TOYOTA LAND CRUISER 1996 J80 Workshop Manual

N09214
DLC3
DI−134
−
DIAGNOSTICS AUTOMATIC TRANSMISSION
1996 LAND CRUISER (RM451U)
(9) After simulating the malfunction conditions, use the
TOYOTA hand−held tester diagnosis selector to
check the DTCs and freeze frame data, etc.
HINT:
Take care not to turn the ignition switch OFF. T urning the ignition
switch off switches the diagnosis system from check mode to
normal mode, so all DTCs, etc. are erased. (10) After checking the DTC, inspect the applicable cir-cuit.
(b) Clear the DTC. The following actions will erase the DTCs and freeze
frame data.Operating the OBD II scan tool (complying with SAE
J1978) or TOYOTA hand−held tester to erase the
codes (See the OBD II scan tool’s instruction book
for operating instructions.).
NOTICE:
If the T OYOTA hand−held tester switches the ECM from the
normal mode to the check mode or vice−versa, or if the
ignition switch is turned from ON to ACC or OFF during the
check mode, the DTCs and freezed frame data will be
erased.
(c) Check the DLC3. The vehicle’s ECM uses V.P.W. (V ariable Pulse Width) for
communication to comply with SAE J1850. The terminal
arrangement of DLC3 complies with SAE J1962 and
matches the V.P.W. format.
Terminal No.Connection/V oltage or ResistanceCondition
2Bus  Line/Pulse generationDuring communication
4Chassis Ground − Body/1 Ω or lessAlways
5Signal Ground − Body/1 Ω or lessAlways
16Battery Positive − Body/9 − 14 V or 1 Ω or lessAlways
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

−
DIAGNOSTICS AUTOMATIC TRANSMISSION
DI−135
1996 LAND CRUISER (RM451U)
HINT:
If your display shows ”UNABLE TO CONNECT TO VEHICLE”
when you have connected the cable of the OBD II scan tool or
TOYOTA hand−held tester to the DLC3, turned the ignition
switch ON and operated the scan tool, there is a problem on the
vehicle side or tool side.
If communication is normal when the tool is connected to
another vehicle, inspect the DLC3 on the original vehicle.
If communication is still not possible when the tool is con-
nected to another vehicle, the problem is probably in the
tool itself, so consult the Service Department listed in the
tool’s instruction manual.
4. CHECK FOR INTERMITTENT PROBLEMS
TOYOTA hand−held tester only:
By putting the vehicle’s ECM in the check mode, 1 trip detection logic is possible instead of 2\
trip detection
logic and sensitivity to detect open circuits is increased. This makes it easier t\
o detect intermittent problems.
(1) Clear the DTC (See step 3).
(2) Set the check mode (See step 3).
(3) Do a simulation test (See page IN−18).
(4) Check the cnnector connection and terminal (See page IN−28).
(5) Visual check and contact pressure (See page IN−28).
(6) Handle the connector (See page IN−28).
5. ROAD TEST
NOTICE:
Perform the test at normal operating ATF temperature 50 − 80°C (122 − 176° F).
(a) D position test in NORM and PWR pattern positions. Shift into the D position and hold the accelerator pedal constant at the full\
throttle valve opening posi-
tion and check the following:
HINT:
When the 2nd start switch in on, there is no 1 → 2 up−shift and 2 →1 down−shift.
(1) 1 →2, 2 → 3 and 3 → O/D up−shift takes place, and shift point should conform to those shown
in the automatic shift schedule. Conduct a test under both Normal and Powe\
r patterns.
HINT:
There is no O/D up−shift or lock−up when the coolant temperature is below 55 °C (131°F ).
Evaluation:
If there is no 1 → 2 up−shift:
Shift solenoid valve No. 2 is stuck.
1−2 shift valve is stuck.
If there is no 2 → 3 up−shift:
Shift solenoid valve No. 1 is stuck.
2−3 shift valve is stuck.
If there is no 3 → O/D up−shift:
3−4 shift valve is stuck.
If the shift point is defective:
Throttle valve, 1−2 shift valve, 2−3 shift valve, 3−4 shift valve etc., are defective.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

