TOYOTA CAMRY 2000 Service Repair Manual

BR0AU±01
± BRAKEFRONT BRAKE CALIPER
BR±29
2052 Author: Date:
REASSEMBLY
Reassembly is in the reverse order of disassembly (See page BR±27).
NOTICE:
Apply lithium soap base glycol grease to the parts indicated by arrows (See page BR±24).

BR0AV±02
BR±30
± BRAKEFRONT BRAKE CALIPER
2053 Author: Date:
INSTALLATION
Installation is in the reverse order of removal (See page BR±26).
HINT:

After installation, fill the brake reservoir with brake fluid, bleed the brake system (See page BR±4).

Check for leaks.

BR0AW±03
W03258
Plug
SpringWheel Cylinder
BootAdjuster

Cup
Piston
C±washer Inspection Hole
Plug
Pin
Front Shoe
Cup
Shoe Hold±down Spring Adjuster
Rear Shoe
Anchor SpringParking Brake Lever
Automatic Adjusting Lever
E±ring
Adjusting Lever Spring Bleeder Plug
High temperature grease Lithium soap base glycol grease
Non±reusable part
N´m (kgf´cm, ft´lbf): Specified torque
8.3 (85, 74 in.´lbf)
10 (100, 7)
± BRAKEREAR DRUM BRAKE
BR±31
2054 Author: Date:
REAR DRUM BRAKE
COMPONENTS

BR0AX±03
BR1532
R00285
BR1534
SST
BR1535
SST BR±32
± BRAKEREAR DRUM BRAKE
2055 Author: Date:
REMOVAL
1. INSPECT SHOE LINING THICKNESS
Remove the inspection hole plug, and check the shoe lining
thickness through the hole.
If less than the minimum, replace the shoes.
Minimum thickness: 1.0 mm (0.039 in.)
2. REMOVE REAR WHEEL
3. REMOVE BRAKE DRUM
(a) Release the parking brake lever and remove the brake
drum.
HINT:
If the brake drum cannot be removed easily, do the following
steps.
(b) Insert a bent wire or equivalent through the hole in the
brake drum, and hold the automatic adjusting lever away
from the adjuster.
(c) Using a screwdriver, reduce the brake shoe adjustment
by turning the adjuster.
4. REMOVE FRONT SHOE
(a) Using SST, disconnect the return spring.
SST 09703±30010
(b) Using SST, remove the shoe hold±down spring, 2 cups
and pin.
SST 09718±00010
(c) Disconnect the anchor spring from the front shoe and re-
move the front shoe.
(d) Remove the anchor spring from the rear shoe.

R00248
SST
Z03633
BR1540
SST
± BRAKEREAR DRUM BRAKE
BR±33
2056 Author: Date:
5. REMOVE REAR SHOE
(a) Using SST, remove the shoe hold±down spring, 2 cups
and pin.
SST 09718±00010
(b) Using a screwdriver, disconnect the parking brake cable
from the anchor plate.
(c) Using pliers, disconnect the parking brake cable from the
lever and remove the rear shoe together with adjuster.
NOTICE:
Do not allow oil or grease on the rubbing face.
6. REMOVE ADJUSTER FROM REAR SHOE
(a) Remove the adjusting lever spring.
(b) Remove the adjuster together with the return spring.
7. REMOVE AUTOMATIC ADJUSTING LEVER AND
PARKING BRAKE LEVER
(a) Remove the E±ring.
(b) Remove the automatic adjusting lever.
(c) Remove the C±washer.
(d) Remove the parking brake lever.
8. REMOVE WHEEL CYLINDER
(a) Using SST, disconnect the brake line. Use a container to
catch the brake fluid.
Torque: 15 N´m (155 kgf´cm, 11 ft´lbf)
SST 09751±36011
(b) Remove the 2 bolts and the wheel cylinder.
Torque: 10 N´m (100 kgf´cm, 7 ft´lbf)
9. DISASSEMBLE WHEEL CYLINDER
(a) Remove the 2 boots.
(b) Remove the 2 pistons and springs.
(c) Remove the 2 piston cups.

BR0AY±03
BR1542
F06408
BR1543
BR±34
± BRAKEREAR DRUM BRAKE
2057 Author: Date:
INSPECTION
1. INSPECT DISASSEMBLED PARTS
Inspect the disassembled parts for wear, rust or damage.
2. MEASURE BRAKE SHOE LINING THICKNESS
Using a ruler, measure the shoe lining thickness.
Standard thickness: 5.0 mm (0.197 in.)
Minimum thickness: 1.0 mm (0.039 in.)
If the thickness is less than the minimum, or shows signs of un-
even wear, replace the brake shoes.
HINT:
If any of the brake shoes have to be replaced, replace all of the
rear brake shoes in order to maintain even braking.
3. MEASURE BRAKE DRUM INSIDE DIAMETER
Using brake drum gauge or equivalent, measure the inside di-
ameter of the drum.
Standard inside diameter: 228.6 mm (9.000 in.)
Maximum inside diameter: 230.6 mm (9.079 in.)
If the drum is scored or worn, the brake drum may be lathed to
the maximum inside diameter.
4. INSPECT REAR BRAKE LINING AND DRUM FOR
PROPER CONTACT
If the contact between the brake lining and drum is improper, re-
pair the lining with a brake shoe grinder, or replace the brake
shoe assembly.

