TOYOTA HIGHLANDER 2020 Accessories, Audio & Navigation (in English)

1914-8. Rear seat entertainment system operation
HIGHLANDER_HIGHLANDER
HV_NAVI_(U)
4
Audio/visual system
Video CD
1 Select “Select Number”.
2 Input the track number, and
select “OK”.
Video CD
If there is the next or previous
page while the disc menu is dis-
played, the page can be
switched.
1 Select “Prev. Page” or “Next
Page”.
2 Next or previous page is dis-
played.
BD video, DVD video,
AVCHD, BDAV
The initial setting can be
changed.
1 Select “Setup”.
2 Select the settings to be
changed. After the settings
are changed, select “OK”.
Changing the initial audio
language
Changing the initial subtitle
language
Changing the initial lan-
guage of the disc menu
Setting the angle mark
Setting the DVD parental
control level
Setting the BD parental con-
trol age
Setting a quick playback
Searching by track
Displaying the next or previ-
ous page
Initial setup
A
B
C
D
E
F
G

1924-8. Rear seat entertainment system operation
HIGHLANDER_HIGHLANDER
HV_NAVI_(U)
Setting a sound dynamic
range
Restores default settings
BD history data such as
bookmarks and resume point
can be deleted.
 Select or to show the
next or previous page.
■Changing the initial audio
language
1 Select “Audio Language”.
2 Select the desired language.
 If you cannot find the desired
language, select “Other” and
input the desired language
code. ( P.216)
■Changing the initial subtitle
language
1 Select “Subtitle Language”.
2 Select the desired language.
 If you cannot find the desired language, select “Other” and
input the desired language
code. (
P.216)
■Changing the initial lan-
guage of the disc menu
1 Select “Menu Language”.
2 Select the desired language.
 If you cannot find the desired
language, select “Other” and
input the desired language
code. ( P.216)
■Setting the angle mark
If the BD/DVD disc has angle
options, you can turn the angle
mark on/off.
1 Each time “Angle Mark” is
selected, “On” or “Off” can be
selected.
■Setting the DVD parental
control level
DVD video
The level of viewer restrictions
H
I
J

1934-8. Rear seat entertainment system operation
HIGHLANDER_HIGHLANDER
HV_NAVI_(U)
4
Audio/visual system
can be set.
1 Select “Parental Control
Level”.
2 Input the 4-digit personal
code and then select “OK”.
 Select 10 times to reset
the personal code in case the
code was forgotten.
3 Select a restriction level
(1-8).
■Setting the BD parental con-
trol age
BD video
The age of viewer restrictions
can be set.
1 Select “BD Parental Control
Age”. 2
Input the 4-digit personal
code and then select “OK”.
 Select 10 times to reset
the personal code in case the
code was forgotten.
3 Input a restriction age (0-255)
and then select “OK”.
■Setting a quick playback
BD video
After inserting a BD disc you
can skip over to the first play-
back point and can immediately
playback the main story.

1944-8. Rear seat entertainment system operation
HIGHLANDER_HIGHLANDER
HV_NAVI_(U)
1Each time “Quick Play” is
selected, “On” or “Off” can be
selected.
■Setting a sound dynamic
range
The difference between the low-
est and highest sound volumes
can be adjusted.
1 Select “Sound Dynamic
Range”.
2 Select the desired setting.
“MAX”: Maximum sound
dynamic range
“MID”: Medium sound dynamic
range
“MIN”: Minimum sound dynamic
range Selecting a control icon
Inputting the selected control
icon
Volume up/down
Fast-forward/rewind
Play/pause
Selecting a track/file
Selecting a folder
Playing an audio CD
and MP3/WMA/AAC
discs
Press the “DISC” button if a
disc has already been
loaded in the disc slot.
The player will start to play
the disc automatically.
Remote controller
A
B
C
D
E
F
G

1954-8. Rear seat entertainment system operation
HIGHLANDER_HIGHLANDER
HV_NAVI_(U)
4
Audio/visual system
Turning on the audio CD and
MP3/WMA/AAC mode
Repeat play
Random playback
1 Insert a disc or press the
“DISC” button.
 The player will start to play
the disc automatically.
1 Press or until
the desired track/file number
appears.
1 Press and hold or
.
MP3/WMA/AAC
1 Press “ ” or “” on the
“FOLDER” button until the
desired folder number
appears.
 Press and hold “ ” on the
“FOLDER” button, the top file
stored in the top folder in the
disc will be selected.
1 Each time is selected,
the mode changes as follow:
Audio CD
track repeat  off
MP3/WMA/AAC
file repeat  folder repeat  off
1 Each time is selected,
the mode changes as follow:
Audio CD
random  off
MP3/WMA/AAC
1 folder random  1 disc ran-
dom  off
Control screen
Turning on the CD mode
Selecting a track/file
Fast forwarding or
rewinding a track/file
H
A
B
6HOHFWLQJDIROGHU
5HSHDWSOD\
5DQGRPSOD\EDFN

