TOYOTA PRIUS C 2018 Owners Manual (in English)

1012. Instrument cluster
2
Instrument cluster
PRIUS c_U (OM52G95U)
The multi-information display presents the driver with a variety of driv-
ing-related data including the current outside air temperature.
● Drive information
Displays information such as the
hybrid system operating condi-
tions and fuel consumption.
●Settings and screen off
Perform operations such as chang-
ing the date/time and screen set-
tings.
●Warning messages ( →P. 490)
Automatically displayed if a malfunction occurs in one of the vehicle’s sys-
tems.
● Menu icons
Select a menu icon to display its content.
Drive information ( →P. 102)
Select to display various drive data.
ECO ( →P. 102)
Displays the fuel consumption information.
LDA (Lane Departure Alert) operational status (→ P. 242)
Select to display the operational status of the LDA.
Settings display (→P. 106)
Select to change the meter display settings and other settings.
Multi-information display
Display contents

1022. Instrument cluster
PRIUS c_U (OM52G95U)
◆Operating the meter control switches
The multi-information display is operated using the meter control
switches.: Select menu icons
: Change displayeditem, scroll up/down
the screen and
move the cursor up/
down
Enter switch
Press: Enter/Set
Press and hold: Reset
Return to the previous screen
◆Drive Information
Depending on whether the odometer or trip meter is displayed, the
displayed contents of average speed, driving time, and EV driving
rate/EV driven distance differ.
● When the odometer is displayed: the record since the hybrid sys-
tem was started is displayed.
● When the trip meter is displayed: the record since the trip meter
was reset is displayed. The record for trip meter A and trip meter
B is displayed separately.
When the trip meter is reset, the record is also reset. ( →P. 98)
■
(average speed)
Average speed will be displayed.
■ (driving time)
Driving time will be displayed.
■ (EV driving rate/EV driven distance)
EV driving rate and driven di stance (percentage and distance
driven using just the electric motor [traction motor] only) will be dis-
played.
1
2
Driving information
3
AV G

1032. Instrument cluster
2
Instrument cluster
PRIUS c_U (OM52G95U)■
(Cruising range)
Displays the estimated maximum distance that can be driven with
the quantity of fuel remaining. • This distance is computed base d on your average fuel consump-
tion. As a result, the actual dist ance that can be driven may differ
from that displayed.
• When only a small amount of fuel is added to the tank, the dis- play may not be updated.
When refueling, turn the power switch off. If the vehicle is refu-
eled without turning the power switch off, the display may not be
updated.
◆Energy monitor
→ P. 1 1 0
◆Simple Screen
Displays the enlarged items (clock, outside temperature and fuel
gauge)
◆ECO Score
Hybrid battery (traction bat-
tery) charge level display
EV drive indicator lamp
Illuminates when only the elec-
tric motor is used to drive the
vehicle
Hybrid System Indicator
Hybrid System Indicator rep-
resents the hybrid system power
output and regenerative
charging. ( →P. 108)
Eco driving conditions display
Driving conditions are displayed in 5 stages and divided into 3 catego-
ries: start, cruise and stop. Every time the vehicle is stopped, the score
is displayed. (Every time the vehicle is accelerated the score that was
last displayed is reset. Accumulative scores are not calculated.)
ECO
1
2
3
4

1042. Instrument cluster
PRIUS c_U (OM52G95U)
◆ECO Savings
Displays the cost of the con-
sumed fuel or the fuel economy,
depending on the data entered
for eco savings.Savings and fuel cost
If the fuel consumptio n comparison is input ( →P. 106), the possi-
ble savings are displayed. If th e fuel consumption comparison
has not been input, your vehicle's actual fuel cost will be dis-
played.
Depending on whether the odometer or trip meter is displayed,
the displayed contents differ.
● When the odometer is displayed: th e savings or fuel cost since
the hybrid system was started is displayed.
● When the trip meter is displayed: the savings or fuel cost since
the trip meter was reset is displayed. The savings or fuel cost
for trip meter A or trip meter B is displayed separately.
When the trip meter is reset, savings or fuel cost is also reset.
( →P. 98)
“Fuel Cons. Comparison”
On the settings screen, input t he fuel consumption comparison.
( → P. 106)
◆ECO Savings Record
If the fuel consumption comparison is input in “ECO Savings”, the
savings history will be displayed. If the fuel consumption compari-
son is not input, fuel cost history will be displayed.
Fuel costs for the current month, the last 3 months and the same
month last year are displayed, enabling a comparison to be made.
If the dollar amount will be displayed on the graph.
1
2

1052. Instrument cluster
2
Instrument cluster
PRIUS c_U (OM52G95U)
◆Past Record
Displays average fuel consumption by the month.
The current month, the last 3 months and the same month last year are
displayed, enabling a comparison to be made.
Press and hold the enter switch to reset. ( →P. 102)
◆Personal Best
Displays the best 3 fuel consumption records and the current fuel
consumption ranking.
Depending on whether the odometer or trip meter is displayed, the
displayed contents differ.
●When the odometer is displayed: the record since the hybrid sys-
tem was started is displayed.
● When the trip meter is displayed: the record since the trip meter
was reset is displayed. The record for trip meter A and trip meter
B is displayed separately.
The top 100 rankings are displayed. Records that are outside the top
100 are not displayed as a ranking.
Fuel consumption data for trips of less than 0.1 miles are not recorded.
◆5 min./1 min. fuel consumption display
Select to display the fuel consumption history since the hybrid sys-
tem was started in intervals of 5 minutes or 1 minute. Current fuel
consumption will also be displayed, enabling it to be compared to
the fuel consumption of up to the last 30 minutes (in 5 min. inter-
vals) or 6 minutes (in 1 min. intervals).
To change the interval, press and hold the enter switch. ( →P. 102)

