Ram 2500 2011 (Gas and Diesel) Repair Manual

JOBNAME: 288987 2011 Maint-Wa PAGE: 28 SESS: 59 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/01bintervals-gas
❏Change the engine oil and oil filter.Under no circum-
stances should the oil change interval exceed 13,000 km
or 6 months whichever occurs first.*
❏Rotate tires, rotate at the first sign of irregular wear even if
it occurs prior to this service.
❏Lubricate the front drive shaft fitting. (All 4x4 models ex-
cept 1500)
❏Inspect the engine air filter if using your vehicle in dusty
or off-road conditions; replace if necessary.
❏Inspect the brake linings; replace if necessary.
❏Inspect the front suspension components, tie rod ends and
boot seals; replace if necessary.
* Oil changes that are prompted by the oil change indicator system prior to this
schedule maintenance interval can be recorded in the oil change log section.
Perform Maintenance At
182,000 km or 84 Months
Odometer Reading
Date
Repair Order No.
CHRYSLER
RETAILERSTAMP
Signature of authorized Chrysler Canada Retailer
................................................................................................

JOBNAME: 288987 2011 Maint-Wa PAGE: 29 SESS: 59 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/01bintervals-gas
Perform Maintenance At
195,000 km or 90 Months
❏Change the engine oil and oil filter.Under no circumstances should the oil change
interval exceed 13,000 km or 6 months whichever occurs first.*
❏Rotate tires, rotate at the first sign of irregular wear even if it occurs prior to this
service.
❏Lubricate the front drive shaft fitting. (All 4x4 models except 1500)
❏Inspect the front (4x4) and rear axle fluid; change if using your vehicle for any of
the following: police, fleet, off-road or frequent trailer towing.
❏Inspect the CV joints.
❏Inspect the exhaust system.
❏Change the automatic transmission fluid and filter.
❏Replace the accessory drive belt(s).
* Oil changes that are prompted by the oil change indicator system prior to this schedule maintenance interval can
be recorded in the oil change log section.
Perform Maintenance
At
90 Months or
195,000 km
Odometer Reading
DateRetailer Copy
Remove and attach to Repair Order
................................................................................................

JOBNAME: 288987 2011 Maint-Wa PAGE: 30 SESS: 59 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/01bintervals-gas
❏Change the engine oil and oil filter.Under no circum-
stances should the oil change interval exceed 13,000 km
or 6 months whichever occurs first.*
❏Rotate tires, rotate at the first sign of irregular wear even if
it occurs prior to this service.
❏Lubricate the front drive shaft fitting. (All 4x4 models ex-
cept 1500)
❏Inspect the front (4x4) and rear axle fluid; change if using
your vehicle for any of the following: police, fleet, off-
road or frequent trailer towing.
❏Inspect the CV joints.
❏Inspect the exhaust system.
❏Change the automatic transmission fluid and filter.
❏Replace the accessory drive belt(s).
* Oil changes that are prompted by the oil change indicator system prior to this
schedule maintenance interval can be recorded in the oil change log section.
Perform Maintenance At
195,000 km or 90 Months
Odometer Reading
Date
Repair Order No.
CHRYSLER
RETAILERSTAMP
Signature of authorized Chrysler Canada Retailer
................................................................................................

JOBNAME: 288987 2011 Maint-Wa PAGE: 31 SESS: 59 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/01bintervals-gas
Perform Maintenance At
208,000 km or 96 Months
❏Change the engine oil and oil filter.Under no circumstances should the oil change
interval exceed 13,000 km or 6 months whichever occurs first.*
❏Rotate tires, rotate at the first sign of irregular wear even if it occurs prior to this
service.
❏Lubricate the front drive shaft fitting. (All 4x4 models except 1500)
❏Inspect the brake linings; replace if necessary.
❏Inspect the front suspension components, tie rod ends and boot seals; replace if
necessary.
❏Adjust the parking brake on vehicles equipped with four-wheel disc brakes.
❏Replace the engine air filter.
❏Change the transfer case fluid. (4x4)
❏Replace the spark plugs on 3.7L and 5.7L engines.
❏Replace the ignition cables on 3.7L engines.
* Oil changes that are prompted by the oil change indicator system prior to this schedule maintenance interval can
be recorded in the oil change log section.
Perform Maintenance
At
96 Months or
208,000 km
Odometer Reading
DateRetailer Copy
Remove and attach to Repair Order
................................................................................................

JOBNAME: 288987 2011 Maint-Wa PAGE: 32 SESS: 59 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/01bintervals-gas
❏Change the engine oil and oil filter.Under no circum-
stances should the oil change interval exceed 13,000 km
or 6 months whichever occurs first.*
❏Rotate tires, rotate at the first sign of irregular wear even if
it occurs prior to this service.
❏Lubricate the front drive shaft fitting. (All 4x4 models ex-
cept 1500)
❏Inspect the brake linings; replace if necessary.
❏Inspect the front suspension components, tie rod ends and
boot seals; replace if necessary.
❏Adjust the parking brake on vehicles equipped with four-
wheel disc brakes.
❏Replace the engine air filter.
❏Change the transfer case fluid. (4x4)
❏Replace the spark plugs on 3.7L and 5.7L engines.
❏Replace the ignition cables on 3.7L engines.
* Oil changes that are prompted by the oil change indicator system prior to this
schedule maintenance interval can be recorded in the oil change log section.
Perform Maintenance At
208,000 km or 96 Months
Odometer Reading
Date
Repair Order No.
CHRYSLER
RETAILERSTAMP
Signature of authorized Chrysler Canada Retailer
................................................................................................

