Z16462
RLP RM1 M2
4WD GND SPD IG Wire harness:
Z16461
GND
4WDRLP M1M2 ECU: SA-164
- SUSPENSION AND AXLEDIFFERENTIAL LOCKING SYSTEM
2114 Author: Date:
2004 LAND CRUISER (RM1071U)
(b) Inspect the system circuit with the connector discon-
nected.
Disconnect the connector from the rear diff. lock control
ECU and inspect the connector on the wire harness side,
as shown in the table.
Symbols (Terminals No.)Trouble partConditionSpecified value
M1 - M2RR Diff. Lock Actuator-Less than 100 W
GND - Body groundBody ground-Continuity
SPD - Body groundSpeed sensorVehicle moves slowly1 pulse each
40 cm (15.75 in.)
IG - Body groundDIFF FuseIgnition switch ON10 - 14 V
RLP B d dRear Diff. Lock Indica-Ignition switch ON with indicator light ONAbout 0 VRLP - Body groundRear Diff. Lock Indica
tor SwitchIgnition switch ON with indicator light OFF10 - 14 V
4WD B d dL iti S it hIgnition switch ON with T/F shift lever except LAbout 0 V4WD - Body groundL position SwitchIgnition switch ON with T/F shift lever L10 - 14 V
RBd dDifferential Lock Con-Ignition switch ON with differential lock control switch RR10 - 14 VR - Body groundDifferential Lock Con
trol SwitchIgnition switch ON with differential lock control switch OFFAbout 0 V
HINT:
If the circuit is not as specified value, check and repair or re-
place the trouble part shown in the table above.
(c) Inspect the system circuit with the connector connected.
(1) Turn the ignition switch to the ON position.
(2) Shift the transfer shift lever to L position.
(3) Using a voltmeter, measure the voltage when the
differential lock control switch is in the position, as
shown in the table.
Tester Connection
- Switch positionSpecified valve
4WD - GND-10 - 14 V
RLP - GNDRR*0.5 V or less
M1 - M2OFF " RR0.5 V or less " 10 - 14 V
(A 1 )05VM2 - M1RR " OFF(Approx. 1 sec.) "0.5 V
or less
*: The rear differential should be locked mechanically.
If the circuit is not as specified value, replace the ECU.
(4) Install the ECU in place.
Page 2892 of 3115
W02075
1 2
3
4 5Relay Housing
Metallic Parts Heater main relay:
Z07257
Free " Lock Lock " Free
Heater Main
Relay
Battery BatteryHeater Main
Relay
12
3 4
5
12
3 4
5
5 2 3
4 62 3
4
F05957
1
4 (+)
(-)
F05962
- SUSPENSION AND AXLEDIFFERENTIAL LOCKING SYSTEM
SA-165
2115 Author: Date:
2004 LAND CRUISER (RM1071U)
3. INSPECT DIFF. LOCK COMPONENTS
(a) Inspect the relay operation.
(1) Jack up the vehicle.
(2) Use a heater main relay and connect it, as shown
below.
NOTICE:
Connect the terminals being careful not to touch the neigh-
boring terminals or metallic parts of the relay housing.
(3) Rotate the tire and check that differential lock has
occurred.
If operation is not as specified, replace the actuator.
(b) Inspect the diff. lock control switch continuity.
Inspect the switch continuity between terminal 1 to termi-
nal 4.
HINT:
If continuity dose not exist, replace the switch.
(c) Inspect the diff. lock indicator switch.
(1) Check that continuity between exists terminals
when the switch is pushed (differential connected
position).
(2) Check that no continuity exists when the switch is
free (differential disconnected position).
HINT:
If operation is not as specified, replace the switch.
Page 2893 of 3115
SA-166
- SUSPENSION AND AXLEDIFFERENTIAL LOCKING SYSTEM
2116 Author: Date:
2004 LAND CRUISER (RM1071U)
(d) Inspect the L position switch (See page TR-49).
(e) Inspect the vehicle speed sensor (See page BE-63).
Page 2894 of 3115
SA167-05
F05181
F05083
F04360
SA-168
- SUSPENSION AND AXLEDIFFERENTIAL LOCKING SYSTEM
2118 Author: Date:
2004 LAND CRUISER (RM1071U)
REMOVAL
1. SHIFTING REAR DIFF. LOCK POSITION
(a) Turn the ignition switch to the ON position.