DI−136
−
DIAGNOSTICS AUTOMATIC TRANSMISSION
1996 LAND CRUISER (RM451U)
If the lock−up is defective:
Lock−up solenoid is stuck.
Lock−up control valve is stuck.
Lock−up signal value is stuck.
(2) In the same way, check the shock and slip at the 1 → 2, 2 →3 and 3 → O/D up−shift.
Evaluation:
If the shock is excessive:
Line pressure is too high.
Accumulator is defective.
Check ball is defective. (3) Run at the D position lock −up or O/D gear and check for abnormal noise and vibration.
HINT:
The check for the cause of abnormal noises and vibration must be made with \
extreme care as it could also
be due to loss of balance in the propeller shaft, differential, torque converter clutch, etc.
(4) While running in the D position, 2nd, 3rd and O/D gears, check to see that the\
possible kick −down
vehicle speed limits for 2 →1, 3 → 2 and O/D →3 kick−downs conform to those indicated on
the automatic shift schedule.
(5) Check for abnormal shock and slip at kick −down.
(6) Check for the lock −up mechanism.
Drive in D position, O/D gear, at a steady speed (lock −up ON) of about 95 km/h (59 mph).
Lightly depress the accelerator pedal and check that the engine RPM does not change
abruptly.
If there is a big jump in engine RPM, there is no lock −up.
(b) 2 position test. Shift into the 2 position and, while driving with the accelerator pedal held \
constantly at the full throttle
valve opening position, push in one of the pattern selectors and check the fo\
llowing points:
HINT:
When the 2nd start switch is on, there is no 1 → 2 up−shift and 2 →1 down−shift.
(1) Check to see that the 1 → 2 up− shift takes place and that the shift point conforms to the automatic
shift schedule.
HINT:
There is no O/D up−shift and lock−up in the 2 position. (2) While running in the 2 position and 2nd ge ar, release the accelerator pedal and check the engine
braking effect.
Evaluation:
If there is no engine braking effect:
2nd coast brake is defective. (3) Check for abnormal noise at acceleration and deceleration, and for shock at up −shift and down −
shift.
(c) L position test. (1) While running in the L position, check to see that there is no up −shift to 2nd gear.
(2) While running in the L position, release the accelerator pedal and check the engine braking ef- fect.
Evaluation:
If there is no engine braking effect:
1stand reverse brake is defective. (3) Check for abnormal noise during acceleration and deceleration.
(d) R position test. Shift into the R position and fully depress the accelerator pedal and ch\
eck for slipping.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

AT3417
OK if hot
Add if hot
Q07273
−
DIAGNOSTICS AUTOMATIC TRANSMISSION
DI−137
1996 LAND CRUISER (RM451U)
(e) P position test.
Stop the vehicle on a grade (more than 5 °) and after shifting into the P position, release the parking
brake. Then, check to see that the parking lock pawl holds the vehicle i\
n place.
6. BASIC INSPECTION
(a) Check the fluid level.
HINT:
Drive the vehicle so that the engine and transmission are
at normal operating temperature.
Fluid temp.: 70 − 80°C (158 − 176° F)
Only use the COOL range on the dipstick as a rough refer-
ence when the ATF is replaced or the engine does not
run.
(1) Park the vehicle on a level surface and set the park-
ing brake.
(2) With the engine idling and the brake pedal de- pressed, shift the shift lever into all positions from P
to L position and return to P position.
(3) Pull out the dipstick and wipe it clean.
(4) Push it back fully into the pipe.
(5) Pull it out and check that the fluid level is in the HOT range.
If the level is at the low side, add new fluid. Fluid type: ATF DEXRON ®II
NOTICE:
Do not overfill.
(b) Check the fluid condition. If the fluid smells burnt or is black, replace it.
(c) Replace the ATF. (1) Remove the drain plug and drain the ATF.
(2) Reinstall the drain plug securely.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

