1F3-28 OM600 ENGINE CONTROLS
Tools Required
001 589 65 09 00 Socket Wrench Insert
000 589 00 68 00 Cleaning Set
Repair Procedure
1. Clamp the nozzle holder (1) in a vice and remove the nozzle
tensioning nut (8).
Notice
Use protective jaws for clamping.
2. Disassemble the fuel injection nozzle.
Socket Wrench Insert 001 589 65 09 00
3. Clean the nozzle needle (6) and nozzle body (7) with an
abradant.
4. Clean the nozzle seat with cleaning cutter.
Cleaning Set 000 589 00 68 00
5. Immerse nozzle needle (6) and nozzle body (7) in filtered
diesel fuel. When the nozzle body is held vertical, the weight
of the nozzle needle must cause it to slide down toward the
nozzle needle seat.
6. Assemble the injection nozzle so that the tip of the thrust
(4) pin is facing toward the nozzle holder.
Tightening Torque 80 Nm
Notice
Nozzle needle (6) and nozzle body (7) should always be
replaced as a pair.

OM600 ENGINE CONTROLS 1F3-29
7. Check the fuel injection nozzle and adjust opening pressure
if necessary.
Opening pressure adjustment
Disassemble the fuel injection nozzle and replace the steel
washer (2).
Notice
Each 0.05mm thickness of the washer results in a pressure
difference of approx. 3bar.

1F3-30 OM600 ENGINE CONTROLS
REMOVAL AND INSTALLATION OF INJECTION TIMING DEVICE
Preceding Work : Removal of vacuum pump
1 Cylinder Head Cover
2 Bolt............................................................10Nm
3 Gasket ................................................... Replace
4 Fuel Injection Pump
5 Seal....................................................... Replace
6 Screw Plug.................................................30Nm
7 Oil Pan
8 Locking Pin
9 Injection Timing Device10 Washer
11 Bolt (Left-Hand Thread).............................46Nm
12 Camshaft Sprocket
13 Washer
14 12-Sided Stretch Bolt............Check, 25Nm + 90°
15 Timing Chain
1 6 Seal
17 Chain Tensioner.........................................80Nm

OM600 ENGINE CONTROLS 1F3-31
Tools Required
601 589 00 08 00Flange
601 589 05 21 00 Locking Screw
116 589 20 33 00 Sliding Hammer
116 589 02 34 00 Threaded Bolt
667 589 04 63 00 Retaining Plate
Removal & Installation Procedure
1. Remove the bolts (2) and then remove the cylinder head
cover (1) and gasket (3).
Installation Notice
Tightening Torque 10 Nm
Notice
Replace the gasket.
Rotate the engine 1 revolution by hand and check TDC
marking of the crankshaft and camshaft.
2. Loosen the camshaft sprocket bolt (14).
Notice
Do not remove the bolt.
Installation Notice
Notice
If max. length of bolt exceeds 53.6mm, replace it.
Tightening Torque 25Nm + 90°
3. Loosen the bolt (11) (left-hand thread).
Notice
Do not remove the bolt.

1F3-32 OM600 ENGINE CONTROLS
5. Remove the plug (6) and seal (5) from the fuel injection
pump and collect oil in a suitable vessel.
Installation Notice
Notice
Replace the seal.
Tightening Torque 30 Nm
6. Install the locking screw (18) into the injection pump.
Notice
Before tightening the bolts for the injection timing device
and the camshaft sprocket, always remove the locking screw
from the injection pump and reinstall the plug.
Locking Screw 601 589 05 21 00
7. Place alignment marks (arrow) on the timing chain (12) and
camshaft sprocket (15). 4. Position the no.1 cylinder at ATDC 15°.
Notice
Do not rotate the engine with camshaft sprocket bolt or
opposite direction of the engine rotation.

OM600 ENGINE CONTROLS 1F3-33
9. Pull out the 12-sided stretch bolt (14) and washer and
remove the camshaft sprocket (12).
Tightening Torque 46 Nm
11. Using special tool (24, 25), remove the locking pin (8).
Sliding Hammer 116 589 20 33 00
Threaded Bolt 116 589 02 34 00
8. Remove the chain tensioner (17).
Installation Notice
Tightening Torque 80 Nm
Notice
Replace the seal (16).
10. Pull out the bolt (11) and washer (10).
Notice
Be careful that the bolt is left-hand thread.
Installation Notice

1F3-34 OM600 ENGINE CONTROLS
12. Push back the timing chain with retaining plate (26) and
remove the injection timing device (9).
Retaining Plate 667 589 04 63 00
13. Installation should follow the removal procedure in the
reverse order.
14. After assembling the engine, check start of delivery and
adjust if necessary.

OM600 ENGINE CONTROLS 1F3-35
INJECTION TIMING DEVICE
Preceding Work : Removal of injection timing device
1 Cam Sprocket........................................... Check
2 Bushing .................................................... Check
3 Governor Weights4 Segment Flange and Drive Hub
5 Compression Springs

1F3-36 OM600 ENGINE CONTROLS
Disassembly & Assembly
1. Remove the governor weights (3).
2. Pull out the compression springs (5) and cam sprocket (1)
from the segment flange (4).
3. Knock out the bushing with a proper drift.
4. Installation should follow the removal procedure in the
reverse order.

OM600 ENGINE CONTROLS 1F3-37
START OF DELIVERY TEST (POSITION SENSOR, RIV METHOD)
1 Position Sensor
2 Battery
3 Fuel Injection Pump4 Seal....................................................... Replace
5 Screw Plug.................................................30Nm
Service Data
Start of Delivery (RIV)
ATDC 14° - 16°