JOBNAME: 288987 2011 Maint-Wa PAGE: 33 SESS: 59 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/01bintervals-gas
Perform Maintenance At
221,000 km or 102 Months
❏Change the engine oil and oil filter.Under no circumstances should the oil change
interval exceed 13,000 km or 6 months whichever occurs first.*
❏Rotate tires, rotate at the first sign of irregular wear even if it occurs prior to this
service.
❏Lubricate the front drive shaft fitting. (All 4x4 models except 1500)
* Oil changes that are prompted by the oil change indicator system prior to this schedule maintenance interval can
be recorded in the oil change log section.
Perform Maintenance
At
102 Months or
221,000 km
Odometer Reading
DateRetailer Copy
Remove and attach to Repair Order
................................................................................................

JOBNAME: 288987 2011 Maint-Wa PAGE: 34 SESS: 59 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/01bintervals-gas
❏Change the engine oil and oil filter.Under no circum-
stances should the oil change interval exceed 13,000 km
or 6 months whichever occurs first.*
❏Rotate tires, rotate at the first sign of irregular wear even if
it occurs prior to this service.
❏Lubricate the front drive shaft fitting. (All 4x4 models ex-
cept 1500)
* Oil changes that are prompted by the oil change indicator system prior to this
schedule maintenance interval can be recorded in the oil change log section.
Perform Maintenance At
221,000 km or 102 Months
Odometer Reading
Date
Repair Order No.
CHRYSLER
RETAILERSTAMP
Signature of authorized Chrysler Canada Retailer
................................................................................................

JOBNAME: 288987 2011 Maint-Wa PAGE: 35 SESS: 59 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/01bintervals-gas
Perform Maintenance At
234,000 km or 108 Months
❏Change the engine oil and oil filter.Under no circumstances should the oil change
interval exceed 13,000 km or 6 months whichever occurs first.*
❏Rotate tires, rotate at the first sign of irregular wear even if it occurs prior to this
service.
❏Lubricate the front drive shaft fitting. (All 4x4 models except 1500)
❏Inspect the engine air filter if using your vehicle in dusty or off-road conditions;
replace if necessary.
❏Inspect the brake linings; replace if necessary.
❏Inspect the front (4x4) and rear axle fluid; change if using your vehicle for any of
the following: police, fleet, off-road or frequent trailer towing.
❏Inspect the CV joints.
❏Inspect the exhaust system.
❏Inspect the front suspension components, tie rod ends and boot seals; replace if
necessary.
❏Replace the top row of spark plugs on 4.7L engines.**
* Oil changes that are prompted by the oil change indicator system prior to this schedule maintenance interval can
be recorded in the oil change log section.
** Vehicles built with the 4.7L engine are equipped with sixteen spark plugs, one set is located on the top of the
engine under the coils and the second set is located on the side of the engine. The spark plugs located under the
coils are a standard plug and must be change every 78,000 kilometres. The spark plugs located on the side of the
engine are a premium plug and must be changed every 156,000 kilometres.
Perform Maintenance
At
108 Months or
234,000 km
Odometer Reading
DateRetailer Copy
Remove and attach to Repair Order
................................................................................................

JOBNAME: 288987 2011 Maint-Wa PAGE: 36 SESS: 60 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/01bintervals-gas
❏Change the engine oil and oil filter.Under no circum-
stances should the oil change interval exceed 13,000 km
or 6 months whichever occurs first.*
❏Rotate tires, rotate at the first sign of irregular wear even if
it occurs prior to this service.
❏Lubricate the front drive shaft fitting. (All 4x4 models ex-
cept 1500)
❏Inspect the engine air filter if using your vehicle in dusty
or off-road conditions; replace if necessary.
❏Inspect the brake linings; replace if necessary.
❏Inspect the front (4x4) and rear axle fluid; change if using
your vehicle for any of the following: police, fleet, off-
road or frequent trailer towing.
❏Inspect the CV joints.
❏Inspect the exhaust system.
❏Inspect the front suspension components, tie rod ends and
boot seals; replace if necessary.
❏Replace the top row of spark plugs on 4.7L engines.**
* Oil changes that are prompted by the oil change indicator system prior to this
schedule maintenance interval can be recorded in the oil change log section.
** Vehicles built with the 4.7L engine are equipped with sixteen spark plugs, one
set is located on the top of the engine under the coils and the second set is
located on the side of the engine. The spark plugs located under the coils are a
standard plug and must be change every 78,000 kilometres. The spark plugs
located on the side of the engine are a premium plug and must be changed
every 156,000 kilometres.
Perform Maintenance At
234,000 km or 108 Months
Odometer Reading
Date
Repair Order No.
CHRYSLER
RETAILERSTAMP
Signature of authorized Chrysler Canada Retailer
................................................................................................

JOBNAME: 288987 2011 Maint-Wa PAGE: 37 SESS: 59 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/01bintervals-gas
Perform Maintenance At
247,000 km or 114 Months
❏Change the engine oil and oil filter.Under no circumstances should the oil change
interval exceed 13,000 km or 6 months whichever occurs first.*
❏Rotate tires, rotate at the first sign of irregular wear even if it occurs prior to this
service.
❏Lubricate the front drive shaft fitting. (All 4x4 models except 1500)
* Oil changes that are prompted by the oil change indicator system prior to this schedule maintenance interval can
be recorded in the oil change log section.
Perform Maintenance
At
114 Months or
247,000 km
Odometer Reading
DateRetailer Copy
Remove and attach to Repair Order
................................................................................................