Q07308
AT3417
OK if hot
Add if hot
AT4252
0 − 1 mm
Q07309
DI−138
−
DIAGNOSTICS AUTOMATIC TRANSMISSION
1996 LAND CRUISER (RM451U)
(3) With the engine OFF, add new fluid through the oil
filler pipe.
Fluid type: ATF DEXRON ®II
Capacity:
Dry fill: 11.0 liters (11.6 US qts, 9.7 Imp. qts)
Drain and refill: 1.9 liters (2.0 US qts, 1.7 Imp. qts)
(4) Start the engine and shift the shift lever into all posi-
tions from P to L position and then shift into P posi-
tion.
(5) With the engine idling, check the fluid level. Add fluid up to the COOL level on the dipstick.
(6) Check the fluid level at the normal operating tem- perature 70 − 80° C (158 − 176°F) and add as nec-
essary.
NOTICE:
Do not overfill.
(d) Check the fluid leaks.
Check for leaks in the transmission.
If there are leaks, it is necessary to repair or replace O −rings,
Seal packings, oil seals, plugs or other parts.
(e) Inspect and adjust the throttle cable. (1) Check that the throttle valve is fully closed.
(2) Check that the inner cable is not slack.
(3) Measure the distance between the outer cable endand stopper on the cable.
Standard distance: 0 − 1 mm (0 − 0.04 in.)
If the distance is not standard, adjust the cable by the adjusting
nuts.
(f) Inspect and adjust the shift lever position. When shifting the shift lever from the N position to other
positions, check that the lever can be shifted smoothly
and accurately to each position and that the position indi-
cator correctly indicates the position.
If the indicator is not aligned with the correct position, carry out
the following adjustment procedures. (1) Loosen the nut on the control rod.
(2) Push the control rod fully rearward.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

Q07310Control Shaft Lever(b)
(c)
Q07311
Neutral Basic Line
Bolt
Groove
−
DIAGNOSTICS AUTOMATIC TRANSMISSION
DI−139
1996 LAND CRUISER (RM451U)
(3) Return the control shaft lever 2 notches to N posi-
tion.
(4) Set the shift lever to N position.
(5) While holding the shift lever lightly toward the R
position side, adjust the control rod nut.
(6) Tighten the control rod nut.
Torque: 13 N·m (130 kgf·cm, 9 ft·lbf)
(7) Start the engine and make sure that the vehicle moves forward when shifting the lever from the N to
D position and reverses when shifting it to the R
position.
(g) Inspec and adjust park/neutral positoin switch. Check that the engine can be started with the shift lever
only in the N or P position, but not in other positions.
If not as stated above, carry out the following adjustment proce-
dure.
(1) Loosen the park/neutral position switch bolt and set
the shift lever to the N position.
(2) Align the groove and neutral basic line.
(3) Hold in position and tighten the bolt.
Torque: 13 N·m (130 kgf·cm, 9 ft·lbf) For continuity inspect of the park/neutral position
switch, see page DI−169 .
(h) Check the idle speed. Idle speed:
650 ± 50 rpm (In N position and air conditioner OFF)
7. MECHANICAL SYSTEM TESTS
(a) Measure the stall speed. The object of this test is to check the overall performance of the transmis\
sion and engine by measuring
the stall speeds in the D and R positions.
NOTICE:
Do the that at normal operating ATF temperature 50 − 80°C (122 − 176° F).
Do not continuously run this test longer than 5 seconds.
To ensure safety, conduct this test in a wide, clear, level area which provides good traction.
The stall test should always be carried out in pairs. One technician should\
observe the condi-
tions of wheels or wheel stoppers outside the vehicle while the other is doin\
g the test.
(1) Chock the 4 wheels.
(2) Connect an OBD II scan tool or TOYOTA hand−held tester to the DLC3.
(3) Fully apply the parking brake.
(4) Keep your left foot pressed firmly on the brake pedal.
(5) Start the engine.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