(b) Shift the transfer shift lever to L position.
(c) Turn the differential lock control switch to the RR position
and lock the rear differential.
HINT:
While rotating the rear wheels, check they are in the differential
lock condition.
(d) Disconnect the cable from the negative terminal of the
battery.
2. REMOVE NO. 1 ACTUATOR PROTECTOR
Remove the nut, bolt and No. 1 actuator protector.
3. REMOVE NO. 2 ACTUATOR PROTECTOR
Remove the 2 nuts and No. 2 actuator protector.
4. DISCONNECT CONNECTORS AND TUBE
5. REMOVE REAR DIFF. LOCK POSITION SWITCH
6. REMOVE COVER
(a) Remove the 3 bolts.
(b) Using a brass bar and hammer, remove the cover.
7. REMOVE ACTUATOR
(a) Remove the shift fork set bolt.
(b) Remove the 4 bolts.
(c) Using a screwdriver, pry out the actuator.
Page 2895 of 3115
SA143-04
F05256
123 (1,250, 91)
74 (750, 54)
Disc
Bearing
Oil Seal
Bearing
Lock Washer
Gasket
Snap Ring Axle Hub
Hub BoltClaw Washer
Adjusting Nut
Lock Nut
Flange
Grease Cap
33 (335, 24)
Brake Caliper
x6
Non-reusable part
N´m (kgf´cm, ft´lbf) : Specified torquex5
28 (290, 21)
Cone Washer
64 (650, 47)
Flexible Hose
See Page SA-16
- SUSPENSION AND AXLEFRONT AXLE HUB
SA-1 1
1961 Author: Date:
2004 LAND CRUISER (RM1071U)
FRONT AXLE HUB
COMPONENTS
Page 2896 of 3115
SA145-04
F04408
F04339
F04340
Matchmarks
- SUSPENSION AND AXLEFRONT AXLE HUB
SA-13
1963 Author: Date:
2004 LAND CRUISER (RM1071U)
DISASSEMBLY
1. REMOVE OIL SEAL AND BEARING
(a) Using a screwdriver, pry out the oil seal.
(b) Remove the bearing from the axle hub.
2. REMOVE BEARING OUTER RACES
(a) Using a brass bar and hammer, remove the outside bear-
ing outer race.
NOTICE:
Be careful not to damage the ABS speed sensor rotor.
(b) Using a brass bar and hammer, remove the inside bearing
outer race.
3. INSPECT BEARINGS
Clean the bearings and outer races and inspect them for wear
or damage.
4. REMOVE DISC
(a) Mount the axle hub with the disc in a soft jaw vice.
NOTICE:
Close vice until it holds disc, do not tighten further.
(b) Place matchmarks on the axle hub and disc.
(c) Remove the 5 bolts and separate the axle hub and disc.
Page 2897 of 3115
SA147-09
F04370
SST
F04362
90°
F04370
SST
SA-16
- SUSPENSION AND AXLEFRONT AXLE HUB
1966 Author: Date:
2004 LAND CRUISER (RM1071U)
INSTALLATION
1. INSTALL AXLE HUB TO STEERING KNUCKLE
(a) Place the axle hub with disc to the steering knuckle.
NOTICE:
Be careful not to damage the ABS speed sensor rotor and
oil seal.
(b) Install the outer bearing.
(c) Install the claw washer.
2. ADJUST PRELOAD
(a) Install the adjusting nut and using SST, tighten it.
SST 09607-60020
Torque: 59 N´m (600 kgf´cm, 43 ft´lbf)
(b) Turn the axle hub several times to settle down the bear-
ing.
(c) Using SST, loosen the adjusting nut until it can rotate by
hand.
SST 09607-60020
(d) Using SST, retighten the adjusting nut.
SST 09607-60020
Torque: 4.3 - 6.5 N´m (44 - 66 kgf´cm, 38 - 57 in.´lbf)
HINT:
Check that there is no looseness on the bearing.
(e) Using a spring tension gauge, measure the preload.
Preload (at starting):
42 - 67 N (4.3 - 6.8 kgf, 9.5 - 15.0 lbf)
3. INSTALL LOCK WASHER AND LOCK NUT
(a) Install a new lock washer and the lock nut.
