check engine RENAULT SCENIC 2011 J95 / 3.G Engine And Peripherals EDC16C36 Workshop Manual

13B-184
AFTER REPAIRDeal with any other faults. Clear the fault memory.
Switch off the ignition until the end of the power-latch phase, and carry out a road test
followed by a check using the diagnostic tool.
V9 MR-372-J84-13B450$104.mif
DIESEL INJECTION
Fault finding – Interpretation of faults13B
DF647
CONTINUED
Check the condition of the connector of the EGR valve (see Wiring Diagram Technical Note, Mégane II ph2,
Scénic II ph2, Component code 1460).
Check the condition of the engine management computer connector (see Wiring Diagram Technical Note,
Mégane II ph2, Scénic II ph2, component code 120).
If the connector(s) is/are faulty and if there is a repair procedure (see Technical Note 6015A, Repairing electrical
wiring, Wiring: Precautions for repair), repair the connector, otherwise replace the wiring.
Check for continuity and absence of interference resistance of the following connections:
– Connection code 3GC between components 1460 and 120.
– Connection code 3JM between components 1460 and 120.
– Connection code 3EL between components 1460 and 120.
If the connection or connections are faulty and there is a repair method (see Technical Note 6015A, Repairing
electrical wiring, Wiring: Precautions for repair), repair the wiring, otherwise replace it
EGR valve with a square connector:
Measure the resistance of the EGR valve between the following connections:
– Connection code 3JM of component 1460.
– Connection code 3GC of component 1460.
EGR valve with a flat connector:
Replace the EGR valve.
Replace the valve if the resistance is not between: 3.9 kΩ When replacing the EGR valve, run command SC036 Reinitialise programming and select EGR valve to
reinitialise the EGR valve offsets (see Replacement of components).
EDC16 C36
Program No.: 91
Vdiag No.: 44, 4C, 48,
50, 54, 58

13B-185
AFTER REPAIRDeal with any other faults. Clear the fault memory.
Switch off the ignition until the end of the power-latch phase, and carry out a road test
followed by a check using the diagnostic tool.
V9 MR-372-J84-13B450$104.mif
DIESEL INJECTION
Fault finding – Interpretation of faults13B
DF652
PRESENT
OR
STOREDTURBINE UPSTREAM TEMPERATURE SENSOR CIRCUIT
CC.O: Short circuit to earth
CO.1: Open circuit or short-circuit on +12 V.
NOTESConditions for applying fault finding procedures to stored faults:
The fault becomes present with the ignition on (CC.0) or after a road test, with the
engine warm (CO.1).
Special notes:
If the fault is present:
– particle filter regeneration is inhibited,
– the vehicle performance is reduced,
– temperature regulation before the particle filter is inhibited.
Use Wiring Diagram Technical Note, Mégane II ph2, Scénic II ph2.
CC.0
NOTESNone.
Check the condition of the turbine upstream temperature sensor connector.
Check the condition of the engine management computer connector.
If the connector or connectors are faulty and if there is a repair procedure (see Technical Note 6015A, Repairing
electrical wiring, Wiring: Precautions for repair), repair the connector, otherwise replace the wiring.
Check the insulation from earth of the following connections:
– connection code 3ABS,
– connection code3ABT,
between components 120 and 1589.
If the connection or connections are faulty and there is a repair procedure (see Technical Note 6015A, Electrical
wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise replace it.
If the fault is still present, replace the turbine upstream temperature sensor.
EDC16C36_V48_DF652/EDC16C36_V50_DF652/EDC16C36_V58_DF652EDC16 C36
Program No.: 91
Vdiag No.: 48, 50, 58

13B-186
AFTER REPAIRDeal with any other faults. Clear the fault memory.
Switch off the ignition until the end of the power-latch phase, and carry out a road test
followed by a check using the diagnostic tool.
V9 MR-372-J84-13B450$104.mif
DIESEL INJECTION
Fault finding – Interpretation of faults13B
DF652
CONTINUED
CO.1NOTESNone.
Check the condition of the turbine upstream temperature sensor connector.
Check the condition of the engine management computer connector.
If the connector or connectors are faulty and if there is a repair procedure (see Technical Note 6015A, Repairing
electrical wiring, Wiring: Precautions for repair), repair the connector, otherwise replace the wiring.
Check the continuity and insulationof the following connections against + 12 volts:
– connection code 3ABS,
– connection code3ABT,
between components 120 and 1589.
If the connection or connections are faulty and there is a repair procedure (see Technical Note 6015A, Electrical
wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise replace it.
If the fault is still present, replace the turbine upstream temperature sensor.
EDC16 C36
Program No.: 91
Vdiag No.: 48, 50, 58

