pop-up roll-over hoops warning light.
15 - Passenger air bag disarming indicator light.
16 - Speedometer.
17 - Service indicator, oil level and
total distance recorder.
18 - Trip recorder zero reset.
19 - Rear fog lamp indicator light.
20 - ESP/ASR warning light.
21 - Front fog lamps indicator light.
22 - Main beam headlamps indicator light.
23 - Dipped beam headlampsindicator light.
24 - Lighting rheostat.
25 - Engine oil temperature gauge.
26 - Snow programme indicatorlight.
27 - Gear lever position indicator.
28 - Sport programme indicator light.
Page 28 of 173
22-09-2003
INSTRUMENTS AND CONTROLS
30
INSTRUMENTS AND CONTROLS
A permanently lit warning light or one that flashes with the engine run-ning, indicates an operating fault inthe relevant unit. Some warninglights may be linked to buzzers anda message on the multi-function dis-
play. Do not ignore this warning:contact a PEUGEOT dealer as soonas possible.
If the Central STOP warning light comes on when you are driving,stop immediately where it is safeto do so.
Central STOP warning light
This light comes on each time the ignition is switched on. It is linked to the "engine oil pres- sure", ''coolant level low'', ''brakefluid level'' and "electronic brakeforce distribution fault'' warning lightsand the ''coolant temperature'' and"engine oil temperature" gauges. Stop immediately if it flashes with the engine running.
Contact a PEUGEOT dealer. Engine oil pressure warning light
Linked to the central STOPwarning
light. If it comes on with the engine running, it is accompanied by an audible signaland the message "Oil pressure
insufficient" or "Top up engine oil
level" on the multi-function display.
Stop immediately. If there is a lack of oil in the lubrication circuit, top up the level.
Contact a PEUGEOT dealer without
delay.
Low coolant level warning light*
Linked to the central STOPwarning
light. This comes on for approximately
3 seconds each time the ignition isswitched on. This warning light is accompanied by an audible signal and the message
"Top up engine coolant level" on
the multi-function display.
Stop immediately.
* According to engine. Warning:
Allow the engine to cool
before topping up. The cooling system is pressurised.
To prevent the risk of scalding, unscrew the cap by two turns toallow the pressure to drop. Once the pressure has dropped, remove the cap and top up the level.
Contact a PEUGEOT dealer.
Handbrake and low brake fluid levelwarning light Linked to the central STOP
warning light. This comes on each time the ignition is switched on. Illumination of this light is accompa- nied by an audible signal and a mes-sage on the multi-function displayindicating the cause of the warning: Ð "Handbrake on" , if the handbrake
is applied or has not been released
correctly,
Ð "Brake fluid level low" if there is
an excessive drop in the brake fluid(if the light remains on even with thehandbrake released),
Ð "Braking fault" is displayed simul-
taneously with the ABS light, indi-cating a malfunction of the elec-tronic brake force distribution.
Stop immediately.
Contact a PEUGEOT dealer.
Page 30 of 173
22-09-2003
INSTRUMENTS AND CONTROLS
32
Low fuel level warning light
The warning light comes on for three seconds when the ignition isswitched on. When this light comes on with the engine running, it is accompanied byan audible signal and the message"Fuel level low" on the multi-function
display. When the warning light comes on, you have enough fuel to driveapproximately 30 miles (50 km) .
The tank capacity is approximately
60 litres. This light flashes to indicate a mal- function of the fuel gauge.
Contact a PEUGEOT dealer. Coolant temperature indicator When the needle is in zone
A, the
temperature is correct. When the needle is in zone B, the
temperature is too high. The central
STOP warning light flashes, accom-
panied by an audible signal and themessage "Engine coolant temper-
ature high" on the multi-function
display.
You must stop immediately.
Warning: wait for the engine to cool
before topping up the level.The cooling system is pressurised.In order to avoid any risk of scalding, unscrew the cap two turns to allowthe pressure to drop. When the pressure has dropped, remove the cap and top up the level.
Contact a PEUGEOT dealer. Engine oil temperature indicator When the engine is running, this indicates the oil temperature. The temperature is too high if the maximum graduation is reached.The central
STOPwarning light
flashes, accompanied by an audiblesignal.
You must stop immediately.
Contact a PEUGEOT dealer.
Seat belt not fastened warning light
With the engine running, this indica- tor light comes on when the driver'sseat belt is not fastened.
Page 31 of 173
22-09-2003
INSTRUMENTS AND CONTROLS
32
Low fuel level warning light
The warning light comes on for three seconds when the ignition isswitched on. When this light comes on with the engine running, it is accompanied byan audible signal and the message"Fuel level low" on the multi-function
display. When the warning light comes on, you have enough fuel to driveapproximately 30 miles (50 km) .
