SUBARU BAJA 2006 1.G Owners Manual

13-14
Consumer information and Reporting safety defects
„
Adverse safety consequences of over-
loading on handling and stopping and on tires
Overloading could affect vehicle handling, stop-
ping distance, vehicle and tire as shown in the
following. This could lead to an accident and
possibly result in severe personal injury. y Vehicle stability will deteriorate.
y Heavy and/or high-mounted loads could in-
crease the risk of rollover.y Stopping distance will increase.
y Brakes could overheat and fail.
y Suspension, bearings, axles and other parts of
the body could break or experience accelerated
wear that will shorten vehicle life. y Tires could fail.
y Tread separation could occur.
y Tire could separate from its rim.
„ Steps for Determining Correct Load
Limit
1. Locate the statement “The combined weight
of occupants and carg o should never exceed
XXX pounds” on your vehicle’s placard. 2. Determine the combined weight of the driver
and passengers that will be riding in your vehicle.
3. Subtract the combined weight of the driver
and passengers from XXX kilograms or XXX
pounds.
4. The resulting figure equals the available
amount of cargo and luggage load capacity. For
example, if the “XXX” am
ount equals 1,400 lbs
(635 kg). and there will be five- 150 lbs (68 kg)
passengers in your vehicle, the amount of avail-
able cargo and luggage load capacity is 650 lbs.
(1,400 – 750 (5

13-15
Consumer information and Reporting safety defects
– CONTINUED –
Uniform tire quality grading stan-
dards
This information indicates the relative perfor-
mance of passenger car tires in the area of
treadwear, traction, and temperature resistance.
This is to aid the consumer in making an in-
formed choice in the purchase of tires.
Quality grades can be found where applicable on
the tire sidewall between tread shoulder and
maximum section width. For example:
Treadwear 200 Traction AA Temperature A
The quality grades apply to new pneumatic tires
for use on passenger cars. However, they do not
apply to deep tread, winter type snow tires,
space-saver or temporary use spare tires, tires
with nominal rim diameters of 12 inches or less,
or to some limited production tires.
All passenger car tires must confirm to Federal
Safety Requirements in addition to these grades. „Treadwear
The treadwear grade is a comparative rating based on the wear rate of the tire when tested
under controlled conditions on a specified gov-
ernment test course.
For example, a tire graded 150 would wear one
and one-half (1-1/2) times as well on the govern-
ment course as a tire graded 100. The relative
performance of tires depends upon the actual
conditions of their use, however, and may depart
significantly from the norm due to variations in
driving habits, service practices and differences
in road characteristics and climate. „
Traction AA, A, B, C
The traction grades, from highest to lowest, are
AA, A, B and C. Those grades represent the
tire’s ability to stop on wet pavement as mea-
sured under controlled conditions on specified
government test surfaces of asphalt and con-
crete. A tire marked C may have poor traction
performance.
The traction grade assigned to this tire is
based on straight-ahead braking traction

13-16
Consumer information and Reporting safety defects
tests, and does not include acceleration,
cornering, hydroplaning, or peak traction
characteristics.
„ Temperature A, B, C
The temperature grades are A (the highest), B,
and C, representing the tire’s resistance to the generation of heat and it s ability to dissipate heat
when tested under controlled conditions on a
specified indoor laboratory test wheel. Sustained
high temperature can cause the material of the
tire to degenerate and reduce tire life, and exces-
sive temperature can lead to sudden tire failure.
The grade C corresponds to a level of perfor-
mance which all passenger car tires must meet
under the Federal Motor Vehicle Safety Stan-
dards No. 109. Grades B and A represent higher
levels of performance on the laboratory test
wheel than the minimum required by law.
The temperature grade for this tire is es-
tablished for a tire that is properly inflated and not overloaded. Excessive speed, un-
derinflation, or exces
sive loading, either
separately or in combination, can cause
heat buildup and possible tire failure.

