2001 PRIUS (RM778U)DTC No.
DTC Detecting ConditionTrouble Area
P0441
Pressure in fuel tank does not drop during purge control (2 trip
detection logic)
P0441During purge cut±off, pressure in fuel tank is very low
compared with atmospheric pressure (2 trip detection logic)
Open or short in vapor pressure sensor circuit

Vapor pressure sensor

Open or short in VSV circuit for EVAPWhen VSV for CCV is ONpressure in fuel tank is maintained
Open or short in VSV circuit for EVAP
VSV f EVAPWhen VSV for CCV is ON, pressure in fuel tank is maintained
hi (2id i l i)
VSV for EVAPat atmospheric pressure (2 trip detection logic)
Open or short in VSV circuit for purge flow switching valve
P0446
Turning the VSV for purge flow switching valve is ON does not
lower the pressure sensor output.

Oen or short in VSV circuit for urge flow switching valve

VSV for purge flow switching valve

Charcoal canister cracked, hole or damaged
P0446Although the VSV for purge flow switching valve is OFF, fluc-
tuation in the pressure sensor output is great.
Open or short in VSV circuit for CCV

VSV for CCV

ECMTurning the VSV for CCV OFF does not charge the pressure
sensor output.
ECM
WIRING DIAGRAM
Refer to DTC P0440 on page DI±81.
INSPECTION PROCEDURE
HINT:

If DTC P0441, P0446, P0450 or P0451 is output after DTC P0440,first troubleshoot DTC P0441,
P0446, P0450 or P0451. If no malfunction is detected, troubleshoot DTC P0440 next.

Read freeze frame data using TOYOTA hand±held tester or OBD II scan tool. Because freeze frame
records the engine conditions when the malfunction is detected. When troubleshooting, it is useful for
determining whether the vehicle was running or stopped, the engine was warmed up or not, the air±fuel
ratio was lean or rich, etc. at the time of the malfunction.

When the ENGINE RUN TIME in the freeze frame data is less than 200 seconds, carefully check the
VSV for EVAP, charcoal canister and vapor pressure sensor.
TOYOTA hand±held tester:
1 Check whether hose close to fuel tank have been modified, and check whether
there are signs of any accident near fuel tank or charcoal canister (See page
DI±81).
NG Repair or replace.
OK
2 Check that fuel tank cap is TOYOTA genuine parts.
NG Replace to TOYOTA genuine parts.
OK

± DIAGNOSTICSENGINE
DI±89
2001 PRIUS (RM778U)
3 Check that fuel tank cap is correctly installed.
NG Correctly install fuel tank cap.
OK
4 Check fuel tank cap (See page EC±7).
NG Replace fuel tank cap.
OK
5 Check filler neck for damage.
NG Replace filler pipe.
OK
6 Check vacuum hoses ((1), (2) and (3) in Fig. 1 in circuit description.
NG Repair or connect VSV or sensor connector.
OK
7 Check hose and tube around fuel tank and charcoal canister (See page
DI±81).
NG Repair or replace.
OK

DI±90
± DIAGNOSTICSENGINE
2001 PRIUS (RM778U)
8 Check VSV connector for EVAP, VSV connector for CCV, VSV connector for
purge flow switching valve and vapor pressure sensor connector for looseness
and disconnection.
NG Repair or connect VSV or sensor connector.
OK
9 Check vacuum hoses ((4), (5), (6) and (7) in Fig. 1 in circuit description).
CHECK:
(a) Check that the vacuum hose is connected correctly.
(b) Check the vacuum hose for looseness and disconnection.
(c) Check the vacuum hose for cracks, hole, damage and blockage.
NG Repair or replace.
OK
10 Check voltage between terminals VC and E2 of ECM connector (See page
DI±81).
NG Check and replace ECM (See page IN±41).
OK
11 Check voltage between terminals PTNK and E2 of ECM connectors (See page
DI±81).
OK Go to step 13.
NG

A14044
To Throttle Body
± DIAGNOSTICSENGINE
DI±91
2001 PRIUS (RM778U)
12 Check for open and short in harness and connector between vapor pressure
sensor and ECM (See page IN±41).
NG Repair or replace harness or connector.
OK
Replace vapor pressure sensor.
13 Check purge flow.
PREPARATION:
(a) Connect the TOYOTA hand±held tester to the DLC3.
(b) Select the ACTIVE TEST mode on the TOYOTA hand±
held tester.
(c) Disconnect the vacuum hose from the VSV for the EVAP
from the charcoal canister.
(d) Start the engine.
CHECK:
When the VSV for the EVAP is operated by the TOYOTA hand±
held tester, check whether the disconnected hose applies suc-
tion to your finger.
OK:
VSV is ON:
Disconnected hose applies suction to your finger.
VSV is OFF:
Disconnected hose applies no suction to your finger.
OK Go to step 16.
NG

DI±92
± DIAGNOSTICSENGINE
2001 PRIUS (RM778U)
14 Check vacuum hose between intake manifold and VSV for EVAP, and VSV for
EVAP and charcoal canister.
CHECK:
(a) Check that the vacuum hose is connected correctly.
(b) Check the vacuum hose for looseness and disconnection.
(c) Check the vacuum hose for cracks, hole, damage and blockage.
NG Repair or replace.
OK
15 Check operation of VSV for EVAP (See page SF±40).
OK Go to step 16.
NG
Replace VSV and charcoal canister,and then clean the vacuum hose between throttle body and
VSV for EVAP, and VSV for EVAP and charcoal canister.
16 Check for open and short in harness and connector between EFI main relay
(Marking: EFI) and VSV for EVAP, and VSV for EVAP and ECM (See page
IN±41).
NG Repair or replace harness or connector.
OK
Check and replace ECM (See page IN±41).

A14043
VSV is ONVSV is OFF
Air F
Air E F
E
± DIAGNOSTICSENGINE
DI±93
2001 PRIUS (RM778U)
17 Check VSV for CCV.
PREPARATION:
(a) Connect the TOYOTA hand±held tester to the DLC3.
(b) Remove the VSV for the CCV from the charcoal canister.
(c) Turn the ignition switch ON and push the TOYOTA hand±
held tester main switch ON.
(d) Select the ACTIVE TEST mode on the TOYOTA hand±
held tester.
CHECK:
Check the VSV operation when it is operated by the TOYOTA
hand±held tester.
OK:
VSV is ON:
Air does not flow from port E to port F.
VSV is OFF:
Air from port E flows out through port F.
OK Go to step 21.
NG
18 Check vacuum hose between VSV for CCV and fresh air valve.
CHECK:
(a) Check that the vacuum hose is connected correctly.
(b) Check the vacuum hose for looseness and disconnection.
(c) Check the vacuum hose for cracks, hole damage and blockage.
NG Repair or replace.
OK
19 Check operation of VSV for CCV.
OK Go to step 20.
NG

A14464
VSV is ONVSV is OFF
Air FilterAir Filter
FE
F E
DI±94
± DIAGNOSTICSENGINE
2001 PRIUS (RM778U)
Replace VSV and charcoal canister, and then clean vacuum hose between charcoal canister and
VSV for CCV.
20 Check for open and short in harness and connector between EFI main relay
(Marking: EFI) and VSV for CCV, and VSV for CCV and ECM (See page IN±41).
NG Repair or replace harness or connector.
OK
Check and replace ECM (See page IN±41).
21 Connect TOYOTA hand±held tester and check operation of VSV purge flow
switching valve.
PREPARATION:
(a) Connect the TOYOTA hand±held tester to the DLC3.
(b) Turn the ignition switch ON and push the TOYOTA hand±
held tester main switch ON.
(c) Select the ACTIVE TEST mode on the TOYOTA hand±
held tester.
CHECK:
Check operation of VSV when VSV is operated by the TOYOTA
hand±held tester.
OK:
VSV is ON:
Air from pipe E is flowing out through pipe F.
VSV is OFF:
Air from pipe E is flowing out through the air filter.
OK Go to step 24.
NG
22 Check VSV for purge flow switching valve (See page SF±45).
NG Go to step 23.

BE6653A10620A14040A14045
START
ON
OFFVSV for EVAP
1.2 V ON
OFF
E2
PTNK
(±) (+)
VSV for CCV
Measure
Voltage30 sec.
± DIAGNOSTICSENGINE
DI±95
2001 PRIUS (RM778U)
OK
Replace VSV and charcoal canister, and clean vacuum hoses ((1), (2) and (3) in Fig. 1 in circuit
description.
23 Check for open and short in harness and connector between EFI main relay
(Marking: EFI) and VSV for purge flow switching valve, and VSV for purge flow
switching valve and ECU (See page IN±41).
NG Repair or replace harness or connector.
OK
Check and replace ECM (See page IN±41).
24 Check fuel tank and charcoal canister.
PREPARATION:
(a) Remove the connector cover from the ECM.
(b) Connect the TOYOTA hand±held tester to the DLC3.
(c) Select the ACTIVE TEST mode on the TOYOTA hand±
held tester.
(d) Start the engine.
(e) The VSV for the CCV is ON by the TOYOTA hand±held
tester.
(f) The VSV for the EVAP is ON by the TOYOTA hand±held
tester and hold the VSV for EVAP until voltage between
terminals PTNK and E2 becomes 1.2 V, then set VSV for
EVAP OFF.
CHECK:
Measure the voltage between terminals PTNK and E2 of the
ECM connectors 30 sec. after switching the VSV for the EVAP
from ON to OFF.
OK:
Voltage: 2.3 V or less
OK Check and replace ECM.
NG

DI±96
± DIAGNOSTICSENGINE
2001 PRIUS (RM778U)
25 Remove fuel tank and check it.
NG Replace fuel tank.
OK
26 Remove charcoal canister and check it (See page EC±7).
NG Replace charcoal canister.
OK
Check and replace ECM (See page IN±41).
OBD II scan tool (excluding TOYOTA hand±held tester):
1 Check whether hose close to fuel tank have been modified, and check whether
there are signs of any accident near fuel tank or charcoal canister (See page
DI±81).
NG Repair or replace.
OK
2 Check that fuel tank cap is TOYOTA genuine parts.
NG Replace to TOYOTA genuine parts.
OK
3 Check that fuel tank cap is correctly installed.
NG Correctly install fuel tank cap.

± DIAGNOSTICSENGINE
DI±97
2001 PRIUS (RM778U)
OK
4 Check fuel tank cap (See page EC±7).
NG Replace fuel tank cap.
OK
5 Check filler neck for damage.
NG Replace filler pipe.
OK
6 Check VSV connector for EVAP, VSV connector for CCV, VSV connector for
purge flow switching valve and vapor pressure sensor connector for looseness
and disconnection.
NG Repair or connect VSV or sensor connector.
OK
7 Check vacuum hoses ((1), (2) , (3), (4), (5), (6), (7), (8) and (9) in Fig. 1 in circuit
description).
CHECK:
(a) Check that the vacuum hose is connected correctly.
(b) Check the vacuum hose for looseness and disconnection.
(c) Check the vacuum hose for cracks, hole damage and blockage.
NG Repair or replace.
OK
