TOYOTA PRIUS 2019 Owners Manual (in English)

PRIUS_OM_OM47C35U_(U)
5215-11. Using the voice command system
5
Audio system
Due to natural language speech recognition technology, this system
enables recognition of a command when spoken naturally. However ,
the system cannot recognize ever y variation of each command.
In some situations, it is possi ble to omit the command for the proce-
dure and directly state the desired operation.
Not all voice commands are displayed in the short cut menu.
This function is available in English, Spanish and French.
■Expression examples for each function
Casual speech recognization
CommandExpression examples
“Call
”Get me .
Call .
“Dial ”Call <3334445555>.

5225-11. Using the voice command system
PRIUS_OM_OM47C35U_(U)
Some recognizable voice commands and their actions are shown
below as examples.
Basic
Phone
Command list
CommandAction
“Help”Prompts voice guidance to offer examples of com-
mands or operation methods
“Go Back”Returns to the previous screen
CommandAction
“Redial”Places a call to the phone number of the latest outgo-
ing call
“Call Back”Places a call to the phone number of latest incoming
call
“Show Recent
Calls”Displays the call history screen
“Dial ber>”Places a call to the said phone number
“Call
”Place a call to the said phone type of the contact from
the phone book

PRIUS_OM_OM47C35U_(U)
5235-11. Using the voice command system
5
Audio system
The Mobile Assistant feature will activate Apple’s Siri® Eyes Free
mode via the steering wheel switches. To operate the Mobile Ass is-
tant, a compatible cellular phone must be registered and connec ted to
this system via Bluetooth
®. (  P. 4 7 2 )
Press and hold the until
you hear the beeps.
The Mobile Assistant can be
used only when the following
screen is displayed.
To cancel the Mobile Assistant,
select “Cancel”, press the on
the steering wheel, or press and
hold the on the steering wheel.
To restart the Mobile Assistant for
additional commands, press the on the steering wheel.
• Mobile Assistant can only be restarted after the system responds to a voice command.
• After some phone and music commands, the Mobile Assistant feat ure will
automatically end to complete the requested action.
■
Adjusting the Mobile Assistant volume
The volume of the Mobile Assistant can be adjusted using the
“PWR•VOL” knob or steering wheel volume control switches. The
Mobile Assistant and phone call volumes are synchronized.
Mobile Assistant
1
2

5245-11. Using the voice command system
PRIUS_OM_OM47C35U_(U)
■Notes about Mobile Assistant
●The available features and functions may vary based on the iOS version
installed on the connected device.
● Some Siri
® features are limited in Eyes Free mode. If you attempt to use an
unavailable function, Siri® will inform you that the function is not available.
● If Siri
® is not enabled on the cellular phone connected via Bluetooth®, an
error message will be displayed on the screen.
● While a phone call is active, the Mobile Assistant cannot be us ed.
● If using the navigation feature of the cellular phone, ensure t he active audio
source is Bluetooth
® audio or iPod in order to hear turn by turn direction
prompts.

525
PRIUS_OM_OM47C35U_(U)
6Interior features
6-1. Using the air conditioning system and defogger
Automatic air conditioning system (vehicles without
11.6-inch display) ............ 526
Automatic air conditioning system (vehicles with
11.6-inch display) ............ 536
Heated steering wheel/ seat heaters .................... 546 6-2. Using the interior lights
Interior lights list ................ 548• Front interior light .......... 549
• Front personal lights ..... 549
• Rear interior light .......... 550
6-3. Using the storage features
List of storage features ..... 551 • Glove box...................... 552
• Console box .................. 552
• Cup holders/bottle holders/
door pockets ................. 553
• Auxiliary boxes.............. 555
• Seat back pockets ........ 556
Luggage compartment features ........................... 557
6-4. Using the other interior features
Other interior features ....... 563 • Sun visors ..................... 563
• Vanity mirrors................ 563
• Power outlets ................ 564
• USB charging ports....... 565
• Wireless charger ........... 567
• Armrest ......................... 576
• Coat hooks.................... 576
• Assist grips ................... 577
Garage door opener.......... 578