13-17
Consumer information and Reporting safety defects
– CONTINUED –
Reporting safety defects (USA)
If you believe that your vehicle has a defect
which could cause a crash or could cause in-
jury or death, you should immediately inform
the National Highway Traffic Safety Admin-
istration (NHTSA) in addition to notifying
Subaru of America, Inc.
If NHTSA receives similar complaints, it may
open an investigation, and if it finds that a
safety defect exists in a group of vehicles, it
may order a recall and remedy campaign.
However, NHTSA cannot become involved
in individual problems between you, your
dealer, or Subaru of America, Inc. To con-
tact NHTSA, you may either call the Auto
Safety Hotline toll-free at 1-800-424-9393
(or 366-0123 in the Washington D.C. area)
or write to: NHTSA, U.S. Department of
Transportation, Washington, D.C. 20590.
You can also obtain other information about
motor vehicle safety from the Hotline.

14-1
14
Index

14-2
Index
A
ABS (Anti-lock Brake System)
........................... 7-33
Warning light ................................................. 3-14
Accessories .............................................. 5-4, 11-62
Air cleaner element ......................................... 11-23
Air conditioner operation ... ................................ 4-10
Air filtration system ............................................ 4-13
Alarm system ..................................................... 2-17
All-Wheel Drive warning light ............................ 3-16
Aluminum wheels .............. .............................. 11-53
Antenna system .................................................. 5-2Anti-lock Brake System (ABS) ........................ ... 7-33
Arming the system .. ........................................... 2-18
Ashtray .............................................................. 6-12
AT OIL TEMPerature warning light ................... 3-13
Audio set ............................................................. 5-4
Auto-dimming mirror/compa ss .......................... 3-30
Automatic transmission ............................ 7-14, 7-21 Capacities ..................................................... 12-3
Fluid ............................................................ 11-29
Selector lever ....................................... 7-15, 7-22
Shift lock release ................................. 7-19, 7-29
SPORTSHIFT mode - Turbo models ............ 7-21
Temperature warning light ............................ 3-13
Automatic/Emergency Locking Retractor
(A/ELR) .......................................................... 1-16
AWD warning light ............................................. 3-16 B
Battery ............................................................. 11-58
Jump starting ................................................ 9-18
Replacement (Remote keyless entry system) .......... .......................................... .. 2-10
Bed extender ............ ......................................... 6-17
Brake Booster ....................................................... 11-42
Fluid ............................................................ 11-38
Pad and lining ............................................. 11-44
Pedal .......................................................... 11-42
Brake pedal
Free play .................................................... 11-42
Reserve distance ........................................ 11-43
Brake system ........... ......................................... 7-32
Warning light ................................................ 3-15
Braking .............................................................. 7-31
Tips ............................................................... 7-31
Breaking Breaking-in of new brake pads and
linings ....................................................... 11-45
Bulb Chart ............................................................. 12-8
Replacing ................................................... 11-63
C
Capacities ............. .......................................... .. 12-3

14-3
Index
Cargo
Bed ............................................................... 6-16
Lamp ............................................................. 6-20
Lamp indicator light ...................................... 3-18
Net hooks ..................................................... 6-13
Tie-down hooks ............................................ 6-17
Catalytic converter ............ ................................... 8-4
Center Console .......................................................... 6-5
Ventilators ....................................................... 4-2
Changing
Flat tire .......................................................... 9-12
Oil and oil filter ............................................ 11-12
Charge warning light ......................................... 3-13 CHECK ENGINE warning light/Malfunction
indicator lamp .... ............................................ 3-12
Checking Brake pedal free play .................................. 11-42
Brake pedal reserve distance ..................... 11-43
Clutch function ................ ............................ 11-43
Clutch pedal free play ................................. 11-44
Engine oil level ............... ............................ 11-10
Fluid level ................. 11-29, 11-36, 11-38, 11-40
Gear oil level ................ .................... 11-32, 11-33
Child restraint system s ...................................... 1-28
Installation with seatbelt ............................... 1-32
Lower and tether anchorages ....................... 1-40 Child safety ............................................................. 5
Locks ............ .......................................... ...... 2-24
Chime Key ................................................................. 3-4
Seatbelt ............................................... 1-17, 3-11
Cigarette lighter socket ........................................ 6-9
Cleaning Aluminum wheels ......................................... 10-4
Fog light lens ................................................ 10-4
Interior .......................................................... 10-6
Ventilator grille .............................................. 4-11
Clock ................................................................. 3-19
Clutch fluid ....................................................... 11-40
Clutch pedal .................................................... 11-43
Coat hook .......................................................... 6-13
Coin compartment ............................................... 6-6
Convenience hook ............................................. 6-13
Cooling system ....... ......................................... 11-17
Corrosion protection .......... ................................ 10-5
Cover Soft bed ........................................................ 6-21
Cruise control .................................................... 7-37
Set indicator light .......................................... 3-18
Cup holder ........................................................... 6-7 D Daytime running li ght system .......... .................. 3-21

