TOYOTA COROLLA HATCHBACK 2021 Accessories, Audio & Navigation (in English)

1013-3. Route guidance
COROLLA_HB_Navi_(U)
3
Navigation system
2 Check that the list of the dis-
tance and time is displayed.
 By selecting one of the num-
ber buttons, the desired route
information is displayed.
●When the vehicle is on the guid-
ance route, the distance mea-
sured along the route is displayed.
Travel time and arrival time are
calculated based on the average
speed of the specified speed limits
and current traffic information.
●When the vehicle gets off the
guidance route, the arrow facing
the destination is displayed
instead of the estimated
travel/arrival time.
●The route information bar fills from
left to right as the vehicle pro-
gresses along the route.
When approaching a turning
point, the lane recommendation
will automatically be displayed
on the map.
During freeway driving, the free-
way information screen can be
displayed.
Distance from the current
position to the freeway
exit/rest area
Name of the freeway exit/rest
area
POIs that are close to a free-
way exit
Select to display farther free-
way exits/rest areas.
●This function is available when
“Automatic Freeway Exit List” is
Lane recommendation
During freeway driving
A
B
C
D

1023-3. Route guidance
COROLLA_HB_Navi_(U)set to on. (
P. 1 1 4 )
When the vehicle approaches
an exit or junction, the freeway
guidance screen will be dis-
played.
Next exit or junction name
Select to hide the freeway
guidance screen.
• To return to the freeway guidance screen, press the “MAP” button.
Remaining distance bar to
the guidance point
●This function is available when
“Intersection Zoom Map” is set to
on. ( P. 1 1 4 )
When the vehicle approaches a
tollgate, the tollgate view will be
displayed.
Select to hide the tollgate
guidance screen.
• To return to the tollgate guidance screen, press the “MAP” button.
Remaining distance bar to
the guidance point
●This function is available when
“Intersection Zoom Map” is set to
on. ( P. 1 1 4 )
When approaching free-
way exit or junction
A
B
C
:KHQDSSURDFKLQJWROO
JDWH
A
B

1033-3. Route guidance
COROLLA_HB_Navi_(U)
3
Navigation system
When the vehicle approaches a
junction, the junction view with
signage will be displayed. Select to hide the real free-
way junction view.
• To return to the real freeway junc-tion view, press the “MAP” button.
Remaining distance bar to
the guidance point
●This function is available when
“Intersection Zoom Map” is set to
on. ( P. 1 1 4 )
When the vehicle approaches
an intersection, the intersection
guidance screen will be dis-
played.
Next street name
Select to hide the intersection
guidance screen.
• To return to the intersection guid-ance screen, press the “MAP”
button.
Remaining distance bar to
the guidance point
●This function is available when
“Intersection Zoom Map” is set to
on. ( P. 1 1 4 )
When approaching junc-
tion
A
B
:KHQDSSURDFK\
LQJLQWHU
VHFWLRQ
A
B
C

1043-3. Route guidance
COROLLA_HB_Navi_(U)
1Select “Turn List” on the map
mode screen. ( P.79)
2 Check that the turn list
screen is displayed.
Turn direction
Next street or destination
name
Distance between turns On this screen, information
about the next turn on the guid-
ance route can be displayed.
1
Select “Turn-by-Turn Arrow”
on the map mode screen.
( P.79)
2 Check that the turn-by-turn
arrow screen is displayed.
Exit number or street name
Turn direction
Distance to the next turn
Turn list screen
A
B
C
7XUQE\WXUQD\
UURZVFUHHQ
A
B
C

1053-3. Route guidance
COROLLA_HB_Navi_(U)
3
Navigation system
●If a voice guidance command can-
not be heard, press the “MAP”
button to hear it again.
●To adjust the voice guidance vol-
ume: P. 6 6
●To mute the voice guidance:
 P. 1 0 0
●Voice guidance may be made
early or late.
●If the navigation system cannot
determine the current position cor-
rectly, you may not hear voice
guidance or may not see the mag-
nified intersection on the screen.
1 Select on the map
screen. ( P. 7 4 )
2 Select the desired item to be
set.
Select to display the over-
view of the entire route.
( P.96)
Select to reorder destina-
tions. ( P.106)
Select to change route type.
( P.106)
Select to set route prefer-
ences. ( P.106)
Select to set detours.
( P.107)
Select to start from adjacent
road. ( P.108)
 To hide the route options
screen, touch any part of the
map screen.
3 Check that the route over-
view is displayed. ( P.96)
Typical voice guid-
ance prompts
As the vehicle approaches
an intersection, or point,
where maneuvering the
vehicle is necessary, the
navigation system’s voice
guidance will provide vari-
ous messages.
WA R N I N G
●Be sure to obey the traffic regu-
lations and keep the road condi-
t i o n i n m i n d e s p e c i a l l y w h e n y o u
are driving on IPD roads (roads
that are not completely digitized
in our database). The route
guidance may not have the
updated information such as the
direction of a one way street.
Editing route
Displaying the edit route
screen
A
B
C
D
E
F

