PONTIAC G6 2007 Owners Manual

{CAUTION:
Changing a tire can be dangerous. The
vehicle can slip off the jack and roll over
or fall on you or other people. You and
they could be badly injured or even killed.
Find a level place to change your tire. To
help prevent the vehicle from moving:
1. Set the parking brake rmly.
2. Put the shift lever in PARK (P).
3. Turn off the engine and do not restart
while the vehicle is raised.
4. Do not allow passengers to remain in
the vehicle.
To be even more certain the vehicle will
not move, you should put blocks at the
front and rear of the tire farthest away
from the one being changed. That would
be the tire, on the other side, at the
opposite end of the vehicle.When your vehicle has a at tire, use the following
example as a guide to assist you in the placement
of wheel blocks.
The following information will tell you next how to
use the jack and change a tire.
391

Removing the Spare Tire and Tools
The equipment you will need is located in the
trunk.
1. If you have a retractable hardtop model, make
sure the hardtop is in the up position.
2. Open the trunk. SeeTrunk on page 113for
more information.
3. If you have a sedan or coupe model, lift the
handle on the spare tire cover. The handle
can hook on the front edge of the trunk’s
weatherstrip to hold the cover out of the way.
If you have a retractable hardtop model,
unlatch the trunk cargo cover so that it is in
the open position. Then remove the cover from
the spare tire.4. Turn the wing nut counterclockwise and
remove it. Then remove the compact
spare tire. SeeCompact Spare Tire on
page 403for more information.
5. Remove the wing nut holding the jack
in place.
6. Remove the extension bolt that is clipped to
the jack. You will need this later to store the
at tire.
7. Remove the jack and wheel wrench from the
trunk.
392

The tools you will be using include the wheel
wrench (A) and jack (B).1. Turn the plastic wing nut counterclockwise to
loosen the wheel wrench.
2. Unhook the wheel wrench from the jack.
393

3. Extend the handle on the wheel wrench by
pressing the button with your index nger
and pulling on the end of the wrench.
You must do this before using the wheel
wrench.
Removing the Flat Tire and
Installing the Spare Tire
1. If your vehicle has a wheel cover or hubcap
that has plastic wheel nut caps, then loosen
the plastic nut caps. You may need to use the
wheel wrench to loosen them. Do not pry
off wheel covers or center caps that
have plastic wheel nut caps.
2. Remove the wheel cover or center cap from
the wheel to locate the wheel nuts.
If your vehicle has a wheel cover or hubcap
without plastic wheel nut caps, gently pry
on the edge of the plastic wheel trim to remove
it from the wheel to nd the wheel nuts.
394

3. Use the wheel wrench to loosen all the wheel
nuts. Do not remove them yet.4. Position the lift head at the jack location
nearest the at tire. Make sure all of the
jack lift head is touching the jacking ange
under the body. Do not place the jack under a
body panel. The lower body panel has an
arrow to aid in locating the jacking location.
395

5. Put the compact spare tire near the at tire
being changed.
{CAUTION:
Getting under a vehicle when it is jacked
up is dangerous. If the vehicle slips off
the jack you could be badly injured or
killed. Never get under a vehicle when
it is supported only by a jack.
{CAUTION:
Raising your vehicle with the jack
improperly positioned can damage the
vehicle and even make the vehicle fall.
To help avoid personal injury and vehicle
damage, be sure to t the jack lift head
into the proper location before raising the
vehicle.6. Raise the vehicle by turning the wheel wrench
clockwise. Raise the vehicle far enough off
the ground so there is enough room for the
compact spare tire to t underneath the
wheel well.
396

7. Remove all of the
wheel nuts.
8. Remove the at tire.
{CAUTION:
Rust or dirt on the wheel, or on the parts to
which it is fastened, can make the wheel
nuts become loose after time. The wheel
could come off and cause an accident.
CAUTION: (Continued)
CAUTION: (Continued)
When you change a wheel, remove any
rust or dirt from the places where the
wheel attaches to the vehicle. In an
emergency, you can use a cloth or a
paper towel to do this; but be sure to use
a scraper or wire brush later, if needed, to
get all the rust or dirt off.
9. Remove any rust or
dirt from the wheel
bolts, mounting
surfaces, and
spare wheel.
397

10. Install the compact spare tire.
{CAUTION:
Never use oil or grease on studs or nuts.
If you do, the nuts might come loose.
Your wheel could fall off, causing a
serious accident.
11. Put the wheel nuts back on with the rounded
end of the nuts toward the wheel. Tighten
each nut by hand until the wheel is held
against the hub.12. Lower the vehicle by turning the wheel
wrench counterclockwise. Lower the jack
completely.
398

{CAUTION:
Incorrect wheel nuts or improperly
tightened wheel nuts can cause the wheel
to come loose and even come off. This
could lead to an accident. Be sure to use
the correct wheel nuts. If you have to
replace them, be sure to get new GM
original equipment wheel nuts. Stop
somewhere as soon as you can and have
the nuts tightened with a torque wrench
to the proper torque specication. See
Capacities and Specifications on page 424
for wheel nut torque specication.
Notice:Improperly tightened wheel nuts can
lead to brake pulsation and rotor damage. To
avoid expensive brake repairs, evenly tighten
the wheel nuts in the proper sequence and to
the proper torque specication. SeeCapacities
and Specifications on page 424for the wheel
nut torque specication.13. Tighten the wheel
nuts rmly in a
crisscross sequence,
as shown, with
the wheel wrench.
Notice:Wheel covers will not t on your
compact spare. If you try to put a wheel cover
on the compact spare, you could damage
the cover or the spare.
Do not try to put a wheel cover on your compact
spare tire. It will not t. Store the wheel cover
in the trunk until you have the at repaired
or replaced.
399

Storing a Flat or Spare Tire
and Tools
All Models (Except GTP
and Retractable Hardtop)
{CAUTION:
Storing a jack, a tire, or other equipment
in the passenger compartment of the
vehicle could cause injury. In a sudden
stop or collision, loose equipment could
strike someone. Store all these in the
proper place.
To store the at tire and jack in the compact spare
tire compartment, do the following:
1. Open the trunk. SeeTrunk on page 113for
more information.
2. Remove the bolt extension (in the yellow
sleeve) from the jack and remove the
center cap from the wheel.3. Place the jack over the bolt (A) on the oor,
making sure it contacts the bolt as shown,
and thread the jack retainer nut until it
contacts the jack.
4. With the valve stem up, place the tire on the
compartment oor with the rear of the tire
beneath the trim panel. The tire may not lay
completely at.
5. Line up a wheel nut hole with the bolt or
wheel center.
400
