TOYOTA LAND CRUISER 1996 J80 Workshop Manual

−
BODY ELECTRICAL BODY ELECTRICAL SYSTEM
BE−7
1996 LAND CRUISER (RM451U)
DEFOGGER SYSTEM
SymptomSuspect AreaSee page
Defogger system does not operate.
1. DEFOG Fuse (I/P F/B)
2. GAUGE Fuse (I/P F/B)
3. Defogger Switch
4. Defogger Relay (No.1 R/B)
5. Defogger Wire
6. Wire Harness−
−
BE−43
BE−43 −
−
POWER WINDOW CONTROL SYSTEM
SymptomSuspect AreaSee page
Power window does not operate (ALL).
(Power door lock does not operate.)
1. POWER Fuse (I/P F/B)
2. GAUGE Fuse (I/P F/B)
3. Power Main Relay (No.1 R/B)
4. Wire Harness−
−
−
−
Power window does not operate (ALL).
(Power door lock is normal.)
1. Ignition Switch
2. Power Main Relay (No.1 R/B)
3. Power Window Master Switch
4. Wire HarnessBE−11
−
BE−46 −
”One touch power window system” does not operate.1. Power Window Master SwitchBE−46
Only one window glass does not operate.
1. Power Window Master Switch
2. Power Window Switch
3. Power Window Motor
4. Wire HarnessBE−46
BE−46
BE−46−
POWER DOOR LOCK CONTROL SYSTEM
SymptomSuspect AreaSee page
Power door lock control system does not operate (ALL).
1. POWER Fuse (I/P F/B)
2. Power Main Relay (No.1 R/B)
3. Wire Harness−
−
−
Power door lock control system does not operate by door lock
control switch.1. Door Lock Control Switch
2. Power Main Relay (No.1 R/B)
3. Wire HarnessBE−51
−
−
Power door lock control system does not operate by door key.
1. Door Key Lock and Unlock Switch
2. Power Main Relay (No.1 R/B)
3. Wire HarnessBE−11−
−
Only one door does not operate.
1. Door Lock Motor
2. Door Lock Link Disconnected
3. Wire HarnessBE−51 −
−
Fault in key confine prevention operation.
1. Power Main Relay (No.1 R/B)
2. Key Unlock Warning Switch
3. Door Courtesy Switch
4. Wire Harness−
BE−11
BE−21 −
SLIDING ROOF SYSTEM
SymptomSuspect AreaSee page
Sliding roof system does not operate.
(Door lock does not operate.)
1. GAUGE Fuse (I/P F/B)
2. Ignition Switch
3. POWER Fuse (No.1 J/B)
4. Power Main Relay (No.1 R/B)
5. Sliding Roof Control Switch
6. Sliding Roof Control Relay
7. Sliding Roof Motor
8. Wire Harness−
BE−11 −
−
BE−58
BE−58
BE−58
−
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

BE−8
−
BODY ELECTRICAL BODY ELECTRICAL SYSTEM
1996 LAND CRUISER (RM451U)
Sliding roof system operates abnormally.
1. Limit Switch
2. Sliding Roof Control Switch
3. Sliding Roof Control RelayBE−58
BE−58
BE−58
Sliding roof system stops operation half way.
1. Sliding Roof Control Relay
2. Sliding Roof Limit Switch
3. Sliding Roof Control Switch
4. Sliding Roof Motor
(Stones to foreign material trapped in motor assembly)BE−58
BE−58
BE−58
BE−58
”Key−off sliding roof” operation does not operate.
1. POWER Fuse (I/P F/B)
2. Door Lock Control Relay
3. GAUGE Fuse (I/P F/B)
4. Ignition Switch
5. Door Courtesy Switch
6. Wire Harness−
BE−51 −
BE−11
BE−21
−
POWER MIRROR SYSTEM
SymptomSuspect AreaSee page
Power mirror system does not operate.
1. CIG Fuse (I/P J/B)
2. Mirror Control Switch
3. Mirror Motor
4. Wire Harness−
BE−69
BE−69 −
Power mirror operate abnormally.
1. Mirror Control Switch
2. Mirror Motor
3. Wire HarnessBE−69
BE−69−
POWER SEAT CONTROL SYSTEM
SymptomSuspect AreaSee page
Power seat does not operate.
1. POWER Fuse (I/P F/B)
2. Power Seat Switch
3. Wire Harness−
BE−62 −
”Sliding operation” does not operate.
1. Slide Motor
2. Power Seat Switch
3. Wire HarnessBE−62
BE−62−
”Reclining operation” does not operate.
1. Reclining Motor
2. Power Seat Switch
3. Wire HarnessBE−62
BE−62−
”Rear vertical operation” does not operate.
1. Rear Vertical Motor
2. Power Seat Switch
3. Wire HarnessBE−62
BE−62−
”Lumber support operation” does not operate.
1. Lumber Support Motor
2. Lumber Support Switch
3. Wire HarnessBE−62
BE−62−
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

BE1LU−01
−
BODY ELECTRICAL POWER SOURCE
BE−9
1147
Author: Date:
1996 LAND CRUISER (RM451U)
POWER SOURCE
LOCATION
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