1062. Instrument cluster
PRIUS c_U (OM52G95U)■
LDA (Lane Departure Alert) warning sensitivity
LDA warning sensitivity can be set to 2 different levels.
■EV Indicator
Select to set the EV indicator on/off.
■ECO savings settings
The gasoline price and fuel consumption comparison settings can
be set and changed.
■Date (clock)
The date, time, and clock mode (12 or 24 hour) settings can be
changed.
■Units
Select to change the units of m
easure displayed on the multi-infor-
mation display.
■Language
Select to change the language displayed.
■Operation guide
Select to display/not display the menu icons.
■Trip summary
Select to display/not display th e trip summary display when the
hybrid system is turned off.
■Initialize Display
Select to reset the me ter display settings.
Screen settings

1072. Instrument cluster
2
Instrument cluster
PRIUS c_U (OM52G95U)
■The clock is displayed when
Vehicles without a smart key system
The power switch is in the “ON” position.
Vehicles with a smart key system
The power switch is in ON mode.
■ Eco score
●As the accelerator pedal is not depressed, the driven distance using cruise
control (if equipped) is not included in the eco score.
● As the eco score evaluation differs according to driving conditions and envi-
ronmental factors, in some cases it may not be linked to fuel consumption.
■ Eco savings
●Fuel cost and savings should be used as a guide only.
● Depending on refueling methods, driving conditions and environmental fac-
tors, the actual and displayed fuel costs may differ.
● In some cases, fuel cost and savings may not be linked to the eco score
evaluation.
■ When disconnecting and reconnect ing 12-volt battery terminals
The following information data will be reset:
● Clock
● Past record (aside from the top 3 results)
● 5 min./1 min. fuel consumption display
● Cruising range
● Average vehicle speed
● Driving time
● EV driving rate/EV driven distance
Additionally, some displays may return to their default settings.
■ Liquid crystal display
Small spots or light spots may appear on the display. This phenomenon is
characteristic of liquid crystal displays, and there is no problem continuing to
use the display.

1082. Instrument cluster
PRIUS c_U (OM52G95U)■
Hybrid System Indicator
Hybrid Eco area
Shows that gasoline engine power is not being used very often.
The gasoline engine will automatically stop and restart under various condi-
tions.
Eco area
Shows that the vehicle is being driven in an Eco-friendly manner.
Power area
Shows that the driving power is more than the upper limit of Eco driving.
(during full power driving etc.)
Keeping the indicator within Eco area can help Eco-friendly driving.
■ Trip summary displayCharge area
Shows energy regeneration
* status.
Regenerated energy will be used to
charge the hybrid battery (traction bat-
tery).
*: When used in this manual, “regenera-
tion” refers to the conversion of energy
created by the movement of the vehicle
into electrical energy.
1
2
3
4
When the hybrid system is turned off,
drive information data since the system
was started is displayed after the ending
animation.
When the doors are locked, the screen
turns off.

1092. Instrument cluster
2
Instrument cluster
PRIUS c_U (OM52G95U)
WARNING
■Eco score
Eco score should be used as a guide only. Always drive safely in accor-
dance with road and traffic conditions.
■ The information display at low temperatures
Allow the interior of the vehicle to warm up before using the liquid crystal
information display. At extremely low temperatures, the display monitor may
respond slowly, and display changes may be delayed.
For example, there is a lag between the driver’s shifting and the new gear
number appearing on the display. This l ag could cause the driver to down-
shift again, causing rapid and excessive engine braking and possibly an
accident resulting in death or injury.
■ Cautions during setting up the display
As the hybrid system needs to be running during setting up the display,
ensure that the vehicle is parked in a place with adequate ventilation. In a
closed area such as a garage, exhaust gases including harmful carbon
monoxide (CO) may collect and enter the vehicle. This may lead to death or
a serious health hazard.
NOTICE
■During setting up the display
To prevent 12-volt battery discharge, ensure that the hybrid system is oper-
ating while setting up the display features.

1102. Instrument cluster
PRIUS c_U (OM52G95U)
Audio system
Multi-information display
Multimedia system
Press the “CAR” button.
If the “Trip Information” or “Past Record” screen is displayed, touch
“Energy”.
Navigation system
Press the “APPS” button.
Touch “Eco” on the “Apps” screen.
If the “Trip Information” or “Past Record” screen is displayed, touch
“Energy”.
Multi-information display
Press the “<” or “>” of the meter control switches and select ,
and then press the “ ∧”or “ ∨”to select the energy monitor display.
Energy monitor/c onsumption screen
You can view the status of your hybrid system on the multi-infor-
mation display and audio system.
1
2
Energy monitor
1
2
