Peugeot 607 Dag 2002.5 Owner's Manual

15-07-2002
YOUR 607 IN DETAIL
116
ELECTRIC WINDOWS
1 - Driver's electric window switch.
2 - Passenger's electric window switch.
3 - Rear right electric window switch.
4 - Rear left electric window switch.
5 - Neutralisation of the rear lighter and the rear electric windows (child
safety)
You have two options :Manual operation : press or pull switch 1gently. The window stops as soon as the switch is
released.
Automatic operation : press or pull switch 1fully.
One touch opens or closes the window completely.
Safety auto-reverse When the window rises and meets an obstacle, it stops and lowers again. Note : In the case of ice or after reconnecting the battery, if the window will
not rise, pull the switch until the window closes completely.

15-07-2002
YOUR 607 IN DETAIL117
EXTERIOR MIRRORS Adjustment from the inside
Turn knob Bto the right or to the
left to select the corresponding
mirror.
 Move knob Bin all four directions
to adjust.
Folding back the mirrors electri-cally  With the ignition on, turn knob Bto
position A.
or,
 Lock the vehicle using the remote control. Note: this function can be neu-
tralised. Contact your PEUGEOT
dealer.
When the vehicle is parked, theexterior mirrors can be folded
back manually. Automatically adjustable mirrors for parking These allow you to see the ground (kerb, wall...) when carrying out park-
ing manoeuvres in reverse gear.
Tilting the mirror to the parking posi- tion:
 switch on the direction indicatoron the parking side,
 engage reverse gear. The exterior mirror corresponding to the side on which you are park-ing tilts downwards.
Returning the mirror to the previousposition:  change out of reverse gear.
Note: to be active, this function must
be initialised by adjusting the mirror,with reverse gear engaged and thedirection indicator on the side of themirror to be adjusted switched on. Each remote control can memorise a specific setting.
The driver's mirror is con- vex in order to eliminatethe 'blind spot' (area atedge defined by a dottedline).
As a result, objects observed inthe driver's and passenger's mir-rors are in reality closer than they
appear. This must be taken into account to judge correctly the distance ofvehicles approaching frombehind.

15-07-2002
YOUR 607 IN DETAIL
118
Automatic day/night interior mirror This automatically and gradually changes between the day and night positions.
To prevent dazzling, the glass of the mirror darkens automatically depending onthe intensity of the light from behind. It clears as the light (headlamps of follow-
ing vehicles, sunlight) decreases, ensuring maximum visibility. Operation Switch on the ignition and press switch
1:
Ð Indicator light 2lit (switch pressed): automatic operation.
Ð Indicator light 2off: automatic system off. The mirror remains at its most clear.
Special feature
To ensure maximum visibility during manoeuvres, the mirror clears automatical- ly when reverse gear is engaged. Manual interior mirror The interior mirror has two positions:
Ð day (normal),
Ð night (anti-dazzle).
To change from one to the other, push or pull the lever on the lower
edge of the mirror.
Areas for toll cards / car park tickets The athermic windscreen has two non-reflective zones located eitherside of the base of the interior
mirror.
They are intended for affixing toll cards and/or car park tickets.

15-07-2002
YOUR 607 IN DETAIL119
HORN Press one of the spokes or the cen- tre of the steering wheel.
Manual adjustment of the headlamps Depending on the load in your vehi- cle, adjusting the beam of your head-lamps is recommended. 0 1 or 2 people in the front seats.
Ð 3 people.
1 5 people.
2 5 people + maximum authorisedloads.
3 Driver + maximum authorisedloads.
Initial setting is position 0.
Automatic adjustment of headlamps Refer to the paragraph on Lighting
under the section entitled 'Towing a
trailer...'. HAZARD WARNING LIGHTS Press the button, the direction indi- cators flash. They can operate with the ignition
off.
Steering wheel height and depth adjustment
When the vehicle is stationary, unlock the steering wheel bypulling handle Adownwards.
 Adjust the height and depth of thesteering wheel then lock by push-ing handle Afully upwards.
Automatic lighting of hazard warning lights* When braking in an emergency , depending on the force of decelera-tion, the hazard warning lights come
on automatically. They switch offautomatically the first time you accel-erate.
It is also possible to switch them off by pressing the button on the fascia.
* According to destination.