14-4
Index
Differential gear oil
Front ........................................................... 11-32
Rear ............................................................ 11-33
Dimensions ........................................................ 12-2
Disarming the system ............................... 2-21, 2-23
Disc brake pad wear warning indicators ............ 7-32
Dome light ................................................ 6-2, 11-78
Door ajar warning lights ..................................... 3-15
Door locks ........................................................... 2-3
Drive belts ....................................................... 11-26
Driving
Car phone/cell phone ........................................ 8
Drinking ............................................................. 7
Drugs ................................................................. 7
Foreign countries ............. ............................... 8-6
Pets ................................................................... 8
Snowy and icy roads .................................... 8-13
Tips ..................................... 7-14, 7-19, 7-29, 8-7
Tired or sleepy ................................................... 8
E
Electrical system . ........................................... ... 12-3
Emergency Locking Retractor (ELR) ................. 1-16
Engine
Compartment overview ................................. 11-8
Coolant ....................................................... 11-18
Exhaust gas (Carbon monoxide) .................... 8-3 Hood ............................................................. 11-5
Oil ............................................................... 11-10
Overheating .................................................. 9-21
Starting ........................................................... 7-9
Stopping ....................................................... 7-11
Exterior care ..................... ................................. 10-2
F
Flat tires ............................................................ 9-12
Floor mat ........................................................... 6-15
Fluid level Automatic transmission ..... ......................... 11-29
Brake .......................................................... 11-38
Clutch ......................................................... 11-40
Power steering ........................................... 11-36
Folding down the rear seat ................................ 1-10
Front Differential gear oil ..................................... 11-32
Fog light ...................................................... 11-70
Fog light button ............................................. 3-24
Seatbelt pretensioners ................................. 1-24
Seats .............................................................. 1-2
Turn signal light, parking light and side
marker light .............................................. 11-71
Fuel ..................................................................... 7-2 Economy hints ................................................ 8-2
Filler door and cap .......................................... 7-4

14-5
Index
Gauge ............................................................. 3-8
Requirements ................................................. 7-2
Fuses ............................................................... 11-59
Fuses and circuits ............................................. 12-5 G
GAWR (Gross Axle Weight Rating) ................... 8-19
Glove box ............................................................ 6-5
GVWR (Gross Vehicle Weight Rating) .............. 8-19 H
Hard bed cover .................................................. 6-24
Hazard warning flasher ....... ................................ 3-6
Head restraint adjustment (Fro nt) ........................ 1-6
Headlight flasher ................. .............................. 3-21
Headlights ............. ................................. 3-20, 11-66
Heater operation .... .......................................... .... 4-7
High beam indicator light ................................... 3-18
High mount stop and cargo light assembly ...... 11-79
Horn ................................................................... 3-35
Hose and connections ......... ............................ 11-18
I
Ignition switch ...................................................... 3-2
Illuminated entry .................................................. 2-9
Illumination brightness contro l ........................... 3-23 Indicator light
High beam .................................................... 3-18
Selector lever position .................................. 3-17
Turn signal .................................................... 3-17
Inside mirror ...................................................... 3-30
Interior light .......................................................... 6-2 J
Jack and tools ..................................................... 9-3
Jump starting ..................................................... 9-18 K Key Interlock release ............................................. 3-5
Number ........................................................... 2-2
Reminder chime ............................................. 3-4
Keys .................................................................... 2-2 L
Leather seat materials ....................................... 10-7
License plate bracket ........................................ 2-30
License plate light ............................................ 11-76
Light control switch ............................................ 3-19
Limited slip differential (LSD ) ............................ 7-30
Loading your vehicle ......................................... 8-17
Lower tether anchorages ................................... 1-40
