C-21

B.6.3.4.2 SECONDARY ALARMS (CATEGORY B)
All non Cat A alarms are classified in the category B. They are clearly displayed to the
driver, but he is still able to drive normally (the dashboard information remains normally
readable).
A message is displayed in the Area “Default”
In addition with the message displayed, the corresp onding alarm LED becomes ORANGE:
- 1 Right HS column (gearbox diagnostic)
- 1 Left HS column (engine diagnostic)

If 1 or more alarms are present, the messages are s crolling in the “default” area


B.6.3.4.3 A
LARMS AND THRESHOLD

Category Message Alarm LED Meaning Threshold
A “V BAT MIN”
+ value in Red 4 LEFT + 3 RIGHT Min. battery voltage
V batt < 11V and
revs > 4000 rpm
B “V BAT MAX”
+ value in Orange 1 Left Max. battery voltage V batt > 15V
B “OILP max”
+ value in Orange 1 Left Max. oil pressure Oil P > 6 bar
A “OILP min”
+ value in Red 4 LEFT + 3 RIGHT Min. oil pressure Oil P < 1.5 bar and
revs > 3000rpm
A “Water T Max”
+ value in Red 4 LEFT + 3 RIGHT Max. water temperature
> 105°C and
revs > 1000 rpm
B “Water T Min”
+ value in Orange 1 Left Min. water temperature <40°C and
revs > 4000rpm
B "AIR T MAX"
+ value in Orange 1 Left Max. air temperature
Air T > 90°C
revs > 1000 rpm
B “HP fuel min”
+ value in Orange 1 Left Min HP fuel pump (rail pressure) < 300 mbars and
revs > 1500 rpm
B “LP fuel min”
+ value in Red 1 Left Min LP fuel pump
< 3 bars and
revs<1000rpm
B "Throttle - def"
+ value in Blue 1 Left Electrical fault on electrical throttle pot.
-
B “Pedal - def”
+ value in Blue 1 Left Electrical fault on pedal pot -
B "Boost P/ air T - def"
+ value in Blue 1 Left Electrical fault on boost pressure / air Tem
p sensor -
Engine
alarm LED gearbox
alarm LED

Downloaded from www.Manualslib.com manuals search engine 98CUP_2013 Release

C-22

B " Manifold P - def"
+ value in Blue 1 Left Electrical fault on manifold sensor -
B "Oil P - def"
+ value in Blue 1 Left Electrical fault on oil pressure sensor -
B
"Water T - def"
+ value in Blue 1 Left Electrical fault on water temperature sensor -
B
“Throt FBW * def”
+ value in blue 1 Left Electrical fault on motorised throttle
B
“High press def”
+ value in Blue 1 Left High pressure sensor default -
B
“Low press def”
+ value in Blue 1 Left Low pressure sensor default -
B
" V.V.T.1 - def"
+ value in Blue 1 Left Intake V.V.T. servo control default difference > 10°
between VVT1_tg and VVT1_pos during more than 5s
B “GB actuator - def”
+ value in Blue 1 Right Gearbox actuator default
(only if connected) -
B "GB Pot - def"
+ value in Blue 1 Right Electrical default on barrel position senso
r -
B “up contact – def”
+ value in Blue 1 Right Electrical default on upshift contactor -
B “Solenoid R”
+ value in Blue 1 Right Electrical default on reverse solenoid (barrel
unlocking) -
B "CBNT - Can Def" - CAN CBNT fault -
B "Steering - def" - Major/minor fault on power ste
ering module -
“Gear” - Gear button pressed, message displayed in the
middle of the screen without alarm

"Pit Limiter" - Speed limiter enabled, message displayed on the top of the screen without alarm
-

B.6.4 BASIC PROCEDURES
B.6.4.1 Power-up

Press the “ON” button of the facia switch panel
(See B.6.1) to power supply the vehicle
The “COSWORTH” home page appears when the dashboard display first comes on, and
then moves to the first driver page (RACE Page)
B.6.4.2 Starting

