boot Peugeot 406 Break 2002 Owner's Manual

THE KEYS The keys allow you to switch on the ignition and to independentlyoperate the locks on the frontdoors, the glove box and the pas-senger air bag disarming switch. Central locking
From the driver's door, the keys allow you to lock and unlock thedoors and the boot. If one of thefront doors is open, the centrallocking does not work. The remote control performs the same functions at a dis-tance.The remote control LockingPressing button
Alocks the
vehicle.This is confirmed by the fixed lighting of the direction indicatorsfor approximately two seconds. Unlocking Pressing button B unlocks the
vehicle.This is confirmed by the rapid fla- shing of the direction indicators. STARTING
STOP position:
The ignition is off.
1st notch, Accessories position:
The ignition is off but the acces- sories can be used. 2nd notch, Running position: The ignition is on. Starting position:
Operates the starter.
YOUR 406 AT A GLANCE
4
Key without
remote control Key with
remote control
108

∀∀
MAINTENANCE OF YOUR 40623
∀All driving conditions.o Arduous conditions.
A AND C SERVICES AND THE INTERMEDIATE VISIT
- Oil filter∀∀- Fuel filter (Petrol only)∀- Fuel filter element (Diesel only)∀- Air filter element∀- Spark plugs (Petrol only)HPI∀
- Operation of lights and indicators∀∀∀- Condition of glass, headlamp & light lenses and mirrors∀∀- Horn∀∀- Windscreen washer jets∀∀- Condition of wiper blades∀∀- Condition and tension of the ancillary drive belts∀∀- Handbrake∀∀- Condition of hydraulic circuits (hoses and covers)∀∀- Condition of rubber boots and gaiters∀∀∀- Brake pads∀∀
o- Play in hubs, link rods, ball joints, flexible mountings∀- Shock absorbers∀- Rear drum brake lining wear∀- Condition and pressure of tyres (including spare wheel)∀∀∀- Emission control check (Petrol only)∀∀∀- Smoke opacity (Diesel only)∀∀- Pollen filter (according to specification)∀∀o- Visual check of the whole vehicle∀∀
DRAIN and
REFILL
REPLACE
CHECK
ROAD TEST SERVICE
Level
Operation Description of Operation First Service
A C Intermediate
- Engine oil∀∀- Bleed fuel filter (Diesel only)∀∀∀
- Engine oil (check + top-up)∀∀- Gearbox level (check + top-up)∀∀- Battery level (check + top-up) if cap is removable∀∀- Front/rear screen wash level (check + top-up)∀∀∀∀- Coolant level (check + top-up)∀∀∀∀- Brake fluid level (check + top-up)∀∀∀- Power steering fluid level (check + top-up, according to specification)∀∀∀

Door open warning light
When the engine is running, the warning light indicates that a door has not beenclosed properly or that the
boot is open.
Electronic immobiliser warning light This indicates a malfunction of the electronic immobilis-
er. Contact a PEUGEOT dealer.
Low fuel level warning light. When the warning light comes on, you have
enough fuel to drive at least 30 miles
(50 km). The tank capacity is approx-imately 70 litres (15.4 gallons). Coolant temperature indicator When the needle is in zone
A,the
temperature is correct. When the needle is in zone B, the
temperature is too high. The central
(STOP) warning light flashes.
You must stop immediately.
Contact a PEUGEOT dealer.
Seat belt not fastened warning light With the engine running, the indicator light comes onwhen the driver's seat belt isnot fastened.
YOUR 406 IN DETAIL
133

Door open warning light
When the engine is running, the warning light indicates that a door has not beenclosed properly or that the
boot is open.
Electronic immobiliser warning light This indicates a malfunction of the electronic immobilis-
er. Contact a PEUGEOT dealer.
Low fuel level warning light. When the warning light comes on, you have
enough fuel to drive at least 30 miles
(50 km). The tank capacity is approx-imately 70 litres (15.4 gallons). Coolant temperature indicator When the needle is in zone
A,the
temperature is correct. When the needle is in zone B, the
temperature is too high. The central
(STOP) warning light flashes.
You must stop immediately.
Contact a PEUGEOT dealer.
Seat belt not fastened warning light With the engine running, the indicator light comes onwhen the driver's seat belt isnot fastened.
YOUR 406 IN DETAIL
133

