02-133170-01
3166-00 Extension housing ▶
Lever assembly - Semi remote
Lever - Shift
Boot - Rubber
Ring - Retainer
O-ring
Bearing
Shim
Arm - Control
Damper assembly
Rod assembly
Bushing assembly - TGS mounting
Pin - TGS mounting
Pin - Spring
Pin - Spring
Adapter - Case 1.
3.
4.
5.
6.
7.
8.
9.
10.
13.
14.
15.
16.
17.
20.Bolt - Flange (42.1 ~ 53.9 Nm)
Seal - Oil
Seal - Oil
Pin - Dowel
Switch - Neutral (29.4 ~ 34.3 Nm)
Gasket
Bolt - Interlock (14.7 ~ 21.5 Nm)
Pin - Detent
Switch - Backup lamp (29.4 ~ 34.3 Nm)
Bolt - Fork hinge (53.9 ~ 67.6 Nm)
Bearing - Poppet ball (29.4 ~ 41.1 Nm)
Bolt - Guide (14.7 ~ 21.5 Nm)
Bolt (2.9 ~ 4.9 Nm)
Bracket - Wiring 21.
22.
23.
24.
25.
26.
27.
28.
29.
30.
31.
32.
33.
34.
02-14
Sectional viewFront view
1. OVERVIEW
1) Characteristics of Transmission
Forward and Reverse gears are helical gear.
The clutch is operated by concentric slave cylinder (CSC).
To prevent the improper gear shift, semi-remote control system has been introduced.
To prevent the gears from engaging improperly, the synchronizer mechanisms and independent
interlock systems are installed on 1/2 gears, 3/4 gears, 5/6 gears and reverse gear.
The High-Force system for reverse gear shift has been introduced.
The synchronizer has three types: Triple (1, 2, 3, R), Double (5), Single (4, 6) -
-
-
-
-
-
6-speed M/T
02-153170-01
2) Sectional Diagram
3) Gear Ratio
Transmission housing
Extension housing
Main shaft Counter shaft Main drive gearIntermediate plate
GearTeeth
Final gear ratio
Input Output
1st 13 38 4.489
2nd 23 35 2.337
3rd 33 29 1.350
4th 28 43 1.000
5th 47 24 0.784
6th 52 23 0.679
R 13 36 4.253
IDLE: 25
03-33010-00
1. SPECIFICATION
Description Specification
Operating type Hydraulic type
Clutch pedal Type Suspended type
Max. operating travel150 ± 3 mm
Pedal height95.2 ± 3 mm
Pedal free play 5 ~ 15 mm
Clutch disc Type Dry type single diaphragm
Diameter of facingOuter: Ø250 mm
Inner: Ø160 mm
Numbers of disc 2
Thickness of discFree: 8.7 ± 0.3 mm
When loaded: 8.0 ± 0.2 mm
Setting load of clutch cover assembly At least 7,800 N
Clutch master
cylinderOperating travel 33.0 mm
Inner diameterØ 15.87
Concentric slave
cylinderMaximum operating travel Max. 20 mm
Operating pressure Max. 2,200 N
Clutch fluid Type DOT 4
Capacity As required
