SunroofIf the vehicle has a sunroof, it can be opened or
put in a tilt position. To tilt the sunroof, slide
the sunshade rearward, then press the switch
marked UP. Press the other end of the switch to
lower the sunroof. The ignition must be in the
ON position for the switch to work.
To open or close the sunroof, press the switch
marked SLIDE rearward or forward. The sunroof
will close partially and stop. Once the sunroof
stops, release the switch and press the button
again to fully close it. The sunroof can be opened
to any position. The sunshade will open when
the sunroof is opened. The sunshade must
be closed manually.
131

✍NOTES
132

Instrument Panel Overview........................ 136
Hazard Warning Flashers.......................... 138
Other Warning Devices............................. 138
Horn.......................................................... 138
Tilt Wheel.................................................. 139
Turn Signal/Multifunction Lever.................. 139
Turn and Lane-Change Signals................. 140
Headlamp High/Low-Beam Changer.......... 140
Flash-to-Pass............................................ 141
Windshield Wipers..................................... 141
Windshield Washer.................................... 142
Rear Window Wiper/Washer...................... 142
Cruise Control........................................... 143
Exterior Lamps.......................................... 146
Headlamps on Reminder........................... 146
Daytime Running Lamps (DRL)................. 147
Automatic Headlamp System..................... 147
Fog Lamps................................................ 148
Instrument Panel Brightness...................... 148
Interior Lamps Control............................... 149
Entry Lighting............................................ 149
Reading Lamps......................................... 150
Accessory Power Outlet(s)........................ 150Power Outlet 115 Volt Alternating
Current.................................................. 151
Ashtray(s) and Cigarette Lighter................ 151
Climate Controls......................................... 152
Climate Control System............................. 152
Outlet Adjustment...................................... 155
Passenger Compartment Air Filter............. 156
Warning Lights, Gages, and Indicators..... 158
Instrument Panel Cluster........................... 159
Speedometer and Odometer...................... 160
Trip Odometers......................................... 160
Tachometer............................................... 161
Safety Belt Reminder Light........................ 161
Airbag Readiness Light............................. 162
Passenger Airbag Status Indicator............. 163
Charging System Light.............................. 165
Brake System Warning Light..................... 166
Anti-Lock Brake System Warning Light...... 167
Low Tire Pressure Warning Light.............. 167
Traction Control System (TCS)
Warning Light........................................ 168
StabiliTrak
®Indicator Light......................... 168
Section 3 Instrument Panel
133

Engine Coolant Temperature Gage............ 169
Malfunction Indicator Lamp........................ 170
Oil Pressure Light..................................... 173
Lights On Reminder.................................. 174
Taillamp Indicator Light............................. 174
Cruise Control Light.................................. 174
Overdrive Off Light.................................... 174
Highbeam On Light................................... 175
Low Washer Fluid Warning Light............... 175
Door Ajar Light.......................................... 175
Fuel Gage................................................. 176
Low Fuel Warning Light............................ 177Audio System(s)......................................... 177
Setting the Time........................................ 178
Radio with CD (Base Level)...................... 179
Radio with CD (MP3)................................ 188
Radio with Six-Disc CD............................. 198
Using an MP3........................................... 210
XM Radio Messages................................. 216
Radio Reception........................................ 218
Care of Your CDs..................................... 219
Care of the CD Player.............................. 219
Fixed Mast Antenna.................................. 219
XM™ Satellite Radio Antenna System....... 219
Section 3 Instrument Panel
134