DI−140
−
DIAGNOSTICS AUTOMATIC TRANSMISSION
1996 LAND CRUISER (RM451U)
(6) Shift into the D position. Press all the way down on the accelerator pedal wi\
th your right foot.
Quickly read the stall speed at this time.
Stall speed: 1,950 ± 150 rpm
(7) Do the same test in R position.
Stall speed: 1,950 ± 150 rpm
Evaluation:
ProblemPossible cause
Stall speed low in D and R positions
 Engine output may be insuf ficient
 Stator one− way clutch is operating properly
HINT:
If more than 600 rpm below the specified value, the torque con-
verter clutch could be faulty.
Stall speed high in D position
 Line pressure too low
 Forward clutch slipping
 No. 2 one− way clutch not operating properly
 O/D one− way clutch not operating properly
Stall speed high in R position
Line pressure too low
 Direct clutch slipping
 1st and reverse brake slipping
 O/D clutch slipping
Stall speed high in D and R positions
Line pressure too low
 Improper fluid level
 O/D one− way clutch not operating properly
(b) Measure the time lag.
When the shift lever is shifted while the engine is idling, there will be a certain time lapse o\
r lag before
the shock can be felt. This is used for checking the condition of the O/D d\
irect clutch, forward clutch,
direct clutch and 1st and reverse brake.
NOTICE:
Do the test at normal operating ATF temperature 50 − 80°C (122 − 176° F).
Be sure to allow 1 minute interval between tests.
Take 3 measurements and take the average value.
(1) Fully apply the parking brake.
(2) Start the engine and check idle speed.
Idle speed: 650 ± 50 rpm (In N position and air conditioner OFF)
(3) Shift the shift lever from N to D position. Using a stop watch, measure the ti\
me it takes from shift-
ing the lever until the shock is felt.
In the same manner, measure the time lag for N → R.
Time lag: N → D Less than 1.2 seconds
In the same way, measure the time lag for N → R.
Time lag: N → R Less than 1.5 seconds
If N → D time or N → R time lag is longer than specified:
Evaluation:
ProblemPossible cause
N → D time lag is longer
Line pressure too low
 Forward clutch worn
 O/D one− way clutch not operating properly
N → R time lag is longer
Line pressure too low
 Direct clutch worn
 1st and reverse brake worn
 O/D one− way clutch not operating properly
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

−
DIAGNOSTICS AUTOMATIC TRANSMISSION
DI−141
1996 LAND CRUISER (RM451U)
8. HYDRAULIC TEST
Measure the line pressure.
NOTICE:
Do the test at normal operation ATF temperature 50 − 80°C (122 − 176° F).
The line pressure test should always be carried out in pairs. One techni\
cian should observe
the conditions of wheels or wheel stoppers outside the vehicle while the ot\
her is doing the test.
Be careful to prevent SST’s hose from interfering with the exhaust pipe.
(1) Warm up the ATF.
(2) Remove the test plug on the transmission case right side and connect SST\
(See page AT−18
for the location to connect SST).
SST 09992 −00094 (09992 −00150, 09992−00270)
(3) Fully apply the parking brake and chock the 4 wheels.
(4) Start the engine and check idling speed.
(5) Keep your left foot pressed firmly on the brake pedal and shift into D p\
osition.
(6) Measure the line pressure when the engine is idling.
(7) Press the accelerator pedal all the way down. Quickly read the highest line pr\
essure when engine
speed reaches stall speed.
NOTICE:
Release the accelerator pedal and stop test if the rear wheels begin to rotate before the engine speed
reaches the specified stall speed.
(8) In the same manner, do the test in R position.
Specified line pressure:
Condition D position kPa (kgf/cm2, psi) R position kPa (kgf/cm2, psi)
Idling422 −
481 (4.3 − 4.9, 61 − 70)510 − 608 (5.2 − 6.2, 74 − 88)
Stall1,285 − 1,530 (13.1 − 15.6, 128 − 153)1,579 − 1,932 (16.1 − 19.7, 158 − 193)
If the measured pressures are not up to specified values, recheck the thro\
ttle cable adjustment and retest.
Evaluation:
ProblemPossible cause
If the measured value at all positions are higher
Throttle cable out of adjustment
 Throttle valve defective
 Regulator valve defective
If the measured value at all positions are lower
Throttle cable out of adjustment
 Throttle valve defective
 Regulator valve defective
 Oil pump defective
 O/D direct clutch defective
If pressure is low in the D position onlyD position circuit fluid leakage
 Forward clutch defective
If pressure is low in the R position only
R position circuit fluid leakage
 Direct clutch defective
 1st and reverse brake defective
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

