ENGINE - 2AZ-FE ENGINE
01MEG03Y
275TU51
Repeat 0.02 in. Leak Pressure Measurement Atmosphere
Purge VSV
(OFF)
ECMCanister Pump Module
Ve n t Va l v e
(OFF)
Leak Detection Pump
& Pump Motor
Canister Pressure
SensorReference Orifice
Purge VSV
Ve n t Va l v e
Pump Motor
System PressureON (Open)
OFF (Close)
ON
OFF (Vent)
ON
OFF
Atmospheric Pressure
0.02 in. Leak Pressure
P0456
Normal
M
P
EG-64
f. Repeat 0.02 in. Leak Pressure Measurement
1) While the ECM operates the vacuum pump, the purge VSV and vent valve turn off and a repeat 0.02
in. leak pressure measurement is performed.
2) The ECM compares the measured pressure with the pressure during EVAP leak check.
3) If the pressure during the EVAP leak check is below the measured value, the ECM determines that
there is no leakage.
4) If the pressure during the EVAP leak check is above the measured value, the ECM determines that
there is a small leakage and stores DTC P0456 in its memory.

ENGINE - 2AZ-FE ENGINE
01NEG13Y
Generator
RegulatorB
DF
RLOECM
Various Electrical
Loads
Battery Current Sensor
Battery Temperature Sensor
Battery Voltage
Battery
Various Sensors and Switches
Throttle Position Sensor
Crankshaft Position Sensor
Accelerator Pedal Position
SensorEG-65
11. Charging Control
General
This system lowers the generated voltage when the vehicle is idling or is being driven at a constant speed,
and raises the generated voltage when the vehicle is decelerating. This reduces the load on the engine as
a result of the electric generation of the generator, thus contributing to the fuel economy of the engine.
During acceleration, this system regulates the generated voltage in order to place the amperage estimation
value close to the target value.
This control consists of the ECM, battery current sensor with a built-in battery temperature sensor,
generator, and various sensors and switches.
The ECM detects driving condition based on signals from various sensors and switches, and detects
charging condition based on signals from the generator, battery current sensor and battery temperature
sensor. Then the ECM outputs signals to the IC regulator to control the genetated voltage of the generator.
The ECM stops the charging control and the generator switches to normal power generation mode under
the following conditions:
Low battery capacity
Low or high battery temparature
Wipers operating or blower motor operating with tail lamp relay ON
System Diagram

ENGINE - 2AZ-FE ENGINE
258AS61 281EG86
Output
Voltage5 (V)
0
-100
Current+100 (A)
Characteristic of Current Sensor
288EG61C
(C) 60
Battery Temperature 0 Resistance(k
)
6 EG-66
Battery Current Sensor
Installed on the negative terminal of the battery, this sensor detects the amount of charging and discharging
amperage of the battery and sends signal to the ECM. Based on this signal, the ECM calculates the battery
capacity. A Hall IC is used for detecting the amount of charging and discharging amperage. The changes
that occur in the magnetic flux density in the core as a result of the charging and amperage of the battery
are converted and output as voltage.
Batter Temperature Sensor
The battery temperature sensor is built into the battery current sensor.
The battery characteristic (battery internal resistance) of taking in current for charging varies according
to battery electrolyte temperature. If the electrolyte temperature is too low or too high, the battery internal
resistance will increase, resulting in early deterioration. To prevent this, the battery temperature sensor
changes its resistance as shown below to detect the temperature.