1063-3. Route guidance
COROLLA_HB_Navi_(U)
When more than 1 destination
has been set, the arrival order of
the destinations can be
changed.
1Select on the map
screen. ( P.74)
2 Select “Reorder”.
3 Select the desired destina-
tion and select “Move Up” or
“Move Down” to change the
arrival order. Then select
“OK”.
1 Select on the map
screen. ( P.74)
2 Select “Route Type”.
3 Select the desired route type.
 The entire route from the
starting point to the destina-
tion is displayed. ( P.96)
 During driving, the route guid-
ance starts after selecting the
desired route type. The conditions to determine the
route can be selected from vari-
ous choices such as freeways,
toll roads, ferries, etc.
1
Select on the map
screen. ( P. 7 4 )
2 Select “Preference”.
3 Select the desired route pref-
erences and select “OK”.
●Even if the “Avoid Freeways”
route preference is turned off, the
route may not be able to avoid
freeways in some cases.
●If the calculated route includes a
trip by ferry, the route guidance
shows a sea route. After traveling
by ferry, the curre nt position may
be incorrect. Upon reception of
GPS signals, it is automatically
corrected.
Reordering destinations
Selecting route typeSetting route preferences

1073-3. Route guidance
COROLLA_HB_Navi_(U)
3
Navigation system
During the route guidance, the
route can be changed to detour
around a section of the route
where a delay is caused by road
repairs, an accident, etc.
1 Select on the map
screen. ( P.74)
2 Select “Detour”.
3 Select the desired detour dis-
tance.
Select to detour within 1 mile
of the current position.
Select to detour within 3
miles of the current position.
Select to detour within 5
miles of the current position.
Select to detour on the entire
route.
Select to make the navigation
system search for the route
based on traffic congestion
information received from
traffic information.
* ( P. 8 3 )
*: This function is not available in
some countries or areas.
●This picture shows an example of
how the navigation system would guide around a delay caused by a
traffic jam.
This position indi cates the loca-
tion of a traffic jam caused by
road repairs, an accident, etc.
This route indicates the detour
suggested by the navigation
system.
●When the vehicle is on a freeway,
the detour distance selections are
5, 15 and 25 miles (or 5, 15 and
25 km if units are in km).
●The navigation system may not be
able to calculate a detour route
depending on the selected dis-
tance and surrounding road condi-
tions.
Detour setting
A
B
C
D
E
A
B

1083-3. Route guidance
COROLLA_HB_Navi_(U)
When a freeway and a surface
road run in parallel, the naviga-
tion system may show the guid-
ance route going on the freeway
while driving on the surface
road, or vice versa.
If this happens, you can
instantly choose the adjacent
road for the route guidance.
1Select on the map
screen. ( P.74)
2 Select “Adjacent Road”.
●When there is no adjacent road,
this screen button will not be dis-
played.
Adjacent road

1093-4. Setup
COROLLA_HB_Navi_(U)
3
Navigation system
3-4.Setup
1 Press the “MENU” button.
2 Select “Setup”.
3 Select “Navigation”.
4 Select the desired item to be
set. Select to set home. (
P.110)
Select to set the favorites list.
( P. 1 1 1 )
Select to set areas to avoid.
( P. 1 1 3 )
Select to set detailed naviga-
tion settings. ( P. 1 1 4 )
●When “Useful Navi. Information
Settings” is displayed on the
screen: P. 1 2 2
Navigation settings
Home, favorites list entries,
areas to avoid can be set as
memory points. The regis-
tered points can be used as
the destinations. ( P.86)
Registered areas to avoid,
will be avoided when the
navigation system searches
for a route.
Displaying navigation set-
tings screen
Navigation settings
screen
A
B
C
D

1103-4. Setup
COROLLA_HB_Navi_(U)
If home has been registered,
that information can be recalled
by selecting “Home” on the
destination screen. (P.86)
1 Display the navigation set-
tings screen. ( P.109)
2 Select “Home”.
3 Select “Address”( P.90) or
“Current Location” to search
for your home.
4 Select “OK” when the editing
home screen appears. 1
Display the navigation set-
tings screen. ( P.109)
2 Select “Home”.
3 Select the desired item to be
edited.
Select to edit the home
name.
Select to edit location infor-
mation.
Select to change the icon to
be displayed on the map
screen. ( P.112)
Select to set display of the
home name on/off.
Select to delete registered
home location.
4 Select “OK”.
Setting up home
Registering home
Editing home
A
B
C
D
E
