− SFIIDLE AIR CONTROL (IAC) VALVE
SF−37
1996 RAV4 (RM447U)
INSPECTION
INSPECT IAC VALVE OPERATION
(a) Connect the positive (+) lead from the battery to terminal
+B and negative (−) lead to terminal RSC, and check that
the valve is closed.
(b) Connect the positive (+) lead from the battery to terminal
+B and negative (−) lead to terminal RSO, and check that
the valve is open.

SF1QD−01
SF−38
− SFIIDLE AIR CONTROL (IAC) VALVE
1996 RAV4 (RM447U)
INSTALLATION
Installation is in the reverse order of removal (See page SF−36).

SF0R1−01
S01935
4WDHold−Down Clamp
Battery
Vacuum Hose
VSVVacuum Hose SF−42
− SFIVSV FOR EXHAUST GAS RECIRCULATION (EGR)
1996 RAV4 (RM447U)
VSV FOR EXHAUST GAS RECIRCULATION (EGR)
COMPONENTS

SF0R2−02
S01917
ContinuityOhmmeter
S01918
No Continuity
Ohmmeter
S01919
Air
E
G
S01920
Air
Filter E
Battery
− SFIVSV FOR EXHAUST GAS RECIRCULATION (EGR)
SF−43
1996 RAV4 (RM447U)
INSPECTION
1. 4WD:
REMOVE BATTERY
2. REMOVE VSV
3. INSPECT VSV
4. INSPECT VSV FOR OPEN CIRCUIT
Using an ohmmeter, check that there is continuity between the
terminals.
Resistance: At 20°C (68°F): 33 − 39 Ω
If there is no continuity, replace the VSV.
5. INSPECT VSV FOR GROUND
Using an ohmmeter, check that there is no continuity between
each terminal and the body.
If there is continuity, replace the VSV.
6. INSPECT VSV OPERATION
(a) Check that air flows from ports E to G.
(b) Apply battery positive voltage across the terminals.
(c) Check that air flows from port E to the filter.
If operation is not as specified, replace the VSV.
7. REINSTALL VSV
8. 4WD:
REINSTALL BATTERY

SF0R3−02
SF−44
− SFIVSV FOR EVAPORATIVE EMISSION (EVAP)
1996 RAV4 (RM447U)
VSV FOR EVAPORATIVE EMISSION (EVAP)
COMPONENTS

SF0R4−02
S01912
Ohmmeter
Continuity
S01913
Ohmmeter
No Continuity
S01915
Air
E
F
S01916
BatteryAir
E
F
− SFIVSV FOR EVAPORATIVE EMISSION (EVAP)
SF−45
1996 RAV4 (RM447U)
INSPECTION
1. REMOVE AIR CLEANER CAP ASSEMBLY (See page
ST−4)
2. REMOVE VSV
3. INSPECT VSV
4. INSPECT VSV FOR OPEN CIRCUIT
Using an ohmmeter, check that there is continuity between the
terminals.
Resistance: At 20°C (68°F): 30 −34 Ω
If there is no continuity, replace the VSV.
5. INSPECT VSV FOR GROUND
Using an ohmmeter, check that there is no continuity between
each terminal and the body.
If there is continuity, replace the VSV.
6. INSPECT VSV OPERATION
(a) Check that air does not flow from ports E to F.
NOTICE:
Never apply more than 60 kPa (0.61 kgf/cm
2, 8.7 psi) of
pressure compressed air to the VSV.
(b) Apply battery positive voltage across the terminals.
(c) Check that air flows from ports E to F.
If operation is not as specified, replace the VSV.
7. REINSTALL VSV
8. REINSTALL AIR CLEANER CAP ASSEMBLY

SF0R5−03
SF−46
− SFIVSV FOR VAPOR PRESSURE SENSOR
1996 RAV4 (RM447U)
VSV FOR VAPOR PRESSURE SENSOR
COMPONENTS

SF0R6−02
S01921
ContinuityOhmmeter
S01922
Ohmmeter
No Continuity
S01923
Air
EG
F
S01924
Air
G E
F
Battery
− SFIVSV FOR VAPOR PRESSURE SENSOR
SF−47
1996 RAV4 (RM447U)
INSPECTION
1. REMOVE AIR CLEANER CAP ASSEMBLY (See page
ST−4)
2. REMOVE VSV
3. INSPECT VSV
4. INSPECT VSV FOR OPEN CIRCUIT
Using an ohmmeter, check that there is continuity between the
terminals.
Resistance: At 20°C (68°F): 33 − 39 Ω
If there is no continuity, replace the VSV.
5. INSPECT VSV FOR GROUND
Using an ohmmeter, check that there is no continuity between
each terminal and the body.
If there is continuity, replace the VSV.
6. INSPECT VSV OPERATION
(a) Check that the air flows from ports E to G.
(b) Apply battery positive voltage across the terminals.
(c) Check that the air flows from ports E to F.
If operation is not as specified, replace the VSV.
7. REINSTALL VSV
8. REINSTALL AIR CLEANER CAP ASSEMBLY

SF0R7−01
S01930
ECT Sensor Connector
ECT Sensor
 Gasket
 Non−reusable part SF−48
− SFIENGINE COOLANT TEMPERATURE (ECT) SENSOR
1996 RAV4 (RM447U)
ENGINE COOLANT TEMPERATURE (ECT) SENSOR
COMPONENTS

SF0R8−01
S01196S01699
Z17274
35 1020 30
TEMPERATURE°C (°F) Acceptable
RESISTANCE kΩ
2
1
0.5
0.3
0.2
0.1
−20 0
2040 60
(32)(68)(104)(140)(176)(212)
(−4)100 80
Ohmmeter
− SFIENGINE COOLANT TEMPERATURE (ECT) SENSOR
SF−49
1996 RAV4 (RM447U)
INSPECTION
1. DRAIN ENGINE COOLANT
2. REMOVE ECT SENSOR
3. INSPECT ECT SENSOR RESISTANCE
Using an ohmmeter, measure the resistance between the ter-
minals.
Resistance: Refer to the graph
If the resistance is not as specified, replace the sensor.
4. REINSTALL ECT SENSOR
Install a new gasket to the ECT sensor.
Torque: 25 N·m (250 kgf·cm, 18 ft·lbf)
5. FILL WITH ENGINE COOLANT
