PORSCHE CAYNNE 2004 1.G Workshop Manual

Seats, Mirrors and Steering Wheel
51
fIf emergency or other serious conditions
require a child to be placed in the front seat,
exercise extreme caution and defensive
driving of your vehicle. You must recognize
that any substantial frontal impact could result
in the deployment of the passenger airbag,
which could lead to serious injury or death of
the child.
Child restraint system for children weighing
up to 29 lbs (13 kg)
If the child restraint system must be fastened to
the passenger's seat in exceptional cases:
– make sure that the PASSENGER AIRBAG OFF
indicator lamp lights up.
– adjust the passenger's seat as far away from
the airbag as possible
Danger!
Risk of serious personal injury or death due
to the passenger airbag triggering uninten-
tionally.
When the ignition is on and child weighing up
to 29 lbs (13 kg) is seated in the child res-
traint system on the passenger seat the indi-
cator lamp “PASSENGER AIRBAG OFF” must
be on.
If the “PASSENGER AIRBAG OFF” indicator
lamp does not light up, it could indicate a
fault in the system.
In this case:
fFasten the child restraint system on the rear
bench immediately.
fHave the fault remedied at your nearest authorized Porsche dealer.
Child restraint system for children weighing
more than 29 lbs (13 kg)
Your vehicle is equipped with weight sensing for
the passenger's seat in accordance with
U.S. Federal Motor Vehicle Safety Standard 208.
Depending on the weight acting on the
passenger's seat, the passenger's airbag will
automatically be switched on or off.
fIn case of doubt, fasten the child restraint
system on the rear bench.Small adult passengers
fMake sure that the PASSENGER AIRBAG OFF
indicator lamp does not light up.
Danger!
Risk of serious or mortal injury due to the
passenger airbag not triggering.
When the ignition is on and the small adult
passenger is seated on the passenger seat,
the indicator lamp “PASSENGER AIRBAG
OFF” must be off.
If the “PASSENGER AIRBAG OFF” indicator
lamp lights up, it could indicate a fault in the
system.
In this case:
fCarry the passenger on the rear bench until the
fault is repaired.
fHave the fault remedied at your nearest authorized Porsche dealer.
10_Cayenne_21_KW17.book Seite 51 Donnerstag, 9. April 2009 3:33 15

52
Seats, Mirrors and Steering Wheel
Automatic locking retractorThe safety belts for the front passenger and the
rear bench are equipped with an automatic locking
retractor for securing the child restraint system.
When activated, this retractor allows you to
securely fasten the child restraint system in place
so that inadvertent movements will not occur.
Danger!
The use of a child restraint system on the
front passenger seat can result in serious
personal injury or death to the child from an
airbag deployment.
To reduce risk of injury from an inflating
airbag in an accident, Porsche strongly
recommends:
fUnder all normal circumstances, the child seat
must be placed in the rear.
Do not use a child restraint system on the front passenger seat.However, there may be serious situations where it
might be necassary to place a child in the front
seat so that he/she can be kept under direct ob-
servation to prevent an immediate risk to the child
(for example, while driving to the doctor or hospi-
tal). The following instructions are provided to you
solely for that purpose.
fSeek appropriate advice from your authorized
Porsche dealer about the possible installation
of a Porsche child restraint system.
fIf a child restraint system must be fastened to
the passenger's seat, adjust the passenger's
seat as far away from the airbag as possible.
Before transporting a child on the passenger seat:
fPlease see the chapter “CHILD RESTRAINT
SYSTEMS” on Page 49.
fIf emergency or other serious conditions
require a child to be placed in the front seat,
exercise extreme caution and defensive dri-
ving of your vehicle. You must recognize that
any substantial frontal impact could result in
the deployment of the passenger airbag, which
coluld lead to serious injury or death of the
child.
A- PASSENGER AIRBAG OFF indicator lamp
Danger!
Risk of serious personal injury or death to the
child, when excessive force is acting on the
passenger's seat due to the seat belt and the
passenger's airbag is switched on uninten-
tionally.
fAfter fastening the child restraint system, do
not adjust the seat.
fCheck the condition of the passenger airbag
system shown by the indicator lamp A in the central console.
10_Cayenne_21_KW17.book Seite 52 Donnerstag, 9. April 2009 3:33 15

