C-31
Checks
-
Extinguisher cylinder compliance check:
The following information must be clearly
visible on the cylinder: · Serial number.
· Capacity and weight or volume of
extinguisher product.
· Activation date or date of last system check.
· Date of next service.
· Homologation number.
Take care not to exceed the extinguisher’s
next scheduled service date.
- Pressure check
The pressure of the cylinder may be checked using a
manometer placed on the cylinder.
The needle must be situated in the green area on th e
manometer dial.
B.7.2 CIRCUIT BREAKER
There is an emergency circuit breaker control at
the base of the windshield pillar. It must be
indicated by a sticker with a red lightening symbol
on a blue background. This button may be used to
switch off the vehicle’s electrics from the outside .
B.7.3 OTHER SAFETY EQUIPMENT
- The presence of the window safety net (ref. 77 11 160 041) on the driver side of
the roll cage is mandatory.
- It is mandatory for foam (ref 77 11 160 040) to be placed on all parts of the roll
cage with which the driver’s helmet may come into c ontact.
- The seats (original part ref: 77 11 167 158 and XL version part ref: 77 11 167
160 ) and the harness (ref 77 111 167 161) are compatible with FHR system.
The use of « FHR » system must be in compliance with the installation
standard of FIA.
Page 32 of 35

Downloaded from www.Manualslib.com manuals search engine 98CUP_2013 Release
C-32
B.7.4 PASSENGER SEAT
A passenger seat may be installed on Clio Cup using the supports with part ref
8201380465 and 8201380466
The seats references remain the same as for driver side.
Fasteners:
Seat supports on the chassis:
Screws CHC10-25 x 4 77 11 156 901
Contact washer Ø10X22 x 4 77 11 156 926
Flat washer Ø10,25X26 ép:3 cl:10.9 x 4 77 03 053 341
Seat on the support :
Screws M8-35 cl.12,9 x 4 77 11 154 904
Contact washer Ø8X18 x 4 77 11 156 945
B.8
BALLAST
To respect the minimum weight
and the race weight
(refer to technical regulation and Nomenclature), s ome
ballast may be fitted.
Only the following ballast must be used: - 1kg: ref 77 11 160 299
- 2kg: ref 77 11 160 300
- 5kg: ref 77 11 160 301
These plates must be mounted using two drilled head
bolts with part ref 77 11 160 302 (sold in sets of 2).
In all cases, these ballast plates will be fitted a t the passenger seat rail sites,
(refer to the current Technical Regulations and Nom enclature).
Page 33 of 35

Downloaded from www.Manualslib.com manuals search engine 98CUP_2013 Release
C-33
B.9 APPENDIX
B.9.1 LIST OF MARKED PARTS
All parts that are specific to Clio Cup are engrave d.
The following genuine Renault parts are identified either by a “Renault Sport” laser
engraving or by a hologram (its presence is compuls ory with NO PAINT)
PART NAME REFERENCE “RENAULT SPORT” HOLOGRAM
Engine bulkhead heat shield 67900 6317 R X
Front shock absorber 98CUP00040 X
Rear Wing 8201380868 X
Battery 7711127895 X
Rear spoiler 96030 5963 R X
Airbox 8201378943 X
Steering column 8201372112 X
Air intake duct 8201409155 X
Left lower air Guide 21469 1078 R X
Left air guide 21559 0558 R X
Right air guide 21558 9177 R X
Roof inside aerator 77 11 160 315 X
Battery cover 77 11 162 704 X
Dashboard Cosworth ICD 82 01 372 416 X
ECU Cosworth SQ7 82 01 381 101 X
Front left door inside cover 82 01 382 021 X
Front right door inside cover 82 01 382 023 X
Facia air duct 82 01 389 867 X
Fire extinguisher 82 01 396 046 X
Water Fan 214819617R X
Rear spoiler lower cover 960303776R X
Turbo air exchanger 98CUP00006 X
Complete fuel tank 98CUP00008 X
Water cooler 98CUP00009 X
Front Right headlight 98CUP00015 X
Front Left headlight 98CUP00017 X
Rear Right light on rear cover 98CUP00022 X
Rear Left light on rear cover 98CUP00024 X
FR door window 98CUP00058 X
FL door window 98CUP00059 X
RR door window 98CUP00061 X
RL door window 98CUP00062 X
RR quarter window 98CUP00063 X
RL quarter window 98CUP00064 X
Rear bumper skin 98CUP00065 X
Rear window 98CUP00068 X
Right rearview mirror 98CUP00070 X
Left rearview mirror 98CUP00071 X
Left rearview mirror cover 98CUP00072 X
Right rearview mirror cover 98CUP00073 X
Windscreen 98CUP00084 X
Roof hatch 82 01 383 889 X
Front crossbeam 752107246R X
rear air diffuser 960302211R X
FR mudguard 98CUP00074 X
Page 34 of 35

