ENGINE - 2AZ-FE ENGINE
165EG25
Camshaft
Position
Sensor
Crankshaft
Position
Sensor
Va r i o u s
SensorG2
NE
ECMIGT1
IGT2
IGT3
IGT4
IGF+BIgnition Coil
(with Igniter)
No.1 Cylinder
No.2 Cylinder
No.3 Cylinder
No.4 Cylinder
185EG38
0.7 mm
(0.028 in.)
Iridium Tip EG-24
IGNITION SYSTEM
1. General
A DIS (Direct Ignition System) is used. The DIS improves the ignition timing accuracy, reduces
high-voltage loss, and enhances the overall reliability of the ignition system by eliminating the distributor.
The DIS in this engine is an independent ignition system which has one ignition coil (with igniter) for each
cylinder.
Iridium-tipped spark plugs are used.
2. Spark Plug
Iridium-tipped spark plugs are used to improve ignition performance while maintaining the same durability
of the platinum-tipped spark plugs.
Specifications
DENSOSK20R11
NGKIFR6A11
Plug Gap1.0 - 1.1 mm
(0.039 - 0.043 in.)

ENGINE - 2AZ-FE ENGINE
206EG40206EG41
206EG42
Stator Segment
ConductorStator
Joined
Joined Segment
Conductor SystemSegment
ConductorStator
StatorConductor
Wire
Conductor Wire
A
AA - A Cross
Section
Segment Conductor Type GeneratorB
BB - B Cross
Section
Conventional Type GeneratorWinding System
Stator
Segment
Conductor
Cross Section
Stator of Segment Conductor Type GeneratorEG-25
CHARGING SYSTEM
1. Segment Conductor Type Generator
A compact and lightweight segment conductor type generator that generates high amperage output in a
highly efficient manner is used.
This generator has a joined segment conductor system in which multiple segment conductors are welded
together to form the stator. Compared to the conventional winding system, the electrical resistance is
reduced due to the shape of the segment conductors, and their arrangement helps to make the generator
compact.
Specifications
Ty p eSE0
Rated Voltage12 V
Rated Output100 A
Initial Output Starting SpeedMax. 1,500 rpm

ENGINE - 2AZ-FE ENGINE
01NEG45Y
RegulatorB
M
IG
RLO
L
Ignition Switch
To Discharge
Wa r n i n g L i g h t
Generator
ECM
281EG13
281EG12
Coil SpringPulley
Helical Coil Type One-way Clutch EG-26
Wiring Diagram
2. Generator Pulley
A helical coil type one-way clutch is used on the generator pulley in order to reduce the load that acts on
the auxiliary equipment belt.
The pulley mounting nut and the generator pulley have been integrated to achieve a compact construction.

ENGINE - 2AZ-FE ENGINE
01NEG46Y
ArmatureSurface Commutator
Permanent Magnet
Brush
LengthEG-27
STARTING SYSTEM
1. General
A compact and lightweight PS (Planetary reduction-Segment conductor motor) type starter is used.
Because the PS type starter contains an armature that uses square-shaped conductors, and its surface
functions as a commutator, it has resulted in both improving its output torque and reducing its overall
length.
In place of the field coil used in the conventional type starter, the PS type starter uses two types of
permanent magnets: main magnets and interpolar magnets. The main magnets and interpolar magnets
have been efficiently arranged to increase the magnetic flux and to shorten the length of the yoke.
Specifications
Starter TypePS Type
Rating Output1.7 kW
Rating Voltage12 V
Length*1mm (in.)128 (5.04)
Weight g (lb)2950 (6.50)
Rotational Direction*2Counterclockwise
*1: Length from the mounted area to the rear end of the starter
*
2: Viewed from pinion side