(b) Using SST, torque the lock nut.
SST 09607-60020
Torque: 64 N´m (650 kgf´cm, 47 ft´lbf)
(c) Check that the axle hub rotates smoothly and there is no
looseness on the bearing.
Page 2898 of 3115
F04362
90°
F04363
- SUSPENSION AND AXLEFRONT AXLE HUB
SA-17
1967 Author: Date:
2004 LAND CRUISER (RM1071U)
(d) Using a spring tension gauge, check the preload.
Preload (at starting):
42 - 67 N (4.3 - 6.8 kgf, 9.5 - 15.0 lbf)
HINT:
Make sure to check preload in the direction of rotation.
If the preload is not within the specified value, adjust it again
with the adjusting nut.
(e) Secure the lock nut by bending one of the lock washer
teeth inward and the other lock washer teeth outward.
4. INSTALL FLANGE
(a) Place a new gasket in position on the axle hub.
(b) Install the flange to the axle hub.
(c) Install the 6 cone washers, washers and new nuts.
Torque: 33 N´m (335 kgf´cm, 24 ft´lbf)
(d) Pull out the drive shaft to the outside of the vehicle and
select the snap ring which ensures the clearance be-
tween the tip of the flange and the snap ring is less than
0.2 mm (0.008 in.).
Snap ring thickness:
1.8 mm (0.0709 in.)2.4 mm (0.0945 in.)
2.0 mm (0.0787 in.)2.6 mm (0.1024 in.)
2.2 mm (0.0866 in.)2.8 mm (0.1102 in.)
(e) Using a snap ring expander, install a new snap ring to the
drive shaft.
(f) Install a new grease cap to the flange.
5. INSTALL BRAKE CALIPER
(a) Install the brake caliper, washers and 2 bolts.
Torque: 123 N´m (1,250 kgf´cm, 91 ft´lbf)
(b) Install the flexible hose and bolt to the steering knuckle.
Torque: 28 N´m (290 kgf´cm, 21 ft´lbf)
6. INSTALL FRONT WHEEL
Torque: 131 N´m (1,340 kgf´cm, 97 ft´lbf)
7. CHECK ABS SPEED SENSOR SIGNAL
(See page DI-505)
Page 2899 of 3115
SA146-04
F04340
Matchmarks
F04341
SST
F04342
SST
RA0009
SA0412
MP Grease SA-14
- SUSPENSION AND AXLEFRONT AXLE HUB
1964 Author: Date:
2004 LAND CRUISER (RM1071U)
REASSEMBLY
1. INSTALL DISC
(a) Mount the disc in a soft jaw vice.
NOTICE:
Close vice until it holds disc, do not tighten further.
(b) Align the matchmarks on the axle hub and disc.
(c) Install the 5 bolts to the axle hub.
Torque: 74 N´m (750 kgf´cm, 54 ft´lbf)
2. INSTALL BEARING OUTER RACES
(a) Using SST and a hammer, carefully install a new outside
bearing outer race.
SST 09950-60020 (09951-00730),
09950-70010 (09951-07100)
(b) Using SST and a hammer, carefully install a new inside
bearing outer race.
SST 09950-60020 (09951-00890),
09950-70010 (09951-07100)
NOTICE:
Be careful not to damage the ABS speed sensor rotor.
3. PACK BEARING WITH MP GREASE
(a) Place MP grease in the palm of your hand.
(b) Pack grease into a new bearing, continuing until the
grease oozes out from the other side.
(c) Employ the same manner around the bearing circumfer-
ence.
4. COAT INSIDE OF AXLE HUB WITH MP GREASE
5. INSTALL INNER BEARING AND OIL SEAL
(a) Place the inner bearing into the axle hub.
Page 2900 of 3115
F04343
SST
- SUSPENSION AND AXLEFRONT AXLE HUB
SA-15
1965 Author: Date:
2004 LAND CRUISER (RM1071U)
(b) Using SST and a hammer, install a new oil seal into the
axle hub.
SST 09950-60020 (09951-01030),
09950-70010 (09951-07100)
NOTICE:
Be careful not to damage the ABS speed sensor rotor.
(c) Coat the lip of the oil seal with MP grease.
