SUBARU FORESTER 1999 Service Repair Manual

2) Remove screws and clip from instrument panel
lower cover.
3) Remove panel lower cover.
S6M0091
4) Disconnect connector from cruise control main
switch (A).
S6M0092B
5) Remove main switch by pushing it outward.
S6M0093
6) Install in the reverse order of removal.
3. CRUISE CONTROL COMMAND SWITCH
CAUTION:
Before starting operation carefully read the
notes given in Chapter 5-5 for proper handling
of the airbag module.
1) Disconnect ground cable from battery.
2) Set front wheels in straight ahead position.
3) Turn ignition switch OFF.
4) Disconnect battery ground cable from battery
and wait for at least 20 seconds before starting
work.5) Using TORXTBIT T30 (Tamper resistant type),
remove the two TORXTbolts which secure driver's
airbag module.
S6M0094A
6) Disconnect airbag module connector on back of
airbag module.
7) Remove horn switch from steering wheel as
shown.
S6M0095
8) Disconnect horn and cruise control command
switch connector, then remove cruise control com-
mand switch.
S6M0096
9) Install in the reverse order of removal.
4. CRUISE CONTROL MODULE
1) Disconnect ground cable from battery.
21
[W12B4]6-2SERVICE PROCEDURE
12. Cruise Control

2) Remove front pillar lower trim.
S6M0097
3) Disconnect connector from cruise control mod-
ule.
4) Remove bolt, then remove cruise control mod-
ule.
S6M0098
5) Install in the reverse order of removal.
5. STOP AND BRAKE SWITCH
1) Disconnect ground cable from battery.
2) Disconnect connector from switch, then remove
the switch.
3) Install in the reverse order of removal.
6. CLUTCH SWITCH
1) Disconnect ground cable from battery.
2) Disconnect connector from switch, then remove
the switch.
3) Install in the reverse order of removal.
13. Front Fog Light
A: REMOVAL AND INSTALLATION
1) Disconnect ground cable from battery.
2) Remove the two screws, then draw out the front
fog light from front bumper.
S6M0085
3) Disconnect the connector.
4) Install in the reverse order of removal.
22
6-2[W12B5]SERVICE PROCEDURE
13. Front Fog Light

2\)
S6M0097
3\)
ule.
4\)
ule.
S6M0098
5\)
5.
1\)
2\)
the
3\)
6.
1\)
2\)
the
3\)
13.
A:
1\)
2\)
fog
S6M0085
3\)
4\)
22
6-2[W12B5]SER
13.

14.
A:
1.
1\)
2\)
3\)
while
S5M0042A
4\)
module.
5\)
NOTE:
Loosen
S6M0482A
6\)
7\)
NOTE:
T
securely
B:
1.
Perform
23
[W14B1]6-2SER
14.

MEMO:
