TOYOTA MIRAI 2022 Owners Manual

52110-1. For owners
Owners Manual_USA_M62084_en
10
For owners
Boulon de réglage A
Boulon de réglage B
 Assurez-vous que le réservoir
de carburant du véhicule est
plein et que la partie de car-
rosserie située autour des
phares n’est pas déformée.
 Garez le véhicule sur un sol
parfaitement horizontal.
 Assurez-vous que la pression
de gonflage des pneus est au
niveau prescrit.
 Demandez à quelqu’un de
s’asseoir sur le siège du con-
ducteur.
 Faites rebondir le véhicule à
plusieurs reprises.
AVERTISSEMENT
●Installation d’une protection de
calandre (barre safari, barre
kangourou, etc.), de lames de
déneigement, de treuils ou d’un
porte-bagages de toit
●Modifications du système de
suspension du véhicule
●Installation d’appareils électro-
niques tels qu’un émetteur-
récepteur radio ou un lecteur de
CD
●Modifications à votre véhicule
pour une personne aux capac-
ités physiques réduites
Headlight aim instruc-
tions for Canadian
owners (in French)
Boulons de réglage verti-
cal
Avant de vérifier la portée
des phares

52210-1. For owners
Owners Manual_USA_M62084_en
1Tournez le boulon A vers la
droite ou vers la gauche à
l’aide d’un tournevis cruci-
forme.
Retenez le sens de rotation
et le nombre de tours.
2 Tournez le boulon B du
même nombre de tours et
dans le même sens qu’à
l’étape 1.
Si vous n’arrivez pas à régler vos
phares en suivant cette procédure,
apportez le véhicule chez votre
concessionnaire Toyota afin qu’il
règle la portée des phares.
Réglage de la portée des
phares

523
Owners Manual_USA_M62084_en
Index
What to do if... (Trouble-shooting) ................... 524
Alphabetical Index....... 527

524What to do if... (Troubleshooting)
Owners Manual_USA_M62084_en
1-1.What to do if... (Troubleshooting)What to do if... (Troubleshooting)
 If you lose your mechanical
keys, new genuine mechani-
cal keys can be made by your
Toyota dealer. ( P.467)
 If you lose your electronic
keys, the risk of vehicle theft
increases significantly. Con-
tact your Toyota dealer imme-
diately. ( P.467)
 Is the electronic key battery
weak or depleted? ( P.423)
 Is the power switch in ON?
When locking the doors, turn the
power switch off. ( P.176)
 Is the electronic key left inside
the vehicle?
When locking the doors, make sure that you have the
electronic key on
your person.
 The function may not operate
properly due to the condition
of the radio wave. ( P.132)
 Is the child-protector lock set?
The rear door cannot be opened
from inside the vehicle when the
lock is set. Open the rear door from
outside and then unlock the child-
protector lock. ( P.124)
 The function to prevent the
electronic key from being left
inside the trunk will operate
and you can open the trunk as
usual. Take the key out from
the trunk. ( P.128)
 Did you press the power
switch while firmly depress-
ing the brake pedal?
( P.172)
 Is the electronic key any-
where detectable inside the
If you have a problem,
check the following before
contacting your Toyota
dealer.
The doors cannot be
locked, unlocked, opened
or closed
You lose your keys
The electronic key does
not operate properly
The doors cannot be
locked or unlocked
The rear door cannot be
opened
The trunk lid is closed
with the electronic key
left inside
If you think something is
wrong
The fuel cell system does
not start

Owners Manual_USA_M62084_en
525What to do if... (Troubleshooting)
vehicle? (P.130)
 Is the steering wheel
unlocked? ( P.173)
 Is the electronic key battery
weak or depleted?
In this case, the fuel cell system
can be started in a temporary way.
( P.470)
 Is the 12-volt battery dis-
charged? ( P.471)
 It is locked automatically to
prevent theft of the vehicle.
( P.173)
 Is the window lock switch
pressed?
The power window except for the
one at the driver’s seat cannot be
operated if the win dow lock switch
is pressed. ( P.158)
 The auto power off function
will be operated if the vehicle
is left in ACC for a period of
time. ( P.176) 
The seat belt reminder light is
flashing
Are the driver and the front passen-
ger wearing the seat belts?
( P.448)
 The parking brake indicator is
on
Is the parking br ake released?
(  P.183)
Depending on the situation,
other types of warning buzzer
may also sound. ( P.441, 451)
 Did anyone inside the vehicle
open a door during setting the
alarm?
The sensor detects it and the alarm
sounds. ( P. 7 0 )
Do one of the following to deac-
tivate or stop the alarms:
 Except for Canada: Unlock
the doors.
 Except for Canada: Unlock
the trunk using the mechani-
cal key.
 For Canada: Unlock the doors
or trunk using the entry func-
tion or wireless remote con-
trol.
The steering wheel can-
not be turned after the
fuel cell system is
stopped
The windows do not open
or close by operating the
power window switches
The power switch is
turned off automatically
A warning buzzer sounds
during driving
An alarm is a ctivated and
the horn sounds

