Manuallyadjustablecomfortseat/sports
seat
AeSeatheight
UseleverAinapumpingmovement:
Upwards-seatmovesupwards
Downwards-seatmovesdownwards
BeForeandaft
RaiselockingleverB.Moveseattodesiredpositionandreleaselever.Ensurethattheseatengagescorrectly.
CeBackrestangle
OperateswitchCuntilthedesiredbackrestangleisreached.
Electricallyadjustablecomfort
seat/sportsseat
Adjustment
Presstheswitchinthedirectionindicatedbythearrowuntilthedesiredsettingisreached.
Controls,Instruments39

AeSeatheightadjustment
BeFore-and-aftpositionadjustment
CeSeatangleadjustment
DeBackrestangleadjustment
EeLumbarsupport(pelvisandspinalcolumn
support)
Topermitarelaxedsittingposture,thebackrestcurvatureiscontinuouslyadjustableinverticalandhorizontaldirectionsforindividualpelvisandspinalcolumnsupport.
Presstheswitchinthedirectionindicatedbythearrowuntilthedesiredbackrestcurvatureisreached.
FeAdjustingthebackrestsidebolsters
(electricallyadjustablesportsseatonly)
PushforwardorpullbackwardswitchFuntilthesidebolstersareadjustedtotheshapeofthebody.
GeAdjustingtheseatcushionsidebolsters
(electricallyadjustablesportsseatonly)
PushforwardorpullbackwardswitchGuntilthesidebolstersareadjustedtotheshapeofthebody.
Seatbackrest
Foldingforward
PullupleverHinthesidepartofthebackrestandfoldthebackrestforward.
Foldingback
Tiltbackandengagethebackrestsothatitcannottipforwardwhenthecarisbraked.
40Controls,Instruments

M-Memorybutton1-Keybutton2,3-Personbuttons
SeatMemory
Individualseatanddoormirrorsettings
Individualseatanddoormirrorsettingscanbestoredandrecalledforthedriver’sposition.
FurtherindividualsettingoptionsareavailableinvehicleswiththeSportChronoPackagePlus.Pleaseobservethechapter“IndividualMemory”intheseparatePCMoperatinginstructions.
Warning!
Riskofcrushingduetouncontrolledrecallofaseatsetting.
Cancelautomaticadjustmentbypressinganyoftheseatadjustmentbuttons.
Donotleavechildreninthevehicleunattended.
Operationwithpersonbuttons2,3
Storingseatposition
1.Switchonignition.Reversegearmustnotbeengaged.
2.Setthedesiredseatanddoor-mirrorpositions.
3.KeepmemorybuttonMdepressedandadditionallypresspersonbutton2or3.Theindividualsettingisnowstoredunderthedesiredpersonbutton.
Recallingseatposition
Theseatpositioncanonlybecalledupwhenthevehicleisstationary.
1.Switchontheignitionoropenthedriver’sdoor.
2.Presspersonbuttonuntiltheseathasreacheditsfinalposition.Thesettingofdoormirrorsandlumbarsupportwillbecompletedevenifthepersonbuttonisnotkeptdepressed.
Note
Automaticseatadjustmentcanbeinterruptedimmediatelybyreleasingthebutton.
Controls,Instruments41

Operatingwiththeremotecontrolofthe
carkey
Individualassignmentoftheremotecontrol
Eachremotecontrol(uptosix)canbeassignedanindividualseatanddoormirrorposition.Thestoredseatanddoormirrorpositionissetautomaticallywhenthevehicleisunlockedusingthecorrespondingremotecontrol.
Storingseatposition
1.Switchtheignitiononwiththedesiredcarkey.Reversegearmustnotbeengaged.
2.Setthedesiredseatanddoor-mirrorpositions.
3.KeepmemorybuttonMdepressedandadditionallypresskeybutton1.Theindividualsettingisnowassignedtothisremotecontrolandtothekeybutton.
Storingindividualloweredpositionofthe
passenger’sdoormirrorasaparkingaid
Oncethedriver’sseatsettinghasbeenstored,anindividualloweredpositionofthepassenger’sdoormirrormaybestoredfordrivinginreverse:
1.Applythehandbrake.
2.Switchtheignitiononwiththedesiredcarkey.
3.Engagereversegear.
4.Selectpassengersidewithmirrorswitch.Thepassenger’smirrorswivelsdownwards.
5.Setpassenger’sdoormirrortodesiredfinalposition.
6.KeepmemorybuttonMdepressedandadditionallypresskeybutton1.Theindividualsettingisnowassignedtothisremotecontrolandtothekeybutton.
Recallingseatposition
Unlockthelockedvehicleortheluggagecompartmentwiththeremotecontrol.Thestoredseatpositionisautomaticallyset.
Theseatpositionassignedtoaremotecontrolcanalsoberecalledwiththekeybutton1ifthecorrespondingkeywasusedtoswitchontheignition.
Ifnoseatpositionhasbeenassignedtoaremotecontrol,thekeybuttonwillnotwork.
Noteonoperation
Automaticseatadjustmentcanbeinterruptedimmediately:
byswitchingontheignition,
bypressingthecentrallockingbutton,
bypressinganymemoryorseatadjustmentbutton.
Clearingthestoredseatposition
1.Switchtheignitiononwiththedesiredcarkey.
2.Pressmemorybuttontwiceandkeybutton1onceconsecutively.
42Controls,Instruments