ENGINE - 2AZ-FE ENGINE
206EG20
Conventional Type
A - A
Cross Section
(PS Type)B - B
Cross Section
(Conventional Type)
B
B
A
A Armature
ArmatureBrushCommutator Brush
Surface CommutatorSquare-shaped
ConductorRound-shaped
Conductor
PS Type
222EG15
Main Magnet
Interpolar Magnet
Yo k e
Main Magnet
Armature
Cross Section of YokeMagnetic Flux Generated by
Relationship between Main Magnets
Magnetic Flux Generated
by Interpolar Magnets
N
N
N
S
S
S EG-28
2. Construction
Instead of constructing the armature coil with conventional type round-shaped conductor wires, the PS
type starter uses square conductors. With this type of construction, the same conditions that are realized
by winding numerous round-shaped conductor wires can be achieved without increasing the mass. As a
result, the output torque has been increased, and the armature coil has been made more compact.
Because the surface of the square-shaped conductors that are used in the armature coil functions as a
commutator, the overall length of the PS type starter has been shortened.
Instead of the field coils used in the conventional type starter, the PS type starter uses two types of
permanent magnets: the main magnets and the interpolar magnets. The main and interpolar magnets are
arranged alternately inside the yoke, allowing the magnetic flux that is generated between the main and
interpolar magnets to be added to the magnetic flux that is generated by the main magnets.
In addition to increasing the amount of magnetic flux, this construction shortens the overall length of the
yoke.

ENGINE - 2AZ-FE ENGINE
240EG98
Idler Pulley for Automatic Tensioner
Generator Pulley
Water Pump Pulley
Air Conditioning
Compressor Pulley Crankshaft Pulley Idler Pulley
258RV77
ArmIdler Pulley
Te n s i o n e r
A - A Cross SectionAAEG-29
SERPENTINE BELT DRIVE SYSTEM
1. General
Accessory components are driven by a serpentine belt consisting of a single V-ribbed belt. It reduces the
overall engine length, weight and the number of engine parts.
An automatic tensioner eliminates the need for tension adjustment.
2. Automatic Tensioner
The automatic tensioner consists of an idler pulley and a tensioner. The idler pulley maintains belt tension
by the force of the spring that is located in the tensioner.

ENGINE - 2AZ-FE ENGINE EG-30
ENGINE CONTROL SYSTEM
1. General
The engine control system for the 2AZ-FE engine has the following systems.
System
Outline
SFI
Sequential Multiport
Fuel InjectionAn L-type SFI system directly detects the intake air volume with a hot-wire
type mass air flow meter.
The fuel injection system is a sequential multiport fuel injection system.
ESA
Electronic Spark
AdvanceIgnition timing is determined by the ECM based on signals from various sensors.
The ECM corrects ignition timing in response to engine knocking.
ETCS-i
Electronic
Optimally controls the throttle valve opening in accordance with the amount of
accelerator pedal effort and the condition of the engine and the vehicle.
Electronic
Throttle Control
System-intelligent
(See page-43)A linkless-type is used, without an accelerator cable.
An accelerator pedal position sensor is provided on the accelerator pedal.
A non-contact type throttle position sensor and accelerator pedal position
sensor are used.
VVT-i
Va r i a b l e Va l v e
Timing-intelligent
(See page EG-48)
Controls the intake camshaft to an optimal valve timing in accordance with the
engine condition.
Air-fuel Ratio
Sensor, Oxygen
Sensor Heater
ControlMaintains the temperature of the air-fuel ratio sensor or oxygen sensor at an
appropriate level to realize accuracy of detection of the oxygen concentration in
the exhaust gas.
Air Conditioning
Cut-off ControlBy turning the air conditioning compressor ON or OFF in accordance with the
engine condition, drivability is maintained.
Cooling Fan Control
(See page EG-52)Radiator cooling fan operation is controlled by signals from ECM based on the
engine coolant temperature sensor signal and the condition of the air
conditioning operation.
Fuel Pump Control
(See page EG-53)Fuel pump operation is controlled by signal from the ECM.
The fuel pump is stopped when the SRS driver’s and front passenger’s airbags
are deployed.
Evapotative Emission
The ECM controls the purge flow of evaporative emissions (HC) in the canister
in accordance with engine conditions.
Evapotative Emission
Control
(See page EG-54)Approximately five hours after the ignition switch has been turned OFF, the
ECM operates the canister pump module to detect any evaporative emission
leakage occurring in the EVAP (evaporative emission) control system through
changes in the 0.02 in. leak pressure.
Charging Control
(See page EG-65)The ECM regulates the charging voltage of the generator in accordance with the
driving conditions and the charging state of the battery.
(Continued)