Seats, Mirrors and Steering Wheel
53
Activating the automatic locking retractor
1. If a child restraint system must be fastened to
the passenger's seat, adjust the passenger's
seat as far away from the airbag as possible.
2. Fasten child seat.
3. Pull the safety belt retractor completely out. At
this point the locking mechanism is activated.
4. Insert the safety belt tongue into the buckle
and make certain that it is properly latched.
Make no more adjustments to the seat.
5. Allow the safety belt to retract until it is tight on
the child restraint system. You may further
tighten the belt by pulling on it to allow more of
it to retract.
Make sure that excessive seat belt forces do
not occur by moving the seat with the child
seat installed.
Releasing the safety belt
fUnbuckle the safety belt latch.
Then make certain that the belt has fully retracted.
At this point the automatic locking feature will be
disengaged.
Seek appropriate advice from your authorized
Porsche dealer about the possible installation of a
Porsche child restraint system.Use only child restraint systems with the LATCH
system recommended by Porsche.
These systems have been tested and adjusted to
the interior of your Porsche and the appropriate
child weight groups. Other systems have not been
tested and could entail an increased risk of injury.
You can obtain child seats that are
LATCH-compatible at your authorized Porsche
dealer.
Always observe the separate installation instruc-
tions for your child seat.
Installing a LATCH child seat systemMarkings on the right and left for the LATCH child
seat anchorage can be found on the backrests of
the outer rear seats.
The anchor bars A for the LATCH child seat
anchorage can be found directly under the
markings between backrest and seat cushion.
LATCH Child Seat System
10_Cayenne_21_KW17.book Seite 53 Donnerstag, 9. April 2009 3:33 15

54
Seats, Mirrors and Steering Wheel Danger!
The use of a child restraint system on the
front passenger seat can result in serious
personal injury or death to the child from an
airbag deployment.
To reduce risk of injury from an inflating
airbag in an accident, Porsche strongly
recommends:
fUnder all normal circumstances, the child seat
must be placed in the rear.
Do not use a child restraint system on the front
passenger seat.
fPlease see your authorized Porsche dealer for
correct Porsche Child Seat availability.
fPorsche recommends the use of a Porsche
Child Seat with Lower Anchorage and Tether for Children system (LATCH) on the rear seats.
1. Secure the child seat to retaining lugs A as
outlined in the operating manual for the child
seat.
2. Pull the child seat to check that both fastening
points are engaged correctly.
Child Restraint AnchoragesfPlease see the chapter “AUTOMATIC LOCKING
RETRACTOR” on Page 52.
If your child restraint seat or seats require the use
of a tether strap, you will want to use the anchor
points A provided behind the rear bench back-
rests.
To ensure proper installation, see your authorized
Porsche dealer.
Warning!
Child restraint anchorages are designed to
withstand only those loads imposed by
correctly fitted child restraints. Under no
circumstances are they to be used for adults
safety belts or harnesses. Such use could
result in serious personal injury or death.
fDo not misuse the child restraint anchorages.
Only attach one child seat tether per ancho-
rage.
fThey are not designed to withstand loads imposed by adults.
10_Cayenne_21_KW17.book Seite 54 Donnerstag, 9. April 2009 3:33 15

