READY TO SET OFF
22
Starting and stopping
HILL START ASSISTANCE
This function, linked with the ESP,
makes hill starts easier and is activated
in the following conditions:
- the vehicle must be stationary, engine running, foot on the brake,
- the gradient of the road must be steeper than 5 %,
- u p h i l l , t h e g e a r b o x m u s t b e i n neutral or in a gear other than
reverse,
- downhill, reverse gear must be engaged.
The HHC (Hill Holder Control) or Hill
Start Assistance function is a driving
comfort feature. It is not an automatic
vehicle parking function or an
automatic handbrake. Operation
With the brake pedal and clutch pedal
pressed, from the time you release the
b r a k e p e d a l y o u h a v e a p p r o x i m a t e l y
2 seconds before the vehicle starts
to roll back and without using the
handbrake within which to move off.
During the moving off phase, the
function is deactivated automatically,
gradually releasing the braking
pressure. During this phase, the typical
noise of mechanical disengaging of
the brakes can be heard, indicating the
imminent movement of the vehicle.
Anomaly
The hill start assistance is deactivated
in the following situations:
- when the clutch pedal is released,
- when the handbrake is applied,
- when the engine is switched off,
- when the engine stalls.
If a malfunction of the
system occurs, this warning
light comes on accompanied
by an audible signal and
c o n fi r m e d b y a m e s s a g e
on the display. Contact a PEUGEOT
dealer to have the system checked.
Page 42 of 214
42
Steering wheel controls
Direction indicators
"Motorway" function
P r e s s t h e c o n t r o l u p o r d o w n t o fl a s h
t h e c o r r e s p o n d i n g d i r e c t i o n i n d i c a t o r
three times. LIGHTING CONTROL
Left
: d o w n w a r d s p a s s i n g t h e
p o i n t o f r e s i s t a n c e .
Right
: u p w a r d s p a s s i n g t h e
p o i n t o f r e s i s t a n c e . Front and rear lighting
Selection is by turning ring
A . Lighting off
A u t o m a t i c l i g h t i n g
S i d e l a m p s
D i p p e d b e a m ( g r e e n )
M a i n b e a m ( b l u e )
Dipped beam/main beam change
P u l l t h e s t a l k f u l l y t o w a r d s y o u .
Lighting-on buzzer O n s w i t c h i n g o f t h e i g n i t i o n , a l l o f t h e
l a m p s t u r n o f f , e x c e p t d i p p e d b e a m i f
a u t o m a t i c g u i d e - m e - h o m e l i g h t i n g h a s
b e e n a c t i v a t e d .
T o a c t i v a t e t h e l i g h t i n g c o n t r o l , t u r n
ring A to the lighting off position "0"
then to the selection of your choice.
O n o p e n i n g t h e d r i v e r ' s d o o r , a
w a r n i n g b u z z e r s o u n d s i f y o u h a v e l e f t
the lighting on.
I f t h e u s e r d o e s n o t o p e r a t e a n y
equipment for 30 minutes, the
E c o n o m y m o d e e n g a g e s t o a v o i d
d i s c h a r g i n g t h e b a t t e r y ( s e e " B a t t e r y "
i n s e c t i o n 7 ) . E l e c t r i c a l f u n c t i o n s a r e
p u t o n s t a n d b y a n d t h e b a t t e r y w a r n i n g
l a m p fl a s h e s .
S i d e l a m p o p e r a t i o n i s n o t a f f e c t e d b y
Economy mode.
C h e c k i n g b y m e a n s o f t h e
i n d i c a t o r l a m p s o n t h e i n s t r u m e n t
p a n e l i s d e s c r i b e d i n t h e
" I n s t r u m e n t s a n d c o n t r o l s " s e c t i o n o f
c h a p t e r 2 .
DIRECTION INDICATORS
Page 43 of 214
42
Steering wheel controls
Direction indicators
"Motorway" function
P r e s s t h e c o n t r o l u p o r d o w n t o fl a s h
t h e c o r r e s p o n d i n g d i r e c t i o n i n d i c a t o r
three times. LIGHTING CONTROL
Left
: d o w n w a r d s p a s s i n g t h e
p o i n t o f r e s i s t a n c e .
Right
: u p w a r d s p a s s i n g t h e
p o i n t o f r e s i s t a n c e . Front and rear lighting
Selection is by turning ring
A . Lighting off
A u t o m a t i c l i g h t i n g
S i d e l a m p s
D i p p e d b e a m ( g r e e n )
M a i n b e a m ( b l u e )
Dipped beam/main beam change
P u l l t h e s t a l k f u l l y t o w a r d s y o u .
