RENAULT KANGOO 1998 KC / 1.G Heating And Ventilation Workshop Manual 77 11 198 230FEBRUARY 1998Edition Anglaise
Heating and Ventilation
HEATING
Renault 1998
"The repair methods given by the manufacturer in this document are based on the
technical specifications current

Page 2 of 73

RENAULT KANGOO 1998 KC / 1.G Heating And Ventilation Workshop Manual EXPLODED VIEW
PRO60.5

Page 3 of 73

RENAULT KANGOO 1998 KC / 1.G Heating And Ventilation Workshop Manual Contents
Pages
Heating and
Ventilation
Control panel
Control cables
Particle filter
Fan assembly (GMV)
Radiator
Air distribution unit61-1
61-2
61-3
61-4
61-5
61-6 HEATING
61
General
Fault finding - In

Page 4 of 73

RENAULT KANGOO 1998 KC / 1.G Heating And Ventilation Workshop Manual HEATING
Control panel
61
REMOVAL
Disconnect the battery.
Remove:
- the ashtray,
- the mounting screws.
92224S
12963R
- the two screws securing the control panel to
the dashboard.
12963R1
Disconnect :

Page 5 of 73

RENAULT KANGOO 1998 KC / 1.G Heating And Ventilation Workshop Manual Fit the complete control panel without screwing it
in place.
On the bottom right-hand side
Fit the cable on to the mark.
Place the air distribution control on position
                , place  the he

Page 6 of 73

RENAULT KANGOO 1998 KC / 1.G Heating And Ventilation Workshop Manual HEATING
Particle filter
61
PRO61.1
REFITTING
Refitting is carried out in reverse order to removal.
Check to make sure that the water drainage channel is correctly fit-
ted in place.
REPLACEMENT
Refer

Page 7 of 73

RENAULT KANGOO 1998 KC / 1.G Heating And Ventilation Workshop Manual HEATING
Fan assembly (GMV)
61
PRO61.2
Take out the fan assembly through the right-hand
side of the plenum chamber.
REFITTING
Refitting is carried out in reverse order to remo-
val.
Check the condition

Page 8 of 73

RENAULT KANGOO 1998 KC / 1.G Heating And Ventilation Workshop Manual HEATING
Radiator
61
13084S98816R
13085S
Other type of quick-release hose clamps.
REMOVAL
The radiator is removed after first removing the
air blower unit, the dashboard and the air distri-
bution unit

Page 9 of 73

RENAULT KANGOO 1998 KC / 1.G Heating And Ventilation Workshop Manual HEATING
Air distribution unit
61
12969-1R
12965-1R
- the visor and the instrument panel,
- the switch stalk block assembly.
REMOVAL
Disconnect the battery.
Remove :
- the steering wheel bolt,
- the st

Page 10 of 73

RENAULT KANGOO 1998 KC / 1.G Heating And Ventilation Workshop Manual HEATING
Air distribution unit
61
13084S
13069R3
13085S
Other type of quick-release clamps. Engine compartment end
Fit a hose clamp and disconnect the quick-release
clamps from the heater hoses.Fit a d