Seats, Mirrors and Steering Wheel
55
A- Door mirror setting – driver’s side
B- Heat door mirror
C- Door mirror setting – passenger’s side
D- Fold in door mirrorsDoor MirrorsThe convex mirror glass on the passenger's side
provides a larger field of view.
Warning!
Risk of accident. Vehicles or objects appear
smaller in convex mirrors and further away
than they are in reality.
fBear this distortion in mind when estimating
the distance of vehicles behind you and when
reversing into a parking space.
fAlso make use of the interior mirror for judging
the distance.
Risk of damage to the door mirrors when
washing the vehicle in a car wash.
fFold in door mirrors before using the car wash.Adjusting mirrors1. Switch ignition on.
2. Select A for the driver’s side or C for the
passenger’s side by turning the control switch.
3. Move the door mirrors in the appropriate
direction by tilting the control switch.
If the electrical adjustment facility fails
fAdjust the mirror by pressing on the mirror
face.Adjusting the door mirrors synchronously
In the multi-purpose display of the instrument
panel, you have the option of adjusting the door
mirrors synchronously.
fPlease see the chapter “SYNCHRONOUS
ADJUSTMENT OF DOOR MIRRORS” on
Page 143.
Folding in door mirrorfSwitch ignition on.
fTurn control switch to D.
Both door mirrors fold in automatically.
If the electrical adjustment facility fails
fFold in mirror manually.Unfolding door mirrorsfSwitch ignition on.
fTurn control switch to A or C.
Both door mirrors unfold automatically.
If the electrical adjustment facility fails
fUnfold mirrors manually.
10_Cayenne_21_KW17.book Seite 55 Donnerstag, 9. April 2009 3:33 15

56
Seats, Mirrors and Steering Wheel
Door mirror heatingThe door mirror heater is ready for operation
when the ignition is switched on.
Switching on
fTurn control switch to B.
Both door mirrors are heated.
Switching off
fChange the position of the control switch.Storing door mirror settingsOn vehicles with seat memory, individual door mir-
ror settings can be stored on the person buttons
of the seat memory and vehicle keys and recalled
with these.
fPlease see the chapter “FRONT SEAT WITH
MEMORY” on Page 37.
fPlease see the chapter “STORING PASSEN-
GER MIRROR SETTING AS A PARKING AID” on
Page 38.
A- Door mirror setting – driver’s side
B- Heat door mirror
C- Door mirror setting – passenger’s side
D- Fold in door mirrorsSwivelling down mirror glass as parking
aidWhen reverse gear is engaged, the mirror glass
on the passenger's side swivels down slightly to
show the curb area.Preconditions
– Vehicle must be equipped with seat memory.
– Control switch must be turned to position C
(passenger mirror’s setting).
– Reverse gear must be engaged.
Moving mirror glass to its initial position with
reverse gear engaged
The mirror glass swivels to its initial position when:
– The car is shifted out of reverse gear or
– The position of the control switch for the door
mirror setting is changed.
10_Cayenne_21_KW17.book Seite 56 Donnerstag, 9. April 2009 3:33 15

Seats, Mirrors and Steering Wheel
57
Interior MirrorInitial position – lever forward
Anti-dazzle setting – lever back
Note on operation
fWhen the interior mirror is being adjusted, anti-
dazzle lever A must point forward.
E- Light-emitting diodes (LED)
F- Button for automatic anti-dazzle operation
G- Light sensorsAutomatic Anti-Dazzle MirrorSensors on the front and rear sides of the interior
mirror measure the incident light. The mirrors
automatically change to anti-dazzle position or
revert to their normal state, depending on the light
intensity.
Note on operation
The incident light in the area of light sensors G
must not be restricted (e.g. by stickers on the
windshield).Switching off automatic anti-dazzle
operation
fPress button F.
Light-emitting diode E goes out.
Note on operation
Anti-dazzle operation switches off automatically,
if:
– Reverse gear is engaged or
– Interior lighting and/or
reading lights in the front are switched on.
Switching on automatic anti-dazzle
operation
fPress button F.
Light-emitting diode E lights up.
Warning!
Danger of injury. Electrolyte fluid can
emerge from broken mirror glass. This fluid
irritates the skin and eyes.
fIf the electrolyte fluid should come into contact
with the skin or eyes, immediately rinse it off
with clean water.
See a doctor if necessary.
Risk of damage to paintwork and leather and
plastic parts, and clothing. Electrolyte fluid
can be removed only while it is still wet.
fClean the affected parts with water.
10_Cayenne_21_KW17.book Seite 57 Donnerstag, 9. April 2009 3:33 15

