check engine RENAULT SCENIC 2011 J95 / 3.G Engine And Peripherals EDC16C36 Workshop Manual

13B-160
AFTER REPAIRDeal with any other faults. Clear the fault memory.
Switch off the ignition until the end of the power-latch phase, and carry out a road test
followed by a check using the diagnostic tool.
V9 MR-372-J84-13B450$103.mif
DIESEL INJECTION
Fault finding – Interpretation of faults13B
DF293
CONTINUED
Make sure that there is no water in the diesel filter.
Bleed the diesel filter and the low and high pressure diesel circuits, if necessary (see MR 364 (Mégane) or 370
(Scénic), Mechanical, 13A, Fuel supply, and 13B, Diesel injection).
If the diesel filter contains a large amount of water, apply the first part of the Test 11: Diesel fuel conformity check
(Is the fuel cloudy or does it separate into 2 parts?)
Start the engine and wait at least 1 minute to confirm the repair.
If the fault was stored but not present, carry out a road test (see Note).
If the fault does not reappear, end of fault finding procedure.
Check the continuity, insulation and the absence of interference resistance of the following connection:
– Connection code 3WT between components 414 and 120.
Check the +12 V after relay feed of the water detection sensor:
– Connection code3FB of component414.
Check the earth of the water detection sensor:
– Connection code NT of component 414.
If there is a repair method (see Technical Note 6015A, Repairing electrical wiring, Wiring: Precautions for
repair), repair the wiring, otherwise replace it.
– Start the engine and wait at least 1 minute to confirm the repair.
Check the conformity of the fuel used by running test 11 Diesel fuel conformity check.
If none of these checks reveal any faults:
– Replace the water detection sensor,
– clear the fault,
– start the engine and wait at least 1 minute to confirm the repair.
Note:
When the water level in the fuel filter unit is below the sensor's electrodes, some driving conditions (cornering,
gradients) may result in water being detected (in fact, the sensor's off-centre position in the fuel filter unit, combined
with the driving conditions, causes water to be detected).
EDC16 C36
Program No.: 91
Vdiag No.: 44, 4C, 48,
50, 54, 58

13B-161
AFTER REPAIRDeal with any other faults. Clear the fault memory.
Switch off the ignition until the end of the power-latch phase, and carry out a road test
followed by a check using the diagnostic tool.
V9 MR-372-J84-13B450$103.mif
DIESEL INJECTION
Fault finding – Interpretation of faults13B
*diff: differential
*temp: temperature
DF308
PRESENT
OR
STOREDCLOGGED PARTICLE FILTER
NOTESConditions for applying fault finding procedures to stored faults:
The fault is declared present after the engine is started or following a road test.
Special notes:
If the fault is present:
– particle filter regeneration is inhibited,
– the EGR function is inhibited,
– the vehicle performance is reduced,
–the level 1 warning light is lit and a warning message (or light) is displayed on the
instrument panel.
Priorities when dealing with a number of faults:
Deal with the following faults first:
– DF315 Particle filter differential pressure sensor if it is present.
– DF308 if DF315 is stored.
– DF316 Particle filter diff* pressure sensor if it is present or stored.
– DF226 Damper valve circuit if it is present or stored.
– DF272 EGR valve control circuit if it is present or stored.
– DF647 EGR valve position regulation if it is present or stored.
– DF309 Particle filter downstream temperature sensor if it is present or stored.
– DF899 Regeneration temperature threshold exceeded if it is present or stored.
– DF310 Particle filter upstream temperature sensor if it is present or stored.
– DF778 Turbine upstream temperature regulation if it is present or stored.
– DF652 Turbine upstream temperature sensor circuit if it is present or stored.
EDC16C36_V48_DF308/EDC16C36_V50_DF308/EDC16C36_V58_DF308EDC16 C36
Program No.: 91
Vdiag No.: 48, 50, 58

13B-163
AFTER REPAIRDeal with any other faults. Clear the fault memory.
Switch off the ignition until the end of the power-latch phase, and carry out a road test
followed by a check using the diagnostic tool.
V9 MR-372-J84-13B450$103.mif
DIESEL INJECTION
Fault finding – Interpretation of faults13B
*temp: temperature
DF309
PRESENT
OR
STOREDPARTICLE FILTER DOWNSTREAM TEMP.* SENSOR
CO.1: Open circuit or short circuit to +12 V
CC.0: Short circuit to earth
NOTESConditions for applying fault finding procedures to stored faults:
The fault becomes present if:
– ignition is on (CC.0),
– following a road test, engine warm (CO.1).
IMPORTANT
The particle filter downstream temperature sensor only measures temperatures
greater than 50°C.
Use the Wiring Diagram Technical Note, Mégane II ph2, Scénic II ph2.
CC.0
NOTESNone.
Check the condition of the particle filter downstream temperature sensor connector.
Check the condition of the engine management computer connector.
If the connector or connectors are faulty and if there is a repair procedure (see Technical Note 6015A, Repairing
electrical wiring, Wiring: Precautions for repair), repair the connector, otherwise replace the wiring.
Check the insulation from earth of the following connections:
– connection code3TG,
– connection code3XU,
between components 120 and 1288.
If the connection or connections are faulty and there is a repair procedure (see Technical Note 6015A, Electrical
wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise replace it.
If the fault is still present, replace the particle filter downstream temperature sensor.
EDC16C36_V48_DF309/EDC16C36_V58_DF309EDC16 C36
Program No.: 91
Vdiag No.: 48, 58

