TOYOTA AVALON 2001 Service Repair Manual

BO2Q8-01
BO-1 12
- BODYFRONT SEAT (Manual Adjuster Type)
1897 Author
: Date
:
2001 AVALON (RM808U)
REMOVAL
REMOVE FRONT SEAT
(a) Using a screwdriver, remove the seat track covers.
HINT:
Tape the screwdriver tip before use.
(b) Remove the 4 bolts.
(c) Disconnect the connectors.
NOTICE:
When disconnecting the side airbag connector take care not to damage the airbag wire harness.
(d) Remove the front seat.
NOTICE:
Be careful not to damage the body.

BO2Q2-01
H12211

Hog Ring Separate type:
Seatback Cover

Hog Ring
Seatback Frame
w/ Lumbar support:
Lumbar Support Assembly
Reclining Adjuster
Inside Cover
Seat Track
Cover
Sliding Motor Seat Track Cover
Front Power
Adjuster ShieldSeatback Pad
Headrest Support
Headrest
Seatback Board
Seat Cushion
Frame
Seat Wire
w/ Power seat control:
Power Seat Position
Control Computer
Seat Cushion
CoverSeat Cushion
Pad
Seat Cushion
Inner Shield
Front Seat Inner Belt
w/ Lumbar support:
Lumbar Support Switch Power Seat Switch
Slide Motor
w/ 4 way-vertical:
Front Vertical Motor
w/ Power seat control:
Seat Memory SwitchSeat Cushion
Shield
Power Seat
Switch Knob
Rear Vertical Motor
N´m (kgf´cm, ft´lbf): Specified torque

Non-reusable part
18 (185, 13)
43 (440, 32)
37 (375, 27)
37 (375, 27)
37 (375, 27)
41 (420, 30)
- BODYFRONT SEAT (Power Adjuster Type)
BO-103
1888 Author
: Date
:
2001 AVALON (RM808U)
FRONT SEAT (Power Adjuster Type)
COMPONENTS

H12210
Bench type:
Headrest SupportHeadrest
Seatback Board
Seatback Frame
Seatback Pad
Seatback Cover
Seat Cushion Cover Seat
Cushion
PadSeat Wire
w/ Power seat control:
Power Seat Position Control Computer
Reclining Adjuster
Inside Cover
Seat Track Cover
Center Armrest
Hog Ring

Hog Ring
Seat
Cushion
Frame
Seat Cushion Inner Shield
Seat Track Cover
Slide Motor
w/ 4 way-vertical:
Front Vertical Motor
w/ Power seat control:
Seat Memory Switch
37 (375, 27)
Reclining
Motor
Power Seat Switch
37 (375, 27)Front Seat
Inner Belt
Front Power
Adjuster Shield
Rear
Vertical Motor
Power Seat
Switch Knob
Seat
Cushion
Shield
N´m (kgf´cm, ft´lbf): Specified torque

Non-reusable part
18 (185, 13)
18 (185, 13)
18 (185, 13)
43 (440, 32)
41 (420, 30)
Seat Track Cover
43 (440, 32)
37 (375, 27)
41 (420, 30)
41 (420, 30)
BO-104
- BODYFRONT SEAT (Power Adjuster Type)
1889 Author
: Date
:
2001 AVALON (RM808U)

BO2Q4-01
H12693A
H12203
H12204
BO-106
- BODYFRONT SEAT (Power Adjuster Type)
1891 Author
: Date
:
2001 AVALON (RM808U)
DISASSEMBLY
CAUTION:

When storing the seatback frame with the side airbag
assembly, do not face down the airbag deployment
side.

Never disassemble the side airbag assembly.
1. Bench type: Driver's seat
REMOVE CENTER ARMREST
2. REMOVE HEADREST
3. REMOVE SEATBACK BOARD
Remove the seatback board.
HINT:
Insert your hand between the upper part of the seatback board
and seat cushion, and press ºAº of the clips to remove the clips
from the frame wire.
4. REMOVE SEAT CUSHION SHIELD
(a) Using a screwdriver, remove the power seat switch
knobs.
HINT:
Tape the screwdriver tip before use.
(b) Remove the 5 screws.
(c) Remove the seat cushion shield as shown in the illustra-
tion, then disconnect the connectors.
(d) w/ Lumbar support:
Remove the 2 screws and lumbar support switch from the
seat cushion shield.
(e) w/ Power seat control:
Remove the 2 screws and seat memory switch from the
seat cushion shield.
5. REMOVE SEAT CUSHION LOWER SHIELD
Remove the screw and seat cushion lower shield as shown in
the illustration.

