DIAGNOSTICS ANTI−LOCK BRAKE SYSTEM
1996 LAND CRUISER (RM451U)
Stop Light Switch Circuit
CIRCUIT DESCRIPTION
This stop light switch senses whether the brake pedal is depressed or releas\
ed, and sends the signal to the
ECU.
WIRING DIAGRAM
INSPECTION PROCEDURE
1 Check operation of stop light.
CHECK:
Check that stop light lights up when brake pedal is depressed and turns off when brake pedal is released.
NG Repair stop light circuit (See page BE−24).
OK
DI5MG−02
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010
Page 662 of 1399
BE6653
R14209
F15325
(−) (+)STP
−
DIAGNOSTICS ANTI−LOCK BRAKE SYSTEM
DI−229
1996 LAND CRUISER (RM451U)
2 Check voltage between terminal STP of ABS ECU and body ground.
PREPARATION:
Remove the ABS ECU with connectors still connected.
CHECK:
Measure the voltage between terminal STP of the ABS ECU
and body ground when the brake pedal is depressed.
OK:
Voltage: 8 − 14 V
OK Proceed to next circuit inspection shown on problem symptoms table (See page DI−200 ).
NG
3 Check for open in harness and connector between ABS ECU and stop light switch (See page IN−28 ).
NG Repair or replace harness or connector.
OK
Check and replace ABS ECU.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010
Page 663 of 1399

W02199
BatteryJunction
Connector
ID
W−B
B−W
ABS Control Relay
1 4
2
6 3
1
4
Motor
Relay
Solenoid
Relay
ABS ECU
ABS ECU
ABS Actuator 4
5
A7
A6
A6 A6
A4 R−L
R−L
DLC1
Short Pin
B−W
IH1
A12
ABS ECU
W
13
C10
GAUGE
2223 ABS
Warning
Light
A
A
J1
C10IH1
20
A7
A7A7
A7
EA3
EA3
2
1 B−W
B−W
B−L OO
O
Y
54
3
23 OY
DI−230
−
DIAGNOSTICS ANTI−LOCK BRAKE SYSTEM
1996 LAND CRUISER (RM451U)
ABS Warning Light Circuit
CIRCUIT DESCRIPTION
If the ECU detects trouble, it lights the ABS warning light while at the same time prohibiting ABS control. At
this time, the ECU records a DTC in memory. After removing the short pin of the DLC1, connect terminals
Tc and E
1 of the DLC1 to make the ABS warning light blink and output the DTC.
WIRING DIAGRAM
INSPECTION PROCEDURE
Troubleshooting in accordance with the chart below for each trouble symptom.
ABS warning light does not light upGo to step 1
ABS warning light remains onGo to step 3
1 Check ABS warning light.
See Combination Meter Troubleshooting on page BE−2.
NG Repair bulb or combination meter assembly.
OK
DI5MJ−03
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010
Page 664 of 1399

R14139
A6A7
Continuity
Continuity Open
1
2
5
6
3
R14140
A7
A6
(−)
(+)
Continuity
Open
1
2
5
6
3
R14144
(+) (−)4
5
A7A6
−
DIAGNOSTICS ANTI−LOCK BRAKE SYSTEM
DI−231
1996 LAND CRUISER (RM451U)
2 Check ABS control relay.
PREPARATION:
(a) Turn the ignition switch OFF.
(b) Disconnect the connectors from the control relay.
CHECK:
Check the continuity between each terminal of the ABS control
relay.
OK:
Terminals A7 −1 and A6− 3Continuity
(Reference value 80 Ω)
Terminals A7 −5 and A7− 6Continuity
Terminals A7 −2 and A7− 5Open
CHECK:
(a) Apply battery positive voltage between terminals A7 −1
and A6−3.
(b) Check the continuity between each terminal of the ABS control relay.
OK:
Terminals A7 −5 and A7− 6Open
Terminals A7 −2 and A7− 5Continuity
CHECK:
Connect the test lead to terminal A7−4 and the test lead
to terminal A7−5. Check continuity between the terminals.
OK:
Continuity
If there is no continuity, connect the test lead to terminal A7−4
and the lead to terminal A7 −5. Recheck continuity between
terminals.
NG Replace ABS control relay.
OK
Check for open in harness and connector be-
tween DLC1 and ABS control relay and body
ground (See page IN−28 ).
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010
Page 665 of 1399
DI−232
−
DIAGNOSTICS ANTI−LOCK BRAKE SYSTEM
1996 LAND CRUISER (RM451U)
3 Is DTC output?
Check DTC on page DI−190 .
YES Repair circuit indicated by code output.
NO
4 Does ABS warning light go off if short pin is removed?
NO Check for short in harness and connector be- tween warning light and DLC1 and ECU (See
page IN−28 ).
YES
5 Check ABS control relay (See step 2).
NG Replace ABS control relay.
OK
Check for short in harness and connector be-
tween DLC1 and ABS control relay (See page
IN−28 ).
