TOYOTA CAMRY 2021 Owners Manual (in English)

181
3
Operation of each component
CAMRY_U
3-5. Opening and closing the windows
The power windows can be opened and closed using the switches.
Operating the switch moves the windows as follows:
Closing
One-touch closing
*
Opening
One-touch opening
*
*
: To stop the window partway, oper- ate the switch in the opposite direc-
tion.
This function can be used to prev ent children from accidentally open-
ing or closing a passenger window.
Press the switch.
The indicator will come on and the
passenger windows will be locked.
The passenger windows can still
be opened and closed using the
driver’s switch even if the lock
switch is on.
■ The power windows can be operated when
Vehicles without a smart key system
The engine switch is in the “ON” position.
Vehicles with a smart key system
The engine switch is in IGNITION ON mode.
Power windows
Opening and closing procedures
1
2
3
4
Preventing accidental operation (window lock switch)
Indicator

1823-5. Opening and closing the windows
CAMRY_U■
Operating the power windows after turning the engine off
Vehicles without a smart key system
The power windows can be operated for approximately 45 seconds even
after the engine switch is turned to the “ACC” or “LOCK” positi on. They can-
not, however, be operated once either front door is opened.
Vehicles with a smart key system
The power windows can be operated for approximately 45 seconds even
after the engine switch is turned to ACCESSORY mode or turned o ff. They
cannot, however, be operated once either front door is opened.
■ Jam protection function
If an object becomes jammed between the window and the window f rame
while the window is closing, window movement is stopped and the window is
opened slightly.
■ Catch protection function
If an object becomes caught between the door and window while the window
is opening, window movement is stopped.
■ When the window cannot be opened or closed
When the jam protection function or catch protection function o perates
unusually and the door window cannot be opened or closed, perfo rm the fol-
lowing operations with the power window switch of that door.
● Vehicles without a smart key system: Stop the vehicle. With the engine
switch in the “ON” position, within 4 seconds of the jam protec tion function
or catch protection function activating, continuously operate the power win-
dow switch in the one-touch closing direction or one-touch open ing direction
so that the door window can be opened and closed.
Vehicles with a smart key system: Stop the vehicle. With the en gine switch
in IGNITION ON mode, within 4 seconds of the jam protection fun ction or
catch protection function activating, continuously operate the power win-
dow switch in the one-touch closing direction or one-touch open ing direc-
tion so that the door window can be opened and closed.

1833-5. Opening and closing the windows
3
Operation of each component
CAMRY_U●
If the door window cannot be opened and closed even when perfor ming the
above operations, perform the following procedure for function initialization.
Vehicles without a smart key system:
Turn the engine switch to the “ON” position.
Vehicles with a smart key system:
Turn the engine switch to IGNITION ON mode.
Pull and hold the power window switch in the one-touch closing direction
and completely close the door window.
Release the power window switch for a moment, resume pulling the
switch in the one-touch closing direction, and hold it there for approxi-
mately 6 seconds or more.
Press and hold the power window switch in the one-touch opening direc-
tion. After the door window is completely opened, continue hold ing the
switch for an additional 1 second or more.
Release the power window switch for a moment, resume pushing th e
switch in the one-touch opening direction, and hold it there fo r approxi-
mately 4 seconds or more.
Pull and hold the power window switch in the one-touch closing direction
again. After the door window is completely closed, continue holding the
switch for a further 1 second or more.
If you release the switch while the window is moving, start aga in from the
beginning.
If the window reverses and cannot be fully closed or opened, have the vehicle
inspected by your Toyota dealer.
■ Door lock linked window operation
●Vehicles without a smart key system: The power windows can be o pened
and closed using the key.
* ( P. 149)
Vehicles with a smart key system: The power windows can be open ed and
closed using the mechanical key.
* ( P. 569)
● The power windows can be opened using the wireless remote control.
*
(P. 148)
*: These settings must be customized at your Toyota dealer.
■ Alarm
The alarm may be triggered if the alarm is set and a power wind ow is closed
using the door lock linked power window operation function. ( P. 83)
■ Power windows open warning buzzer
A buzzer sounds and a message is shown on the multi-information display in
the instrument cluster when the engine switch is turned off and the driver’s
door is opened with the power windows open.
■ Customization
Some functions can be customized. ( P. 616)
1
2
3
4
5
6