Lighting-on buzzer O n s w i t c h i n g o f t h e i g n i t i o n , a l l o f t h e
l a m p s t u r n o f f , e x c e p t d i p p e d b e a m i f
a u t o m a t i c g u i d e - m e - h o m e l i g h t i n g h a s
b e e n a c t i v a t e d .
T o a c t i v a t e t h e l i g h t i n g c o n t r o l , t u r n
ring A to the lighting off position "0"
then to the selection of your choice.
O n o p e n i n g t h e d r i v e r ' s d o o r , a
w a r n i n g b u z z e r s o u n d s i f y o u h a v e l e f t
the lighting on.
I f t h e u s e r d o e s n o t o p e r a t e a n y
equipment for 30 minutes, the
E c o n o m y m o d e e n g a g e s t o a v o i d
d i s c h a r g i n g t h e b a t t e r y ( s e e " B a t t e r y "
i n s e c t i o n 7 ) . E l e c t r i c a l f u n c t i o n s a r e
p u t o n s t a n d b y a n d t h e b a t t e r y w a r n i n g
l a m p fl a s h e s .
S i d e l a m p o p e r a t i o n i s n o t a f f e c t e d b y
Economy mode.
C h e c k i n g b y m e a n s o f t h e
i n d i c a t o r l a m p s o n t h e i n s t r u m e n t
p a n e l i s d e s c r i b e d i n t h e
" I n s t r u m e n t s a n d c o n t r o l s " s e c t i o n o f
c h a p t e r 2 .
DIRECTION INDICATORS
Page 44 of 214
43
Steering wheel controls
ERGONOMICS
and
COMFORT
3
Daytime lights
Depending on the country in which
t h e v e h i c l e i s s o l d , t h e v e h i c l e m a y
b e e q u i p p e d w i t h d a y t i m e l i g h t s . T h e
d i p p e d h e a d l a m p s c o m e o n w h e n t h e
v e h i c l e i s s t a r t e d .
R e a r f o g l a m p s ( a m b e r ,
2 n d r o t a t i o n o f t h e r i n g
f o r w a r d s ) .
F r o n t f o g l a m p s ( g r e e n ,
1 s t r o t a t i o n o f t h e r i n g
f o r w a r d s ) .
Front and rear foglamps
R o t a t e r i n g
B f o r w a r d s t o s w i t c h o n
a n d r e a r w a r d s t o s w i t c h o f f . T h e
s t a t u s i s c o n fi r m e d b y t h e l a m p o n t h e
i n s t r u m e n t p a n e l .
T h e s e o p e r a t e w i t h t h e s i d e l a m p s a n d
t h e d i p p e d b e a m h e a d l a m p s .
Do not forget to switch them off
w h e n t h e y a r e n o l o n g e r n e e d e d .
O p e r a t i o n o f t h e u t o m a t i c l i g h t i n g
s w i t c h e s o f f t h e r e a r f o g l a m p s , b u t t h e
f r o n t f o g l a m p s r e m a i n o n . T h i s w a r n i n g l i g h t c o m e s o n
o n t h e i n s t r u m e n t p a n e l .
T h e i n s t r u m e n t s a n d c o n t r o l s
( i n s t r u m e n t p a n e l , d i s p l a y , a i r
c o n d i t i o n i n g c o n t r o l p a n e l , . . . ) a r e
o n l y l i t o n s w i t c h i n g t o t h e a u t o m a t i c
switching on of the lights mode or
w h e n t h e l i g h t s a r e s w i t c h e d o n
m a n u a l l y .
T o s w i t c h o f f t h e f r o n t a n d r e a r
f o g l a m p s , t u r n t h e r i n g r e a r w a r d s t w i c e
in succession.
I n c l e a r w e a t h e r o r i n r a i n , b o t h d a y
a n d n i g h t , r e a r f o g l a m p s d a z z l e a n d
their use is prohibited. Automatic switching on of the lights
I n f o g g y w e a t h e r o r i n s n o w ,
t h e b r i g h t n e s s s e n s o r c a n
d e t e c t s u f fi c i e n t l i g h t . A s a
consequence, the lights will not come
o n a u t o m a t i c a l l y .
I f n e c e s s a r y , y o u m u s t s w i t c h o n
t h e d i p p e d h e a d l a m p s m a n u a l l y .
D o n o t c o v e r t h e b r i g h t n e s s s e n s o r
l o c a t e d o n t h e w i n d s c r e e n , b e h i n d
t h e m i r r o r . I t i s u s e d f o r t h e a u t o m a t i c
s w i t c h i n g o n o f t h e l i g h t s a n d f o r t h e
a u t o m a t i c w i p e r s .