A-Seatheating,leftB-Seatheating,right
HeatedSeats
Switchingon
Readinessforoperation
Two-stageseatheatingisreadyforoperationwhentheignitionison.
Highheatingpower
Pressbutton.Bothlight-emittingdiodesinthebuttonlightup.
Lowheatingpower
Presstherocker-switchsymbolagain.Onelight-emittingdiodeinthebuttonlightsup.
Switchingoff
Pressbutton.Light-emittingdiodesgoout.
Controls,Instruments43

RearSeatBackrests
Foldingforward
Extrastoragespaceisgainedbyfoldingtherearseatbackrestsforward.
Pullleverforwardandfoldthebackrestforward.
Foldingback
Tiltthebackrestbackuntilyoufeelitclickintoplace.Whendoingso,makesurethattheseatbeltisproperlyrouted(seegure).
Cabriolet
Donotfolduptherearseatbackrestswiththewindstopinstalled.
44Controls,Instruments

SteeringWheelAdjustment
Adjustingsteeringwheelheightand
longitudinaldirection
Warning!
Riskofaccident.Thesteeringwheelmaymovefurtherthandesiredifyouattempttoadjustitwhendriving.Youcanlosecontrolofthevehicle,causingseriouspersonalinjuryordeath.
Donotadjustthesteeringwheelwhendriving.
1.Insertignitionkeyfullyintoignitionlock.
2.Pushthelockingleverdownwards.
3.Adjuststeeringwheeltofitthechosenbackrestangleandyourseatpositionbymovingthesteeringwheelupordownandlongitudinally.
4.Swivellockingleverbackuntilyoufeelitengage.Ifnecessary,movesteeringwheelslightlylongitudinally.
Controls,Instruments45

Multi-FunctionalSteeringWheel
Function
Warning!
Thereisadangerofaccidentifyousetoroperatetheon-boardcomputer,radio,navigationsystem,telephoneorotherequipmentwhendriving.Operatingthesedeviceswhiledrivingcoulddistractyoufromtrafcandcauseyoutolosecontrolofthevehicle.
Operatethesecomponentswhiledrivingonlyifthetrafficsituationallowsyoutodososafely.
Carryoutanycomplicatedoperatingorsettingproceduresonlywhilethevehicleisstationary.
Dependingontheequipmentinyourvehicle,youcanusethefunctionkeysofthemulti-functionalsteeringwheeltooperatethefollowingPorschecommunicationsystems:
–PCM
–Telephone
–CDchanger
Readinessforoperationof
multi-functionalsteeringwheel
Themulti-functionalsteeringwheelisreadyforoperationwhentheignitionandPCMareswitchedon.
Operatingthefunctionkeys
PleasereadtheseparatePCMoperatinginstructionsbeforeoperatingthefunctionkeys.
Therotaryknobsatthetopleftandrightofthesteeringwheelcanalsobepressed.
TurnvolumecontrolUpwards-increasevolume.Downwards-decreasevolume.PressvolumecontrolToswitchvolume/muteonandoff.
TurnrotaryknobToselect/markfunctioninthePCMwithinamenu.Todothis,turntherotaryknobupwardordownward.PressrotaryknobToactivateselectedfunction.
PressscreenbuttonTocallthestoredPCMfunction.ThebuttoncanbeassignedthedesiredfunctioninthePCM.
PressBackbuttonTomovebackinthePCMmenu.
PressHandsetPickupbuttonToacceptatelphonecall.
PressHandsetHangupbuttonToendorrefuseatelephonecall.
46Controls,Instruments

