RENAULT CLIO 2003 X65 / 2.G Owners Manual
Manufacturer: RENAULT, Model Year: 2003, Model line: CLIO, Model: RENAULT CLIO 2003 X65 / 2.GPages: 210, PDF Size: 5.64 MB
Page 1 of 210
Q X B I U D B * T [ G 3 D J H
nu654-6 - CLIO IIC:\Documentum\Checkout
u654-6_eng_T1.WIN 4/11/2002 13:44- page 1
Page 2 of 210
Q X B I U D B * T [ G 3 D J H
nu654-6 - CLIO IIC:\Documentum\Checkout
u654-6_eng_T1.WIN 4/11/2002 13:44- page 2
RENAULT
recommends
Page 3 of 210
Q X B I U D B * T [ G 3 D J H
nu654-6 - CLIO IIC:\Documentum\Checkout
u654-6_eng_T1.WIN 4/11/2002 13:44-page3
0.01
Welcome to your new RENAULT
This driver’s handbookcontains all the information you will need:
• to get to know your Renault, to use it to the best advantage and to benefit from all the latest technical developments
which are incorporated in it.
• to ensure that it is always running well by following the simple, but strict, advice concerning regular maintenance.
• to enable you to deal quickly with minor faults which do not require specialist attention.
The few minutes you spend reading this handbook will be amply rewarded by the information which it provides and the
technical innovations it will bring to your attention. If certain points are still unclear, the technicians in our Network will
be happy to provide you with any additional information you may require.
The following symbols are used in this handbook to help you while you are reading it:
To indicate a risk, danger or safety advice.
The description of the models given in this handbook is based on the technical specifications known at the date this
document was produced.The handbook covers all equipment(standard or optional)which is available for these
models, but their presence on the vehicle depends on the version, options selected and country of marketing.
Certain equipment which is due to be made available during the year may also be included in this handbook.
Enjoy driving your new Renault.
Copying or translation, in part or in full, is forbidden without written permission from Renault, 92100 Billancourt 2002.
Page 4 of 210
Q X B I U D B * T [ G 3 D J H
nu654-6 - CLIO IIC:\Documentum\Checkout
u654-6_eng_T1.WIN 4/11/2002 13:44- page 4
0.02
Brief overview
• Tyre pressures .............................................................................................. 0.04 - 0.05
• Adjusting the seats and driving position ............................................... 1.11
¬1.14
• Child restraints ........................................................................................... 1.24
¬1.36
• Warning lights ............................................................................................ 1.42
¬1.52
• Horn and headlamp flash ............................................................. 1.55
¬1.57 - 1.62
• De-icing .................................................................................................................... 1.61
• Running in, driving ................................................................................... 2.02
¬2.30
• Heating/air conditioning ........................................................................... 3.04
¬3.22
• Opening the bonnet ............................................................................................... 4.02
• Levels (engine oil, windscreen washer, etc.) .......................................... 4.03
¬4.11
• Emergency spare wheel ............................................................................ 5.02
¬5.05
• Practical advice (changing the bulbs, fuses, repairs, operating
incidents) .................................................................................................... 5.02
¬5.34
Page 5 of 210
Q X B I U D B * T [ G 3 D J H
nu654-6 - CLIO IIC:\Documentum\Checkout
u654-6_eng_T1.WIN 4/11/2002 13:44- page 5
0.03
CONTENTS
Sections
1
2
3
4
5
6
7Getting to know your car.....................................................................
Driving...............................................................................................................
Your comfort.................................................................................................
Maintenance..................................................................................................
Practical advice...........................................................................................
Technical specifications........................................................................
Alphabetical index....................................................................................
Page 6 of 210
Q X B I U D B * T [ G 3 D J H
nu654-6 - CLIO IIC:\Documentum\Checkout
u654-6_eng_T1.WIN 4/11/2002 13:44- page 6
0.04
Tyre inflation pressures when cold(in bar)
Versions1.2
1.2 16V1.4 16V
1.6 16V2.0 16V1.5 dCi
1.9 dCi
Tyre sizes 175/65 R14 T
185/55 R15 H175/65 R14 T
185/55 R15 H195/45 R16 195/50 R15 175/65 R14 T
185/55 R15 H
Normal use(2)
• Front 1.9 2.2 (1) 2.3 2.3 2.2
•Rear 1.822.12.12
Motorway use(2)
• Front 2 2.3 (1) 2.7 2.5 2.3
• Rear 2 2.1 (1) 2.2 2.2 2.1
Wheel sizes5.5 J 14
6.0 J 157 J 16 7 J 16 5.5 J 14
6.0 J 15
Tyre safety and use of chains
Refer to the information on tyres in Section 5 for information on maintenance and, depending on the version, the
conditions under which snow chains may be fitted to the vehicle.
Special features of the 2.0 16V version
The tyres on this vehicle cannot be fitted with chains. If you wish to fit snow chains, you must usespecial equipment.
Consult your Renault Dealer.
(1)Vehicle with automatic transmission:add0.1 bar.