Once the vehicle’s electrics are on, flick the vehi cle's “IGNITION” switch to the up (ON)
position.
Check that no gear is engaged (the letter “N” is di splayed on one of the display screen’s
driver pages).
Press on the “START” button without touching the Gas Pedal


The vehicle will only start if the following elect ronic equipments are connected
and are working properly:
- ECU
- CBNT
- Master relay
It is possible to start without plugging the dashbo ard
NOTE :
For the first engine start after engine refitting, it’s necessary to bleed the fuel
rail. To make it properly, please follow carefully the procedure indicated in chapter C-
Engine

Downloaded from www.Manualslib.com manuals search engine 98CUP_2013 Release

C-23

B.6.4.3 Turning off the engine

Flick the “IGNITION” switch to the down (OFF) posit ion

NOTE : The vehicle’s electrics remain switched on
Except in the event of an emergency stop, it’s stri ctly not advised to turn off the
engine using the power supply switch (OFF button).
It is also recommended to wait 30seconds between sw itching off the engine and
switching off the power supply.
Respecting these two recommendations will guarantee optimum operation of the power
steering.
B.6.4.4 Switching off the power supply

Press the “OFF” button of the facia switch panel an d hold there for at least half a second.
The dashboard display is switched off.
NOTE: Switching off the power supply also switches off th e engine.

B.6.4.5 Changing gears

2 modes are possible and are completely independent . It’s possible to make randomly
upshift and downshift manually (using the lever) or in semi-auto using paddle shift kit.

Please refer to Chapter D-Transmission/shifting for a complete description of the shifting
modes.
B.6.4.6 Pit limiter

The purpose of this function is to limit the vehicl e's speed to 60kph
. It is enabled and
disabled by the driver.
Principle:
By pressing the button “PIT” of the steering wheel, Engine revs are thus limited (by the
ECU) to those corresponding to a speed of 60kph and the message “PIT LIMITER” is
displayed on the dashboard in the RPM Area :

Downloaded from www.Manualslib.com manuals search engine 98CUP_2013 Release

C-24

If the pit limiter is activated while the current s peed is > 60kph, all the Shiftlights flashes
together till the vehicle reach 60kph (at this part icular moment, all shiftlights remains ON
but without flashing)


NOTE
: The speed limiter does not control the brakes. Cons equently, the vehicle speed
will only slow rapidly to 60kph if the driver appli es the brakes.

To disable the pit limiter mode, the driver has to press the button “PIT” of the steering
wheel : the message “ Pit Limiter” disappears on the display.

Specific conditions:
The driver may only enable and disable the speed li miter when the vehicle is in on a
forward gear (1 to 4)
B.6.4.7 Controlling the rain light

The rain light is switched on by flicking the “rain ” switch to the up position (ON).

The central rear rain light is ON continuously whe n enabled.

However, it is lightning automatically with flashin g phases (flashes at 0.5Hz) in the
following specific situations: - When the Pit limiter is enabled
- For a period of 20 seconds after the engine stall s
- When Reverse Gear ratio is shifted

Downloaded from www.Manualslib.com manuals search engine 98CUP_2013 Release

C-25

B.6.4.8 Resetting the chassis sensors

This procedure allows to reset the following sensor s:
- Front Brake pressure sensor
- Rear brake pressure sensor
- Steering angle sensor
It is necessary to make a reset if one of the follo wing sensor has been changed or if the
brake circuit has been bleeded.
CONDITIONS :


The car must be in the following configuration to a llow the procedure:
- Engine stalled
- Gearbox in Neutral
- Speed = 0 kph
- Brake pedal released
- Steering wheel straight
- Car on a flat surface · Press the “ON” button to power supply the car
· Display the “brake diagnostic” page
· Press the “RESET” button, the following message app ears :

· press again the “RESET” button gain to start the pr ocedure or “PAGE” button
(steering wheel) to cancel it

