39
OVERVIEW FEATURES & OPERATIONS TOYOTA SAFETY SENSE SAFETY & EMERGENCY FEATURES
4 8 * 5 $ ) * / ( 5 0 $ 0 / 4 5 " / 5 4 1 & & % $ 3 6 * 4 &
$ 0 / 5 3 0 - . 0 % &
4 & 5 5 * / ( $ 0 / 4 5 " / 5 4 1 & & % $ 3 6 * 4 &
$ 0 / 5 3 0 -
Note: When your vehicle is too close to a vehicle ahead, and sufficient
automatic deceleration via the cruise control is not possible, the display will
flash and the buzzer will sound to alert the driver. An example of this would be
if another driver cuts in front of you while you are following a vehicle. Depress
the brake pedal to ensure an appropriate vehicle-to-vehicle distance.
If you are already using DRCC “
,” push ON-OFF button to turn the system off
first, then push and hold ON-OFF button for at least 1.5 seconds to switch.
Note: When the engine is turned off, it will automatically default to DRCC.
Refer to the Toyota Owner’s Manual for additional information on DRCC operation,
settings adjustments, limitations, and precautions before attempting to use it.
1.5 seconds
Set
Acceleration when there are no longer any preceding vehicles driving
slower than the set speed
The system accelerates until the set speed is reached. The system then
returns to constant speed cruising.
To adjust speed or cancel, see steps (2) and (3) of ADJUSTING SET SPEED on
page 37.
" % + 6 4 5 * / ( % * 4 5 " / $ & $ 0 / 5 * / 6 & %
MY21_Avalon_QRG_V2_ML_0709.indd 397/13/20 1:15 PM
Page 42 of 56
40
TOYOTA SAFETY SENSE™
5 I F " V U P N B U J D ) J H I # F B N T " ) #
T B G F U Z T Z T U F N J T E F T J H O F E U P I F M Q Z P V T F F
more clearly at night. At speeds above 25 mph, AHB can detect the headlights of
oncoming vehicles and taillights of preceding vehicles, then automatically toggles
between high and low beams accordingly.
See Toyota.com/safety-sense for more information.
Refer to the Toyota Owner’s Manual for a list of additional situations in which the
system operation may be limited.
Automatic High Beams (AHB)
1 V T I U I F M F W F S B X B Z G S P N Z P V X J U I U I F I F B E M J H I U T X J U D I J T J O U I F i” or
“AUTO” position.
1 S F T T U I F i
” switch.
The AHB indicator will come on when the headlights are turned on automatically
to indicate that the system is active.
Note: Pull the lever back toward you or press the AHB switch to turn the AHB
system off.
The AHB indicator will turn off and “
” or “” will turn on. To activate the
system again, push the lever its original position or press the “
” switch.
When all of the following conditions are met, the high beams will be automatically
U V S O F E P O B G U F S B Q Q S P Y J N B U F M Z T F D P O E
t 7 F I J D M F T Q F F E J T B C P W F B Q Q S P Y J N B U F M Z N Q I L N I
• The area ahead of the vehicle is dark.
• There are no oncoming or preceding vehicles with headlights or tail lights
turned on.
• There are few street lights on the road ahead.
If any of the following conditions occur, the high beams will be automatically turned off:
t 7 F I J D M F T Q F F E E S P Q T C F M P X B Q Q S P Y J N B U F M Z N Q I L N I
• The area ahead of the vehicle is not dark.
• Oncoming or preceding vehicles have headlights or tail lights turned on.
• There are many streetlights on the road ahead.
ACTIVATING THE AHB SYSTEM
CONDITIONS WHERE AHB WILL TURN ON/OFF AUTOMATICALLY
(2) (1)
MY21_Avalon_QRG_V2_ML_0709.indd 407/13/20 1:15 PM
Page 43 of 56
41
OVERVIEW FEATURES & OPERATIONS TOYOTA SAFETY SENSE SAFETY & EMERGENCY FEATURES
SAFETY & EMERGENCY FEATURES
Moving the lever downward will allow the door to be opened only from the outside.
Lock
Unlock
Rear door child safety locks
Safety Connect®
Safety Connect is a subscription-based telematics service that uses Global
1 P T J U J P O J O H 4 Z T U F N ( 1 4
E B U B B O E F N C F E E F E D F M M V M B S U F D I O P M P H Z U P Q S P W J E F T B G F U Z
and security features to subscribers. Safety Connect is staffed with live agents at
the Toyota response center, which operates 24 hours per day, 7 days per week.
Services for subscribers include:
• Automatic collision notification
• Stolen vehicle locator
t & N F S H F O D Z B T T J T U B O D F i 4 0 4 w C V U U P O
• Enhanced roadside assistance
For additional information, refer to the “Owner’s Manual” or visit www.Toyota.com/
connected-services.
Microphone
LED light indicators
(Green is Active)
“SOS” button
MY21_Avalon_QRG_V2_ML_0709.indd 417/13/20 1:15 PM
Page 44 of 56
42
SAFETY & EMERGENCY FEATURES
Keep as low on
hips as possible
Take up slack
Too high
1 2 7 ( , I D S D V V H Q J H U
Page 45 of 56
43
OVERVIEW FEATURES & OPERATIONS TOYOTA SAFETY SENSE SAFETY & EMERGENCY FEATURES
Pull up
Trunk-Internal release
Tire Pressure Monitoring (warning) System (TPMS)
The tire pressure warning system can be selected on “” of the Multi-
J O G P S N B U J P O E J T Q M B Z . * %
System reset initialization
1 S F T T “” switches and select “” G S P N U I F . V M U J * O G P S N B U J P O % J T Q M B Z . * %
Press “
” or “” switches and select the “,” then push and hold “.”
1 S F T T “
” or “” switches and select “TPWS” and then push and hold “.”
1 S F T T i 4 F U 1 S F T T V S F w U I F O Q S F T T B O E I P M E “
” until the warning light blinks
three times.
The tire pressure detected by the tire pressure warning system can be displayed
P O U I F . V M U J J O G P S N B U J P O E J T Q M B Z . * %
Refer to the load label on the door jamb or the Owner’s Manual for tire inflation
specifications.
If the tire pressure indicator flashes for 1 minute and then remains on, take the
vehicle to your local Toyota dealer.
NOTE: The warning light may come on due to temperature changes or
changes in tire pressure from natural air leakage. If the system has not been
initialized recently, setting the tire pressures to factory specifications should
turn off the light.
MY21_Avalon_QRG_V2_ML_0709.indd 437/13/20 1:15 PM
Page 46 of 56
44
Luggage floor cover
Luggage floor coverJack
Jack Jack handle
Jack handle Spare tire
Spare tire Tool tray
Tool trayWheel nut wrench
Wheel nut wrench
Spare tire & tools
SAFETY & EMERGENCY FEATURES
TOOL LOCATION
2WD models
AWD models
MY21_Avalon_QRG_V2_ML_0709.indd 447/13/20 1:15 PM
Page 47 of 56
45 Refer to the Owner’s Manual for tire changing and jack positioning procedures.
(2) Loosen the center fastener that
secures the spare tire. (1) Remove the tool tray.
REMOVE THE SPARE TIRE
OVERVIEW FEATURES & OPERATIONS TOYOTA SAFETY SENSE SAFETY & EMERGENCY FEATURESAWD models 2WD models
MY21_Avalon_QRG_V2_ML_0709.indd 457/13/20 1:15 PM