BE1LV−01
BE−10−
BODY ELECTRICAL IGNITION SWITCH AND KEY UNLOCK WARNING
SWITCH
1148
Author: Date:
1996 LAND CRUISER (RM451U)
IGNITION SWITCH AND KEY UNLOCK WARNING SWITCH
LOCATION
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

BE1LW−01
−
BODY ELECTRICAL IGNITION SWITCH AND KEY UNLOCK WARNING
SWITCHBE−11
1996 LAND CRUISER (RM451U)
INSPECTION
1. INSPECT IGNITION SWITCH CONTINUITY
Switch positionTester connectionSpecified condition
LOCK−No continuity
ACC7 − 9Continuity
ON3 − 4, 6 − 7 − 9Continuity
START2 − 3 − 4
6 − 9 − 10Continuity
If continuity is not as specified, replace the switch.
2. INSPECT SWITCH CONTINUITY
ConditionTester connectionSpecified condition
SW OFF
(Key removed)−No continuity
SW ON (Key set)1 − 5Continuity
If continuity is not as specified, replace the switch.
3. INSPECT DOOR COURTESY SWITCH CONTINUITY
(See page BE−21 )
4. INSPECT SEAT BELT WARNING RELAY CIRCUIT
(See page BE−34 )
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

BE1LX−01
BE−12
−
BODY ELECTRICAL HEADLIGHT AND TAILLIGHT SYSTEM
1150
Author: Date:
1996 LAND CRUISER (RM451U)
HEADLIGHT AND TAILLIGHT SYSTEM
LOCATION
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

BE1LY−01
−
BODY ELECTRICAL HEADLIGHT AND TAILLIGHT SYSTEM
BE−13
1996 LAND CRUISER (RM451U)
COMPONENTS
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

BE1LZ−01
BE−14
−
BODY ELECTRICAL HEADLIGHT AND TAILLIGHT SYSTEM
1996 LAND CRUISER (RM451U)
INSPECTION
1. INSPECT LIGHT CONTROL SWITCH CONTINUITY
Switch positionTester connectionSpecified condition
OFF−No continuity
TAILA2 − A11Continuity
HEADA2 − A11 − A13Continuity
If continuity is not as specified, replace the switch.
2. INSPECT HEADLIGHT DIMMER SWITCH CONTINU-
ITY
Switch positionTester connectionSpecified condition
FlashA9 − A12 − A14Continuity
Low beamA3 − A9Continuity
High beamA9 − A12Continuity
If continuity is not as specified, replace the switch.
3. INSPECT HEADLIGHT CONTROL RELAY CONTINU-
ITY
ConditionTester connectionSpecified condition
Constant1 − 2Continuity
Apply B+ between
terminals 1 and 2.3 − 4Continuity
If continuity is not as specified, replace the relay.
4. INSPECT TAILLIGHT CONTROL RELAY CONTINUITY
ConditionTester connectionSpecified condition
Constant1 − 2Continuity
Apply B+ between
terminals 1 and 2.2 − 3Continuity
If continuity is not as specified, replace the relay.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

−
BODY ELECTRICAL HEADLIGHT AND TAILLIGHT SYSTEM
BE−15
1996 LAND CRUISER (RM451U)
5. INSPECT HEADLIGHT RETAINER CIRCUIT
(a) Connect the positive (+) leads from the battery to termi-
nals 1 and 6, and the negative ( −) lead to terminal 3.
(b) Connect the 3.4 W test bulb between terminal 7 and the positive (+) lead from the battery.
(c) Disconnect the positive (+) lead from terminal 1, and check that the test bulb is lighting.
(d) Connect the negative ( −) lead to terminal 5, and check
that the test bulb goes out.
If operation is not as specified, replace the relay.
6. INSPECT TAILLIGHT CIRCUIT
(a) Connect the positive (+) leads from the battery to termi- nals 1 and 6, and the negative ( −) lead to terminal 2.
(b) Connect the 3.4 W test bulb between terminal 8 and the positive (+) lead from the battery.
(c) Disconnect the positive (+) lead from terminal 1, and check that the test bulb is lighting.
(d) Connect the negative ( −) lead to terminal 5, and check
that the test bulb goes out.
If operation is not as specified, replace the relay.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

BE1M0−01
BE−16
−
BODY ELECTRICAL HEADLIGHT AND TAILLIGHT SYSTEM
1996 LAND CRUISER (RM451U)
ADJUSTMENT
1. ADJUSTING HEADLIGHT AIM ONLY
(a) Put the vehicle in below conditions.
Make sure the body around the headlight is not de-
formed.
Park the vehicle on a level place.
The driver gets into the driver’s seat and puts the
vehicle in a state ready for driving (with a full tank).
Bounce the vehicle several times.
(b) Adjust headlight in vertical alignment.
If the gauge bubble is outside the acceptable range of the beam
angle gauge, adjust it using adjusting screw A.
HINT:
The beam angle will change about 0 °11’ with one mark.
Brought to you by BirfMark