1964-8. Rear seat entertainment system operation
HIGHLANDER_HIGHLANDER
HV_NAVI_(U)
Selecting a control icon
Inputting the selected control
icon
Volume up/down
Fast-forward/rewind
Play/pause
Stop
Displaying the option screen
Selecting a chapterTurning on the SD card mode
Playing music (
P.197)
Playing still pictures
( P.198)
Playing SD video ( P.200)
Playing AVCHD video
( P.200)
Playing movie ( P.200)
Formatting the SD card
( P.203)
Deleting the BD history data
( P.203)
Playing an SD card
This system can play music,
still pictures and video that
are stored in an SD card.
Press the “SD” button if an
SD card has already been
inserted in the SD card slot.
Remote controller
A
B
C
D
E
F
G
H
0DLQPHQX
I
A
B
C
D
E
F
G

1974-8. Rear seat entertainment system operation
HIGHLANDER_HIGHLANDER
HV_NAVI_(U)
4
Audio/visual system
1 Press the button to
play/pause.
 Press and hold the but-
ton while pausing, the video is
played slowly.
1 Press or until
the desired track/file number
appears.
1 Press and hold or
. You can play music that is
stored on an SD card.
1
Select “Music”.
2 Music will start playing.
Repeat play
Random playback
Playing/pausing an SD
card media
Selecting a chap-
ter/track/file
Fast forwarding or
rewinding a chap-
ter/track/file
Playing music
A
B

1984-8. Rear seat entertainment system operation
HIGHLANDER_HIGHLANDER
HV_NAVI_(U)
You can display still pictures that
are stored on an SD card.
1Select “Picture”.
2 Select the desired still picture
to show.
 Select or to show the
next or previous page.
3 Selected picture is displayed
on the screen.
 Press the or button to
display the next or previous
still picture.
 Press the “SD” button to return to the SD menu screen.
Press the “OPTION” button
while displaying a still picture,
the following screen appears.
Press the “OPTION” button
once again or select “Hide But-
tons” to turn off the option
screen.
Turning off the option screen
Displaying the slideshow
setup screen
Returning to “Library View”
screen
Zooming out the still pictures
Rotating the still pictures
Displaying the detail informa-
tions of the still picture
Starting slideshow
Playing still pictures
Option screen
A
B
C
D
E
F
G

1994-8. Rear seat entertainment system operation
HIGHLANDER_HIGHLANDER
HV_NAVI_(U)
4
Audio/visual system
You can display still pictures one
by one at a constant interval.
1 Select “Slideshow” to start
slideshow.
 When pressing the or
button during slideshow, the
previous or next still picture
will be shown, and the slide-
show will continue from that
picture.
 Press the “ENT” or “OPTION”
button to stop slideshow.
1 Select or to rotate a
still picture.
 The rotate information will be
maintained until the system is
turned off or the SD card is
removed.
1 Select to zoom out the
still pictures.
 Select again to cancel
zoom out.
 This function is only available
for smallsized still pictures. 1
Select “Detailed Information”.
2 Detail informations of the still
picture are displayed.
1 Select “Setup”.
2 The slideshow settings can
be changed. After the set-
tings are changed, select
“OK”.
Selects slideshow interval
time (seconds)
5  10  15  30  60
Selects slideshow effect
“Fade”  “Slide” “Wipe1”
 “Wipe2”  “Dissolve”
 “Zoom” “Off”
Selects on/off repeat slide-
show
Starting slideshow
Rotating the still pictures
Zoom out the still pictures
Displaying the detail infor-
mations of the still picture
Slideshow setup
A
B
C

2004-8. Rear seat entertainment system operation
HIGHLANDER_HIGHLANDER
HV_NAVI_(U)
Restores default settings
You can play videos that are
stored in an SD card.
1 Select “SD Video”, “SD
AVCHD” or “Movie”.
2 Video will start playing.
 Press the “SD” button to
return to the SD menu screen. Press the “OPTION” button
while watching a video, the fol-
lowing screen appears.
Press the “OPTION” button
once again or select “Hide But-
tons” to turn off the option
screen.
When there are two pages,
select “>” or “<” to change the
page.
SD video
SD AVCHD
Playing video
D2SWLRQVFUHHQ