Q07312
DI−142
−
DIAGNOSTICS AUTOMATIC TRANSMISSION
1996 LAND CRUISER (RM451U)
9. MANUAL SHIFTING TEST
The purpose of this manual shifting test is to determine whether
a problem is caused by either mechanical or electrical factors.
Disconnecting the solenoid wire disables electrically −con-
trolled automatic gear shifting. In this case, operating the shift
lever is the only way to shift the transmission gear. If the gear
is not changed by shift lever operation, it is assumed that there
is a mechanical problem.
(a) Turn the ignition switch OFF.
(b) Disconnect the solenoid wire connector.
(c) Warm up the engine.
(d) Drive the vehicle.
(e) Check the transmission operation when the shift lever is moved into L, 2 and D positions.
Standard:
Shift LeverOperation
L to 2Shift up
2 to DShift up
D to 2Shift down
2 to LShift down
(f) Turn the ignition switch OFF.
(g) Connect the solenoid wire connector.
(h) Clear DTCs.
HINT:
When the solenoid wire is disconnected, the transmission gear
will be set as listed below:
Shift LeverGear
PParking
RReverse
NNeutral
DO/D (4th)
23rd
L1st
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

DI5KB−03
−
DIAGNOSTICS AUTOMATIC TRANSMISSION
DI−143
1996 LAND CRUISER (RM451U)
DIAGNOSTIC TROUBLE CODE CHART
If a DTC is displayed during the DTC check, check the circuit listed for that code i\
n the table below and pro-
ceed to the page given.
DTC No.
(See page)Detection ItemTrouble AreaMIL*Memory
P0500
( DI−153 )Vehicle Speed Sensor Malfunc-
tion
(No. 1 Vehicle Speed Sensor)Open or short in No. 1 vehicle speed sensor circuit
 No. 1 vehicle speed sensor
 ECM

P0710
( DI−154 )Transmission Fluid Temperature
Sensor Malfunction
(ATF Temperature Sensor) Open or short in ATF temperature sensor circuit
 ATF temperature sensor
 ECM

P0750
( DI−156 )Shift Solenoid A Malfunction
(Shift Solenoid Valve No. 1)Shift solenoid valve No. 1 is stuck open or closed
 Valve body is blocked up or stuck
P0753
( DI−157 )Shift Solenoid A Electrical
Malfunction
(Shift Solenoid Valve No. 1)Open or short in shift solenoid valve No. 1 circuit
 Shift solenoid valve No. 1
 ECM

P0755
( DI−156 )Shift Solenoid B Malfunction
(Shift Solenoid Valve No. 2)Shift solenoid valve No. 2 is stuck open or closed
 Valve body is blocked up or stuck
P0758
( DI−157 )Shift Solenoid B Electrical
Malfunction
(Shift Solenoid Valve No. 2)Open or short in shift solenoid valve No. 2 circuit
 Shift solenoid valve No. 2
 ECM

P0770
( DI−161 )Shift Solenoid E Malfunction
(Shift Solenoid Valve SL)Shift solenoid valve SL is stuck open or closed
 Valve body is blocked up or stuck
 Lock− up clutch

P0773
( DI−163 )Shift Solenoid E Electrical
Malfunction
(Shift Solenoid Valve SL)Open or short in shift solenoid valve SL circuit
 Shift solenoid valve SL
 ECM

P1700
( DI−166 ) Speed Sensor No. 2 Circuit
Malfunction
(No. 2 Vehicle Speed Sensor)Open or short in No. 2 vehicle speed sensor circuit
 No. 2 vehicle speed sensor
 ECM

P1780
( DI−169 )Park/Neutral Position Switch
MalfunctionShort in park/neutral position switch circuit
 Park/neutral position switch
 ECM

*:  ...MIL light up
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010