Activation
Turn the ring to the AUTO position.
T h e a c t i v a t i o n o f t h i s f u n c t i o n i s
a c c o m p a n i e d b y a m e s s a g e o n t h e
d i s p l a y .
Deactivation
T u r n t h e r i n g f o r w a r d s o r r e a r w a r d s .
T h e d e a c t i v a t i o n o f t h i s f u n c t i o n i s
a c c o m p a n i e d b y a m e s s a g e o n t h e
d i s p l a y .
T h e f u n c t i o n i s d e a c t i v a t e d t e m p o r a r i l y
w h e n y o u u s e t h e m a n u a l l i g h t s s t a l k . The side lights
a n d d i p p e d b e a m
h e a d l a m p s s w i t c h
o n a u t o m a t i c a l l y i f
the light is poor, or
d u r i n g o p e r a t i o n o f t h e w i n d s c r e e n
w i p e r s . T h e y s w i t c h o f f a s s o o n a s t h e
light becomes bright enough or the
windscreen wipers stop.
T h i s f u n c t i o n i s n o t c o m p a t i b l e w i t h t h e
d a y t i m e l i g h t s .
Page 45 of 214
44
Steering wheel controls
If the brightness sensor
does not function
correctly, the lights come on
a c c o m p a n i e d b y t h e s e r v i c e
w a r n i n g l i g h t , a n a u d i b l e
s i g n a l a n d a m e s s a g e o n t h e d i s p l a y .
C o n s u l t a P E U G E O T d e a l e r .
Guide-me-home lighting
T h e t e m p o r a r y m a i n t a i n i n g o f t h e
d i p p e d h e a d l a m p s l i g h t i n g , w i t h t h e
i g n i t i o n o f f , m a k e s t h e d r i v e r ' s e x i t
e a s i e r w h e n t h e l i g h t i s p o o r .
HEADLAMP BEAM
D e p e n d i n g o n t h e l o a d i n y o u r v e h i c l e ,
t h e b e a m s e t t i n g m u s t b e a d j u s t e d .
0 - N o l o a d .
1 - P a r t i a l l o a d .
2 - A v e r a g e l o a d .
3 - M a x i m u m a u t h o r i s e d l o a d .
Manual operation
- W i t h t h e i g n i t i o n o f f , " fl a s h " t h e
h e a d l a m p s w i t h i n o n e m i n u t e a f t e r
switching off the ignition.
T h e g u i d e - m e - h o m e l i g h t i n g s w i t c h e s
o f f a u t o m a t i c a l l y a f t e r a s e t t i m e .
Automatic operation
R e f e r t o t h e " D i s p l a y fl o w c h a r t "
s e c t i o n o f c h a p t e r 9 .
Initial setting is position 0.
A c t i v a t e t h e f u n c t i o n v i a t h e
" V e h i c l e c o n fi g " m e n u .
Page 46 of 214
44
Steering wheel controls
If the brightness sensor
does not function
correctly, the lights come on
a c c o m p a n i e d b y t h e s e r v i c e
w a r n i n g l i g h t , a n a u d i b l e
s i g n a l a n d a m e s s a g e o n t h e d i s p l a y .
C o n s u l t a P E U G E O T d e a l e r .
Guide-me-home lighting
T h e t e m p o r a r y m a i n t a i n i n g o f t h e
d i p p e d h e a d l a m p s l i g h t i n g , w i t h t h e
i g n i t i o n o f f , m a k e s t h e d r i v e r ' s e x i t
e a s i e r w h e n t h e l i g h t i s p o o r .
HEADLAMP BEAM
D e p e n d i n g o n t h e l o a d i n y o u r v e h i c l e ,
t h e b e a m s e t t i n g m u s t b e a d j u s t e d .
0 - N o l o a d .
1 - P a r t i a l l o a d .
2 - A v e r a g e l o a d .
3 - M a x i m u m a u t h o r i s e d l o a d .
Manual operation
- W i t h t h e i g n i t i o n o f f , " fl a s h " t h e
h e a d l a m p s w i t h i n o n e m i n u t e a f t e r
switching off the ignition.
T h e g u i d e - m e - h o m e l i g h t i n g s w i t c h e s
o f f a u t o m a t i c a l l y a f t e r a s e t t i m e .
Automatic operation
R e f e r t o t h e " D i s p l a y fl o w c h a r t "
s e c t i o n o f c h a p t e r 9 .
Initial setting is position 0.