ENGINE - 2AZ-FE ENGINE
Service Tip
To clear the DTC that is stored in the ECM, use a hand-held tester or disconnect the battery terminal
or remove the EFI fuse for 1 minute or longer.
EG-67
Fail-safe
Due to a failure in the battery current sensor or battery temperature sensor, the ECM may determine the
necessity of performing a fail-safe operation. Then, the ECM stops the charging control and the generator
switches to the normal power generation mode.
When the ECM detects a malfunction in a sensor, the ECM memorizes the DTC (Diagnostic Trouble Code).
The MIL (Malfunction Indicator Lamp) does not illuminate.
DTC Chart
DTC No.Detection ItemDTC No.Detection Item
P0516Battery Temperature Sensor
Circuit LowP1551Battery Current Sensor
Circuit Low
P0517Battery Temperature Sensor
Circuit HighP1552Battery Current Sensor
Circuit High
P0560System VoltageP1602Detection of Battery
P1550Battery Current Sensor
Circuit
12. Diagnosis
When the ECM detects a malfunction, the ECM makes a diagnosis and memorizes the failed section.
Furthermore, the MIL in the combination meter illuminates or blinks to inform the driver.
The ECM will also store the DTCs of the malfunctions. The DTCs can be accessed by the use of the
hand-held tester.
For details, refer to the 2006 RAV4 Repair Manual (Pub. No. RM01M1U).
13. Fail-safe
When a malfunction is detected at any of the sensors, there is a possibility of an engine or other malfunction
occurring if the ECM were to continue to control the engine control system in the normal way. To prevent
such a problem, the fail-safe function of the ECM either relies on the data stored in memory to allow the
engine control system to continue operating, or stops the engine if a hazard is anticipated. For details, refer
to the 2006 RAV4 Repair Manual (Pub. No. RM01M1U).

ENGINE
ENGINE - 2AZ-FE ENGINE
01NEG49Y
01NEG50Y
EG-2
2AZ-FE ENGINE
DESCRIPTION
The 2AZ-FE engine is an in-line, 4-cylinder, 2.4-liter, 16-valve DOHC engine. This engine uses the VVT-i
(Variable Valve Timing-intelligent) system, DIS (Direct Ignition System), ETCS-i (Electronic Throttle
Control System-intelligent). It has been developed to realize high performance, quietness, fuel economy and
clean emission.

ENGINE - 2AZ-FE ENGINE
01MEG02Y
Valve Timing : Intake Valve Opening Angle
: Exhaust Valve Opening Angle
VVT-i Operation
Range
VVT-i Operation
RangeTDC
3
3
43
65
25
45
BDCEG-3
Engine Specifications
No. of Cyls. & Arrangement4-cylinder, In-line
Valve Mechanism16-valve DOHC, Chain Drive (with VVT-i)
Combustion ChamberPentroof Type
ManifoldsCross-flow
Fuel SystemSFI
Ignition SystemDIS
Displacement cm3 (cu. in.)2362 (144.1)
Bore x Stroke mm (in.)88.5 x 96.0 (3.48 x 3.78)
Compression Ratio9.8 : 1
Max. Output*1(SAE-NET)124 kW @ 6000 rpm (166 HP @ 6000 rpm)
Max. Torque*1(SAE-NET)224 N.m @ 4000 rpm (165 ft-lbf @ 4000 rpm)
IntakeOpen3 - 43 BTDC
Valve Timing
IntakeClose65 - 25 ABDCVa l v e T i m i n g
ExhaustOpen45 BBDCExhaustClose3 ATDC
Firing Order1 - 3 - 4 - 2
Research Octane Number91 or higher
Octane Rating87 or higher
Oil GradeILSAC
Tailpipe Emission RegulationULEV-II, SFTP
Evaporative Emission RegulationLEV-II, ORVR
Engine Service Mass*2 (Reference) kg (lb)138 (304.2)
*1: Maximum output and torque rating is determined by revised SAE J1349 standard.
*
2: Weight shows the figure with oil and water fully filled.

