913-2. Destination search
COROLLA_HB_Navi_(U)
3
Navigation system
There are 3 methods to search
for a destination by Points of
Interest.
1 Display the destination
screen. ( P.86)
2 Select “Point of Interest”.
3 Select the desired search
method.
Select to change the search
area. ( P.87)
Select to search by name.
( P. 9 1 )
Select to search by category.
( P. 9 2 )
Select to search by phone
number. ( P.93)
 When selecting some search
methods, if a state (province)
has not been selected yet,
“State/Province” screen is dis-
played. ( P. 8 7 ) 1
Select “Name”.
2 Enter a POI name and select
“Search”.
3 Select the desired POI.
“Sort/Category/City”: Select to sort
(name, distance) the displayed
entries, change the POI category,
or enter a city name.
When entering the name of a
specific POI, and there are 2
or more sites with the same
name, the list screen will be
displayed. Select the desired
POI.
●To search for a facility name using
multiple search words, put a
space between each word.
1 Select “Sort/Category/City”.
2 Select “Enter a city name”.
3 Enter a city name and select
“Search”.
“Any City”: Select to cancel the city
setting.
4Select the desired city name.
5 Select the desired POI.
Searching by point of
interest
A
B
C
D
6HDUFKLQJE\QDPH
6HOHFWLQJDFLW\WRVHDUFK

923-2. Destination search
COROLLA_HB_Navi_(U)
1Select “Sort/Category/City”.
2 Select “Change POI cate-
gory”.
3 Select the desired category.
 If there is more than 1 result
for the selected category, a
detailed list will be displayed.
“List All Categories”: Select to dis-
play all POI categories.
4 Select the desired POI. 1
Select “Category”.
2 Select the desired search
point.
Select to search for POIs
near your current position.
Select to search for POIs
along the set route.
Select to search for POIs
near a specific city center.
( P.93)
Select to search for POIs
near a destination.
When more than 1 destina-
tion has been set, a list will
be displayed on the screen.
Select the desired destina-
tion.
3 Select the desired POI cate-
gory.
 Select “Other POIs” to select
other than default POI catego-
ries. The following button can
be displayed.
“List All Categories”: Select to dis-
play all POI categories.
“Favorite POI Categories”: Select to
use the 6 POIs that have been pre-
viously set. ( P.116)
4 Select the desired POI.
Selecting from the catego-
ries
Searching by category
A
B
C
D

933-2. Destination search
COROLLA_HB_Navi_(U)
3
Navigation system
●The names of POIs located within
approximately 200 miles (320 km)
from the selected search point can
be displayed. They are displayed
up to 200 names.
1 Select “Near a City Center in
XX
*”.
2 Enter a city name and select
“Search”.
“Last 5 Cities”: Se lect the desired
city name from the list of the last 5
cities.
3 Select the desired city name.
4 Select “OK” when the city
center map screen is dis-
played.
5 Follow the steps in “Search-
ing by category” from step 3.
( P. 9 2 )
*: XX represents the selected
search area name.
●If the navigation system has never
been used, selecting the city
name from “Last 5 Cities” will not
be available.
1 Select “Phone #”.
2 Enter a phone number and
select “OK”.
 If multiple locations with the
same phone number exist,
the list screen will be dis-
played.
●If there is no match for the entered
phone number, a list of identical
numbers with different area codes
will be displayed.
When “Near a City Center in
XX
*” is selected
Searching by phone num-
ber

943-2. Destination search
COROLLA_HB_Navi_(U)
To use this function, it is neces-
sary to register a home and/or a
favorite location. Up to 2 favor-
ites can be registered as preset
destinations. (P. 11 0 , 111 )
To set the home or a preset des-
tination as the destination,
select the corresponding button.
1 Turn the engine switch to
ACC or ON.
2 Press the “MAP” button.
3 Select the desired item.
Select to set the registered
home as the destination.
Select to set a registered
favorite as the destination.
(Up to 2 favorites can be reg-
istered as preset destina-
tions.)
 The estimated time of arrival
to the registered home and
preset destinations from the
current position will be dis-
played.
 If the home or a preset desti-
nation has not been regis- tered, “Save Home” or “Save
Favorite” will be displayed,
respectively. To register a
home or preset destination,
select the corresponding but-
ton.
●When the destination is very close
to the current po
sition, “Nearby”
will be displayed.
●The one-touch buttons for home
and favorites will disappear after
the vehicle has been driven for a
while.
●The color of the estimated arrival
time indicator may change
depending on the traffic informa-
tion received.
●This function is available when
“Automatic Destination List Info” is
set to on. ( P. 1 1 4 )
One-touch setting
home/favorite as a desti-
nation
A
B

953-2. Destination search
COROLLA_HB_Navi_(U)
3
Navigation system
1 Select “Go” on the confirm
destination screen.
 For details about this screen:
P. 9 6
2 Select “OK” on the route
overview screen.
 For details about this screen:
P. 9 6
●The route for returning may not be
the same as that for going.
●The route guidance to the destina-
tion may not be the shortest route
or a route without traffic conges- tion.
●Route guidance may not be avail-
able if there is no road data for the
specified location.
●When setting the destination on a
map with a scale more than 0.5
mile (800 m), the map scale
changes to 0.5 mile (800 m) auto-
matically. If this occurs, set the
destination again.
●If a destination that is not located
on a road is set, the vehicle will be
guided to the point on a road near-
est to the destination. The road
nearest to the selected point is set
as the destination.
Starting route guid-
ance
When the destination is set,
the entire route map from
the current position to the
destination is displayed.
Starting route guidance
WA R N I N G
●Be sure to obey traffic regula-
tions and keep road conditions
in mind while driving. If a traffic
sign on the road has been
changed, the r
oute guidance
may not indicate such changed
information.