A c t i v a t e t h e f u n c t i o n v i a t h e
" V e h i c l e c o n fi g " m e n u .
Page 47 of 214
45
Steering wheel controls
ERGONOMICS
and
COMFORT
3
2 F a s t w i p e ( h e a v y r a i n ) .
1 N o r m a l w i p e ( m o d e r a t e r a i n ) .
l Intermittent wipe.
0 Off.
Single wipe
( p r e s s d o w n w a r d s ) .
In the I ntermittent position, the wiping
s p e e d i s i n p r o p o r t i o n t o t h e v e h i c l e
speed.
W h e n e v e r t h e i g n i t i o n h a s b e e n
s w i t c h e d o f f f o r m o r e t h a n o n e m i n u t e ,
WINDSCREEN WIPER STALK
Manual windscreen wipers w i t h t h e w i n d s c r e e n w i p e r s t a l k i n
p o s i t i o n 2 , 1 o r I , t h e s t a l k m u s t b e
r e a c t i v a t e d :
- m o v e t h e s t a l k t o a n y p o s i t i o n ,
- t h e n m o v e i t b a c k t o t h e r e q u i r e d
position.
D o n o t c o v e r t h e r a i n s e n s o r ,
l o c a t e d i n t h e c e n t r e o f t h e
windscreen, behind the
mirror. Activation
P r e s s t h e c o n t r o l d o w n w a r d s .
A c t i v a t i o n o f t h e f u n c t i o n i s
a c c o m p a n i e d b y a m e s s a g e o n t h e
d i s p l a y .
Deactivation/Switching off
P l a c e t h e w i n d s c r e e n w i p e r s s t a l k i n
position
I , 1 or 2 . D e a c t i v a t i o n o f t h e
f u n c t i o n i s a c c o m p a n i e d b y a m e s s a g e
o n t h e d i s p l a y .
I n t h e e v e n t o f m a l f u n c t i o n o f t h e
a u t o m a t i c w i n d s c r e e n w i p e r s , t h e
w i n d s c r e e n w i p e r s w i l l o p e r a t e i n
intermittent mode.
C o n t a c t a P E U G E O T d e a l e r t o h a v e
t h e s y s t e m c h e c k e d .
In the
AUTO position, the windscreen
w i p e r s o p e r a t e a u t o m a t i c a l l y a n d
a d a p t t h e i r s p e e d t o t h e i n t e n s i t y o f t h e
r a i n f a l l .
W h e n n o t i n AUTO mode, for the
o t h e r p o s i t i o n s , r e f e r t o t h e m a n u a l
windscreen wipers section.
T h e a u t o m a t i c w i n d s c r e e n w i p e r s
f u n c t i o n m u s t b e r e a c t i v a t e d
if the
i g n i t i o n h a s b e e n s w i t c h e d o f f f o r m o r e
t h a n o n e m i n u t e , b y p r e s s i n g t h e s t a l k
d o w n w a r d s .
W h e n u s i n g a n a u t o m a t i c c a r
w a s h , s w i t c h o f f t h e i g n i t i o n t o
a v o i d t r i g g e r i n g o f t h e a u t o m a t i c
wiping.
I n w i n t e r , i t i s a d v i s a b l e t o w a i t f o r t h e
w i n d s c r e e n t o c o m p l e t e l y c l e a r o f i c e
b e f o r e o p e r a t i n g t h e a u t o m a t i c w i p e .
Automatic windscreen wipers
Page 48 of 214
46
Steering wheel controls
Wash-wipe and headlamp wash
P u l l t h e s t a l k t o w a r d s y o u , t h e w a s h -
w i p e i s a c c o m p a n i e d b y a t i m e d s w e e p
of the wipers.
T h e h e a d l a m p w a s h i s l i n k e d w i t h t h e
w a s h - w i p e , i t i s t r i g g e r e d i f t h e d i p p e d
h e a d l a m p s a r e o n .
T u r n t h e r i n g p a s t t h e fi r s t
n o t c h : t h e w i n d s c r e e n w a s h
then the windscreen wiper
o p e r a t e f o r a fi x e d t i m e .
I n w i n t e r , i n t h e e v e n t o f a
c o n s i d e r a b l e a m o u n t o f s n o w
o r i c e , s w i t c h o n t h e r e a r s c r e e n
d e m i s t e r . O n c e d e - i c i n g i s c o m p l e t e ,
r e m o v e t h e s n o w o r i c e w h i c h h a s
a c c u m u l a t e d o n t h e r e a r w i p e r
b l a d e . Y o u c a n t h e n o p e r a t e t h e r e a r
windscreen wiper.