526What to do if... (Troubleshooting)
Owners Manual_USA_M62084_en
 Turn the power switch to ACC
or ON, or start the fuel cell
system. (The alarm will be
deactivated or stopped after a
few seconds.)
 Is the message displayed on
the multi-information display?
Check the message on the multi-
information display. ( P.451)
 When a warning light turns on
or a warning message is dis-
played, refer to P.441, 451.
 Stop the vehicle in a safe
place and repair the flat tire
temporarily with the emer-
gency tire puncture repair kit.
( P.455)
 Try the procedure for when
the vehicle becomes stuck in
mud, dirt, or snow. ( P.480)
A warning buzzer sounds
when leaving the vehicle
A warning light turns on
or a warning message is
displayed
When a problem has
occurred
If you have a flat tire
The vehicle becomes
stuck

Owners Manual_USA_M62084_en
527Alphabetical Index
Alphabetical Index
A
A/C ................................... 325, 332Air conditioning filter ............. 419
Automatic air conditioning sys-tem ............................. 325, 332
Eco air conditioning mode .. 326, 334
Front seat concentrated airflow mode (S-FLOW) ................. 338
ABS (Anti-lock Brake System) ............................................... 315Warning light ........................ 443
ACA (Active Cornering Assist) ............................................... 315
ACC ......................................... 176
Active Cornering Assist (ACA) ............................................... 315
Active Sound Control (ASC).. 188
AHB (Automatic High Beam) . 193
Air conditioning filter ............. 419
Air conditioning system 325, 332 Air conditioning filter ............. 419
Automatic air conditioning sys-tem ............................. 325, 332
Eco air conditioning mode .. 326, 334
Front seat concentrated airflow mode (S-FLOW) ................. 338
Air purification screen ........... 111
Airbags ...................................... 34 Airbag operating conditions.... 36
Airbag precautions for your child............................................. 39
Correct driving posture ........... 27
Curtain shield airbag operating conditions ............................. 37
Curtain shield airbag precautions ............................................. 39
Front passenger occupant clas- sification system ................... 46
General airbag precautions .... 39 Locations of airbags ...............34
Modification and disposal of air-
bags......................................42
Side airbag operating conditions .............................................37
Side airbag precautions..........39
Side and curtain shield airbags operating conditions .............37
Side and curtain shield airbags precautions ...........................39
SRS airbags ...........................34
SRS warning light .................442
Alarm .........................................70 Warning buzzer ....................441
ALL AUTO control ..................324
Anchor brackets ... ..............54, 62
Antennas (smart key system)130
Anti-lock Brake System (ABS) ...............................................315Warning light.........................443
Approach warning ..................244
Armrest ......... ......................... ..361
ASC (Active Sound Control) ..188
Assist grips .............................362
Audio system-linked display .104
Automatic air conditioning sys- tem .................................325, 332Eco air conditioning mode ..326, 334
Automatic air conditioning sys- tem (vehicles with 12.3-inch dis-
play) .......................................332
Automatic air conditioning sys- tem (vehicles with 8-inch dis-
play) .......................................325
Automatic headlight leveling system ...................................192
Automatic High Beam ............193
Automatic light control system ...............................................192
Auxiliary boxes .......................351
Average fuel economy ...........101

528Alphabetical Index
Owners Manual_USA_M62084_en
Average vehicle speed........... 104
B
Back-up lights Replacing light bulbs ............ 429
Battery (12-volt battery) ......... 400 Battery checking................... 400
If the 12-volt battery is dis-charged .............................. 471
Preparing and c hecking before
winter.................................. 320
Warning light ........................ 442
Battery (traction battery) ......... 79
Blind Spot Monitor (BSM) ...... 249 Enabling/disabling the system........................................... 251
Brake Brake hold ............................ 186
Fluid ............................. 399, 486
Parking brake ....................... 183
Warning light ........................ 441
Brake assist ............................ 315
Break-in tips ........ ................... 162
Brightness control Instrument panel light control . 98
BSM (Blind Spot Monitor) ...... 249 Enabling/disabling the system........................................... 251
Buzzer Hands off steering wheel warn-ing (LTA) ............................. 232
Vehicle sway warning function (LTA) ................................... 233
C
Care ................................. 380, 384 Aluminum wheel ornaments . 380
Aluminum wheels ................. 380
Exterior ................................. 380
Interior .................................. 384
Roof film ............................... 381 Seat belts .............................384
Traction battery air intake vent
...........................................420
Cargo and luggage .................167
Cargo capacity ........................170
Chains......................................321
Child restraint system ..............52 Fixed with a LATCH system ...60
Fixed with a seat belt..............56
Front passenger occupant clas-sification system ...................46
Points to remember ................52
Riding with children ................51
Types of child restraint system installation method ...............54
Using an anchor bracket ........62
Child safety ...............................51 12-volt battery precautions .401, 474
Airbag precautions .................39
Child restraint system .............54
Electronic sunshade .............356
Heated steering wheel and seat heater precautio ns..............342
How your child should wear the seat belt ................................30
Power window lock switch ....158
Power window precautions...157
Rear door child-protectors ....124
Removed electronic key battery precautions .........................424
Seat belt extender precautions .............................................30
Seat belt precautions..............51
Trunk precautions .................126
Child-protectors......................124
Cleaning ..........................380, 384 Aluminum wheel ornaments .380
Aluminum wheels .................380
Exterior .................................380
Interior ..................................384
Radar sensor ........................208

