YOUR 807 IN DETAIL121
Automatic day/night interior mirror
This automatically and gradually changes between the day and
night positions.
To prevent dazzling, the glass of the mirror darkens automatically depending on
the intensity of the light from behind. It clears as the li ght (headlamps of follow
ing vehicles, sunlight) decreases, ensuring maximum visibility.
Operation
Switch on the ignition and press switch 1:
– Indicator light 2lit (switch pressed): automatic operation.
– Indicator light 2off: automatic system off. The mirror remains at its most clear.
Special feature
T o ensure maximum visibility during manoeuvres, the mirror clears automatical
ly when reverse gear is engaged. Sun visor with illuminated
courtesy mirror
With the ignition on, the mirror is
automatically lit up when the flap is
opened.
Rear screen sun blind
Pull the blind by the central tab, and
then position its attachments on the
corresponding hooks.
Side blinds
Side blinds are available in the rear
2
nd
and/or 3 rd
rows.
Pull the side blind by the centre tab.
Position the blind's attachment(s) on
the corresponding hook(s).
18-11-2002

Horn
Press one of the spokes or
the centre of the steering
wheel.
YOUR 807 IN DETAIL
122
Manual adjustment of the
headlamps
Depending on the load in your vehi
cle, adjusting the beam of your head
lamps is recommended.
0 1 or 2 people in the front seats.
1 5 people.
2 6 to 8 people.
3 Driver + maximum authorised
loads.
Initial setting is position 0.
Automatic adjustment of
headlamps
Refer to the paragraph on Lighting
under the section entitled 'Towing a
trailer...'. Hazard warning lights
Press the button, the direction indi
cators flash.
They can operate with the ignition
off.
Steering wheel height and
depth adjustment
When the vehicle is stationary,
unlock the steering wheel by lower
ing the lever
A.
Adjust the height and depth of the
steering wheel, then lock by pushing
lever Afully upwards.
Automatic lighting of hazard
warning lights*
When braking in an emergency,
depending on the force of decelera
tion, the hazard warning lights come
on automatically. They switch off
automatically the first time you accel
erate.
It is also possible to switch them off
by pressing the button on the fascia.
*According to destination.
18-11-2002

YOUR 807 IN DETAIL123
COURTESY LIGHTS
Off.
Comes on on opening one of the doors.
Permanently on, with the key in the accessories position or the i gnition on.
1 Front courtesy light
2 2nd row rear courtesy light
3 3rd row rear courtesy light
4 Front map reading lights
5 2nd row rear map reading lights
6 3rd row rear map reading lights The front and rear courtesy lights
come on when the ignition key is
removed, on unlocking the vehicle or
on opening one of the doors.
They gradually go off after the igni
tion has been switched on
, after the
vehicle is locked or after the last door
is closed.  With the ignition off, pressing
switch 1turns on the front
and rear courtesy lights for ten
minutes.
 With the ignition off, pressing
switch 2 or 3 turns on the corre
sponding rear courtesy light for
ten minutes.
The front and rear map reading lights
are switched on by operating the cor
responding switch. These are active
when the key is in the accessories
position (1st notch) or the ignition is
on.
18-11-2002

YOUR 807 IN DETAIL
124
18-11-2002

YOUR 807 IN DETAIL125
INTERIOR LAYOUT
1. Spectacles holder
2. Glove box To open the glove box, press the
button.
To close it, press the lid.
It has dedicated compartments
for storing a pen, a mobile tele
phone, a pair of spectacles,
coins or tokens and credit cards.
3. Audio equipment concealing flap
Lower the flap fully to lock it.
Press the flap to raise it.
4. Central storage compartment
5. Passenger upper glove box To open the glove box, press the
button.
To close it, press the lid.
It has dedicated compartments
for storing a pair of spectacles,
keys, five audio CDs and four
audio cassettes or nine audio
CDs. 6. Passenger lower glove box
This is fitted with a lock.
To open the glove box, lift the
handle.
The glove box lights when the lid
is opened.
It contains three sockets for
connecting video equipment.
It has dedicated compartments
for storing maps, a packet of
cigarettes, an A4 format docu
ment, etc.
7. Lighter or 12 volt accessories socket
8. Cooled compartment This can hold up to three cans.
Turn the closer, at the top, to
open or close the air feed.
9. Can holder and ashtray This retractable support, with
light, contains up to two can
holders, a removable ashtray
and a location for the lighter
when it is used as a 12V socket. 10. Storage compartment or
remote control keypad
The storage compartment must
not be used as an ashtray.
11. Storage
12. Door tray with storage compartment for a bottle
of water
13. Instrument panel fuse box
18-11-2002

