YOUR 406 COUPE IN DETAIL
92
02-02-2004

02-02-2004
6 - Head restraint height andangle adjustment Adjustment is correct when the top of the head restraint is levelwith the top of the head.
To raise the head restraint, pull it upwards.
To lower the head restraint, it isnecessary to push simultaneously:
Ð the button located on the left
guide on top of the seat back,
Ð the head restraint downwards. The head restraint has a frame with notches which prevent itfrom dropping down (safetydevice in case of impact).
To remove the head restraint, press the tab. 7 - Lumbar adjustment
To obtain better back support,turn the knob.
Passenger seat
To gain access to the rear seats, there are two ways to tilt the seatback:
Ð pull the handle at the top right of the seat, or
Ð lift the handle at the bottom left of the seat.
93
YOUR 406 COUPE IN DETAIL
SEATS Manual adjustment of the front seats
1 - Forwards-backwards adjust- ment Lift the lever and slide the seat forwards or backwards.
2 - Adjusting the seat cushion angle Lift the lever to set the best angle.
3 - Adjusting the driver's seat height Pull the telescopic handle for- wards and pivot it up or down.
4 - Adjusting the seat back angle Turn the knob to obtain the bestangle.
5 - Tilting the seat back To gain access to the rear seats,pull the handle, tilt the seat backas much as possible, and movethe seat forwards. On reposition-ing, the seat will resume its origi-nal settings.
Note: never reposition the seat
using the forwards-backwards adjustment control.
Never drive with the head restraints removed; theymust be in place and cor-rectly adjusted.

Electrical adjustment of the front seats
A - Forwards-backwards adjustmentPush the switch forwards or backwards to slide the seat.
B - Adjusting the seat cushion angle Tilt the front part of the switch up or down.
C - Adjusting the driver's seat height Push the switch up or down.
D - Seat back angle adjustment Tilt the switch forwards or backwards
E - Tilting the seat back Pull the lever and tilt the seat back forwards. As long as you hold the seat back in the tilted position, the seat moves forward automatically (when the dooris closed, the ignition must be switched on in order tomove the seat forwards). On repositioning, the seat resumes its original settings.
YOUR 406 COUPE IN DETAIL
94
02-02-2004

02-02-2004
Recalling a memorised position
¥ Door open and ignition off Within ten minutes of switching off
the ignition and opening the door, ashort press on button 1or 2recalls
the memorised position of the seat,then of the exterior mirrors.
¥ Door closed or ignition on:
Ð keeping the button pressedadjusts the seat and the exteriormirrors.
When adjustment is completed ableep will sound.
YOUR 406 COUPE IN DETAIL 95
Memorising the seat and mirror positions
Two driving positions can be memo- rised.
To memorise:
Ð place the ignition key in the acces- sories position;
Ð adjust your seat and mirrors;
Ð simultaneously press button " M"
and button " 1" for the first driving
position or button " 2" for the
second driving position. When the position has been memorised, you will hear twobleeps. Memorising a new position cancels the previous one. Heated seat controls Press the switch.The temperature is controlled auto-
matically. Pressing a second time stops opera- tion.

02-02-2004
REAR SEATS Rear seat with fold-down backs Before carrying out any operation, in order to prevent damage to the seat belts, hook them in the locations under the front seatbelts. The rear seat back folds down in two sections.To fold down the seat back The release controls are situated in the boot. Pull the control corresponding to the part of the seat back that you wish tofold down. When returning the seat back to its original position, ensure that it islocked correctly to guarantee your
safety.
YOUR 406 COUPE IN DETAIL
96
Ski flap Lower the arm rest to access the ski flap.

YOUR 406 COUPE IN DETAIL97
Special points relating to the transportation of children on thefront passenger seat* Children under the age of 10 must not travel in the forwards facingposition, unless the rear seats arealready occupied by other childrenor the rear seats cannot be used(absent or folded). In this case,adjust the front passenger seat tothe intermediate longitudinal posi-tion and leave the passenger air bagarmed. The transportation of children in the rearwards facing position is permit-ted. In this position, it is essential todisarm the passenger air bag. Otherwise, the child would risk beingkilled or seriously injured if the airbag were to inflate.
GENERAL POINTS RELATING TO CHILD SEATS Although one of PEUGEOT's main criteria when designing your vehicle, the safe- ty of your children also depends on you.
For maximum safety, please follow these precautions:
Ð Since 1992, all children under the age of 10 must travel in approved child
seats* suited to their weight , on seats fitted with a seat belt or ISOFIX
mountings.
Ð A child weighing less than 9 kg must travel in the rearwards facing posi-
tion both in the front and in the rear. PEUGEOT recommends that chil-dren should travel in the "rearwards facing" position up to the age of two.
Ð Statistically, the safest seats in your vehicle for the transportation of chil-dren are the rear seats. PEUGEOT recommends that children travel in therear even when a "rearwards facing" child seat is used.
Ð If a child is travelling on a booster seat, check that the lap section of the seat belt passes over the child's thighs correctly. The chest section of the seat beltmust be positioned on the child's shoulder without touching the neck. PEU-
GEOT recommends that you use a booster seat with a back, fitted with a seatbelt guide at shoulder level.
Ð Remember to fasten the seat belt or the child seat harness keeping the slack
in relation to the child's body to a minimum , even for short journeys.
* According to current legislation in the country.
02-02-2004