· Check in the “brake diagnostic” page that the value of :
Front BP = 0 bar
Rear BP = 0 bar
Steering angle = 0 °

This page only reminds
the conditions to
perform the RESET
procedure

Downloaded from www.Manualslib.com manuals search engine 98CUP_2013 Release

C-26

B.6.5 ADJUSTING THE DRIVING POSITION

B.6.5.1 Adjusting the steering wheel

To optimize the driving position, the height and de epness of the steering wheel may be
adjusted by unlocking the steering column lever (1)


NOTE :
After having set the
steering column position,
the adjustment lever
must be removed (1
screw to remove). It is
strictly forbidden to run
with it (FIA regulation)



B.6.5.2 Adjusting the seat

To move the seat forwards or backwards, place the s eat in the required position and then
re-screw the brackets in the appropriate holes (2).

The height and angle of the seat may be adjusted th e same way by altering its
attachment points on the brackets (3).


(2)
(3)

Downloaded from www.Manualslib.com manuals search engine 98CUP_2013 Release

C-27

B.6.6 VENTILATION

The vehicle has 4 air vents: · 1 in the middle of the facia : activated by the “he at” switch on facia switch panel
· 2 on the roof: air coming though the roof hatch

Ventilation on the facia upper surface:

View from below:
The air comes from the electric ventilator and is directed by the lower duct to the facia


Electric
ventilator fitted
on the engine
bulkhead

Downloaded from www.Manualslib.com manuals search engine 98CUP_2013 Release

C-28

Roof ventilation:

B.7 SAFETY EQUIPMENT

B.7.1 FIRE EXTINGUISHER

Each vehicle is equipped with an extinguishing
system targeting the driver compartment and the
engine compartment.
The fire extinguisher is located behind the driver’ s
seat.




The fire extinguisher is fitted on its support usin g 2 metallic straps which are mandatorily
screwed (automatic clamping forbidden).
The fire extinguisher support is fitted on the chas sis using 4 M6 screws (+2 spacers) + 4
nuts screwed under the chassis through plates (weld ed to the chassis)

Control unit
(3 positions)
2 mandatory
screwed clamps
Roof hatch Inside aerator

Downloaded from www.Manualslib.com manuals search engine 98CUP_2013 Release

C-29

The system consists of 3 jets:
· In the driver compartment right hand side of the st eering wheel


· 2 in the engine compartment

1 pointing on the Turbo : 1 pointing on the air intake :

Use:
The extinguishing system can be triggered in 2 different ways:

· The driver presses on the button “Fire Ext” situate d on the Facia
control panel (9)
· From Outside: by pressing the button (E) located on the outside of the vehicle at
the base of the windshield pillar, and which must b e indicated by a red letter E.

Downloaded from www.Manualslib.com manuals search engine 98CUP_2013 Release

C-30

You must fit the wiring of the white connector directly on the plastic windscreen lower
grid using a tyrap® as indicated below:



The fire extinguisher is controlled by a deported c ontrol unit fitted on the central tunnel.
A specific fire extinguisher loom allows to link th is control unit + fire extinguisher to the
chassis loom.

Position 1: system isolated

This position is to test the extinguisher loom. Eve rything must be correctly connected to
the loom. When you push the fire button (Facia swit ch panel or from outside deported
button), the green light must go ON but the extinguisher will n ot deploy.


NOTE :
if the green light is ON without testing the syste m, there is a default on the
loom. In this case, you must be careful because the extinguisher is directly connected to
the command box. As a consequence, if you switch to position 3, you will immediately
deploy the extinguisher.
Position 2: battery check


If the orange light goes ON, the battery is ok.
Position 3: system armed


“System armed” means that if you push the fire butt on (Facia switch panel or from
outside deported button), you will immediately depl oy the extinguisher.
The green light goes ON only when the extinguisher is deployed.
3
1
2 deported