YOUR 807 IN DETAIL
126
18-11-2002

YOUR 807 IN DETAIL127
REAR INTERIOR LAYOUT
1. Access handle
2. Grab handle and coat hook
3. Door tray with storage for a
can and a bottle of water or for
the portable bin with ashtray
4. High load retaining net fasten ings
Open the covers of the upper
fastenings at the 3rd row.
Install the ends of the metal bar
in these fastenings.
Secure the two tray strap hooks
in the stowing rings on the floor.
Pull the two straps taut.
Secure the two hooks on the
elastic parts of the tray in these
rings.
Note: the rings are located
directly below the corresponding
upper fastenings. 5. Storage compartment
6. Can holder
7. Storage compartment
8. Bottle holder or portable bin
with ashtray
9. Luggage retaining net "low load" version fastenings
Fold the net in two.
Secure the two centre hooks in
the stowing rings on the floor.
Secure the net's remaining four
hooks on the tailgate pillars.
10. 12V socket for accessories
11. Luggage retaining net Secure the net's four hooks in
their stowing rings on the floor.
12. Tonneau To install it :
– position one end of the tonneau roller in the 2nd row, – compress the opposite end of
the roller and position it,
– release it to allow it to engage,
– unroll the tonneau as far as the rear shelf,
– secure the two hooks under the rear shelf,
To remove it:
– remove the tonneau hooks under the rear shelf,
– return the tonneau into its roller,
– compress it and remove it from its support at the 2nd row.
13. Rear shelf with umbrella holder
To remove the shelf:
– pull it rearward
– lift it slightly, then remove it
There are several options for
storing it:
– either hooked onto the ton neau
– or behind the seats or the rear bench seat
18-11-2002

When this warning light
comes on, connected to the
STOPwarning light,
accompanied by a buzzer
and the message "Braking
fault" , it indicates that there is a mal
function of the electronic brake force
distribution, which can cause a loss of
control of the vehicle when braking.
Stop immediately.
In both cases, consult a Peugeot
dealer.
ANTILOCK BRAKING
SYSTEM (ABS) AND THE
ELECTRONIC BRAKE FORCE
DISTRIBUTION (EBFD)
The ABS, in conjunction with the elec
tronic brake force distribution, increas
es the stability and manoevrability of
your vehicle, particularly on poor or
slippery road surfaces.
Note: when changing wheels (tyres
and rims), make sure that these are
approved.
The antilock braking system comes
into operation automatically when
there is a risk of wheel lock.
When this warning light
comes on, accompanied by
a buzzer and the message
"ABS fault" , it indicates
that there is a malfunction
of the ABS, which can cause a loss
of control of the vehicle when brak
ing.
YOUR 807 IN DETAIL
128
To return to normal operation, pull
the lever upwards until a click is
heard.Illumination of this light,
accompanied by an audible
signal and the message
"handbrake on" on the
multi–function display, indi
cates that the handbrake is still on or
has not been properly released.
HANDBRAKE
Applying
When parking, pull the handbrake to
immobilize your vehicle.
Warning : when parking on a slope,
direct your wheels towards the pave
ment and pull the handbrake.
Releasing
Pull on the handle and press the but
ton to release the handbrake.
Disengaging
Apply the handbrake.
Pull the button located at the end of
the handbrake forwards.
The handbrake lever lowers.
You can now pivot the seat. EMERGENCY BRAKING
ASSISTANCE SYSTEM
In an emergency, this system
enables the optimum braking pres
sure to be reached more quickly,
thus reducing the stopping distance.
It is triggered according to the speed
of activation of the brake pedal. The
effect of this is a reduction in the
resistance of the pedal and an
increase in braking efficiency. Normal operation of the ABS may
make itself felt by slight vibrations
of the brake system.
In emergency braking, press
very firmly without releasing
the pressure.
18-11-2002