15-07-2002
YOUR 607 IN DETAIL
120
SUN VISOR WITH
ILLUMINATED COURTESYMIRROR With the ignition on, the mirror is automatically illuminated when theflap is opened.
COURTESY LIGHTS
1 - Front courtesy light
2 - Front map reading lights
With the key in the accesories position (1st notch) or with the ignition on, operate the relevant switch.
3 - Rear courtesy light
4 - Rear map reading lights With the key in the accesories position (1st notch) or with the ignition on, operate the relevant switch.
The front and rear courtesy lights come on when the ignition key is removed, onunlocking the vehicle or on opening one of the doors.
They gradually go off after the ignition has been switched on or the vehicle is locked.  Pressing switch 1turns on the front and rear courtesy lights.
Note: The courtesy lights and sill lights can be neutralised by pressing switch 1
for more than three seconds. The map reading lights are not affected by this and may be switched on.  To re-activate the lights, press the switch. Sill illuminationThe sill light is at the bottom of each door trim. The light comes on automatically when the door is opened and goes
off automatically when the door isclosed.

15-07-2002
YOUR 607 IN DETAIL121
4 Control buttons
A- Switching 'SPORT' suspension on / off
B - Central locking / Unlocking
C - Opening / Closing / Partial opening of sunroof
D - Unrolling / storing of rear screen electric blind
5 Front armrest
6 Rear ashtray Press the cover to open the ashtray.
To empty the ashtray, open it then release it by pulling it towards you.
To refit the ashtray, clip it back into its housing.
7 Rear lighter Push in and wait for a few moments until it springs out auto-
matically.
8 Heated rear seats control
CENTRE CONSOLE 1 Storage compartment
2 Front lighter Press and wait for a few moments until it springs out
automatically.
Ventilated glove box
To open the glove box, lift the han- dle. The glove box is lit up when the cover is opened. The glove box has a vent Ethat
can be closed, which produces the same conditioned air as the ventsin the passenger compartment. It also has a pen holder F
and
three sockets Gfor connecting
video equipment.
3 Front ashtray
Press the cover to open the ashtray.
To release the ashtray for emptying, open it then push the cover
downwards. To refit the ashtray, clip it back into its housing.

15-07-2002
Luggage net Six stowing rings allow the net to be placed in different positions.
YOUR 607 IN DETAIL
122
Rear sunblind The blind, fitted to the rear parcel shelf, is intended to protect occu-pants from the glare of the sun andthe lights of cars behind
.
Sunblind operation: With the engine running:  Briefly press button Don the cen-
tre console to open it out.
 Briefly press button Dagain to
store it away.
Warning: Do not place anything on
the blind, to avoid it being damaged. Rear armrest This provides access to the ski flap from the passenger compartment. It has two cup holders.
Storage compartmentsThere are two storage compartments located behind the side trim of theboot. The left side storage compartment is fitted with a CD storage bracket foreight single CDs and one double CD.
To access a storage compartment:
Push the handle downwards and fold down the panel.
Rear shelf compartment This is provided for the storage of a first aid kit. The catch on the lid is designed to withstand a weight of 9 lbs (4kg) onimpact.

YOUR 607 IN DETAIL123
PORSCHE TIPTRONIC system' AUTOMATIC GEARBOX The four speed automatic gearbox offers a choice between the comfort of inte-
gral automatic operation , enhanced by a sportand a snow programme, or the
pleasure of manual gear changing .
Gear selection gate  Move the lever in the gate to select a function. Once the function is selected, the corresponding indicator light appears on the instrument panel screen.
S: sport programme.
: snow programme.
P ark: to immobilise the vehicle and to start the
engine , with the handbrake on or off.
R everse: to reverse(select this function with the vehi-
cle stationary, engine at idle). N eutral: to start the engine and to park, with the hand-
brake on. Note: if position Nis inadvertently engaged while dri-
ving, allow the engine to return to idle before engaging function Dto accelerate.
D rive: for driving in automatic mode.
M anual: for drivingin manual mode.
Moving Off
With the engine running, to move off from position P:
 it is essential to press the brake
pedal to exit position P,
 select function R, D or M, then
gradually release the pressure onthe brake pedal; the vehicle
moves off immediately.
You can also move off from position N:
 release the handbrake, with yourfoot on the brake,
 select function R, D or M, then
gradually release the pressure onthe brake pedal; the vehicle
moves off immediately.
WARNING When the engine is at idle, brakes not applied, if function R, D or Mis select-
ed, the vehicle moves even withoutthe accelerator being pressed. For this reason, do not leave
children unsupervised inside the vehicle, with the engine running. When maintenance operations need to be carried out with the engine run-ning, apply the handbrake and selectposition P.
15-07-2002

