TOYOTA AVALON 2001 Service Repair Manual
Manufacturer: TOYOTA, Model Year: 2001, Model line: AVALON, Model: TOYOTA AVALON 2001Pages: 1897, PDF Size: 26.61 MB
Page 1101 of 1897
AB0118
R13006AB0119FI1390
H01003H01136
D SquibSpiral
CableAirbag
Sensor
Assembly
E1 TcACC ON
or
DTC B0100/13
" u
DLC1
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-365
521 Author: Date:
2001 AVALON (RM808U)
4 Check D squib.
PREPARATION:
(a) Turn the ignition switch to LOCK.
(b) Disconnect negative (-) terminal cable from the battery,
and wait at least for 90 seconds.
(c) Connect the steering wheel pad connector.
(d) Connect negative (-) terminal cable to the battery, and
wait at least for 2 seconds.
CHECK:
(a) Turn the ignition switch to LOCK, and wait at least for 20
seconds.
(b) Turn the ignition switch to ACC or ON, and wait at least
for 20 seconds.
(c) Clear the DTC stored in memory (See page DI-349).
(d) Turn the ignition switch to LOCK, and wait at least for 20
seconds.
(e) Turn the ignition switch to ACC or ON, and wait at least
for 20 seconds.
(f) Check the DTC (See page DI-349).
OK:
DTC B0100/13 is not output.
HINT:
Codes other than code B0100/13 may be output at this time, but
they are not relevant to this check.
NG Replace steering wheel pad.
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check.
Page 1102 of 1897
H01000H02142H02195
D SquibSpiral
Cable
Airbag
Sensor
Assembly
D+ u"
(-) (+) D-
R14286H01004H01138
D SquibSpiral
Cable
Airbag
Sensor
Assembly
D+
(-)(+)D-
DI-366
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
522 Author: Date:
2001 AVALON (RM808U)
5 Check spiral cable.
PREPARATION:
(a) Disconnect the connector between the airbag sensor as-
sembly and the spiral cable.
(b) Release the airbag activation prevention mechanism of
the spiral cable connector on the airbag sensor assembly
side (See page DI-349).
CHECK:
For the connector (on the spiral cable side) between the spiral
cable and the steering wheel pad, measure the resistance be-
tween D+ and D-.
OK:
Resistance: 1 MW or Higher
NG Repair or replace spiral cable.
OK
6 Check harness between airbag sensor assembly and spiral cable.
PREPARATION:
Release the airbag activation prevention mechanism of the
connector (on the airbag sensor assembly side) between the
airbag sensor assembly and the spiral cable (See page
DI-349).
CHECK:
For the connector (on the spiral cable side) between the airbag
sensor assembly and the spiral cable, measure the resistance
between D+ and D-.
OK:
Resistance: 1 MW or Higher
NG Repair or replace harness or connector be-
tween airbag sensor assembly and spiral cable.
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check.
Page 1103 of 1897
R14286H01001H01139
D SquibSpiral
Cable
Airbag
Sensor
Assembly
D+ u"
(-) (+)D-
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-367
523 Author: Date:
2001 AVALON (RM808U)
DTC B0101/14 Open in D Squib Circuit
CIRCUIT DESCRIPTION
The D squib circuit consists of the airbag sensor assembly, spiral cable and steering wheel pad.
It causes the airbag to deploy when the airbag deployment conditions are satisfied.
For details of the function of each components, see OPERATION on page RS-3.
DTC B0101/14 is recorded when an open is detected in the D squib circuit.
DTC No.DTC Detecting ConditionTrouble Area
B0101/14
Open circuit in D+ wire harness or D- wire harness of
squib
D squib malfunction
Spiral cable malfunction
Airbag sensor assembly malfunctionSteering wheel pad (D squib)
Spiral cable
Airbag sensor assembly
Wire harness
WIRING DIAGRAM
See page DI-362.
INSPECTION PROCEDURE
1 Prepare for inspection. (See step 1 on page DI-475)
2 Check D squib circuit.
CHECK:
For the connector (on the spiral cable side) between the spiral
cable and the steering wheel pad, measure the resistance be-
tween D+ and D-.
OK:
Resistance: Below 1 W
NG Go to step 5.