13B-187
AFTER REPAIRDeal with any other faults. Clear the fault memory.
Switch off the ignition until the end of the power-latch phase, and carry out a road test
followed by a check using the diagnostic tool.
V9 MR-372-J84-13B450$104.mif
DIESEL INJECTION
Fault finding – Interpretation of faults13B
DF778
PRESENT
OR
STOREDTURBINE UPSTREAM TEMPERATURE REGULATION
1.DEF: Positive loop deviation
NOTESConditions for applying the fault finding procedure to a stored fault:
The fault becomes present after starting the engine.
Priorities when dealing with a number of faults:
Deal with faults DF652 Turbine upstream temperature sensor circuit and DF226
Damper valve circuit first, if they are present or stored.
Special notes:
If the fault is present:
–The level 1 warning light is illuminated.
– A loss of engine performance will be perceived.
Use Wiring Diagram Technical Note, Mégane II ph2, Scénic II ph2.
EDC16C36_V48_DF778/EDC16C36_V50_DF778/EDC16C36_V58_DF778EDC16 C36
Program No.: 91
Vdiag No.: 48, 50, 58

13B-188
AFTER REPAIRDeal with any other faults. Clear the fault memory.
Switch off the ignition until the end of the power-latch phase, and carry out a road test
followed by a check using the diagnostic tool.
V9 MR-372-J84-13B450$104.mif
DIESEL INJECTION
Fault finding – Interpretation of faults13B
DF778
CONTINUED
Check the turbine upstream temperature sensor connections.
check the engine management computer connections.
If there is a repair method (see Technical Note 6015A, Repairing electrical wiring, Wiring: Precautions for
repair), repair the wiring, otherwise replace it.
Check the continuity, absence of interference resistance and insulation from + 5 V and + 12 V of the following
connections:
– Connection code 3ABS,
– Connection code 3ABT,
between components1589 and 120.
If the connection or connections are faulty and there is a repair procedure (see Technical Note 6015A, Electrical
wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise replace it.
Check the continuity, the absence of interference resistance, and the insulation against earth of the following
connection:
– Connection code 3ABS between components 1589 and 120.
If the connection is faulty and there is a repair procedure (see Technical Note 6015A, Electrical wiring repair,
Wiring: Precautions for repair), repair the wiring, otherwise replace it.
Check for the earth on the connector of the turbine upstream temperature sensor:
– Connection code 3ABT of component 1589.
Apply TEST 4 Turbocharged air inlet circuit check.
If the fault is still present, warm up the engine until parameter PR064 coolant temperature = 80°C.
Then run the engine at fast idle speed: PR055 engine speed = 1500 rpm for 2 minutes.
If PR667 Turbine upstream temperature remains fixed at 200°C, replace the turbine upstream temperature
sensor.
EDC16 C36
Program No.: 91
Vdiag No.: 48, 50, 58

13B-190
AFTER REPAIRDeal with any other faults. Clear the fault memory.
Switch off the ignition until the end of the power-latch phase, and carry out a road test
followed by a check using the diagnostic tool.
V9 MR-372-J84-13B450$104.mif
DIESEL INJECTION
Fault finding – Interpretation of faults13B
DF891
PRESENT
OR
STOREDGROUP 1 INJECTORS FEED
1.DEF: Faulty connections
2.DEF: Short-circuit on earth or short-circuit on +12 V
NOTESConditions for applying the fault finding procedure to a stored fault:
If the fault becomes present after:
– the ignition is switched on,
– the engine is started.
Priority when dealing with a number of faults:
Deal with faults DF026 Cylinder 1 injector control circuit, DF027 Cylinder 2
injector control circuit, DF028 Cylinder 3 injector control circuit and DF029
Cylinder 4 injector control circuit first, if they are present or stored.
Special notes:
If the fault is present:
–the level 2 injection warning light is illuminated,
– the engine stops.
Use bornier Elé. 1681 for all operations on the engine management computer
connectors.
Use Wiring Diagram Technical Note, Mégane II ph2, Scénic II ph2.
EDC16C36_V44_DF891/EDC16C36_V4C_DF891/EDC16C36_V48_DF891/EDC16C36_V50_DF891/EDC16C36_V54_DF891/
EDC16C36_V58_DF891EDC16 C36
Program No.: 91
Vdiag No.: 44, 4C, 48,
50, 54, 58

13B-191
AFTER REPAIRDeal with any other faults. Clear the fault memory.
Switch off the ignition until the end of the power-latch phase, and carry out a road test
followed by a check using the diagnostic tool.
V9 MR-372-J84-13B450$104.mif
DIESEL INJECTION
Fault finding – Interpretation of faults13B
DF891
CONTINUED
Check the condition of the injector connectors (see Wiring Diagram Technical Note, Mégane II ph2, Scénic II
ph2, Component codes 193, 194, 195, 196).
Check the condition of the engine management computer connector (see Wiring Diagram Technical Note,
Mégane II ph2, Scénic II ph2, component code 120).
If the connector or connectors are faulty and if there is a repair procedure (see Technical Note 6015A, Repairing
electrical wiring, Wiring: Precautions for repair), repair the connector, otherwise replace the wiring.
Check the continuity and insulation of the following connections:
– Connection code 3KW between components 193 and 120.
– Connection code 3CR between components 193 and 120.
– Connection code 3KX between components 194 and 120.
– Connection code 3CS between components 194 and 120.
– Connection code 3KY between components 195 and 120.
– Connection code 3CT between components 195 and 120.
– Connection code 3KZ between components 196 and 120.
– Connection code 3CU between components 196 and 120.
If there is a repair method (see Technical Note 6015A, Repairing electrical wiring, Wiring: Precautions for
repair), repair the wiring, otherwise replace it.
If the fault is still present, contact the Techline
EDC16 C36
Program No.: 91
Vdiag No.: 44, 4C, 48,
50, 54, 58

