Page 861 of 1574

SSANGYONG MUSSO 2003 Service Manual 5A-2 AUTOMATIC TRANSMISSIONSPECIFICATIONS
MODEL PART NUMBERS AND APPLICATIONS
Transmission
0574-000001 (9) 0574-000002 (8)
0574-000004 (10) 0574-000005 (7) Torque Converter
179K160K160K179KEngine Ver

5A-2 AUTOMATIC TRANSMISSIONSPECIFICATIONS
MODEL PART NUMBERS AND APPLICATIONS
Transmission
0574-000001 (9) 0574-000002 (8)
0574-000004 (10) 0574-000005 (7) Torque Converter
179K160K160K179KEngine Version661LAE32
662LA(Turbo) E23
MODEL SPECIFICATIONS
Application
Torque Converter Mean diameter of fluid circuit Maximum torque multiplication Stall speed (rpm)0574-000001 (D23LA)0574-000002 (E32)0574-000004 (D29LA) 0574-000005 (E23) 0574-0000200574-000021
Gear Ratios First Second ThirdFourthReverse
Lubricant
TypeCapacityDry SystemService Refill
Gear Train End Float Gear Set Pinion End FloatDescriprtion
260
2.0 : 1
2100 - 2250 2050 - 22502100 - 2200 1800 - 2100
2.741 : 1 1.508 : 11.000 : 10.708 : 12.429 : 1
Castrol TQ95 or other approved fluid 9.0 Litres (approx)4.5 Litres (approx)0.50 - 0.65 mm0.10 - 0.50 mm
DWMC P/NO
36100-05420 (1)36100-05430 (1)36100-05410 (1)36100-05440 (1)

Page 862 of 1574

SSANGYONG MUSSO 2003 Service Manual AUTOMATIC TRANSMISSION 5A-3
CLUTCH PACK DETAILS
C1Composition Steel
C2
Composition Steel
C3
CompositionSteel
C4 CompositionSteel
0574-000002
5
5(2)
5
4(2)
4
4(2)
3
4(1)0574-000001, 0574-000004, 0574-

AUTOMATIC TRANSMISSION 5A-3
CLUTCH PACK DETAILS
C1Composition Steel
C2
Composition Steel
C3
CompositionSteel
C4 CompositionSteel
0574-000002
5
5(2)
5
4(2)
4
4(2)
3
4(1)0574-000001, 0574-000004, 0574-000005
4
6(2)
4
5(2)
3
5(2)
3
4(1)
Note : Numbers in brackets indicate number of selective thickness steel plates required to achieve specifed
clutch pack clearance

Page 863 of 1574

SSANGYONG MUSSO 2003 Service Manual 5A-4 AUTOMATIC TRANSMISSIONSPECIAL TOOLS
SPECIAL TOOLS TABLE
Part Number
0555 - 332083 0555 - 3360460555 - 3362560555 - 3362570555 - 336258 0555 - 336259 0555 - 3362600555 - 3362610555 - 3362620555 -

5A-4 AUTOMATIC TRANSMISSIONSPECIAL TOOLS
SPECIAL TOOLS TABLE
Part Number
0555 - 332083 0555 - 3360460555 - 3362560555 - 3362570555 - 336258 0555 - 336259 0555 - 3362600555 - 3362610555 - 3362620555 - 336263 0555 - 336264 0555 - 3362650555 - 3362660555 - 3362670555 - 336268 0555 - 336269 0555 - 3362700555 - 332895Description
Solenoid / Thermistor, Electronic Tester
Solenoid, Bench Tester
Transmission Bench Cradle Pump Puller
Pin Remover / Installer Tool (Cross Shaft / Detent Lever)Clutch Spring CompressorClutch Pack Clearance Kit
Seal Removal Tool (Cross - Shaft) Oil Seal Dolly (Cross - Shaft)Assembly BulletSeal CompressorPin Press Seal Dolly
Alignment ToolPump Seal DollyEnd Float AdaptorEnd Float Shaft
Locknut Crimping Tool (W-Car Only)