BR0AZ±02
W01679
BR1553
F06423
± BRAKEREAR DRUM BRAKE
BR±35
2058 Author: Date:
INSTALLATION
Installation is in the reverse order of removal
(See page BR±32).
NOTICE:
Apply lithium soap base glycol grease and high tempera-
ture grease to the parts indicated by the arrows
(See page BR±31).
1. AFTER INSTALLATION, FILL BRAKE RESERVOIR
WITH BRAKE FLUID, BLEED BRAKE SYSTEM
(See page BR±4)
2. CHECK FOR LEAKS
3. CHECK OPERATION OF AUTOMATIC ADJUSTING
MECHANISM
(a) Move the parking brake lever of the rear shoe back and
forth. Check that the adjuster turns.
If the adjuster does not turn, check for incorrect installation of
the rear brake.
(b) Adjust the adjuster length as short as possible.
(c) Align the adjusting hole on the brake drum and the largest
hole on the axle carrier, install the brake drum.
(d) Pull the parking brake lever all the way up until a clicking
sound can no longer be heard.
4. CHECK CLEARANCE BETWEEN BRAKE SHOES AND
DRUM
(a) Remove the drum.
(b) Measure the brake drum inside diameter and diameter
between the brake shoes. Check that the difference be-
tween the diameters is the correct shoe clearance.
Shoe clearance: 0.6 mm (0.024 in.)
If incorrect, check the parking brake system.

BR0B0±03
F02610
Pad Support Plate
Outer Pad
Anti±squeal Shim
Inner Anti±squeal Shim Anti±squeal Shim
Inner Anti±squeal Shim
Inner Pad
Pad Support Plate
Disc brake grease
N´m (kgf´cm, ft´lbf) : Specified torque
29 (300, 21)20 (200, 14)
BR±36
± BRAKEREAR BRAKE PAD
2059 Author: Date:
REAR BRAKE PAD
COMPONENTS

BR0B1±03
R00591
R00514
R10387
± BRAKEREAR BRAKE PAD
BR±37
2060 Author: Date:
REPLACEMENT
1. REMOVE REAR WHEEL
Remove the wheel and temporarily fasten the disc with the hub
nuts.
2. INSPECT PAD LINING THICKNESS
Check the pad thickness through the caliper inspection hole
and replace pads if not within specification.
Minimum thickness: 1.0 mm (0.039 in.)
3. LIFT UP CALIPER
(a) Remove the bolt and flexible hose from the bracket.
(b) Remove the installation bolt from the torque plate.
(c) Lift up the caliper and suspend it securely.
HINT:
Do not disconnect the flexible hose.
4. REMOVE 2 BRAKE PADS
5. REMOVE 4 ANTI±SQUEAL SHIMS
6. REMOVE 4 PAD SUPPORT PLATES
NOTICE:
The support plates can be used again provided that they
have sufficient rebound, no deformation, cracks or wear,
and have had all rust, dirt and foreign particles cleaned off.
7. CHECK DISC THICKNESS AND RUNOUT
(See page BR±42)
8. INSTALL 4 PAD SUPPORT PLATES
9. INSTALL NEW PADS
NOTICE:
When replacing worn pads, the anti±squeal shims must be
replaced together with the pads.
(a) Apply disc brake grease to both side of the inner anti±
squeal shims (See page BR±36).
(b) Install the 2 anti±squeal shims on each pad.
(c) Install 2 pads with the pad wear indicator plate facing up-
ward.
NOTICE:
There should be no oil or grease adhering to the friction
surfaces of the pads or the disc.
10. INSTALL CALIPER
(a) Draw out a small amount of brake fluid from the reservoir.
(b) Press in the piston with a hammer handle or similar imple-
ment.
HINT:
If the piston is difficult to push in, loosen the bleeder plug and
push in the piston while letting some brake fluid escape.
(c) Install the caliper and torque the installation bolt.
Torque: 20 N´m (200 kgf´cm, 14 ft´lbf)
(d) Install the flexible hose and bolt to the bracket.
Torque: 29 N´m (300 kgf´cm, 21 ft´lbf)

BR±38
± BRAKEREAR BRAKE PAD
2061 Author: Date:
11. INSTALL REAR WHEEL
Torque: 103 N´m (1.050 kgf´cm, 76 ft´lbf)
12. DEPRESS BRAKE PEDAL SEVERAL TIMES
13. CHECK THAT FLUID LEVEL IS AT MAX LINE