58
Seats, Mirrors and Steering Wheel
Steering WheelTiptronic rocker switchesThe Porsche Tiptronic is a six-speed transmission
and features an “automatic” and a “manual” gear-
shift mode.
You can change temporarily to manual mode using
rocker switches A on the steering wheel.
fFor further information on gearshifting with
Tiptronic S:
Please see the chapter “TIPTRONIC S” on
Page 170.
HornfPress button B to operate the horn.Airbag unitAirbag unit C is located behind the padded
steering wheel boss.
In conjunction with the safety belts, the “airbag” is
a safety system designed to provide the driver and
passengers with maximum protection from injury
in an accident.
fFor further information on the airbag system:
Please see the chapter “AIRBAG SYSTEMS” on
Page 45.
Steering Wheel HeatingThe steering wheel heating is switched on and off
automatically when the ignition is switched on
depending on the interior temperature.On vehicles with manual air conditioningThe steering wheel heating switches itself on
when the following criteria are fulfilled at the same
time:
1. Low outside temperature.
2. Low engine temperature.
3. The interior temperature setting in the display
of the air conditioning is 10 and more bars.
or at the highest level (all bars) of the interior
temperature setting on the display of the air
conditioning.
The steering wheel heating switches itself off
again after a warming-up phase, or is switched off
if one of the criteria is no longer met.
fFor more information about setting the interior
temperature on vehicles with manual air condi-
tioning:
Please see the chapter “SETTING
TEMPERATURE” on Page 68.
10_Cayenne_21_KW17.book Seite 58 Donnerstag, 9. April 2009 3:33 15

Seats, Mirrors and Steering Wheel
59
Steering Wheel Adjustment
Warning!
Risk of accident. The steering wheel may
move further than desired if you attempt to
adjust it when driving.
You can lose control of the vehicle, causing
serious personal injury or death.
fDo not adjust the steering wheel when driving.
Risk of crushing due to uncontrolled recall of
seat memory settings.
fDo not leave children in the car unattended.
Manual adjustment
1. Swivel locking lever A downwards.
2. Adapt the steering wheel setting to the back-
rest angle and your seat position. Move the
steering wheel in the desired direction.
3. Swivel locking lever A back until you feel it
engage.Electrical adjustment
fPress control switch B in the relevant direction
until the desired setting is reached.
The steering wheel setting can be stored in the
seat memory.
fFor further information on storing and calling
up the steering wheel setting on vehicles with
comfort memory:
Please see the chapter “FRONT SEAT WITH
MEMORY” on Page 37.
10_Cayenne_21_KW17.book Seite 59 Donnerstag, 9. April 2009 3:33 15

60
Seats, Mirrors and Steering Wheel
Multi-Functional Steering Wheel
Warning!
There is a danger of accident if you set or
operate the on-board computer, radio, navi-
gation system, telephone or other equipment
when driving.
This could distract you from the traffic and
cause you to lose control of the vehicle resul-
ting in serious personal injury or death.
fOperate the components while driving only if
the traffic situation allows you to do so safely.
fCarry out any complicated operating or setting procedures only with the vehicle stationary.
Depending on the equipment in your vehicle, you
can use these function keys to operate the
following Porsche communication systems:
–PCM
–Radio
– Telephone,
– TV tuner,
– CD audio, DVD audio, DVD video,
or an iPod or USB storage device connected via
the universal audio interface.
Readiness for operation of multi-
functional steering wheel– With ignition switched on and
– With Porsche communication systems
switched on.
fPlease read and understand the operating in-
structions supplied for the Porsche communi-
cation systems before operating the function
keys.
Note on operation
The Porsche communication systems cannot be
switched on and off using the multi-functional
steering wheel.
Operating the function keysThe function keys on the steering wheel (arrows)
can be operated by pressing and by pulling.
Various functions may require you to press or pull
the buttons several times in order to achieve the
desired setting.
10_Cayenne_21_KW17.book Seite 60 Donnerstag, 9. April 2009 3:33 15