02-02-2004
YOUR 406 COUPE IN DETAIL
98
CHILD SEATS RECOMMENDED BY PEUGEOT
In addition to the ISOFIX child seats, PEUGEOT offers a complete range of child seats which are secured using the seat
belt :
Group 0+: from birth to 13 kg
L1 - "Britax Babysure": installed in the rear-facing position using a three-point seat belt.
L2 - "Ršmer Baby-Safe": installed in the rear-facing position using a three-point seat belt. The deep and strengthened shell is designed to guarantee the child optimum protection in the event of a side collision.When one of these seats is installed in the front, it is compulsory to disarm the passenger air bag and the vehicle's seat must be adjusted to the intermediate longitudinal position.
Group 1: from 9 to 18 kg
L3 - "Ršmer Prince": installed using a two or three-point seat belt. For the safety of your child, it is imperative that the restraining cushion is used.
Group 2: from 15 to 25 kg
L4 - "Ršmer Vario'': installed using a two or three-point seat belt.

Never leave one or more children alone and unsu-pervised in a vehicle. Never leave a child or an
animal in a vehicle which is exposed to the sun and has thewindows closed.
To protect your young children from the sun, fit blinds on the rearwindows. Never leave the keys within reach of children inside the vehicle. Observe strictly the recommenda- tions for assembling and securingthe child seat as shown in thechild seat instructions.
To prevent the doors from opening
accidentally, use the child lock*. Also, do not open the rear win- dows more than a third*.
* According to model.
YOUR 406 COUPE IN DETAIL 99
Groups 2 and 3: from 15 to 36 kg
L5 - "Recaro Start'': installed using a three-point seat belt.
The height and width at the shoulders and length of the seat cushion must be adjusted according to the age and build of your child.
L6- "Klippan Optima": installed in the rear using a three-point seat belt. From the age of 6 years (approximately 22 kg), the booster is used on its own
Groups 1, 2 and 3: from 9 to 36 kg
L7 - "Kiddy Life": installed in the rear using a three-point seat belt. The height and width at the shoulders and the length of the seat cushion must be adjusted according to the age and build of your child.
For the safety of young children (from 9 to 18 kg), PEUGEOT recommends use of the restraining cushion.
Recommendations For optimum installation of a forwards facing child seat, check that the back of the child seat is resting against the back of the vehicle's seat correctly and thatthe head restraint does not cause any discomfort. If it is necessary to remove the head restraint, as in the case of the "RECARO
Start", "KLIPPAN Optima" and "KIDDY Life" child seats (over 6 years of age),ensure that the head restraint is securely stored or attached so that it cannot actas a projectile in the event of sharp braking. Disarm the passenger air bag when installing a "rearwards facing" child seat on the front passenger seat. Otherwise, the child would risk beingseriously injured or killed were the air bag to inflate.
02-02-2004

02-02-2004
YOUR 406 COUPE IN DETAIL
100
THE INSTALLATION OF CHILD SEATS SECURED USING THE SEAT BELT In accordance with European regulations (Directive 2000/3), the table below indicates the options for the installation of child seats secured using the seat belt and universally approved (child seats which can be installed in all vehicles using the seatbelt), in relation to the weight of the child and the seat in the vehicle:
U : U: seat suitable for the installation of a child seat secured using the seat belt and universally approved. "Rearwards
facing" and "forwards facing" child seats.
L : only the child seats indicated may be installed on the seat concerned (according to destination).
Make Model Approval No¡
L1 : BRITAX Babysure E11 0344117
L3 : ROMER Prince E1 03301058
L4 : ROMER Vario E1 03301120
L5 : RECARO Start E1 03301108
L6 : KLIPPAN Optima E17 030007 (a) Group 0: from birth to 10 kg.
(b) The rules for transporting children on the front passenger seat are specific to each country. Consult the current legislation in your country.
Weight of the child / indicative age
Seat < 13 kg 9 to 18 kg 15 to 25 kg 22 to 36 kg
Group 0(a) and 0+ Group 1 Group 2 Group 3 Up to 1 year From 1 to 3 years From 3 to 6 years From 6 to 10 years approx. approx. approx
Front passenger seat (b)
with and without height adjustment L1 L3 L4, L5, L6 L5, L6
Rear side UU UU
seat

02-02-2004
SEAT BELTS
To adjust the height of the front seat belts Pinch control 1and slide it.
To lock the seat beltsPull the strap, then insert the buckle into the stalk. Pre-tensioning and force-limitingfront seat belts Safety in the event of a frontal impact has been improved by the introduc-tion of pre-tensioning and force-limit-ing front seat belts. Depending onthe seriousness of the impact, thepre-tensioning system instantly tight-ens the seat belt firmly against thebody of the occupant. The pre-tensioning seat belts are active when the ignition is on. The force-limiting device reduces the pressure of the seat belt against theoccupant's body in the event of anaccident. Rear seat belts The rear seats are fitted with two three-point inertia reel belts.
YOUR 406 COUPE IN DETAIL
101
To be effective, a seat belt must be tightened asclose to the body as pos-sible.
Depending on the nature and theseriousness of the impact, thepre-tensioners may be triggeredbefore and independently of theair bags. In all cases, the air bag warning light comes on. Following a collision, have the system checked by a PEUGEOT
dealer.