SunVisors
Swivelthesunvisors
Swingthesunvisorsdowntopreventglarefromthefront.
Coupb,Cabriolet:Topreventglarefromtheside,unclipthesunvisorfromtheinnerbracketandswivelroundsothatitisinfrontofthedoorwindow.
Vanitymirror
Thevanitymirrorontherearofthesunvisoriscoveredbyalid.
Warning!
Riskofinjuryinanaccidentorriskofdamagetomirrorlidandconvertibletop.
Keepthelidclosedwhiledrivingandwhenclosingtheconvertibletop.
Warning!
Riskofdamage.
Donotforcethelidbeyonditsendposition.
Coupé,Cabriolet
Thevanitymirrorilluminationisswitchedonautomaticallywhenthecoverisopened(arrow).
Targa
Thevanitymirrorilluminationisswitchedonautomaticallywhentheslidingcoverisopened(arrow).Thelightisswitchedoffwhenthesunvisorisinitsupperorlowerendposition.
Controls,Instruments47

SafetyBelts
Generalinformation
Warning!
Alwaysmakesureyourandyourpassengers’safetybeltsareproperlyfastenedwhilethevehicleisinmotion.Failuretofollowsafetybeltwarningsmayresultinseriouspersonalinjuryordeath.
Foryourandyourpassengers’protection,usesafetybeltsatalltimeswhilethevehicleisinmotion.
Useappropriatechildrestraintsystemsforallsmallchildren.
Warning!
Properwearingofsafetybelts
Safetybeltsmustbepositionedonthebodyastorestraintheupperbodyandlapfromslidingforward.Improperlypositionedsafetybeltscancauseseriouspersonalinjuryordeathincaseofanaccident.
Theshoulderbeltshouldalwaysrestonyourupperbody.Theshoulderbeltshouldneverbewornbehindyourbackorunderyourarm.
Formaximumeffectiveness,thelapbeltshouldbewornlowacrossthehips.
Pregnantwomenshouldpositionthebeltaslowaspossibleacrossthepelvis.Makesureitisnotpressingagainsttheabdomen.
Beltsshouldnotbeworntwisted.
Donotwearbeltsoverrigidorbreakableobjectsinoronyourclothing,suchaseyeglasses,pens,keys,etc.asthesemaycauseinjury.
Severallayersofheavyclothingmayinterferewithproperpositioningofbelts.
Beltsmustnotrubagainstsharpobjectsordamagemayoccurtothebelt.
Twooccupantsshouldneversharethesamebeltatthesametime.
Warning!
Careandmaintenance
Keepbeltbucklesfreeofanyobstructionthatmaypreventasecurelocking.
Beltsthathavebeensubjectedtoexcessivestretchforcesinanaccidentmustbeinspect-edorreplacedtoensuretheircontinuedeffec-tivenessinrestrainingyou.Thesameappliestobelttensionersystemswhichhavebeentriggered.Inaddition,theanchorpointsofthebeltsshouldbechecked.
Ifsafetybeltsdonotworkproperly,seeyourauthorizedPorschedealerimmediately.
Ifthebeltsshowdamagetowebbing,bind-ings,bucklesorretractors,theyshouldbereplacedtoensuresafeoperation.
Donotmodifyordisassemblethesafetybeltsinyourvehicle.
Thebeltsmustbekeptcleanortheretractorsmaynotworkproperly.
Pleaseobservethechapter”CARCAREINSTRUCTIONS”onpage257.
Neverbleachordyesafetybelts.
Donotallowsafetybeltstoretractuntiltheyarecompletelydryaftercleaningorthismaycausedamagetothebelt.
Belttensioner
Dependingontheforceofanimpact,fastenedsafetybeltsaretightenedinanaccident.
Thebelttensionersaretriggeredin:
–Front,sideandrearimpactsofsufficientseverity.
–FortheCabriolet,incasesofvehiclerollover.
Note
Thebelt-tensionersystemcanbetriggeredonlyonce;thesystemmustbereplacedafterward.
Ifthereisafaultinthebelt-tensionersystem,theairbagwarninglightlightsup.