Display BThis enables the following information to be displayed:
– the time,
– the date,
– the outside temperature (the °C symbol flashes when there is a risk of ice),
– the radio displays,
– the status of the doors. The display shows you whether a door, the boot or thebonnet is open and if the fuel filler cap is missing.
– the warning messages (e.g. ''battery low'') or information messages (e.g. "top up fuel tank''), displayed temporarily, can be cleared by pressing button 1or 2,
– the trip computer. Setting the parameters Press button 1for two seconds to access the settings. The information flashes
to show it is ready to be modified.Then, individual presses on button 1 allow you to scroll through the various data
in the following sequence:
– language in which the information is displayed,
– hour,
– unit of distance (kms or miles),
– unit of temperature (Celsius or Fahrenheit),
– time format (12 then 24 hour mode)
– minutes,
– year,
– month,
– day, Pressing button 2allows you to change the information selected. Maintain the
pressure for rapid scrolling.After ten seconds without moving, the display returns to the main screen and the modified data is recorded.
YOUR 406 IN DETAIL 137

Display CThis enables the following information to be displayed:
– the time,
– the date,
– the outside temperature (the °C symbol flashes when there is a risk of ice),
– the radio displays,
– the status of the doors. The display shows you whether a door, the boot or the
bonnet is open,
– the warning messages are displayed temporarily (e.g. "top up fuel tank'') and can be cleared using the remote control,
– the trip computer (see following page),
– the satellite navigation system (see corresponding section). Setting the parameters
The remote control allows you to access the settings. Accessing the different menus is described in the section on the Satellite Navigation System.
YOUR 406 IN DETAIL
138

This is located inside the boot on the left hand side. It holds up to 6 discs.
To insert a disc into the changer:
-open sliding panel A,
-press button Bto eject the cartridge C,
-open one of the six compartments of the cartridge by pulling tab D,
-insert the disc with the printed face upwards and close the compartment,
-insert the cartridge into the changer,
-close the sliding panel A.
CD CHANGER
YOUR 406 IN DETAIL
73
The use of blank compact discs can cause malfunctions.

YOUR 406 IN DETAIL
84
This is located inside the boot on the left hand side. It holds up to 6 discs.
To insert a disc into the changer:
-open sliding panel A,
-press button Bto eject the cartridge C,
-open one of the six compartments of the cartridge by pulling tab D,
-insert the disc with the printed face upwards and close the compartment,
-insert the cartridge into the changer,
-close the sliding panel A.
RM2 CD CHANGER
The use of blank compact discs can cause malfunctions.

406 Saloon AUDIO SYSTEM (RM2) Presentation
Your 406 saloon is fitted with a JBL Audio Hi-Fi system, designed specifically for the passenger compartment. At the heart of the system, a 240 watt multifunction amplifier (1) (located in the boot) independently controls 10 high acoustic definition speakers. These speakers provide optimal reproduction and distribution of the sound in the vehicle, both in the front and the
rear. The speakers are situated:– in the fascia: two Micro Tweeters (3) set into two Mediums (4) for reproduction of the sound in the front.
– in the front doors: two Woofers (2) for reproduction of bass frequencies in the front.
– on the rear parcel shelf: two Tweeters (5) for reproduction of treble (high frequencies) in the rear are set into two ellipti-
cal speakers (6), which are adjusted to reproduce a very wide range of bass and ultra-bass frequencies throughout the
whole of the passenger compartment. You will appreciate the clarity and depth and notice that the sound fills the
whole of the vehicle perfectly.
Adjusting in CD modeThe basic functions remain those of the audio set.
There is no need for any further adjustment. However, in order to take
full advantage of your JBL audio system, you are advised to set theAUDIO functions (BASS, TREB, FAD, BAL) to position "0"(zero) and
the Loudness (LOUD)to the "ON" position.
YOUR 406 IN DETAIL 85

YOUR 406 IN DETAIL
86
406 Estate AUDIO SYSTEM (RM2) Presentation
Your 406 estate is fitted with a JBL Audio Hi-Fi system, designed specifically for the passenger compartment.. At the heart of the system, a 180 watt multifunction amplifier (1) (located in the boot) independently controls 10 high acoustic definition speakers. These speakers provide optimal reproduction and distribution of the sound in the vehicle, both in the front and the
rear. The speakers are situated:– in the fascia: two Micro Tweeters (3) set into two Mediums (4) for reproduction of the sound in the front.
– in the front doors: two Woofers (2) for reproduction of bass frequencies in the front.
– on the boot pillar: two Micro Tweeters (5) for reproduction of treble (high frequencies), set into two Mediums (6)giving
uniform sound reproduction throughout the whole of the vehicle.
Adjusting in CD modeThe basic functions remain those of the audio set.
There is no need for any further adjustment. However, in order to take
full advantage of your JBL audio system, you are advised to set theAUDIO functions (BASS, TREB, FAD, BAL) to position "0"(zero) and
the Loudness (LOUD)to the "ON"position.
