display TOYOTA PRIUS 2002 1.G Navigation Manual

73
Any areas you want to avoid due to traffic
jams, construction work or other reasons
can be registered as an area to avoid.
Push the
“MENU” switch to display
Menu screen and then touch the
“Marked points” switch to display the
following screen.
1UE063
INFORMATION
 Some areas and freeways may not
be able to be set as an avoid point.
 If a destination is input in the area to
avoid or the route calculation cannot
be made without running through
the area to avoid, a route passing
through the area to avoid may be
shown.
1. Touch the “Register” switch of Area
to avoid.
2UE017
Area to avoid(a) Registering area to avoid

742. Show the map of the area to avoid in
the same way as you input any des-
tination or display the map of the area
you want to avoid. (See page 8 through
22.)
2UE018
3. Touch the “OK” switch at the center of
the area that you want to avoid.
2UE019
4. Depending on the contents to be
edited, touch either
or
switch. When you touch the
“OK” switch, the fol-
lowing message appears.
2UE020
After a few seconds, the Marked points
screen returns.

75
1. Touch the
“Edit” switch of Area to
avoid to display the Edit area to avoid
screen.
2UE021
2. Touch the point you want to edit from the list.
2UE022
You can edit the name, location and size of
area to avoid. Touch any change switch that
you want to edit. 3. Edit the name, location or size of the
area to avoid.
2UE023
2UEP691
(b) Editing area to avoid

76
2UEP692
When editing is completed, touch the “OK”
switch.
INFORMATION
If you try to change the map to an in-
appropriate scale, a message ap-
pears.
 For magnification or reduction of the
map scale, see page 47.
1. Touch the “Delete” switch of Area to
avoid to display the Delete area to
avoid screen.
2UE024
2. Select the area you want to delete.
Delete all: All areas to avoid registered in the
system are deleted.
2UE025
2UE026
3. Either of the above messages appears.
To delete the area(s), touch the
“Yes”
switch.
If you want to try again or cancel the deletion,
touch the
“No” switch. The previous
screen will return.
(c) Deleting area to avoid

77
The current vehicle position mark will be
automatically corrected during driving
on reception of GPS signals. If your ve-
hicle cannot receive GPS signals, you
can correct the current position mark
manually.
1UE040
1. Push the “MENU” switch to display
the Menu screen, and touch the “Set-
up” switch.
2UE0271
2. Touch the “Calibration” switch.
2UE0272
3. Touch the “Position/Direction”switch.
INFORMATION
For additional information on current
position accuracy, see “Limitations of
the Navigation System” on page 49.
Current position calibration

80You can set the values shown on the Set-
up screen.
1. Push the
“MENU” switch.
1UE040
2. Touch the “Setup” switch to display
the Setup screen. Select your desired
items you want to set. Selected items
will be highlighted in green.
3UE001
3. Touch the “OK” switch on the screen
and the previous screen returns.
To default: Touch the
“Default” switch on
the screen. All of the settings can be de-
faulted.
Map color (day or night): You can select
your desired map color.
Auto reroute: You can set the system will or
will not automatically search for a new route
to the destination.
Estimated travel time: You can set to dis-
play the time required to reach the destina-
tion on the road guidance screen.
Adjust time zone: You can select your de-
sired time zone. Distance:
You can change “km” or “miles” to
display your desired units.
Notify seasonal restrict: You can select to
notify or not to notify a seasonal restriction.
Voice guide in all modes: You can set the
voice guide in all modes or not.
Current street name: You can select to
show or not to show a current street name on
the Map screen.
Setup

81
1. Push the
“MENU” switch.
2. Touch the
“Setup” switch.
3UE001
3. Select your desired day and/or night Map color and then touch the ”OK”switch to return the Map screen. See
“The map color list” below for details.
Touch the
“Normal” switch to default the
Map color.
Touch the
“Auto” switch to select the Map
color automatically. The Map color is
changed in every three month. The Map color list
Switch NO.Map color“Auto” mode
1GreenMar.−May
2BlueJun.−Aug.
3GraySep.−Nov.
4BeigeDec.−Feb.
When the auto reroute feature is turned
on, the system will automatically search
for a new route to the destination if you
leave the guidance route. This feature
does
not operate while you are driving on
roads where the guidance is not avail-
able.
1. Push the
“MENU” switch to display
the Menu screen, and touch the “Set-
up” switch.
1UE040
Map colorAuto reroute

82
3UE002
2. Touch the “On” switch of the “Auto
reroute”. If you can not find the item on
the list, touch
or switch to
scroll the list.
INFORMATION
If your vehicle leaves the guidance
route, the system searches for a new
route to the destination. The new route
may or may not take you back to the
previous route depending on how far
you are off the original guidance route.
When the estimated travel time feature is
turned on, the time required to reach the
destination is displayed on the Route
guidance screen.
1UE040
To turn the Estimated travel time on:
1. Push the
“MENU” switch to display
the Menu screen, and touch the “Set-
up” switch.
3UE003
2. Touch the “On” switch of the Esti-
mated travel time. If you cannot find
the item on the list, touch
or switch and scroll the list.
Estimated travel time

83
3UE004
To set the average speeds:
1. Touch the “Change speed” switch ofEstimated travel time.
2. Touch
or to set the average ve-
hicle speeds for driving on a Freeway,
Main street and Residential area.
If you touch the
“Default” switch, the de-
fault speed is set at each item.
3. After you finish setting the desired speeds, touch the
“OK” switch. The
Setup screen returns.
INFORMATION
 The displayed time to the destination
is the approximate driving time cal-
culated based on the speeds you se-
lected and your actual position
along the guidance route.
 The time shown may vary greatly de-
pending on your progress along the
route (which may be af fected by road
conditions such as traffic jams,
construction work, etc.)
 Up to 99 hours 59 minutes can be dis-
played.
1. Push the “MENU” switch.
1UE040
2. Touch the “Setup” switch.
3UE005
Adjusting time zone

843. Touch the
“Adjust” switch, the Ad-
just time zone screen appears on the
display.
3UE006a
4. Select your desired time zone. Se- lected switch is highlighted in green.
Touch the
“On” switch and then touch
or switch to set the daylight saving time.
5. Touch
“OK” switch on the screen and
the Setup screen returns. 1. Push the
“MENU” switch.
1UE040
2. Touch the “Setup” switch.
3UE007
3. Touch “km” or “miles” to select
your desired units.
4. Touch the
“OK” switch. 1. Push the
“MENU” switch.
1UE040
2. Touch the “Setup” switch.
3UE008
Distance indicationNotifying seasonal restriction