OK
DI4CL-02
Page 1104 of 1897
AB0118
R13006AB0069
AB0119W02044
H01002
H01140
D SquibSpiral
CableAirbag
Sensor
Assembly
E1TcACCON
or
DTC B0101/14 DLC1"u
D+D-
DI-368
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
524 Author: Date:
2001 AVALON (RM808U)
3 Check airbag sensor assembly.
PREPARATION:
(a) Connect the connector to the airbag sensor assembly.
(b) Using a service wire, connect D+ and D- of the connector
(on the spiral cable side) between the spiral cable and the
steering wheel pad.
(c) Connect negative (-) terminal cable to the battery, and
wait at least for 2 seconds.
CHECK:
(a) Turn ignition switch to ACC or ON, and wait at least for 20
seconds.
(b) Clear DTC stored in memory (See page DI-349).
(c) Turn ignition switch to LOCK, and wait at least for 20 se-
conds.
(d) Turn ignition switch to ACC or ON, and wait at least for 20
seconds.
(e) Check DTC (See page DI-349).
OK:
DTC B0101/14 is not output.
HINT:
Codes other than code B0101/14 may be output at this time, but
they are not relevant to this check.
NG Replace airbag sensor assembly.
OK
Page 1105 of 1897
W02044
H01003AB0118
R13006AB0119H01141
"u D Squib
Spiral
Cable
Airbag
Sensor
Assembly
E1TcACCON
or
DTC B0101/14
DLC1
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-369
525 Author: Date:
2001 AVALON (RM808U)
4 Check D squib.
PREPARATION:
(a) Turn ignition switch to LOCK.
(b) Disconnect negative (-) terminal cable from the battery,
and wait at least for 90 seconds.
(c) Connect the steering wheel pad connector.
(d) Connect negative (-) terminal cable to the battery, and
wait at least for 2 seconds.
CHECK:
(a) Turn ignition switch to ACC or ON, and wait at least for 20
seconds.
(b) Clear DTC stored in memory (See page DI-349).
(c) Turn ignition switch to LOCK, and wait at least for 20 se-
conds.
(d) Turn ignition switch to ACC or ON, and wait at least for 20
seconds.
(e) Check DTC (See page DI-349).
OK:
DTC B0101/14 is not output.
HINT:
Codes other than code B0101/14 may be output at this time, but
they are not relevant to this check.
NG Replace steering wheel pad.
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check.
Page 1106 of 1897
R14286H01000H01142
D SquibAirbag
Sensor
Assembly
D+ u"
D- Spiral
Cable
H01004R14286H01143
D SquibSpiral
Cable
Airbag
Sensor
Assembly
D+
(-)
(+)D-
DI-370
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
526 Author: Date:
2001 AVALON (RM808U)
5 Check spiral cable.
PREPARATION:
Disconnect the connector between the airbag sensor assembly
and the spiral cable.
CHECK:
For the connector (on the spiral cable side) between the spiral
cable and the steering wheel pad, measure the resistance be-
tween D+ and D-.
OK:
Resistance: Below 1 W
NG Repair or replace spiral cable.
OK
6 Check harness between airbag sensor assembly and spiral cable.
CHECK:
For the connector (on the spiral cable side) between the airbag
sensor assembly and the spiral cable, measure the resistance
between D+ and D-.
OK:
Resistance: Below 1 W
NG Repair or replace harness or connector be-
tween airbag sensor assembly and spiral cable.
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check.
Page 1107 of 1897
H01001H02145H02198
D SquibSpiral
Cable
Airbag
Sensor
Assembly
D+
(-) (+)
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-371
527 Author: Date:
2001 AVALON (RM808U)
DTC B0102/11 Short in D Squib Circuit (to Ground)
CIRCUIT DESCRIPTION
The D squib circuit consists of the airbag sensor assembly, spiral cable and steering wheel pad.
It causes the SRS to deploy when the SRS deployment conditions are satisfied.
For details of the function of each component, see OPERATION on page RS-3.
DTC B0102/11 is recorded when a ground short is detected in the D squib circuit.
DTC No.DTC Detecting ConditionTrouble Area
B0102/11
Short circuit in D squib wire harness (to ground)
D squib malfunction
Spiral cable malfunction
Airbag sensor assembly malfunctionSteering wheel pad (D squib)
Spiral cable
Airbag sensor assembly
Wire harness
WIRING DIAGRAM
See page DI-362.
