Page 441 of 1399

TOYOTA LAND CRUISER 1996 J80 Workshop Manual N09214
DI−4
−
DIAGNOSTICS ENGINE
1996 LAND  CRUISER   (RM451U)
The diagnosis system operates in normal mode
during normal vehicle use. It also has a check mode
for technicians to simulate malfunc

Page 442 of 1399

TOYOTA LAND CRUISER 1996 J80 Workshop Manual P22215
−
DIAGNOSTICS ENGINE
DI−5
1996 LAND CRUISER   (RM451U)
Terminal No.
Connection / Voltage or ResistanceCondition
2Bus
 Line / Pulse generationDuring transmission
4Chassis Ground /  ↔ Bod

Page 443 of 1399

TOYOTA LAND CRUISER 1996 J80 Workshop Manual FI3605
ON
OFF Flashing
0.13 Second
DI−6
−
DIAGNOSTICS ENGINE
1996 LAND  CRUISER   (RM451U)
NOTICE:
When simulating symptoms with an OBD II scan tool (ex-
cluding TOYOTA hand −held tester) to che

Page 444 of 1399

TOYOTA LAND CRUISER 1996 J80 Workshop Manual −
DIAGNOSTICS ENGINE
DI−7
1996 LAND CRUISER   (RM451U)
(10) After checking the DTC, inspect the applicable cir-
cuit.
(b) Clear the DTC.
The following actions will erase the DTCs and freezed
frame

Page 445 of 1399

TOYOTA LAND CRUISER 1996 J80 Workshop Manual P04771
InsideOutside
DI−8
−
DIAGNOSTICS ENGINE
1996 LAND  CRUISER   (RM451U)
6. BASIC INSPECTION
When the malfunction code is not confirmed in the DTC check, troubleshooting\
 should be performed

Page 446 of 1399

TOYOTA LAND CRUISER 1996 J80 Workshop Manual A00149
DLC1
E1
TE1 SST
P09137
P23430
−
DIAGNOSTICS ENGINE
DI−9
1996 LAND CRUISER   (RM451U)
OK
5 Check idle speed.
PREPARATION:
(a) Warm up engine to normal operating temperature.
(b) Switch off a

Page 447 of 1399

TOYOTA LAND CRUISER 1996 J80 Workshop Manual P09401
P22893
DI−10
−
DIAGNOSTICS ENGINE
1996 LAND  CRUISER   (RM451U)
OK
Proceed to matrix chart of problem symp-
toms on page  DI−19.
7 Check fuel pressure.
PREPARATION:
(a) Be sure that enoug

Page 448 of 1399

TOYOTA LAND CRUISER 1996 J80 Workshop Manual −
DIAGNOSTICS ENGINE
DI−11
1996 LAND CRUISER   (RM451U)
NG Proceed to page IG−1  and continue to trouble-
shoot.
OK
Proceed to matrix chart of problem symp-
toms on page  DI−19.
7. ENGINE OPER

Page 449 of 1399

TOYOTA LAND CRUISER 1996 J80 Workshop Manual DI−12
−
DIAGNOSTICS ENGINE
1996 LAND  CRUISER   (RM451U)
(b) TOYOTA Enhanced Signals.
TOYOTA hand−held tester displayMeasurement ItemNormal Condition*
MISFIRE RPMEngine RPM for first misfire ran

Page 450 of 1399

TOYOTA LAND CRUISER 1996 J80 Workshop Manual DI5OV−03
−
DIAGNOSTICS ENGINE
DI−13
1996 LAND CRUISER   (RM451U)
DIAGNOSTIC TROUBLE CODE CHART
HINT:
Parameters listed in the chart may not be exactly the same as your reading due to \
the type