13B-164
AFTER REPAIRDeal with any other faults. Clear the fault memory.
Switch off the ignition until the end of the power-latch phase, and carry out a road test
followed by a check using the diagnostic tool.
V9 MR-372-J84-13B450$103.mif
DIESEL INJECTION
Fault finding – Interpretation of faults13B
DF309
CONTINUED
CO.1NOTESNone.
Check the condition of the particle filter downstream temperature sensor connector.
Check the condition of the engine management computer connector.
If the connector or connectors are faulty and if there is a repair procedure (see Technical Note 6015A, Repairing
electrical wiring, Wiring: Precautions for repair), repair the connector, otherwise replace the wiring.
Check the continuity and insulation from + 12 V of the following connections:
– connection code3TG,
– connection code3XU,
between components 120 and 1288.
If the connection or connections are faulty and there is a repair procedure (see Technical Note 6015A, Electrical
wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise replace it.
If the fault is still present, replace the particle filter downstream temperature sensor.
EDC16 C36
Program No.: 91
Vdiag No.: 48, 58

13B-165
AFTER REPAIRDeal with any other faults. Clear the fault memory.
Switch off the ignition until the end of the power-latch phase, and carry out a road test
followed by a check using the diagnostic tool.
V9 MR-372-J84-13B450$103.mif
DIESEL INJECTION
Fault finding – Interpretation of faults13B
DF310
PRESENT
OR
STOREDPARTICLE FILTER UPSTREAM TEMP.* SENSOR
CO.1: Open circuit or short circuit to +12 V
CC.0: Short circuit to earth
NOTESConditions for applying fault finding procedures to stored faults:
The fault becomes present if:
– ignition is on (CC.0),
– following a road test, engine warm (CO.1).
Special notes:
If the fault is present:
– particle filter regeneration is inhibited,
–the level 1 warning light is lit,
–the OBD warning light comes on after three consecutive driving cycles (start
+5 seconds, switch off the ignition and wait 1 minute).
IMPORTANT
The particle filter upstream temperature sensor only measures temperatures
above 50°C.
Use the Wiring Diagram Technical Note, Mégane II ph2, Scénic II ph2.
EDC16C36_V48_DF310/EDC16C36_V50_DF310/EDC16C36_V58_DF310EDC16 C36
Program No.: 91
Vdiag No.: 48, 50, 58

13B-166
AFTER REPAIRDeal with any other faults. Clear the fault memory.
Switch off the ignition until the end of the power-latch phase, and carry out a road test
followed by a check using the diagnostic tool.
V9 MR-372-J84-13B450$103.mif
DIESEL INJECTION
Fault finding – Interpretation of faults13B
*temp: temperature
DF310
CONTINUED 1
CC.0NOTESNone.
Check the condition of the particle filter upstream temperature sensor connector.
Check the condition of the engine management computer connector.
If the connector or connectors are faulty and if there is a repair procedure (see Technical Note 6015A, Repairing
electrical wiring, Wiring: Precautions for repair), repair the connector, otherwise replace the wiring.
Check the insulation from earth of the following connections:
– connection code3XT,
– connection code3TD,
between components 120 and 1287.
If the connection or connections are faulty and there is a repair procedure (see Technical Note 6015A, Electrical
wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise replace it.
If the wiring of the particle filter downstream temperature sensor, component code 1288, is present (with or without
the sensor being present), check the electrical insulation in relation to + 12 V between the following connections:
•3XU between components 120 and 1288,
•3TG between components 120 and 1288.
If the connection or connections are faulty and there is a repair procedure (see Technical Note 6015A, Electrical
wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise replace it.
If the fault is still present, replace the particle filter upstream temperature sensor.
EDC16 C36
Program No.: 91
Vdiag No.: 48, 50, 58