ENGINE - 2AZ-FE ENGINEEG-31
System
Outline
Engine
Immobilizer*
2
Prohibits fuel delivery and ignition if an attempt is made to start the engine with
an invalid ignition key.
Diagnosis
(See page EG-67)When the ECM detects a malfunction, the ECM diagnoses and memorizes the
failed section.
Fail-safe
(See page EG-67)When the ECM detects a malfunction, the ECM stops or controls the engine
according to the data already stored in memory.
*2: Models with Engine Immobilizer System

ENGINE - 2AZ-FE ENGINE
01MEG04Y
SENSORSACTUATORS
MASS AIR FLOW METER
INTAKE AIR TEMPERATURE
SENSOR
ENGIEN COOLANT
TEMPERATURE SENSOR
THROTTLE POSITION
SENSOR
CRANKSHAFT POSITION
SENSOR
CAMSHAFT POSITION
SENSOR
ACCELERATOR PEDAL
POSITION SENSOR
AIR-FUEL RATIO SENSOR
(Bank 1, Sensor 1)
HEATED OXYGEN SENSOR
(Bank 1, Sensor 2)
KNOCK SENSOR
COMBINATION METER
Vehicle Speed Signal
IGNITION SWITCH
Ignition Signal
Starter Signal
PA R K / N E U T R A L P O S I T I O N
SWITCH
TRANSMISSION CONTROL
SWITCH
CRUISE CONTROL SWITCHVG
THA
THW
VTA1
VTA2
NE
G2
VPA
VPA2
A1A
OX1B
KNK1
SPD
IGSW
STA
D, 2, L
R, P, N
3
CCSECM#10
#20
#30
#40
IGT1 IGT4
IGF1
M
OC1
FC
HA1A
HT1BSFI
No.1 INJECTOR
No.2 INJECTOR
No.3 INJECTOR
No.4 INJECTOR
ESA
IGNITION COIL
with IGNITER
SPARK PLUGS
ETCS-i
THROTTLE CONTROL
MOTOR
VVT-i
CAMSHAFT TIMING OIL
CONTROL VALVE
FUEL PUMP CONTROL
CIRCUIT OPENING
RELAY
AIR-FUEL RATIO AND
HEATED OXYGEN SENSOR
HEATER CONTROL
AIR-FUEL RATIO SENSOR
HEATER (Bank1, Sensor1)
HEATED OXYGEN SENSOR
HEATER (Bank1, Sensor2)
EG-32
2. Construction
The configuration of the engine control system in the 2AZ-FE engine is shown in the following chart.
(Continued)

ENGINE - 2AZ-FE ENGINE
01MEG05Y
DEFGGER SWITCH
TA I L L I G H T S W I T C H
STOP LIGHT SWITCH
CURRENT SENSOR
CANISTER PUMP MODULE
CANISTER PRESSURE
SENSOR
TRANSPONDER KEY ECU*
AIRBAG SENSOR ASSEMBLY
EPS ECU
AIR CONDITIONING ECU
SKID CONTROL ECU
DLC3
BATTERYELS1
ELS3
STP
ST1-
THB
VCIB
PPMP
IMI
IMO
CANH,
CANL
TC
TA C H
BATTECMFA N H
FA N L
MPMP
VPMP
PRG
RLO
DF
MREL
+B
WCOOLING FAN CONTROL
COOLING FAN RELAY No.1
COOLING FAN RELAY No.2
COOLING FAN RELAY No.3
EVAPORATIVE EMISSION
CONTROL
CANISTER PUMP MODULE
LEAK DETECTION PUMP
VENT VALVE
GENERATOR
MAIN RELAY
COMBINATION METER
MIL
PURGE VSV
: CANEG-33