The ESP system offers
increased safety during
normal driving, but should
not incite the driver to
take risks or to drive at
high speed.
The operation of the system is
ensured to the extent to which the
recommendations of the manufac
turer regarding the wheels (tyres
and wheel rims), the braking
components, the electronic com
ponents and the assembly and
repair procedures within the
PEUGEOT network are observed.
After an impact, have the system
checked by a PEUGEOT dealer.
Operation of the ASR and ESP
systems
When one of these two sys
tems is operating, this light
flashes.
YOUR 807 IN DETAIL 129
Disarming the ESP / ASR
systems
In certain conditions (vehicle stuck in
mud or snow, or on loose ground...),
it could prove useful to disarm the
ASR and ESP systems to make the
wheels spin and regain grip.
Press switch "1", situated under
the steering wheel on the right of
the fascia.
The indicator light comes
on, accompanied by the
message "ESP/ASR dis
armed" : the ESP and ASR
systems no longer act on
the engine operation but remain
active on the brakes.
They engage again:  automatically above 20 mph
(30 km/h),
 manually by pressing switch
1 again. Operating check
When a malfunction of the
systems occurs, the indicator
light comes on accompanied
by an audible signal and the
message "ESP/ASR not
operational" on the multifunction dis
play.
Contact a PEUGEOT dealer to have
the system checked.TRACTION CONTROL (ASR)
AND DYNAMIC STABILITY
CONTROL (ESP)
These systems are linked and com
plement the ABS.
The ASR system optimises drive to
prevent the wheels skidding, by acting
on the brakes of the drive wheels and
on the engine. It also allows the direc
tional stability of the vehicle to be
improved on acceleration.
If there is a variation between the tra
jectory followed by the vehicle and
that required by the driver, the ESP
system automatically acts on the
engine and the brake of one or more
wheels, in order to put the vehicle
back on course.
18-11-2002

Changing a memorised speed
To memorise a speed higher than
the previous one: press button 3;
 release it when you have
reached the required speed.
To memorise a speed lower than the
previous one:  press button 2;
 release it when you have
reached the required speed.
Cancelling the cruise control  place knob 1in the OFFposition
or switch off the ignition.
YOUR 807 IN DETAIL
130
CRUISE CONTROL
Cruise control enables the vehicle to
maintain a steady speed pro
grammed by the driver, regardless of
the road characteristics and without
the driver having to touch the accel
erator or brake pedals.
In order for it to be memorised, the
vehicle speed must be greater than
approximately 25 mph (40 km/h) and
fourth or fifth gear must be engaged.
Operation Place knob 1 in the ON
position.
A speed can be memorised.
Illumination of this indicator light indi
cates that the cruise control is on.  Place knob 1 in the OFF position
to cancel. Memorising a speed
As soon as you reach the chosen
speed, press button
2or 3. This
memorises the speed, which will be
maintained automatically.
Note: It ispossible to accelerate
momentarily without disarming the
cruise control.
Cancelling the memorised speed
If you wish to cancel the memorised
speed:  Press button 4or the brake or
clutch pedal.
The warning light goes out to indi
cate that the cruise control is dis
armed.
Recalling the memorised speed
After cancellation, press button 2 or
3 . Your vehicle will return to the last
memorised speed.
Illumination of the indicator light
indicates that the cruise control is
operating again.
Do not use cruise control
on slippery roads or in
heavy traffic.
18-11-2002