H12205H12206H12660
Bench type:
Separate type:
H12207
- BODYFRONT SEAT (Power Adjuster Type)
BO-107
1892 Author
: Date
:
2001 AVALON (RM808U)
6. REMOVE FRONT SEAT INNER BELT
(a) Disconnect the connector.
(b) Remove the connector, then remove the nut, washer and
front seat inner belt.
Torque: 41 N´m (420 kgf´cm, 30 ft´lbf)
7. REMOVE SEAT CUSHION INNER SHIELD
8. REMOVE SEATBACK COVER
(a) Remove the headrest supports.
(b) Remove the hog rings.
(c) Disengage the hook as shown in the illustration.
(d) Remove the seatback cover with pad.
(e) Remove the seatback cover from the seatback pad.
9. REMOVE FRONT POWER ADJUSTER SHIELD
10. Bench type:
REMOVE FRONT SEAT CENTER BELT
Torque: 41 N´m (420 kgf´cm, 30 ft´lbf)
11. REMOVE SEAT CUSHION COVER
(a) Remove the seat wire clamp from the seat cushion as-
sembly.
(b) Separate type:
Remove the 4 bolts and seat cushion assembly.
Torque: 18 N´m (185 kgf´cm, 13 ft´lbf)
(c) Bench type:
Remove the 5 bolts and seat cushion assembly.
Torque: 18 N´m (185 kgf´cm, 13 ft´lbf)
(d) Remove the seat cushion cover with pad from the seat
cushion frame.
(e) Remove the seat cushion cover from the seat cushion
pad.
12. REMOVE POWER SEAT SWITCH
13. REMOVE SEAT WIRE

H12208
LH side:
RH side:
Lumber Support
Wire HarnessSide Airbag
Wire Harness
H12209
BO-108
- BODYFRONT SEAT (Power Adjuster Type)
1893 Author
: Date
:
2001 AVALON (RM808U)
14. REMOVE RECLINING ADJUSTER INSIDE COVERS
Remove the 4 screws and reclining adjuster inside covers.
15. REMOVE SEATBACK FRAME
Torque: 41 N´m (420 kgf´cm, 30 ft´lbf)
16. w/ Lumbar support:
REMOVE LUMBAR SUPPORT ASSEMBLY
17. REMOVE SLIDE MOTOR
(a) Remove the 2 screws, then disconnect the drive cable.
(b) Remove the slide motor from the power seat adjuster.
18. w/ 4 way-vertical:
REMOVE FRONT VERTICAL MOTOR
19. REMOVE REAR VERTICAL MOTOR
20. REMOVE RECLINING MOTOR

BO2Q6-01
BO-1 10
- BODYFRONT SEAT (Power Adjuster Type)
1895 Author
: Date
:
2001 AVALON (RM808U)
INSTALLATION
Installation is in the reverse order of removal (See page BO-105).

BO2Q5-01
- BODYFRONT SEAT (Power Adjuster Type)
BO-109
1894 Author
: Date
:
2001 AVALON (RM808U)
REASSEMBLY
Reassembly is in the reverse order of disassembly (See page BO-106).

BO2Q3-01
- BODYFRONT SEAT (Power Adjuster Type)
BO-105
1890 Author
: Date
:
2001 AVALON (RM808U)
REMOVAL
REMOVE FRONT SEAT
(a) Using a screwdriver, remove the seat track covers.
HINT:
Tape the screwdriver tip before use.
(b) Remove the 4 bolts.
Torque: 37 N´m (375 kgf´cm, 27 ft´lbf)
(c) Disconnect the connectors.
NOTICE:
When disconnecting the side airbag connector take care not to damage the airbag wire harness.
(d) Remove the front seat.
NOTICE:
Be careful not to damage the body.

BO2P5-01
BE3367
2 - 2.5 mm
(0.028 - 0.030 in.)0.7 - 0.75 mm(0.079 - 0.098 in.)
- BODYFRONT WIPER AND WASHER
BO-41
1826 Author
: Date
:
2001 AVALON (RM808U)
ADJUSTMENT
ADJUST WASHER NOZZLE
Using a tool like the one shown in the illustration, change the
direction of the nozzle hole to adjust the point where washer
fluid hits the windshield.