INSPECTION PROCEDURE
1 Prepare for inspection (See step 1 on page DI-475).
2 Check D squib circuit.
CHECK:
For the connector (on the spiral cable side) between the spiral
cable and the steering wheel pad, measure the resistance be-
tween D+ and body ground.
OK:
Resistance: 1 MW or Higher
NG Go to step 5.
OK
DI4DM-02
Page 1108 of 1897
H01002
AB0118
R13006AB0069
AB0118
W02042H02144H11569
D SquibSpiral
Cable
Airbag
Sensor
Assembly
D+
E1D-
TcACC ON
or
DTC B0102/11 "u
DLC1
DI-372
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
528 Author: Date:
2001 AVALON (RM808U)
3 Check airbag sensor assembly.
PREPARATION:
(a) Connect the connector to the airbag sensor assembly.
(b) Using a service wire, connect D+ and D- of the connector
(on the spiral cable side) between the spiral cable and the
steering wheel pad.
(c) Connect negative (-) terminal cable to the battery, and
wait at least for 2 seconds.
CHECK:
(a) Turn the ignition switch to ACC or ON, and wait at least
for 20 seconds.
(b) Clear the DTC stored in memory
(See step 5 on page DI-349).
(c) Turn the ignition switch to LOCK, and wait at least for 20
seconds.
(d) Turn the ignition switch to ACC or ON, and wait at least
for 20 seconds.
(e) Check the DTC (See page DI-349).
OK:
DTC B0102/11 is not output.
HINT:
Codes other than code B0102/11 may be output at this time, but
they are not relevant to this check.
NG Replace airbag sensor assembly.
OK
Page 1109 of 1897
H01003AB0118
R13006AB0119
W02042H01128
D SquibSpiral
Cable
Airbag
Sensor
Assembly
E1Tc ACC
ON
or
DTC B0102/11 " u
DLC1
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-373
529 Author: Date:
2001 AVALON (RM808U)
4 Check D squib.
PREPARATION:
(a) Turn the ignition switch to LOCK.
(b) Disconnect negative (-) terminal cable from the battery,
and wait at least for 90 seconds.
(c) Connect the steering wheel pad connector.
(d) Connect negative (-) terminal cable to the battery, and
wait at least for 2 seconds.
CHECK:
(a) Turn the ignition switch to ACC or ON, and wait at least
for 20 seconds.
(b) Clear the DTC stored in memory
(See step 5 on page DI-349).
(c) Turn the ignition switch to LOCK, and wait at least for 20
seconds.
(d) Turn the ignition switch to ACC or ON, and wait at least
for 20 seconds.
(e) Check the DTC (See page DI-349).
OK:
DTC B0102/11 is not output.
HINT:
Codes other than code B0102/11 may be output at this time, but
they are not relevant to this check.
NG Replace steering wheel pad.
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check. If the malfunctioning part can not be
detected by the simulation method, replace all SRS components including the wire harness.
Page 1110 of 1897
H01000H02145H02200
D SquibSpiral
Cable
Airbag
Sensor
Assembly
D+
u"
(-) (+)
R14301H01004H06304
D SquibSpiral
Cable
(-) (+)
Airbag
Sensor
Assembly
D+
DI-374
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
530 Author: Date:
2001 AVALON (RM808U)
5 Check spiral cable.
PREPARATION:
Disconnect the connector between the airbag sensor assembly
and the spiral cable.
CHECK:
For the connector (on the spiral cable side) between the steer-
ing wheel pad and the spiral cable, measure the resistance be-
tween D+ and body ground.
OK:
Resistance: 1 MW or Higher
NG Repair or replace spiral cable.
OK
6 Check harness between airbag sensor assembly and spiral cable.
CHECK:
For the connector (on the spiral cable side) between the spiral
cable and the airbag sensor assembly, measure the resistance
between D+ and body ground.
OK:
Resistance: 1 MW or Higher
NG Repair or replace harness between airbag sen-
sor assembly and spiral cable.
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check. If the malfunctioning part can not be
detected by the simulation method, replace all SRS components including the wire harness.