1843-5. Opening and closing the windows
CAMRY_U
WARNING
Observe the following precautions.
Failure to do so may result in death or serious injury.
■Closing the windows
● The driver is responsible for all the power window operations, including the
operation for the passengers. In order to prevent accidental op eration,
especially by a child, do not let a child operate the power windows. It is
possible for children and other passengers to have body parts c aught in
the power window. Also, when riding with a child, it is recommended to use
the window lock switch.( P. 181)
● When using the wireless remote control, key or mechanical key a nd oper-
ating the power windows, operate the power window after checkin g to
make sure that there is no possibility of any passenger having any of their
body parts caught in the window. Also do not let a child operate window by
the wireless remote control, key or mechanical key. It is possi ble for chil-
dren and other passengers to get caught in the power window.
● When exiting the vehicle, turn the engine switch off, carry the key and exit
the vehicle along with the child. There may be accidental operation, due to
mischief, etc., that may possibly lead to an accident.
■ Jam protection function
● Never use any part of your body to intentionally activate the jam protection
function.
● The jam protection function may not work if something gets jammed just
before the window is fully closed. Be careful not to get any pa rt of your
body jammed in the window.
■ Catch protection function
● Never use any part of your body or clothing to intentionally ac tivate the
catch protection function.
● The catch protection function may not work if something gets caught just
before the window is fully opened. Be careful not to get any part of your
body or clothing caught in the window.
●Check to make sure that all passengers
do not have any part of their body in a
position where it could be caught when
a window is being operated.

1853-5. Opening and closing the windows
3
Operation of each component
CAMRY_U
Opens the moon roof*
The moon roof stops slightly before
the fully open position to reduce
wind noise.
Press the switch again to fully open
the moon roof.
Closes the moon roof*
*
: Lightly press either side of the moon roof switch to stop the moon
roof partway.
Tilts the moon roof up*
Tilts the moon roof down*
*: Lightly press either side of themoon roof switch to stop the moon
roof partway.
Moon roof
: If equipped
Use the overhead switches to open and close the moon roof and
tilt it up and down.
Opening and closing
1
2
Tilting up and down
1
2

1863-5. Opening and closing the windows
CAMRY_U
■The moon roof can be operated when
Vehicles without a smart key system
The engine switch is in the “ON” position.
Vehicles with a smart key system
The engine switch is in IGNITION ON mode.
■ Operating the moon roof after turning the engine off
Vehicles without a smart key system
The moon roof can be operated for approximately 45 seconds afte r the
engine switch is turned to the “ACC” or “LOCK” position. It cannot, however,
be operated once either front door is opened.
Vehicles with a smart key system
The moon roof can be operated for approximately 45 seconds afte r the
engine switch is turned to ACCESSORY mode or turned off. It can not, how-
ever, be operated once either front door is opened.
■ Jam protection function
If an object is detected between the moon roof and the frame wh ile the moon
roof is closing or tilting down, travel is stopped and the moon roof opens
slightly.
■ Sunshade
The sunshade can be opened and closed manually. However, the su nshade
will open automatically when the moon roof is opened.
■ Door lock linked moon roof operation
●Vehicles without a smart key system: The moon roof can be opene d and
closed using the key.
* (  P. 149)
Vehicles with a smart key system: The moon roof can be opened a nd
closed using the mechanical key.
* (  P. 569)
● The moon roof can be opened using the wireless remote control.
*
(P. 148)
*: These settings must be customized at your Toyota dealer.

1873-5. Opening and closing the windows
3
Operation of each component
CAMRY_U■
When the moon roof does not close normally
Perform the following procedure:
●If the moon roof closes but then re-opens slightly
Stop the vehicle.
Press and hold the “CLOSE” switch.
*1
The moon roof will close, reopen and pause for approximately 10 sec-
onds.
*2 Then it will close again, tilt up and pause for approximately 1 sec-
ond. Finally, it will tilt down, open and close.
Check to make sure that the moon roof is completely closed and then
release the switch.
● If the moon roof tilts down but then tilts back up
Stop the vehicle.
Press and hold the “UP” switch
*1 until the moon roof moves into the tilt
up position and stops.
Release the “UP” switch once and then press and hold the “UP” s witch
again.
*1
The moon roof will pause for approximately 10 seconds in the tilt up posi-
tion.
*2 Then it will adjust slightly and pause for approximately 1 second.
Finally, it will tilt down, open and close.
Check to make sure that the moon roof is completely closed and then
release the switch.
*1: If the switch is released at the incorrect time, the procedure will have to
be performed again from the beginning.
*2: If the switch is released after the above mentioned 10 second pause, automatic operation will be disabled. In that case, press and h old the
“CLOSE” or “UP” switch, and the moon roof will tilt up and paus e for
approximately 1 second. Then it will tilt down, open and close. Check to
make sure that the moon roof is completely closed and then release the
switch.
If the moon roof does not fully close even after performing the above proce-
dure correctly, have the vehicle inspected by your Toyota deale r.
■ Alarm
The alarm may be triggered if the alarm is set and the moon roo f is closed
using the door lock linked moon roof operation function. ( P. 83)
■ Moon roof open warning buzzer
A buzzer sounds and a message is shown on the multi-information display in
the instrument cluster when the engine switch is turned off and the driver's
door is opened with the moon roof open.
■ Customization
Some functions can be customized. ( P. 616)
1
2
3
1
2
3
4