526
PRIUS_OM_OM47C35U_(U)
6-1. Using the air conditioning system and defogger
Automatic air conditioning system
(vehicles without 11.6-inch display)
■Adjusting the temperature setting
Move the temperature setting
knob upwards to increase the
temperature and downwards to
decrease the temperature.
If is not pressed, the sys-
tem will blow ambient tempera-
ture air or heated air.
■
Fan speed setting
Move the fan speed setting
knob upwards to increase the
fan speed and downwards to
decrease the fan speed.
The fan speed is shown on the
display. (7 levels)
Press to turn the fan off.
Air outlets and fan speed are automatically adjusted according
to the temperature setting.
Air conditioning controls
Temperature
setting knob
Fan speed
setting knob

PRIUS_OM_OM47C35U_(U)
5276-1. Using the air conditioning system and defogger
6
Interior features
■Change the airflow mode
Move the airflow change knob
upwards or downwards to
change the airflow mode.
The air outlets used are
switched each time the knob is
operated.
Air flows to the upper body
Air flows to the upper body
and feet
Air flows to the feet
Air flows to the feet and the
windshield defogger oper-
ates
Airflow change
knob
1
2
3
4

5286-1. Using the air conditioning system and defogger
PRIUS_OM_OM47C35U_(U)■
S-FLOW mode
In S-FLOW mode, priority for the
airflow is given to the front seats,
reducing the airflow and air conditioning effect on the rear se ats.
When a passenger is not detected in the front passenger seat,
depending on the set temperature and ambient temperature, prior -
ity for the airflow will be given to the driver’s seat only.
However, air will always be blown from the side outlet of the front pas-
senger seat.
The following S-FLOW modes are available:
Automatic S-FLOW mode
The system determines whether o r not a rear passenger is in the
vehicle by the opening and closing of a rear door. When a rear
passenger is determined to be in the vehicle, S-FLOW mode will
be automatically disabled.
To enable S-FLOW mode again, press and enter manual
S-FLOW mode. ( P. 532)
The indicator will illuminate when S-FLOW mode is
enabled.
Manual S-FLOW mode
When is pressed, S-FLOW mode will be manually
enabled/disabled. ( P. 532)
The indicator will illuminate when S-FLOW mode is enabled.
When the power switch is turned to ON mode, the system is oper-
ated in automatic S-FLOW mode.
■Other functions
● Switching between outside air and recirculated air modes
(  P. 529)
● Defogging the windshield ( P. 5 3 0 )
● Defogging the rear window and outside rear view mirrors
(  P. 530)

PRIUS_OM_OM47C35U_(U)
5296-1. Using the air conditioning system and defogger
6
Interior features
Press .
Adjust the temperature setting.
Press .
The cooling and dehumidification function switches between on a nd
off each time is pressed.
To stop the operation, press .
■Automatic mode indicator
If the fan speed setting or air flow modes are operated, the au to-
matic mode indicator goes off. However, automatic mode for func -
tions other than that o perated is maintained.
■Switching between outside air and recirculated air modes
Press .
The mode switches between outside air mode (indicator off) and recir-
culated air mode (indicator on) each time is pressed.
■
Using the “CLIMATE CONTROL”
Press .
When “ECO” is displayed on the air conditioning screen, the air
conditioning is controlled with l ow fuel consumption prioritized such
as reducing f an speed, etc.
The Climate control is turned on when the power switch is turne d to ON
mode while the driving mode is Eco drive mode.
Pressing again will cancel “CLIMATE CONTROL”.
Using automatic mode
Other functions
1
2
3
4

5306-1. Using the air conditioning system and defogger
PRIUS_OM_OM47C35U_(U)■
Defogging the windshield
Defoggers are used to defog the windshield and front side win-
dows.
Press .
Set to outside air mode if the recirculated air mode is used.
(It
may switch automatically.)
To defog the windshield and the side windows early, turn the ai r flow and
temperature up.
To return to the previous mode, press again when the wind-
shield is defogged.
■
Defogging the rear window and outside rear view mirrors
Defoggers are used to defog the rear window and to remove rain-
drops, dew and frost from the outside rear view mirrors.
Press .
The defoggers will automatically turn off after approximately 1 5 minutes.
■
Eco score (A/C score)
 P. 1 2 9