13B-167
AFTER REPAIRDeal with any other faults. Clear the fault memory.
Switch off the ignition until the end of the power-latch phase, and carry out a road test
followed by a check using the diagnostic tool.
V9 MR-372-J84-13B450$103.mif
DIESEL INJECTION
Fault finding – Interpretation of faults13B
DF310
CONTINUED 2
CO.1NOTESNone.
Check the condition of the particle filter upstream temperature sensor connector.
Check the condition of the engine management computer connector.
If the connector or connectors are faulty and if there is a repair procedure (see Technical Note 6015A, Repairing
electrical wiring, Wiring: Precautions for repair), repair the connector, otherwise replace the wiring.
Check the continuity and insulation from + 12 V of the following connections:
– connection code3XT,
– connection code3TD,
between components 120 and 1287.
If the connection or connections are faulty and there is a repair procedure (see Technical Note 6015A, Electrical
wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise replace it.
If the fault is still present, replace the particle filter upstream temperature sensor.
EDC16 C36
Program No.: 91
Vdiag No.: 48, 50, 58

13B-168
AFTER REPAIRDeal with any other faults. Clear the fault memory.
Switch off the ignition, wait for the end of the power-latch phase and perform a road
test followed by a check using the diagnostic tool.
V9 MR-372-J84-13B450$104.mif
13B
* diff: differential
*temp: temperature
DF311
PRESENT
OR
STOREDFAILED REGENERATIONS LIMIT EXCEEDED
NOTESConditions for applying fault finding procedures to stored faults:
The fault is declared present after the engine is started or following a road test.
Special notes:
If the fault is present,
–the level 1 warning light is illuminated.
– particle filter regenerations when driving are inhibited.
Priorities when dealing with a number of faults:
Firstly, deal with the following faults:
– DF308 Particle filter clogged if it is present or stored.
– DF315 Particle filter diff.* pressure sensor if it is present or stored.
– DF316 "Particle filter diff* pressure if it is present or stored"
– DF055 Turbocharging pressure regulation circuit if it is present or stored.
– DF309 Particle filter downstream temperature sensor if it is present or stored.
– DF899 Regeneration temperature threshold exceeded if it is present or stored.
– DF310 Particle filter upstream temperature sensor if it is present or stored.
– DF778 Turbine upstream temperature regulation if it is present or stored.
– DF652 Turbine upstream temperature sensor circuit if it is present or stored.
– DF272 EGR valve control circuit if it is present or stored.
– DF647 EGR valve position regulation if it is present or stored.
EDC16C36_V48_DF311/EDC16C36_V58_DF311
DIESEL INJECTION
Fault finding – Interpretation of faults
EDC16 C36
Program No.: 91
Vdiag No.: 48, 58

13B-170
AFTER REPAIRDeal with any other faults. Clear the fault memory.
Switch off the ignition until the end of the power-latch phase, and carry out a road test
followed by a check using the diagnostic tool.
V9 MR-372-J84-13B450$104.mif
DIESEL INJECTION
Fault finding – Interpretation of faults13B
* diff: differential
DF312
PRESENT
OR
STOREDSPEED REQUEST
NOTESConditions for applying fault finding procedures to stored faults:
The fault is declared present after the engine is started or following a road test.
Special notes:
If the fault is present:
– the special regenerate particle filter warning light is lit or a warning message is
displayed on the instrument panel.
– The vehicle needs to be driven specially to activate particle filter regeneration during
driving.
Priorities when dealing with a number of faults:
Firstly, deal with the following faults:
– DF308 Particle filter clogged if it is present or stored.
– DF311 Failed regenerations limit exceeded if it is present.
– DF315 Particle filter diff* pressure sensor if it is present or stored.
The fault appears after:
– 7 failed regeneration attempts when driving and the weight of soot in the particle filter is greater than
21 g.
– the weight of soot in the particle filter is greater than 58 g.
PART A:
The flow chart on the following page can be used to analyse the driving profile and causes of the activation of this
fault.
EDC16C36_V48_DF312/EDC16C36_V58_DF312EDC16 C36
Program No.: 91
Vdiag No.: 48, 58

13B-172
AFTER REPAIRDeal with any other faults. Clear the fault memory.
Switch off the ignition until the end of the power-latch phase, and carry out a road test
followed by a check using the diagnostic tool.
V9 MR-372-J84-13B450$104.mif
DIESEL INJECTION
Fault finding – Interpretation of faults13B
DF312
CONTINUED 2
Is there at least one?
Within ET706 to ET715 Stored engine status No. 1 to No. 10:
Read the values of the statuses relating to the mileage of the last failures
These are the engine statuses at the last failures
Is the engine status value for one of the last
failures equal to STOPPED?Contact the
Techline.
Read PR383 "Weight of soot in particle filter" in the current context, and in
the context of fault DF312 appearing (the weight of soot when DF312
appeared).
Current value of PR383 > soot weight at the
time of DF312 + 5g?
A
YES
NO
NO
YES
PART
B
NOYESPART
C
EDC16 C36
Program No.: 91
Vdiag No.: 48, 58