1883-5. Opening and closing the windows
CAMRY_U
WARNING
Observe the following precautions.
Failure to do so may cause death or serious injury.
■Opening the moon roof
● Do not allow any passengers to put their hands or heads outside the vehi-
cle while it is moving.
● Do not sit on top of the moon roof.
■ Closing the moon roof
● The driver is responsible for moon roof opening and closing operations.
In order to prevent accidental operation, especially by a child, do not let a
child operate the moon roof. It is possible for children and other passen-
gers to have body parts caught in the moon roof.
● When exiting the vehicle, turn the engine switch off, carry the key and exit
the vehicle along with the child. There may be accidental operation, due to
mischief, etc., that may possibly lead to an accident.
■ Jam protection function
● Never use any part of your body to intentionally activate the jam protection
function.
● The jam protection function may not work if something gets caught just
before the moon roof is fully closed. Also, the jam protection function is not
designed to operate while the switch is being pressed. Take care so that
your fingers, etc. do not get caught.
●Check to make sure that all passengers
do not have any part of their body in a
position where it could be caught when
the moon roof is being operated.
● When using the wireless remote con-
trol, key or mechanical key and operat-
ing the moon roof, operate the moon
roof after checking to make sure that
there is no possibility of any passenger
having any of their body parts caught in
the moon roof. Also, do not let a child
operate moon roof by the wireless
remote control, key or mechanical key.
It is possible for children and other pas-
sengers to get caught in the moon roof.

1893-5. Opening and closing the windows
3
Operation of each component
CAMRY_U
Opens the electronic sunshade
Slide and hold the switch
backward. The electronic sun-
shade will fully open automati-
cally.
*
Closes the electronic sunshade
Slide and hold the switch for-
ward. The electronic sunshade will
fully close automatically.
*
*
: Quickly slide and release the switch in either direction to s top the
electronic sunshade partway.
Tilts the panoramic moon roof up
(press)
*
When the panoramic moon roof is
tilted up, the electronic sunshade
will open to the half-open position
of the roof.
*: Lightly press the switch
again to stop the panoramic moon
roof partway.
Tilts the panoramic moon roof down (press and hold)
The panoramic moon roof can be tilted down only when it is in t he tilt-up
position.
Panoramic moon roof
: If equipped
Use the overhead switches to operate the panoramic moon roof
and electronic sunshade.
Opening and closing th e electronic sunshade
1
2
Tilting the panoramic moon roof up and down

1903-5. Opening and closing the windows
CAMRY_U
Opens the panoramic moon roof*
Slide and hold the switch
backward. The panoramic moon
roof and electronic sunshade will
open automatically.
The panoramic moon roof can be
opened from the tilt-up position.
*: Quickly slide and release the switch in either direction to stop the
panoramic moon roof partway.
Closes the panoramic moon roof
Slide and hold the switch
forward. The panoramic moon
roof will fully cl ose automatically.
■The panoramic moon roof can be operated when
The engine switch is in IGNITION ON mode.
■ Operating the panoramic moon roo f after turning the engine off
The panoramic moon roof and electronic sunshade can be operated for
approximately 45 seconds after the engine switch is turned to A CCESSORY
mode or turned off. They cannot, however, be operated once eith er front door
is opened.
■ Jam protection function
If an object is detected between the panoramic moon roof and th e frame in
the following situations, travel is stopped and the panoramic m oon roof opens
slightly:
● The panoramic moon roof is closing or tilting down.
● The electronic sunshade is closing.
■ Door lock linked panoramic moon roof operation
● The panoramic moon roof can be opened and closed using the mech anical
key.
* (  P. 569)
● The panoramic moon roof can be opened using the wireless remote con-
trol.
* (P. 148)
*: These settings must be customized at your Toyota dealer.
Opening and closing the panoramic moon roof