✍NOTES
135

Instrument Panel Overview
136

The main components of your instrument panel are the following:
A. Air Outlets. SeeOutlet Adjustment on
page 155.
B. Instrument Panel Cluster. SeeInstrument
Panel Cluster on page 159.
C. Climate Control System. SeeClimate Control
System on page 152.
D. Hazard Warning Flasher Button. SeeHazard
Warning Flashers on page 138.
E. Audio System. SeeAudio System(s) on
page 177.
F. Rear Window Defogger Button. See “Rear
Window Defogger” underClimate Control
System on page 152.
G. Passenger Airbag Status Indicator. See
Passenger Airbag Status Indicator on page 163.
Front Passenger Safety Belt Reminder Light.
SeeSafety Belt Reminder Light on page 161.
H. Power Remote Control Mirror Button. See
Outside Remote Control Mirrors on page 122.
I. Instrument Panel Brightness Control. See
Instrument Panel Brightness on page 148.
J. Rear Liftglass Release Button. See
Liftgate/Liftglass on page 96.K. Tire Pressure Monitor Reset Button. SeeTire
Pressure Monitor System on page 330.
L. Coinholder. SeeCoinholder(s) on page 127.
M. TRAC OFF Button. SeeTraction Control
System (TCS) on page 230.
N. Content Theft-Deterrent Security Light. See
Content Theft-Deterrent on page 100.
O. Storage Compartment. SeeInstrument Panel
Storage Area on page 127.
P. Turn Signal/Multifunction Lever and Exterior
Lamp Stalk. SeeTurn Signal/Multifunction
Lever on page 139andExterior Lamps
on page 146.
Q. Hood Release. SeeHood Release on
page 280.
R. Tilt Lever. SeeTilt Wheel on page 139.
S. Horn. SeeHorn on page 138.
T. Cruise Control Lever (Option). SeeCruise
Control on page 143.
U. Ignition Switch. SeeIgnition Positions on
page 103.
137

V. Windshield Wiper Lever. SeeWindshield
Wipers on page 141.
W. Cigarette Lighter or Accessory Power Outlet.
SeeAshtray(s) and Cigarette Lighter on
page 151orAccessory Power Outlet(s) on
page 150.
X. Shift Lever. SeeAutomatic Transaxle Operation
on page 108orManual Transaxle Operation
on page 111.
Y. Power Outlet. SeePower Outlet 115 Volt
Alternating Current on page 151.
Z. Parking Brake. SeeParking Brake on
page 114.
AA. Center Console Storage Area. SeeCenter
Console Storage Area on page 127.
AB. Glove Box. SeeGlove Box on page 127.
Hazard Warning Flashers
The hazard warning ashers let you warn the
police and others that you have a problem. The
front and rear turn signal lamps will ash on
and off.The hazard warning
asher button is located
in the center of the
instrument panel.
The hazard warning ashers work no matter what
position the key is in, and even if the key is not
in the ignition switch.
Press the button to make the front and rear turn
signal lamps ash on and off. Press the button
again to turn the ashers off.
While the hazard warning ashers are on, the turn
signals do not work.
Other Warning Devices
If you carry reective triangles, you can set
them up at the side of the road about 300 feet
(100 m) behind your vehicle.
Horn
Press near or on the horn symbols on your
steering wheel pad to sound the horn.
138

Tilt Wheel
A tilt steering column allows you to adjust the
steering column before you drive. You can also
raise it to the highest level to give your legs more
room when you exit and enter the vehicle.
The tilt lever is located
underneath, on the left
side of the steering
wheel column.
To tilt the column, move the lever downward.
Adjust the steering wheel to a comfortable position,
then move the lever upward to lock the column
in place.
Turn Signal/Multifunction Lever
The turn signal/multifunction lever is located on
the left side of the steering column.
This lever operates the following:
Exterior Lamps. SeeExterior Lamps on
page 146.
Turn and Lane-Change Signals. SeeTurn and
Lane-Change Signals on page 140.
Headlamp High/Low-Beam Changer. See
Headlamp High/Low-Beam Changer on
page 140.
Flash-to-Pass. SeeFlash-to-Pass on
page 141.
Fog Lamps. SeeFog Lamps on page 148.
139

Turn and Lane-Change Signals
The turn signal has an upward (for right) and a
downward (for left) position. These positions allow
you to signal a turn or a lane change.
To signal a turn, move the lever all the way up or
down. When the turn is nished, the lever will
return automatically.
To signal a lane change, raise or lower the lever
until the arrow starts to ash. Hold it there until you
complete your lane change. The lever will return
by itself when you release it.
An arrow on the
instrument panel cluster
will ash in the
direction of the turn or
lane change.
If you signal a turn or a lane change and notice
the arrow ashing rapidly, a signal bulb may
be burned out and other drivers will not see your
turn signal.If a bulb is burned out, have it replaced to help
avoid an accident. If the arrows do not go on at all
when you signal a turn, check for burned-out
bulbs and then check the fuse. SeeFuses and
Circuit Breakers on page 365.
Headlamp High/Low-Beam Changer
The headlamps must be on for this feature to
work. For high beams, push the turn signal lever
away from you.
When the high beams
are on, this light on the
instrument panel
cluster also will be on.
It will go off when you switch to the low beams. To
switch back to low beams, pull the lever toward you.
140