Downloaded from www.Manualslib.com manuals search engine 98CUP_2013 Release
C-34
FL Mudguard 98CUP00075 X
FR door 98CUP00076 X
FL dooe 98CUP00077 X
Front cover 98CUP00080 X
Rear cover 98CUP00081 X
Fuel pump / gauge 98CUP00093 X
RR door 98CUP00078 X
RL door 98CUP00079 X
Gearbox command rod 809mm 8201418758 X
Gearbox command rod 784mm 8201418759 X
Rear camber/alignment shim 10’ 8201369770 X
Rear camber/alignment shim 20’ 8201369771 X
Rear camber/alignment shim 30’ 8201369772 X
Rear camber/alignment shim 1° 8201369773 X
Anti-roll bar 54611 9898 R X
Anti-roll bar rod 8201079463 X
Front master cylinder 19,1mm 77 11 158 019 X
Rear master cylinder 20.6mm 77 11 158 025 X
Gearbox manual lever 77 11 160 560 X
Clutch mechanism 77 11 160 633 X
FR calliper 77 11 160 362 X
FL Calliper 77 11 160 363 X
FL upright 77 11 160 481 X
FR upright 77 11 160 480 X
Turbo upstream pipe 82 01 370 056 X
Flywheel 82 01 350 850 X
AP clutch disc 82 01 370 335 X
Front brake disc AP 320x28 82 01 395 136 X
Front calliper support 82 01 403 772 X
Front hub 432000010R X
Subframe crossbeam 82 00 537 434 X
RR central hub 98CUP00035 X
RL central hub 98CUP00036 X
FR wishbone 82 01 361 749 X
FL wishbone 82 01 361 750 X
Front brake pad RC6ER 8201442791 X
Rear brake pads RC6 77 11 162 956 X
Rear brake pads RC5+ 77 11 162 954 X
Page 35 of 35

Downloaded from www.Manualslib.com manuals search engine 98CUP_2013 Release
C-35
B.9.2 REPLACEMENT OF MECHANICAL COMPONENTS
The mileage of the below parts must be monitored by the user throughout the vehicle’s
lifetime.
The mileage stated in the table below is the maximu m expected mileage before
replacement, notwithstanding any incidents or accid ents.
Should any component become faulty or its condition deteriorate before reaching the
stated mileage, please contact Renault Sport Techno logies.
NOTE :
This list may not under any circumstances be cons idered to be part of the
manufacturer’s warranty.
Parts Recommanded milage
Front axle
Point E and Point F ball joint 5000 km
Wishbone ball joints 3000 km
Wheel bearing 5000 km
Shock absorbers + Bump stop 5000 km
Support strut 10000 km
Anti-roll ball joint 7000 km
Wheel stud and nut 5000 km
Rear Axle
Point F ball joint 7000 km
Point E ball joint 7000 km
Point A ball joint 7000 km
Wheel bearing 5000 km
Shock absorbers + Bump stop 5000 km
Wheel stud and nut 5000 km
Steering
Power steering module 15000 km
Steering rack 7500 km
Steering rod ball joint (point H) 7000 km
Rack ball joint 7000 km
Transmission
Gearbox 7500 km
Clutch friction 4500 km
Clutch mecanism 4500 km
Slave cylinder bearing 5000 km
Driveshafts 5000 km
Engine
Engine / Turbo / HP pump / WG / pop off 10000 km
Starter / alternator 10000 km
Engine + Gearbox mountings 10000 km
Motorised Throttle 6000 km
Gas Pedal potentiometer 10000 km
Brakes
Front brake disc 1500 km
Front brake caliper 6000 km
Rear brake disc 8000 km
Rear brake calliper 8000 km
NOTE:
Particular attention must be paid to the state of t he fasteners after any work has
been carried out.