15-07-2002
Notes It is only possible to change from one gear to another if the vehicle speed and enginespeed permit. If they do not, the vehicle willoperate temporarily in automatic mode. When the vehicle is stationary or moving
very slowly, the gearbox automaticallyselects gear M1.
Programmes S(sport) and (snow) do not
operate in manual mode.
Operating abnormality Any operating abnormality isshown by illumination of this warn-ing light, accompanied by an audi-ble signal and the message 'Auto-
matic gearbox faulty' on the
multi-function display. In this situation the gearbox operates in
downgrade mode (locked in 3rd gear). Youmay feel a substantial knock when selectingreverse from Pto Rand from Nto R(this will
not cause any damage to the gearbox). Do not exceed 60 mph (100 km/h).
Contact a PEUGEOT dealer as soon as possible.Automatic operation Automatic changing of the four gears:
select function Din the gate.
The gearbox always selects the most suitable gear according to the follow-ing parameters:
Ð the style of driving,
Ð the road profile,
Ð the vehicle load.The gearbox is then operating in auto- adaptive mode, without any action onyour part.
WARNING Never select function N when the vehi-
cle is moving.Never select functions Por Runless
the vehicle is stationary.Never change betwen functions to optimise braking on a slippery surface. Notes For immediate maximum acceleration
without touching the gear lever, pressthe accelerator pedal down as far as it
will go (kickdown). The gearbox willautomatically change down or main-tain the gear selected until maximumengine speed is reached. When the brake is applied, the gear- box will automatically change down in
order to provide efficient engine brak-ing.
If you take your foot off the accelerator
suddenly, the gearbox will not change
to a higher gear for reasons of safety. Sport and snow programmes In addition to the auto-adaptive pro- gramme, there are two special pro-grammes.The programme is displayed on theinstrument panel screen. Sport programme
Press button
Sonce the vehicle has
been started and function Dselected.
The gearbox automatically favours sporty driving and more dynamicacceleration. Snow programme This programme improves starting and
drive when traction is poor.
Press button once the vehicle has
been started and function Dselected.
The gearbox adapts to driving on slip-pery roads. Note: you can return to the auto-adap-
tive programme at any time.
Press button Sor again to switch
off the programme you are in.
Manual operationManual changing of the four gears:
select function Min the gate,
push the lever to the +sign to
change to a higher gear,
pull the lever to the -sign to change
to a lower gear.
You can change from position D(dri-
ving in automatic mode) to position M
(driving in manual mode) at any time.
YOUR 607 IN DETAIL
124
If the battery is flat and the lever is in position
P, it will
be impossible to changeto another position.

15-07-2002
YOUR 607 IN DETAIL125
EMERGENCY BRAKING
ASSISTANCE SYSTEM
In an emergency, this system enables the optimum braking pres-
sure to be reached more quickly,thus reducing the stopping distance. It is triggered according to the speed
of activation of the brake pedal. The
effect of this is a reduction in theresistance of the pedal and an
increase in braking efficiency.
ABS ANTI-LOCK BRAKING SYSTEM
The ABS with Electronic Brake Force Distribution (EBFD) increases the sta-bility and manoeuvrability of yourvehicle, particularly on poor or slip-pery road surfaces. Note:
when changing wheels (tyres
and rims), make sure that these are approved. The anti-lock braking system comes into operation automatically whenthere is a risk of wheel lock.
Illumination of this warninglight, accompanied by anaudible signal and the mes-sage "Braking fault" on the
multi-function display, indi-
cates a malfunction of the electronicbrake force distribution, which cancause a loss of control of the vehiclewhen braking.
Stop immediately.
Contact a PEUGEOT dealer.
Normal operation of the ABS may make itself felt by slight vibrationsof the brake pedal. In emergency braking, press very firmly without releasingthe pressure.
MANUAL GEARBOX Reverse
To change to reverse gear, lift the ring under the gear lever knob andpush the gear lever to the left then tothe front. Reverse gear can only be engaged when the vehicle is stationary withthe engine idling.