13B-192
AFTER REPAIRDeal with any other faults. Clear the fault memory.
Switch off the ignition until the end of the power-latch phase, and carry out a road test
followed by a check using the diagnostic tool.
V9 MR-372-J84-13B450$104.mif
DIESEL INJECTION
Fault finding – Interpretation of faults13B
DF892
PRESENT
OR
STOREDGROUP 2 INJECTORS FEED
1.DEF: Faulty connections
2.DEF: Short-circuit on earth or short-circuit on +12 V
NOTESConditions for applying the fault finding procedure to a stored fault:
If the fault becomes present after:
– the ignition is switched on,
– the engine is started.
Priority when dealing with a number of faults:
Deal with faults DF026 Cylinder 1 injector control circuit, DF027 Cylinder 2
injector control circuit, DF028 Cylinder 3 injector control circuit and DF029
Cylinder 4 injector control circuit first if they are present or stored.
Special notes:
If the fault is present:
–the level 2 injection warning light is illuminated,
– the engine stops.
Use bornier Elé. 1681 for any operations on the connectors of the engine management
computer.
Use Wiring Diagram Technical Note, Mégane II ph2, Scénic II ph2.
EDC16C36_V44_DF892/EDC16C36_V4C_DF892/EDC16C36_V48_DF892/EDC16C36_V50_DF892/EDC16C36_V54_DF892/
EDC16C36_V58_DF892EDC16 C36
Program No.: 91
Vdiag No.: 44, 4C, 48,
50, 54, 58

13B-193
AFTER REPAIRDeal with any other faults. Clear the fault memory.
Switch off the ignition until the end of the power-latch phase, and carry out a road test
followed by a check using the diagnostic tool.
V9 MR-372-J84-13B450$104.mif
DIESEL INJECTION
Fault finding – Interpretation of faults13B
DF892
CONTINUED
Check the condition of the injector connectors (see Wiring Diagram Technical Note, Vehicle, Component
codes 193, 194, 195, 196).
Check the condition of the engine management computer connector (see Wiring Diagram Technical Note,
Mégane II ph2, Scénic II ph2, component code 120).
If the connector or connectors are faulty and if there is a repair procedure (see Technical Note 6015A, Repairing
electrical wiring, Wiring: Precautions for repair), repair the connector, otherwise replace the wiring.
Check the continuity and insulation of the following connections:
– Connection code 3KW between components 193 and 120.
– Connection code 3CR between components 193 and 120.
– Connection code 3KX between components 194 and 120.
– Connection code 3CS between components 194 and 120.
– Connection code 3KY between components 195 and 120.
– Connection code 3CT between components 195 and 120.
– Connection code 3KZ between components 196 and 120.
– Connection code 3CU between components 196 and 120.
If there is a repair method (see Technical Note 6015A, Repairing electrical wiring, Wiring: Precautions for
repair), repair the wiring, otherwise replace it.
If the fault is still present, contact the Techline
EDC16 C36
Program No.: 91
Vdiag No.: 44, 4C, 48,
50, 54, 58

13B-195
AFTER REPAIRDeal with any other faults. Clear the fault memory.
Switch off the ignition until the end of the power-latch phase, and carry out a road test
followed by a check using the diagnostic tool.
V9 MR-372-J84-13B450$104.mif
DIESEL INJECTION
Fault finding – Interpretation of faults13B
* diff: differential
DF953
PRESENT
OR
STOREDPARTICLE FILTER ABSENT
NOTESConditions for applying fault finding procedures to stored faults:
The fault is declared present after the engine is started or following a road test.
Special notes:
If the fault is present:
– particle filter regeneration is inhibited,
– blue/white smoke and black particles coming from the exhaust,
the OBD warning light will illuminate after three consecutive driving cycles (start + 5
seconds, switch off the ignition and wait 40 seconds).
Priorities when dealing with a number of faults:
– DF315 Particle filter diff.* pressure sensor if present or stored
IMPORTANT
In the long term, this fault may lead to premature wear and a greater risk of
turbocharger failure.
Use Wiring Diagram Technical Note, Mégane II ph2, Scénic II ph2.
EDC16C36_V48_DF953/EDC16C36_V50_DF953/EDC16C36_V58_DF953EDC16 C36
Program No.: 91
Vdiag No.: 48, 50, 58