Owners Manual_USA_M62084_en
Alphabetical Index529
Roof film ............................... 381
Seat belts ............................. 384
Clock ......................................... 97
Coat hooks .............................. 362
Condenser .............................. 398
Console box ............................ 351
Consumption screen.............. 111
Coolant .................................... 397 Capacity ............................... 484
Checking .............................. 397
Preparing and c hecking before
winter.................................. 320
Cooling system ...................... 397 Fuel cell system overheating 477
Overheating.......................... 477
Cruise control Dynamic radar cruise control with full-speed range .......... 237
Cup holders ............................ 350
Current fuel economy ............ 101
Curtain shield airbags ............. 34
Customizable features ........... 498
D
Daytime running light system191
Defogger Outside rear view mirrors ... 327, 334
Rear window ................ 327, 334
Windshield.................... 326, 334
Digital Rearview Mirror .......... 144
Dimension ............................... 482
Dinghy towing ........................ 171
Display Dynamic radar cruise control with full-speed range .......... 237
Head-up display ................... 107
Intuitive parking assist .......... 254
LTA (Lane Tracing Assist) ..... 229
Multi-information display ...... 100
Parking Support Brake function (rear pedestrians) ............... 282 RCD (Rear Camera Detection)
...........................................269
Rear Camera Detection (RCD) ...........................................269
Toyota multi-operation touch 353
Toyota Teammate Advanced Park ....................................287
Warning message.................451
Display change button .............98
Do-it-yourself maintenance ...387
Door courtesy lights...............346
Door lock Doors ....................................121
Smart key system .................130
Wireless remote control........ 119
Doors .......................................121 Automatic door locking and unlocking system ................125
Door glasses ........................156
Door lock ..............................121
Open door warning buzzer .122, 124
Outside rear view mirrors .....154
Rear door child-protectors ....124
Drive distance .........................104
Drive information ....................104
Driver’s seat position memory ...............................................136Driving position memory .......136
Memory recall function .........138
Power easy access system ..136
Driving .....................................161 Break-in tips .........................162
Correct driving posture ...........27
Driving mode select switch ...313
Fuel cell vehicle driving tips ....89
Procedures ...........................161
Winter drive tips....................320
Driving informatio n display ...101
Driving position memory .......136 Memory recall function .........138
Power easy access system ..136

530Alphabetical Index
Owners Manual_USA_M62084_en
Driving range ............................ 97
Driving support system informa- tion display ........................... 104
Dynamic radar cruise control with full-speed range ........... 237Approach warning ................ 244
Warning message ................ 247
E
ECB (Electronically Controlled Brake System) ...................... 315Warning light ........................ 441
ECO Accelerator Guidance ... 102
Eco score ................................ 102
EDR (Event data recorder)......... 8
Elapsed time ........................... 104
Electric motor (traction motor) ........................................... 74, 79Location.................................. 79
Specification ......................... 484
Electric Power Steering (EPS) ............................................... 315Warning light ........................ 443
Electronic key ......................... 118 Battery-saving function......... 131
If the electronic key does not operate properly ................. 468
Replacing the battery ........... 423
Electronic sunshade .............. 355 Operation ............................. 355
Electronically Controlled Brake System (ECB) ....................... 315Warning light ........................ 441
Emergency flashers ............... 432
Emergency shut off system .... 87
Emergency tire puncture ....... 455
Emergency tire puncture repair kitStorage location ................... 456
Emergency, in case of If a warning buzzer sounds .. 441
If a warning light turns on ..... 441 If a warning message is dis-
played .................................451
If the 12-volt battery is dis- charged ..............................471
If the electronic key does not operate properly .................468
If the fuel cell system will not start ....................................466
If the fuel door cannot be opened ...........................................468
If the vehicle is submerged or water on the road is rising ..433
If you have a flat tire .............455
If you lose your keys.............467
If you think something is wrong ...........................................439
If your vehicle becomes stuck ...........................................480
If your vehicle has to be stopped in an emergency .................432
If your vehicle needs to be towed ...........................................435
If your vehicle ove rheats ......476
Energy monitor ....................... 111
EPS (Electric Po wer Steering)
...............................................315 Warning light.........................443
Event data recorder (EDR) .........8
F
Flat tire.....................................455 Tire pressure w arning system
...........................................405
Floor mats .................................26
Fluid Brake ....................................486
Transmission ........................486
Washer .................................399
Footwell light ..........................346
Front footwell lights ...............346
Front passenger occupant clas- sification system ....................46