T o t o p u p t h e l e v e l s , r e f e r t o t h e
" L e v e l s " s e c t i o n o f c h a p t e r 6 .
Special position of the
windscreen wipers
In the minute following switching
o f f o f t h e i g n i t i o n , a n y a c t i o n o n t h e
s t a l k p o s i t i o n s t h e w i p e r s a g a i n s t t h e
windscreen uprights.
T h i s a c t i o n e n a b l e s y o u t o p o s i t i o n
t h e w i p e r b l a d e s f o r w i n t e r p a r k i n g ,
c l e a n i n g o r r e p l a c e m e n t .
R e f e r t o t h e " C h a n g i n g a
w i n d s c r e e n w i p e r b l a d e " s e c t i o n o f
c h a p t e r 7 .
T o p a r k t h e w i p e r s i n t h e i r n o r m a l
p o s i t i o n a f t e r t h i s h a s b e e n d o n e ,
s w i t c h o n t h e i g n i t i o n a n d m o v e t h e
s t a l k . T u r n t h e r i n g t o t h e fi r s t n o t c h .
Rear windscreen wiper Rear windscreen wash
Page 49 of 214
47
Steering wheel controls
ERGONOMICS
and
COMFORT
3
CRUISE CONTROL "CRUISE"
I n o r d e r f o r i t t o b e p r o g r a m m e d o r
a c t i v a t e d , t h e v e h i c l e s p e e d m u s t b e
g r e a t e r t h a n 2 5 m p h ( 4 0 k m / h ) w i t h a t
l e a s t 4 t h g e a r e n g a g e d . This cruise control shows the function
s e l e c t i o n s t a t u s o n t h e i n s t r u m e n t
p a n e l a n d d i s p l a y s t h e p r o g r a m m e d
s p e e d :
Function
selected,
d i s p l a y i n g o f t h e
"Cruise Control"
symbol.
F u n c t i o n d e a c t i v a t e d ,
OFF ( e x a m p l e a t
6 5 m p h ( 1 0 7 k m / h ) ) .
F u n c t i o n a c t i v a t e d
( e x a m p l e a t
65 mph ( 1 0 7 k m / h ) ) .
V e h i c l e s p e e d a b o v e
( e . g .
70 mph 1 1 8 k m / h ) ) ,
t h e p r o g r a m m e d
s p e e d i s d i s p l a y e d
fl a s h i n g .
O p e r a t i n g f a u l t
detected,
OFF - t h e d a s h e s
fl a s h .
" T h i s i s t h e s p e e d a t w h i c h t h e d r i v e r
w i s h e s t o d r i v e " .
T h i s a i d t o d r i v i n g i n f r e e - fl o w i n g
t r a f fi c e n a b l e s t h e v e h i c l e t o m a i n t a i n
t h e s p e e d p r o g r a m m e d b y t h e d r i v e r ,
u n l e s s a s t e e p g r a d i e n t m a k e s t h i s
impossible.
Page 50 of 214
48
Steering wheel controls
Selecting the function
- P l a c e t h e s w i t c h i n t h e CRUISE
position. The cruise control is
s e l e c t e d b u t i s n o t y e t a c t i v e a n d
n o s p e e d h a s b e e n p r o g r a m m e d .
First activation/
programming a
speed
- R e a c h t h e c h o s e n speed by pressing the
a c c e l e r a t o r .
- P r e s s t h e SET - or
SET + button.
T h i s p r o g r a m m e s / a c t i v a t e s t h e
r e f e r e n c e s p e e d a n d t h e v e h i c l e w i l l
m a i n t a i n t h i s s p e e d . Temporary exceeding
of the speed
It is possible to
accelerate a n d d r i v e
m o m e n t a r i l y a t a s p e e d g r e a t e r t h a n
t h e p r o g r a m m e d s p e e d . T h e v a l u e
p r o g r a m m e d fl a s h e s .
W h e n t h e a c c e l e r a t o r p e d a l i s
r e l e a s e d , t h e v e h i c l e w i l l r e t u r n t o t h e
p r o g r a m m e d s p e e d .
Deactivation (off)
- P r e s s t h i s b u t t o n o r t h e b r a k e o r c l u t c h
p e d a l . Reactivation
- F o l l o w i n g d e a c t i v a t i o n o f t h e c r u i s e
control, press this button.
Y o u r v e h i c l e w i l l r e t u r n t o t h e l a s t
p r o g r a m m e d s p e e d .
A l t e r n a t i v e l y , y o u c a n r e p e a t t h e " fi r s t
a c t i v a t i o n " p r o c e d u r e .