963-2. Destination search
COROLLA_HB_Navi_(U)
Select to search for the route.
(P. 9 5 )
• If a destination has already been
set, “Go Directl y” and “Add to
Route” will be displayed.
“Go Directly”: Select to delete the
existing destination(s) and set a
new one.
“Add to Route”: Select to add a
destination to the current route.
Select to register as a mem-
ory point.
Select to call the registered
number.
Select to update information
about the selected entry.*
*: This function is displayed only when there is information from
the Cloud. ( P. 8 8 )
Current position
Destination point
Select to display a list of the
turns required to reach the
destination. ( P. 9 8 )
Select to change the route.
( P.98)
Select the desired route from
3 possible routes. ( P.97)
Type of route and its distance
Distance of the entire route
Select to start guidance.
Select and hold to start demo
mode. ( P.97)
Displayed when the route
displayed is from the Cloud.
( P.99)
Confirm destination
screen
A
B
C
D
5RXWHRYHUYLHZVF\
UHHQ
A
B
C
D
E
F
G
H
I

973-2. Destination search
COROLLA_HB_Navi_(U)
3
Navigation system
Before starting the route guid-
ance, the demonstration of the
route guidance can be viewed.
1 Select and hold “OK” on the
route overview screen until a
beep sounds.
 Press the “HOME” or “MAP”
button to end demo mode.
1 Select “3 Routes”.
2 Select the desired route.
Displayed when the route
displayed is available from
the Cloud. ( )
Select to display the quick-
est route.
Select to display the route
that is the shortest distance
to the set destination.
Select to display the alterna-
tive route.
Select to display the informa-
tion about the 3 routes.
( P. 9 7 ) 1
Select “Info”.
2 Check that the 3 routes infor-
mation screen is displayed.
Time necessary for the entire
trip
Distance of the entire trip
Distance of the toll road
Distance of the freeway
Distance of the ferry trip
Starting demo mode
3 routes selection
A
B
C
D
E
'LVSOD\LQJURXWHVLQIRUPD
WLRQ
A
B
C
D
E

983-2. Destination search
COROLLA_HB_Navi_(U)
A list of turn information from the
current position to the destina-
tion can be displayed.
1Select “Turn List”.
2 Check that the turn list is dis-
played.
Current position
Distance to the next turn
Turn direction at the intersec-
tion
Select to display the map of
the selected point.
●Not all road names on the route
may appear on the list. If a road
changes its name without requir-
ing a turn (such as on a street that
runs through 2 or more cities), the
name change will no t appear on
the list. The street names will be
displayed in order from the start-
ing point, along wit h the distance
to the next turn or the destination.
Destinations can be added,
reordered or deleted, and condi-
tions for the route to the destina-
tion can be changed.
1 Select “Edit Route”.
2 Select the desired item.
Select to add destinations.
( P.98)
Select to delete destinations.
( P.99)
Select to reorder destina-
tions. ( P.106)
Select to set route prefer-
ences. ( P.106)
1 Select “Add”.
2 Search for an additional des-
tination in the same way as a
destination search. ( P.86)
 Up to 5 destinations can be
set.
3 Select “Add” at the position in
the route which you want to
add the destination.
Displaying turn list
A
B
C
D
(GLWLQJURXWH
$GGLQJGHVWLQDWLRQV
A
B
C
D

993-2. Destination search
COROLLA_HB_Navi_(U)
3
Navigation system
1 Select “Delete”.
2 Select “Yes” when the confir-
mation screen appears.
 If more than 1 destination has
been set, select the destina-
tion(s) to be deleted. (The
navigation system will recal-
culate route(s) to the remain-
ing set destination(s).)*: This function is not available in
some countries or areas.
When starting route guidance or
rerouting, a route can be pro-
vided automatically by the
Cloud. This function is available
when dynamic route setting is
enabled. ( P. 1 1 4 )
Deleting destinations
A route from the Cloud*

1003-3. Route guidance
COROLLA_HB_Navi_(U)
3-3.Route guidance
Distance to the next turn and
an arrow indicating the turn-
ing direction
Guidance route
Current position
Select to mute the voice
guidance.
Route information (P.100)
Select to delete destinations.
( P. 2 2 )
Displays the lane recommen-
dation. ( P.101)
Guidance point
●If the vehicle goes off the guid-
ance route, the ro ute will be recal-
culated.
●For some areas, the roads have
not been complete ly digitized in
our database. For this reason, the
route guidance may select a road that should not be traveled on.
●When arriving at the set destina-
tion, the destinat
ion name will be
displayed on the upper part of the
screen.
●When the automatic zoom func-
tion is enabled, the map will auto-
matically change to a detailed
map as the vehicl e approaches a
guidance point. ( P. 1 1 5 )
●Vehicle with head-up display:
When the head-up display is set
to on, turn-by-turn guidance
arrows will be displayed on the
windshield.
When the vehicle is on the guid-
ance route, the route informa-
tion bar displays the distance
with the estimated travel/arrival
time to the destination.
When the set destination is 1
1 Check that the distance and
time to destination is dis-
played.
When the set destinations are
more than 1
1 Select the route information
bar.
Route guidance
screen
During the route guidance,
various types of guidance
screens can be displayed
depending on conditions.
Screen for route guidance
A
B
C
D
E
F
G
H
'LVWDQFHDQGWLPHWRGHVWL
QDWLRQ