(2)Special note concerning vehicles used under full load(maximum permissible all-up weight)and towing a trailer:
Maximum speed must be limited to 60 mph (100 km/h) and the tyre pressure increased by0.2 bar(or3PSI).
Refer to the information on weights in Section 6 for more details.
Page 7 of 210
Q X B I U D B * T [ G 3 D J H
nu654-6 - CLIO IIC:\Documentum\Checkout
u654-6_eng_T1.WIN 4/11/2002 13:44-page7
0.05
Tyre pressures when cold(in PSI) (continued)
Versions1.2
1.2 16V1.4 16V
1.6 16V2.0 16V1.5 dCi
1.9 dCi
Tyre sizes 175/65 R14 T
185/55 R15 H175/65 R14 T
185/55 R15 H195/45 R16 195/50 R15 175/65 R14 T
185/55 R15 H
Normal use
•Front 28 32 (1) 33 33 32
•Rear 2629303029
Motorway use(2)
• Front 29 33 (1) 39 36 33
• Rear 28 30 (1) 32 32 30
Wheel sizes5.5 J 14
6.0 J 157 J 16 7 J 16 5.5 J 14
6.0 J 15
Tyre safety and use of chains
Refer to the information on tyres in Section 5 for information on maintenance and, depending on the version, the
conditions under which snow chains may be fitted to the vehicle.
Special features of the 2.0 16V version
The tyres on this vehicle cannot be fitted with chains. If you wish to fit snow chains, you must usespecial equipment.
Consult your Renault Dealer.
(1)Vehicle with automatic transmission:add3PSI.
(2)Special note concerning vehicles used under full load(maximum permissible all-up weight)and towing a trailer:
Maximum speed must be limited to 60 mph (100 km/h) and the tyre pressure increased by0.2 bar(or3PSI).
Refer to the information on weights in Section 6 for more details.
Page 8 of 210
Q X B I U D B * T [ G 3 D J H
nu654-6 - CLIO IIC:\Documentum\Checkout
u654-6_eng_T1.WIN 4/11/2002 13:44-page8
0.06
Page 9 of 210
Q X B I U D B * T [ G 3 D J H
nu654-6 - CLIO IIC:\Documentum\Checkout
u654-6_eng_T1.WIN 4/11/2002 13:44-page9
1.01
Section 1: Getting to know your car
Keys - plip remote control unit ............................................................................................................ 1.02 - 1.03
Doors ....................................................................................................................................................... 1.04 - 1.05
Automatic locking of doors when driving ..................................................................................................... 1.06
Engine immobiliser system ................................................................................................................... 1.07 - 1.08
Head restraints - Seats ......................................................................................................................... 1.09
¬1.12
Seat belts/Methods of restraint in addition to the front seat belts ................................................. 1.13
¬1.23
Child safety ........................................................................................................................................... 1.24
¬1.36
Clock and external temperature ...................................................................................................................... 1.37
Driving position ................................................................................................................................... 1.38
¬1.41
Instruments ........................................................................................................................................... 1.42
¬1.49
On-board computer .......................................................................................................................... 1.50
¬1.52
Rear-view mirrors .................................................................................................................................. 1.53 - 1.54
Steering wheel .................................................................................................................................................. 1.54
Lighting and external signals ............................................................................................................... 1.55 - 1.56
Headlight beam adjustment ............................................................................................................................. 1.57
Wipers ................................................................................................................................................... 1.58
¬1.60
De-icing .............................................................................................................................................................. 1.61
Visible and audible warning signals ............................................................................................................... 1.62
Fuel tank (filling with fuel) .................................................................................................................. 1.63 - 1.64
Page 10 of 210
1
2
Q X B I U D B * T [ G 3 D J H
nu654-6 - CLIO IIC:\Documentum\Checkout
u654-6_eng_T1.WIN 4/11/2002 13:44-page10
1.02
KEYS / RADIO FREQUENCY REMOTE CONTROL
1Remote control coded ignition
key, key for doors and fuel filler
cap.The plip remote control1locks and
unlocks the doors.
It is supplied with power by a
battery which has to be replaced
when the battery tell-tale light2no
longer comes on. (Refer to the
information on the radio frequency
remote control batteries.)
If there is a child (or
animal) in the car, never
leave it unattended with
the key in the ignition.
With the key in the ignition it
would be possible to operate
electrical equipment such as the
window risers and there is a risk
that the child may be seriously
injured (by trapping his or her
neck, arm, hand, etc.).
Locking/unlocking the doors
Press the remote control for
approximately one second to lock or
unlock the doors. (Tell-tale light2
will switch on.)
- The hazard warning lights flash
twiceto indicate that the doors
have beenlocked.
Note:Depending on the vehicle, if
eitheradoorortailgateisopenor
not properly closed or if a rear
interior light remains in the
“continuous lighting” position
(see information on interior lights
in section 3), the hazard warning
lights will not flash.
- The hazard warning lights flash
onceto indicate that the doors
have beenunlocked.