The tank capacity is approximately
60 litres. This light flashes to indicate a mal- function of the fuel gauge.
Contact a PEUGEOT dealer. Coolant temperature indicator When the needle is in zone
A, the
temperature is correct. When the needle is in zone B, the
temperature is too high. The central
STOP warning light flashes, accom-
panied by an audible signal and themessage "Engine coolant temper-
ature high" on the multi-function
display.
You must stop immediately.
Warning: wait for the engine to cool
before topping up the level.The cooling system is pressurised.In order to avoid any risk of scalding, unscrew the cap two turns to allowthe pressure to drop. When the pressure has dropped, remove the cap and top up the level.
Contact a PEUGEOT dealer. Engine oil temperature indicator When the engine is running, this indicates the oil temperature. The temperature is too high if the maximum graduation is reached.The central
STOPwarning light
flashes, accompanied by an audiblesignal.
You must stop immediately.
Contact a PEUGEOT dealer.
Seat belt not fastened warning light
With the engine running, this indica- tor light comes on when the driver'sseat belt is not fastened.
Page 142 of 173
22-09-2003
PRACTICAL INFORMATION
130
CHECKING THE LEVELS Oil level
Check the level regularly and top
up between changes. The maxi-mum consumption is 0.5 l per600 miles (1,000 km). Check the level with the vehicle level, engine cold, using the oil levelgauge on the instrument panel orthe dipstick.
Dipstick There are two marks onthe dipstick: A=maximum
Never fill past this mark
B= minimum
To maintain the reliability of engines and emissioncontrol systems, the useof additives in engine oilis prohibited.
Oil change According to the information given in
"PEUGEOT SERVICING" .
Note: avoid used oil coming into
prolonged contact with the skin. Viscosity selection In all cases, the oil selected must meet the manufacturer's requirements. Brake fluid level:
Ð The level must always be between
the DANGER and MAXIMUM
marks in the reservoir.
Ð If the level drops substantially, contact a PEUGEOT dealer
immediately.
Fluid change:
Ð must be carried out according to the manufacturer's servicing schedule.
Ð use fluids recommended by the manufacturer, which fulfil DOT4standards.
Note: brake fluid is harmful to health
and very corrosive. Avoid all contactwith the skin. Cooling system Use the fluid recommended by the
manufacturer. When the engine is warm, the tem- perature of the coolant is controlled
by the engine fan. As this fan canoperate with the ignition keyremoved and because the coolingsystem is pressurised, wait for atleast one hour after the engine hasstopped before carrying out anywork. Slacken the cap to the first notch torelease the pressure to prevent anyrisk of scalding. When the pressurehas dropped, remove the cap andtop up the level. Note:
the coolant does not need to
be changed. Used oil Do not dispose of used oil, brake fluid or coolant into drains or into theground. Power steering reservoir Open the reservoir, with the engine at ambient temperature.The level should always beabove the MIN. mark and closeto the MAX. mark.
Windscreen and headlamp* wash level For best quality cleaning and for your
safety, we would advise that you use
products recommended by PEUGEOT.
* According to destination.
Page 155 of 173
22-09-2003
PRACTICAL INFORMATION139
* Fuses located inside the top of the fuse box.
Fuse no. Rating Functions
9 30 A Front electric windows - Automatic front electric windows.
10 15 A Diagnostic socket - 12 volt rear socket - Trailer.
11 20 A Audio equipment - Multi-function display - Steering wheel controls - Automatic gearbox - Retractable roof control unit.
12 10 A Front right and rear right side lights - Number plate and trailer lighting -
Central locking/alarm/hazard warning lights/ESP switches lighting -
Air conditioning/ashtray lighting - Automatic gearbox switches lighting -
Lighter.
14 30 A Door opening/closing controls - Deadlocking controls.
15 30 A Press-operation electric rear windows - Hinged covers motor.
16 10 A Engine fuse box - Alarm - Steering wheel controls - Air bags.
17 10 A Rear right brake light - 3rd brake light.
18 10 A Diagnostic socket - Steering wheel controls - Electrochromatic mirror - Brake pedal (stop) andclutch switches - Coolant level switch - Second brake switch.
19 30 A PARC shunt.
22 10 A Front left and rear left side lights - Number plate and trailer lighting.
23 15 A Alarm siren - Interior alarm control unit.
24 15 A Instrument panel - Audio equipment - Multi-function display - Air conditioning - Rear parking
assistance - Rain/brightness sensor.
26 30 A Heated rear screen.
27* Not used.
28* 40 A Retractable roof pump.