ENGINE - 2GR-FE ENGINEEG-71
FEATURES OF 2GR-FE ENGINE
The 2GR-FE engine has achieved the following performance through the use of the items listed below.
(1) High performance and reliability
(2) Low noise and vibration
(3) Lightweight and compact design
(4) Good serviceability
(5) Clean emission and fuel economy
Item
(1)(2)(3)(4)(5)
A steel laminate type cylinder head gasket is used.
An upright intake port is used.
EngineA taper squish shape is used for combustion chamber.Engine
ProperA cylinder block made of aluminum alloy is used.Proper
The skirt portion of the piston is applied with resin to
reduce friction.
An oil pan No. 1 made of aluminum alloy is used.
The Dual VVT-i (Variable Valve Timing-intelligent)
system is used.
Va l v e
Mh i
Hydraulic lash adjusters are used.
MechanismTiming chains and chain tensioners are used.
Roller rocker arms are used.
Lubrication
SystemAn oil filter with a replaceable element is used.
Cooling SystemThe TOYOTA Genuine SLLC (Super Long Life Coolant)Cooling SystemThe TOYOTA Genuine SLLC (Super Long Life Coolant)
is used for the engine coolant.
The linkless-type throttle body is used.
Intake andThe intake air chamber made of plastic is used.Intake and
Exhaust
S
A stainless steel exhaust manifold is used.
SystemAn ultra thin-wall, high-cell density ceramic type TWC
(Three-Way Catalytic converter) is used.
The fuel delivery pipe made of plastic is used.
Fuel SystemA compact 12-hole type injector is used.Fuel SystemQuick connectors are used to connect the fuel hose with
the fuel pipe.
Ignition System
The DIS (Direct Ignition System) makes ignition timing
adjustment unnecessary.
Ignition System
The long-reach type spark plugs are used.
(Continued)

ENGINE - 2GR-FE ENGINE EG-72
Item
(1)(2)(3)(4)(5)
ChargingA segment conductor type generator is used.Charging
SystemA generator pulley with a clutch is used.
Starting
SystemThe PS (Planetary reduction-Segment conductor motor)
type starter is used.
Serpentine Belt
Drive SystemA serpentine belt drive system is used.
The MRE (Magnetic Resistance Element) type VVT sensorsThe MRE (Magnetic Resistance Element) type VVT sensors
are used.
The ETCS-i (Electronic Throttle Control System-intelligent)
Engine
The ETCS i (Electronic Throttle Control System intelligent)
is used.
Control
SystemThe ACIS (Acoustic Control Induction System) is used.SystemThe air intake control system is used.
The charging control is used.
Evaporative emission control system is used.

ENGINE - 2GR-FE ENGINE
285EG05
Oil Delivery PipeCylinder Head Covers
Cylinder Head
Cover Gaskets
Oil Delivery Pipe
285EG06
Engine
FrontShim A A
For Right Bank
For Left BankA - A Cross SectionEG-73
ENGINE PROPER
1. Cylinder Head Cover
Lightweight yet high-strength aluminum cylinder head covers are used.
An oil delivery pipe is installed inside the cylinder head cover. This ensures lubrication to the sliding parts
of the roller rocker arm, improving reliability.
2. Cylinder Head Gasket
A steel-laminate type cylinder head gasket is used. A shim is used around the cylinder bore of the gasket to
help enhance sealing performance and durability.

ENGINE - 2GR-FE ENGINE
285EG08 285EG07
Intake
Va l v e
Spark
Plug
Hole
Exhaust
Va l v eIntake Side
Exhaust SideCamshaft Housing
Exhaust
SideIntake
Side
Upright
Intake Port
Taper Squish A
A
View from Back Side A - A Cross Section
215EG19 215EG18
Siamese Type Independent Type EG-74
3. Cylinder Head
The cylinder head structure has been simplified by separating the cam journal portion (camshaft housing)
from the cylinder head.
The cylinder head, which is made of aluminum, contains a pentroof-type combustion chamber. The spark
plug is located in the center of the combustion chamber in order to improve the engine’s anti-knocking
performance.
The intake ports are on the inside and the exhaust ports are on the outside of the left and right banks
respectively.
Upright intake ports are used to improve the intake efficiency.
A taper squish combustion chamber is used to improve anti-knocking performance and intake efficiency.
In addition, engine performance and fuel economy have been improved.
The siamese type intake port is used to reduce the overall surface area of the intake port walls. This
prevents the fuel from adhering onto the intake port walls, thus reducing HC exhaust emissions.
