TOYOTA iA 2016 Owners Manual (in English)

411
iA_OM_OM99M17z_(U)
4-4. Interior Equipment
4
Interior Features
Cup Holder
WARNING
■Never use a cup holder to hold hot liquids while the vehicle is moving
Using a cup holder to hold hot liquids while the vehicle is moving is danger-
ous. If the contents spill, you could be scalded.
■ Do not put anything other than cu ps or drink cans in cup holders
Putting objects other than cups or drink
cans in a cup holder is dangerous.
During sudden braking or maneuvering,
occupants could be hit and injured, or
objects could be thrown around the vehi-
cle, causing interference with the driver
and the possibility of an accident. Only
use a cup holder for cups or drink cans.

412
iA_OM_OM99M17z_(U)
4-4. Interior Equipment
Bottle Holder
Bottle holders are on the inside of
the front doors.
Bottle holder
NOTICE
Do not use the bottle holders for containers without caps. The contents may
spill when the door is opened or closed.

413
iA_OM_OM99M17z_(U)
4-4. Interior Equipment
4
Interior Features
Storage Compartments
This console box is designed to
store eyeglasses or other acces-
sories.
Push and release to open.
WARNING
■Keep storage boxes closed when driving
Driving with the storage boxes open is dangerous. To reduce the possibility
of injury in an accident or a sudden stop, keep the storage boxes closed
when driving.
■ Do not put articles in storage spaces with no lid
Putting articles in storage spaces with no lid is dangerous as they could be
thrown around the cabin if the vehicle is suddenly accelerated and cause
injury depending on how the article is stored.
NOTICE
Do not leave lighters or eyeglasses in the storage boxes while parked under
the sun. A lighter could explode or the plastic material in eyeglasses could
deform and crack from high temperature.
Overhead Console

414
iA_OM_OM99M17z_(U)
4-4. Interior Equipment
To open the glove compartment,
pull the latch toward you.
To close the glove compartment, firmly press in the center of the glove
compartment lid.
A cup or small items can be placed on the center console tray using
the center console divider.
The center console tray is large
enough to place a small item
when the center console divider is
not in use.
Glove Compartment
Center Console Tray
WARNING
■ Never use a cup holder to hold hot liquids while the vehicle is moving
Using a cup holder to hold hot liquids while the vehicle is moving is danger-
ous. If the contents spill, you could be scalded.

iA_OM_OM99M17z_(U)
4154-4. Interior Equipment
4
Interior Features
Lift the trunk mat.
Always hang clothes on the coat
hooks and the assist grips without
hangers.
Cargo Sub-Compartment
Rear Coat Hooks
WARNING
■Never hang heavy or sharp objects on the assist grips and coat hooks
Hanging heavy or sharp-ended objects such as a coat hanger from the
assist grips or coat hooks is dangerous as they can fly off and hit an occu-
pant in the cabin if a curtain air bag was to deploy, which could result in seri-
ous injury or death.

416
iA_OM_OM99M17z_(U)
4-4. Interior Equipment

417
iA_OM_OM99M17z_(U)
5Maintenance and Care
5-1. Essential InformationIntroduction ....................... 418
5-2. Scheduled Maintenance Maintenance Monitor ........ 420
5-3. Owner Maintenance Owner Maintenance Precautions ..................... 424
Hood ................................. 426
Engine Compartment Overview ......................... 428
Engine Oil ......................... 429
Engine Coolant ................. 431
Brake/Clutch Fluid............. 434
Window Washer Fluid ....... 435
Body Lubrication ............... 436
Wiper Blades..................... 437
Battery............................... 440
Key Battery Replacement ................... 443
Tires .................................. 446
Light Bulbs ........................ 451
Fuses ................................ 460
5-4. Appearance Care Exterior Care ..................... 468
Interior Care ...................... 476

418
iA_OM_OM99M17z_(U)
5-1. Essential Information
Introduction
Be extremely careful and prevent injury to yourself and others or dam-
age to your vehicle when using this manual for inspection and mainte-
nance.
If you are unsure about any procedure it describes, we strongly urge
you to have a reliable and qualified service shop perform the work,
preferably your Scion dealer.
Factory-trained Scion technicians and genuine Scion parts are best
for your vehicle. Without this ex pertise and the parts that have been
designed and made especially for your Scion, inadequate, incom-
plete, and insufficient servicing may result in problems. This could
lead to vehicle damage or an accident and injuries.
For expert advice and quality service, consult your Scion dealer.
To continue warranty eligibility and to protect your investment, it is
your responsibility to properly main tain your vehicle according to fac-
tory recommended schedul es outlined in this manual. Keep a copy of
the repair order. It proves that the maintenance that has been per-
formed is under warranty coverage. If any problem should arise while
your vehicle is under warranty, yo ur Scion dealer will promptly take
care of it.
This evidence may consist of the following:
● The Maintenance Log, found within the Warranty and Maintenance
Guide, must be completely filled out showing mileage, repair order
number, date for each service, and signed by a qualified automotive
service technician who service vehicles.
● Original copies of repair orders or other receipts that include the
mileage and date the vehicle was serviced. Each receipt should be
signed by a qualified automot ive service technician.
● For self maintenance, a statement that you completed the mainte-
nance yourself, displaying mileag e and the date the work was per-
formed. Also, receipts for the replacement parts (fluid, filters, etc.)
indicating the date and mileage mu st accompany this statement.

iA_OM_OM99M17z_(U)
4195-1. Essential Information
5
Maintenance and Care
If you elect to perform maintenance yourself or have your vehicle serviced at
a location other than your Scion dealer, Scion requires that all fluids, parts
and materials must meet Scion standards for durability and performance as
described in this manual.
Claims against the warranty resulting from lack of maintenance, as
opposed to defective materials or authorized Scion workmanship, will
not be honored.
Any auto repair shop using parts eq uivalent to your Scion’s original
equipment may perform maintenance. But we recommend that it
always be done by your Scion dealer using genuine Scion parts.
Selecting “Maintenance Monitor” enables the system to notify you of
your vehicle’s approaching ins pection/servicing period (P. 420).

420
iA_OM_OM99M17z_(U)
5-2. Scheduled Maintenance
Maintenance Monitor
“Oil Change” with a flexible setting*1 is available. Consult your Autho-
rized Scion Dealer when you want to change the setting
*2. Once the
system turns on, the wrench indicator light in the instrument cluster
will be illuminated when remaining oi l life becomes less than 300
miles (500 km), or remaining days ar e less than 15 (whichever comes
first).
■Reset method
Press and hold the selector with
the ignition switched off, then
switch it on. Keep pressing the
selector for mo re than 5 sec-
onds. The master warning light
will flash for a few seconds
when the reset is completed.
*1The flexible setting is available in the United States and Puerto Rico.
Based on the engine operating conditions, the onboard computer in your
vehicle calculates the remaining oil life. Toyota Genuine Motor Oil 0W-20
or equivalent are required to achieve optimum calculation performance.
*2Once the Flexible Oil Maintenance Setting is selected, the system must be
reset whenever replacing the engine oil.
Select the icon on the home screen to display the “Applica-
tions” screen.
Select “Maintenance” to display the maintenance list screen.
Switch the tab and select the se tting item you want to change.
You can customize settings in the setup display as follows:
Maintenance Monitor (Type A audio)
Selector
Maintenance Monitor (Type B audio)
1
2
3
